Cary Audio Design Cinema 2 and User manual

Cary Cinema Power Amplifiers
Cinema 2 - Cinema 3 - Cinema 5
Installation and Users Manual
NOTE:
Before installing your new Cary Cinema power amplifier, please read this manual carefully as it
will inform you of the specifications, proper installation and operation procedures. Also
included in this manual are guidelines on how to service and care for your new Cary Cinema
amplifier.

2
Cary Cinema Power Amplifiers
Congratulations! You have just purchased one of the finest solid state power amplifiers made.
Whether two, three or five channels, your Cinema power amplifier is the perfect foundation
for your home stereo or theater system. In addition to the awesome power, the Cinema
power amplifier delivers flawless reproduction of musical detail and subtle special effects.
Cary Cinema power amplifier features include:
•Remote trigger (works with + 4.2 to + 32 Volts DC, see page 5)
•Short circuit protection,
•Thermal Protection circuits,
•DC offset protection,
•Matched Sanken, 50 Mhz multiple emitter output transistors.
•Soft start circuit prevents “Brown outs” when amplifier is turned on.
For the technically inclined, the following is an overview of the design characteristics of the
amplifier:
The input of the amplifier is fed into a high quality Burr-Brown op-amp for Balanced to Single-
Ended conversion. This input circuit is connected to a constant current source, differential
style with a current mirror. The pre-drive circuit is constant current Single-Ended Class A.
The output is a follower stage that uses special “designed for audio” high speed power
transistors that have excellent linearity characteristics. The power supply consists of a 700 or
1400 VA toroidal power transformer and either two or four 33,000uF/80V electrolytic
capacitors. Special attention was paid to circuit stabilization and speed of the amplifier to
reduce transient inter-modulation (TIM) distortion.
The Cinema power amplifier has three protection circuits to prevent damage to your speaker
and the power amplifier.
•AC Fuse - Fused with a 3.5A/7.5A for 240V and a 7.5A/15A for 120V.
•Thermal protection - if a channel overheats its output is disconnected until it cools down
to a safe operating temperature.
•DC offset sensor - If an amplifier malfunction or signal source malfunction occurs, the
potential exists for providing DC voltage to the loudspeaker. If this happens, the channel
will automatically shut down. No damage can occur.
In building the Cinema power amplifiers significant effort has been focused on building an
amplifier that delivers outstanding mechanical performance, is easy to use, and has sonic
properties that will delight the most demanding customer. Thank you for choosing Cary
Cinema Design and enjoy your new Cary Cinema power amplifier.
* Short circuit protection activates if load impedance is about 1.6 ohms or less. Constant tripping of short circuit
can degrade output transistors. To reset protection, turn the amplifier off, wait 10 seconds, then turn the
amplifier on.

3
SPECIFICATIONS
Operating the Cinema power amplifier is a simple procedure since each unit is designed for long term
stability in virtually any home or commercial operating situation. Therefore, if the unit is operated
outside the parameters outlined in this Owner's Manual, damage may result.
1.1 Caution Terms
When the following cautionary terms are used in this manual, these definitions apply:
WARNING: Electrical hazard! Misuse or failure to follow instructions
properly may result in personal injury or death!
CAUTION: No risk or personal injury; however, misuse or failure to
follow instructions may result in damage to
equipment.
NOTE: No risk of personal injury or equipment damage. However,
misuse or failure to follow instructions may prevent proper
performance to the equipment.
This section describes the basic specifications of the Cary Cinema Power Amplifiers at the time of
printing. Specifications are subject to improvement without notice or obligation.
POWER OUTPUT: Class AB, 200 Watts/channel - 8 ohms
350 Watts/channel - 4 ohms
DAMPING FACTOR: 100 @ 8 ohms
50 @ 4 ohms
PEAK CURRENT: 35 amps
FREQUENCY RESPONSE: 10 to 50 kHz +/-0.1 dB
-3 dB @ 200 kHz
DIMENSIONS: 6.25”H x 17.7”W x 19.5”D – (6.25” x 17.7” x 12”, Cinema 2)
Allow 2”D for binding post and front panel switch
INPUT POWER REQUIREMENTS: 100, 110, 117, 220, 240, / 50-60Hz
POWER CONSUMPTION: 155/115/90 Watts – Idling with no signal input
2500/1500/1000 Watts –All channels, 8-ohm load, full power
NET WEIGHT: 38/48/80 lbs.

