Casio DT-X7 Series User manual
Handheld Terminal
User’s Guide
Series
Be sure to read “Safety
Precautions” inside this
guide before trying to use
your Handheld Terminal.
After reading this guide,
keep it in a safe place for
future reference.
E
PN430049-002
DTX7EHyo14.indd3DTX7EHyo14.indd3 2007/11/1918:04:332007/11/1918:04:33
Information in this document is subject to change without advance notice. CASIO Computer Co.,
Ltd. makes no representations or warranties with respect to the contents or use of this manual
and specifically disclaims any express or implied warranties of merchantability or fitness for any
particular purpose.
This Product is equipped with the Brycen BL-RAPPORE Stack and My Wirefree
Network Bluetooth User Interface Application, the use of which is governed by a license
granted by Brycen Co., Ltd.
BLUETOOTH is a registered trademark owned by Bluetooth SIG, Inc. and licensed to
CASIO COMPUTER CO., LTD.
Microsoft and Windows are either registered trademarks or trademarks of Microsoft
Corporation in the United States and/or other countries.
•
•
•
DT-X7E2.indb2DT-X7E2.indb2 2007/09/1813:42:532007/09/1813:42:53
E-1
Contents
Safety Precautions .........................................................................................E-3
Operating Precautions .................................................................................E-10
Important ......................................................................................................E-11
Regulatory Information ...............................................................................E-12
Checking in the Box .....................................................................................E-16
Handheld Terminal System Configuration .................................................E-17
General Guide ...............................................................................................E-20
Loading and Removing the Battery Pack...................................................E-23
Loading ..............................................................................................................E-24
Removing...........................................................................................................E-25
Attaching the Hand Strap ............................................................................E-27
Setting up ......................................................................................................E-28
Using the mouse emulator function ...................................................................E-28
Adjusting Display Brightness ............................................................................ E-30
Display Auto Dimmer ........................................................................................E-30
Using the Laser Scanner (DT-X7M10E/DT-X7M10R) .................................E-31
Attaching the contact scanning guide ................................................................E-31
Warning Label.................................................................................................... E-32
Bar Code Scanning Position .............................................................................. E-32
Adjusting the Laser Light Emission Width .................................................E-33
Using the Linear Imager (DT-X7M10U) .......................................................E-35
Performing Communications .....................................................................E-36
IR Communication.............................................................................................E-36
Bluetooth®Communication ...............................................................................E-37
Resetting the Handheld Terminal................................................................E-38
Performing a Full Reset (Initialization) ............................................................E-39
DTX7EP0102.indd1DTX7EP0102.indd1 2007/09/2810:16:392007/09/2810:16:39
E-2
DT-X7 Specifications ...................................................................................E-40
Using the USB Cradle (HA-F60IO)...............................................................E-43
General Guide ....................................................................................................E-43
Connecting the USB Cradle Power Supply ....................................................... E-45
Specifications .....................................................................................................E-47
Using the Ethernet Cradle (HA-F62IO)........................................................E-48
General Guide ....................................................................................................E-48
Connecting the Ethernet Cradle Power Supply..................................................E-50
Specifications .....................................................................................................E-52
Using the Cradle-type Battery Charger (HA-F30CHG)..............................E-53
General Guide ....................................................................................................E-53
Connecting the AC Adaptor for Cradle-type Battery Charger...........................E-54
Specifications .....................................................................................................E-56
Using the Cradle-type Dual Battery Charger (HA-F36DCHG) ..................E-57
General Guide ....................................................................................................E-57
Charging Battery Pack .......................................................................................E-59
Connecting Multiple Cradle-type Dual Battery Chargers..................................E-60
Specifications .....................................................................................................E-61
Using the Dual Battery Charger (HA-F32DCHG)........................................E-63
General Guide ....................................................................................................E-63
Charging Battery Pack .......................................................................................E-65
Connecting Multiple Dual Battery Chargers......................................................E-66
Specifications .....................................................................................................E-67
Using Rechargeable Battery Pack..............................................................E-68
Battery Pack Specifications................................................................................E-68
Large-capacity Battery Pack Specifications.......................................................E-68
Attaching the Hand Belt (HA-F95HB)..........................................................E-69
Attaching the Hand Belt.....................................................................................E-69
Using the Dry-cell Battery Case (HA-F22BC).............................................E-71
Alkaline Battery Handling Precautions..............................................................E-71
Loading ..............................................................................................................E-73
Removing...........................................................................................................E-74
Specifications .....................................................................................................E-74
DTX7EP0102.indd2DTX7EP0102.indd2 2007/09/2810:01:482007/09/2810:01:48
E-3
Safety Precautions
Congratulations upon your selection of this CASIO product. Be sure to read the
following Safety Precautions before trying to use it for the first time.
