CashCode SNR Mounting instructions

UNIVERSAL RECYCLER MODE is set by switch 2.3 to OFF position. Coin
changer from any manufacturer must be connected to the recycler’s harness.
BILL ENABLE OVERRIDE RULES:
The following is implemented to enhance sales while still preventing
dispensing of small coins. The Universal Recycler limits acceptance of bills
when it calculates there is insufficient change for the transaction.
These rules act to disable 1000VEF (if recycled 500VEF), 2000VEF and
5000VEF bills.
When the Universal recycler calculates that there are insufficient bills and
coins to provide change, three short red flashes will be shown.
When a bill is rejected because it was disabled by VMC or DIP SWITCHES,
two short red flashes will be shown.
If number of bills in the recycling cassette more than 4, then the recycler will
modify dispense command for coins to dispense it in bills first.
MDB v4.0 RECYCLER’S COMMANDS SUPPORT MODE is set by switch 2.3
to ON position. Coin changer must be disconnected from the recycler’s
harness and connected to MDB bus of VMC’s board.
There are no override rules in this mode.
OPTIONAL ACCESSORIES AND DOCUMENTS
•CASHCODE BILL SET Description: – Part# BSD-VEF6-B
•CASHCODE Bill Validator MDB
Protocol Interface Descriptions: – Part# MAN-MDB
Crane Payment Innovations
www.CranePI.com
2017 Crane Payment Innovations PT# UG-MMB-VE88-12401_A.doc 07/17
MMB-VE88-12401
Software Description
CURRENCY:
50, 100, 500, 1000, 2000, 5000 Venezuelan Bolivar Fuerte (VEF)
(see Bill Set Description BSD-VEF6-B for more details)
Currency Processing Data version – 01 (07/14/2017)
EXTERNAL COMMUNICATION INTERFACE:
MDB interface
CashCode Universal Recycler
New VEF (2016) Ready!

EXTERNAL COMMUNICATION INTERFACE FEATURES:
MDB INTERFACE
•Country Code = 1937h
•Decimal Place = 0
•Scaling Factor = 50
•MDB Level: 1(sw2.3=OFF) or 2 (sw2.3=ON)
DIP SWITCHES SETTING:
Switch 1 ON state OFF state Default
Setting
SW1.1 50 VEF Disabled 50 VEF Enabled OFF
SW1.2 100 VEF Disabled 100 VEF Enabled OFF
SW1.3 500 VEF Disabled 500 VEF Enabled OFF
SW1.4 1000 VEF Disabled 1000 VEF Enabled OFF
SW1.5 2000 VEF Disabled 2000 VEF Enabled OFF
SW1.6 5000 VEF Disabled 5000 VEF Enabled OFF
SW1.7 Reserved Reserved OFF
SW1.8 Reserved Reserved OFF
Switch 2 ON state OFF state Default
Setting
SW2.1 High Security High Acceptance OFF
SW2.2 Override rules disabled Override rules enabled OFF
SW2.3 MDB v.4.0 Recycler Universal recycler OFF
SW2.4 Service Mode To work with a “Host
Machine Controller” OFF
RECYCLING CASSETTE CONTROLS:
The Recycling Cassette controls are shown on the drawing below.
RECYCLING CASSETTE DIP SWITCHES SETTING:
Switch ON state OFF state Default
Setting
SW1 Assign for 1000 VEF Assign for 500 VEF OFF
SW2 Cassette setup mode Normal operation OFF
RECYCLING CASSETTE INDICATOR
After power on Recycling cassette indicator shows control firmware version:
F1 -> 24
After initialization indicator shows number of bills inside of the recycling
cassette.
In case of an error it will start flashing showing consequently number of bills
and one of the following error codes:
E0h – there was a hardware error detected
E1h – no communication with Coin Changer. In this case device will emulate
Coin Changer with 1 tube (5000 VEF or 10000 VEF).
FEED/UNLOAD BUTTONS
The Feed button is used for setting a Loading mode. This mode makes the
entered bills of a selected denomination to be loaded into the recycling
cassette. To cancel a loading mode, the Feed button must be pressed again.
If bills do not enter within 20 second s, the loading mode will be canceled
automatically.
By pressing the unload button one bill will be dispensed from the recycling
cassette through the entry channel. If the feed and unload buttons are pressed
simultaneously then all bills will be unloaded from the recycling cassette into
the drop cassette.
RECYCLING CASSETTE SETUP MODE
Recycling Cassette setup mode allows user to adjust recycling cassette feed
and unload levels (maximal number of bills accepted into the cassette and
number of bills to be left in the cassette during unload operation
correspondingly) without need of special equipment. In order to enter the setup
mode set SW2 to ON. The cassette indicator will start blinking “FL”(Fill level)
or “UL”(unload level) and the set level consequently. Press FEED button to
increase level and UNLOAD to decrease it. In order to switch between feed
and unload settings press two buttons simultaneously.
When setting is done set SW2 to OFF. Unit will switch to normal operation. No
power cycling is necessary.
DIP Switches
Unload button
Feed button
LCD display