4
INPUT IMPEDANCE:44K ohms for single-ended
91K ohms for balanced
OUTPUT IMPEDANCE: 4 and 8 ohms
GAIN: 27.2 dB
THD: < 0.05 %, 20 Hz-20 kHz
NOISE: > 100 dB below rated output, A-weighted
SENSITIVITY:1.42 Volts for full output
POWER SUPPLY CAPACITORS: 4 or 2 - 33,000 mFd @ 80 Volts (Cinema 5 or Cinema
2)
POWER TRANSFORMERS: 1 – Toroidal
200% duty cycle
BREAK-IN PERIOD: 100 hours of music playing time
FINISH: Textured black chassis with silver anodized aluminum faceplate
Standard, black faceplate optional
AC CORD: 3 conductor shielded and detachable
1.3
Front Panel Features
POWER SWITCH: Main power switch for all channels.
LED 5/3/2: Indicates channels operating. The LED’s will not light if the
power amplifier is in protection mode or if the fuse is blown.
1.4
Rear Apron Features
AC INLET: 3-conductor detachable power cord connector
INPUTS: 5, 3 or 2 signal input connections via shielded interconnect
cables either single-ended RCA or XLR balanced
OUTPUT:5, 3 or 2 , 5-way binding posts provide output to the speaker
system (4 or 8 ohm).
FUSES: AC power fuse. Only replace with 15 AMP (Cinema-5), 10
AMP (Cinema-3) or 7 AMP (Cinema-2) SLOW BLOW@
250 VOLT! 7.5A/3.5A for 220V (Cinema-5/-3/-2)
RCA/XLRSWITCHES: Select single-ended or balanced operation for each
channel.

5
REMOTE TRIGGER: 1/8” connection jack. Set the front panel Main Power
switch to OFF to use the remote turn on/turn off feature
with the remote trigger controlled by an external switch.
INSTALLATION
This section describes the unpacking and installation procedures for your Cinema power
amplifier.
2.1 Unpacking
All shipping containers have been specially designed to protect their contents and special care has been
taken to prevent damage under normal shipping conditions. Mishandling should be evident upon
inspection of the shipping container. If shipping damage is found after visual inspection, take care not
to destroy the evidence. If necessary, document the damage with photographs and contact the
transport carrier immediately.
Carefully remove your new Cinema power amplifier from its packing carton and examine it closely for
signs of shipping damage. We strongly recommend saving all original packing cartons to protect your
amplifier from damage should you wish to store it or ship it for after-sales service.
2.2 Warranty Card
If you were the original purchaser of this unit and you purchased it in the United States, you should fill
out the enclosed warranty registration card and return it to Cary Audio Design within 15 days of your
purchase. Cary Audio Design also suggests that you keep your original packing cartons in case you ever
need to ship the unit when moving to a new home. Warranty restrictions apply. Consult the warranty
section of this manual for details. Please be certain to keep a copy of the original sales receipt from your
Authorized Cary Cinema dealer.
2.3 Cinema Amplifier Placement
The Cinema power amplifier is designed for use inside climate controlled rooms. It must be protected
from the elements and temperature extremes. For example, avoid placing the unit in extremely hot
locations such as near radiators or other heating units. Avoid installation where it might be damp or
wet to avoid potential shock hazards.
2.4 Power Requirements
The Cinema Amplifier is designed to operate from residential or commercial AC current mains. The
design voltage is 117 VAC at 50/60Hz (Foreign units 234 VAC at 50/60Hz).
2.5 Cables
The speaker cables from the output posts of the Cinema Amplifier to the speaker system can be any
convenient length, as your speaker set-up requires. Select speaker cables of sufficient size to preserve
the outstanding performance capabilities of your Cinema Amplifier. Heavy gauge #14 wire is suitable
for distances up to 10 feet, #12 for 25 feet. Most audio dealers will have proper speaker cable in stock
for this purpose. Consult your Authorized Cary Cinema dealer for advice.

6
2.6 Interconnects
Signal input connections are made via the input jack on the rear of the Cinema amplifier, either single-
ended or balanced. The interconnect cables from the output of the processor can be any convenient
length your installation set-up requires. The choice of a high quality interconnect cable is important.
Once again, your audio dealer will have the proper cables in stock for this purpose.
WARNING: Do not touch the speaker output binding posts during
normal operation. You may be shocked. Do not short-circuit the speaker
output binding posts. Damage may occur or the fuse may blow. Do not
parallel or “bridge” the speaker output binding posts as this will damage
the amplifier.
OPERATION
Your new Cinema power amplifier is ready for operation after installing the AC power cord, speaker
and interconnect cables. Make sure the RCA/XLR switch is in the proper input selector position for
your particular installation.
3.1 On-Off Power Switch
Push the main power switch on the front panel to the “ON” position for normal use. (Set it to
OFF for remote turn on/off operation and it will be turned on and off by the trigger in the
surround sound processor.) LED’s 1-2, 1-3 or 1-5 will light up. At this point you can play music
or start the movie. Flip the main power switch to OFF for normal shut down.
3.2 Break In Period
The transistors and capacitors take approximately 100 hours of music playing to fully settle in for peak
performance. The Cinema power amplifier will sound good right out of the box and continue to
improve as it goes through ‘break in.’ After the first couple of hours you will notice increased depth and
tighter bass.
SERVICE AND CARE
The Cinema power amplifier chassis may be cleaned with a soft towel and Windex® (or a similar
window cleaner). Spray it on the cleaning cloth to moisten it, not on the amplifier. Do not use solvents
or harsh chemicals to clean the amplifier. They may remove the labels from the chassis. The frequency
and need of cleaning will be governed by operating environmental conditions. Avoid letting it become
dusty or wet. A ‘feather duster’ type cleaner will also work well for cleaning the amplifier.
4.1 Factory Service
Careful consideration has been given to the design of your Cinema power amplifier to keep
maintenance problems to a minimum. If problems arise, refer to the trouble-shooting guide at the end
of this manual. If the problem is not easily solved, we suggest that you contact our Customer Service
Department at phone number [phone] to describe your problem in detail. Do not return
the Cinema power amplifier to the factory without a Return Authorization Number
from the Customer Service Department.

7
Cary Audio Design will assume no responsibility if the transportation company refuses to pay a damage
claim due to your improper packing or lack of insurance should the unit be lost in shipment. We
strongly suggest using the original packing cartons for all shipping of your Cinema power amplifier.
Non-Warranty Repairs
Cary Audio Design will provide repair service for its products charging on a time and expense
basis for the repairs.
PROPRIETARY RIGHTS: Cary Audio Design has proprietary right in the circuit design
and components of its units. While the purchaser is entitled to use the unit for its intended
purpose, use of the unit for copying, imitation, or reverse engineering is a violation of these
proprietary rights and is forbidden.
WARNINGS
Make no attempt to put the Cinema Amplifier in service outside of the cabinet -
Contact with high voltages found in the unit can be fatal!!!
Completely remove AC power plug from the wall and allow 30 minutes for the
high voltage capacitors to discharge through bleeder resistors before attempting
to clean the inside of the amplifier.
CAUTIONS
Never remove/insert AC plug when the unit is on or the
AC power switch is in the “ON” position
Obstruction of the top portion of the Cinema Amplifier will result
in overheating

8
CINEMA AMPLIFIER TROUBLESHOOTING GUIDE
SYMPTOM CAUSE REMEDY
Hum or “Buzzing” through -Ground loop -Install 2-pin adapter on AC.
the speakers cord to float the ground.
-Intermittent or poor
“” “” connection of interconnect -Replace interconnect
ground
“” “” -RCA/XLR Switch -If using balanced inputs,
not in correct position make sure switch is toward
XLR connector and toward
RCA jack for RCA in.
Reduced Output -RCA/XLR Switch -If using balanced inputs,
not in correct position make sure switch is toward
XLR connector and toward
RCA jack for RCA in.
AC fuseblows -Overload -Playing very loud
into very
low impedance. Replace
fuse.
“” “” -Short at output -Make sure (+) and (-) of
binding post are not
shorted.
LED out -Protection circuit -Turn power off. Wait 10
activated seconds and turn back on.

9
UNITED STATES LIMITED WARRANTY
Cary Audio Design, Inc. warrants to the original United States purchaser for use in the United States, that this product
shall be free from defects in or workmanship for three (3) years from the date of the original purchase. This warranty is
for the original purchaser only and does not transfer to any subsequent owner.
During the warranty period, Cary Audio Design or an authorized Cary Audio Design service facility will provide free of
charge both parts and labor necessary to correct defects in material or workmanship.
To obtain such warranty service, the original purchaser must:
(1) Complete and send in the warranty Registration Card within 15 days of purchase.
(2) Notify Cary Audio Design as soon as possible after the discovery of a possible
defect and submit the following:
(a) The model number and serial number;
(b) A copy of the original sales receipt from an Authorized Cary Cinema dealer with date of purchase;
(c) A detailed description of the problem;
(3) Deliver the product to Cary Audio Designs or the nearest authorized service facility,
or ship the same in its original container or equivalent, fully insured and with the shipping
charges to Cary Audio prepaid by the owner.
Correct maintenance, repair and use are important to obtain performance from this product. Therefore, carefully read
the Operating Manual. This warranty does not apply to any defect that Cary Audio Design in its sole discretion
determines is due to:
(1) Improper maintenance or repair, including the installation of parts or accessories that do
not conform to the quality and the specifications of the original parts.
(2) Misuse, abuse, neglect or improper installation.
(3) Accidental or incidental damage.
WARRANTY DISCLAIMER
Except for the express warranties stated herein, Cary Audio Design disclaims all other warranties including, without
limitation, all implied warranties of merchantability and fitness for a particular purpose.
EXCLUSIVE REMEDY
Notwithstanding the foregoing, the purchaser’s exclusive remedy for any breach of warranty, express or implied, is limited
to the repair or replacement of the defective unit or the refund of the purchase price, at the option of Cary Audio
Design. Under no circumstances is Cary Audio Design liable for incidental or consequential damages. Any implied
warranties imposed by law terminate one (1) year from the date of purchase.
INTERNATIONAL PURCHASERS (Outside the USA)
Cary Audio Design warrants its merchandise to purchasers within the United States exclusively for use within the United
States. It provides no other warranties, expressed or implied. If you are a non-USA purchaser, consult with your local
dealer or distributor to determine the details of your local warranty.
The foregoing constitutes Cary Audio Design’s entire obligation with respect to this product, and the original purchaser
and any user or owner shall have no other claim for incidental or consequential damages. Some states do not allow the
exclusion or limitation of incidental or consequential damages, so the above limitation and exclusion may not apply to you.
This warranty gives legal rights and you may also have other rights, which vary from state to state.
Cary Audio Design
1020 Goodworth Drive
Apex, North Carolina 27539
Tel: [phone]
Fax: [phone]
www.caryaudio.com
[email protected]