Markings and Symbols
The following are the meanings of the markings and symbols used in these Safety
Precautions.
Danger This symbol indicates information that, if ignored or applied
incorrectly, creates the danger of death or serious personal injury.
Warning
This symbol indicates information that, if ignored or applied
incorrectly, creates the possibility of death or serious personal
injury.
Caution
This symbol indicates information that, if ignored or applied
incorrectly, creates the possibility of personal injury or property
damage.
A diagonal line indicates something you should not do. The symbol shown
here indicates you should not try to take the unit apart.
A black circle indicates something you should do. The symbol shown here
indicates you should unplug the unit from the wall outlet.
Precautions During Use
Warning
Disassembly and Modification
Never try to disassemble or modify the Handheld Terminal and its options in
any way. High voltage inside creates the danger of electric shock.
Abnormal Conditions
Should the Handheld Terminal and its options become hot or start to emit
smoke or a strange odor, immediately turn off the power, and contact your
original vendor or an authorized CASIO service provider. Continued use
creates the danger of fire and electric shock.
•
•
•
•
DT-X7E2.indb3DT-X7E2.indb3 2007/09/1813:42:552007/09/1813:42:55
E-4
Warning
Foreign Objects
Should any foreign matter get into the Handheld Terminal and its options,
immediately turn off the power and contact your original vendor or an
authorized CASIO service provider. Continued use creates the danger of fire
and electric shock.
Dropping and Damage
Should you drop the Handheld Terminal and its options and damage them,
immediately turn off the power and contact your original vendor or an
authorized CASIO service provider. Continued use creates the danger of fire
and electric shock.
Moisture
Though the Handheld Terminal is water splash-resistant, its optional
peripherals are not. Keep loose metal objects and containers filled with
liquids away from your Handheld Terminal and the optional peripherals.
Also, never connect or disconnect peripherals to the Handheld Terminal
while they are wet. Water getting into the Handheld Terminal or its
peripherals creates the danger of fire and electric shock.
Laser Light
This product (DT-X7M10E, DT-X7M10R) scans bar codes using laser light.
Never look directly into the laser light or shine the laser light into the eyes.
LED Light
This product (DT-X7M10U) scans bar codes using LED light. Never look
directly into the LED light or shine the LED light into the eyes.
•
•
•
•
•
Warning
Interference with the Operation of Other Equipment
(Using Wireless Data Communication)
Keep your Handheld Terminal at least 22 centimeters (811/16") away from
anyone wearing a pacemaker. Radio waves emitted by the Handheld
Terminal can affect the operation of a pacemaker.
In order to protect someone wearing a pacemaker from the risk of
unintentional interference, turn off the Handheld Terminal before boarding a
crowded train or entering any other crowded area.
•
•
DTX7EP0309.indd4DTX7EP0309.indd4 2007/09/2513:23:352007/09/2513:23:35
E-5
Caution
Foreign Objects
Take care to ensure that metals or combustible objects are not inserted into
the openings of the Handheld Terminal and its options. Such the objects
inside of the Handheld Terminal create the danger of fire and electric shock.
Location
Do not locate the Handheld Terminal and its options on a surface that is
unstable or uneven. Doing so creates the danger of the Handheld Terminal
falling, which can cause personal injury.
Do not locate the Handheld Terminal and its options in an area subject to
large amounts of humidity or dust. Doing so creates the danger of fire and
electric shock.
Do not leave the Handheld Terminal and its options for a long period in a car
parked in direct sunlight.
Heavy Objects
Never place heavy objects on top of the Handheld Terminal and its options.
Doing so creates the danger of loss of balance and the objects falling, which
can cause personal injury.
LCD Screen
Never apply strong pressure to the screen or subject it to strong impact.
Doing so can crack the screen or LCD panel glass, which can cause the
danger of personal injury.
Should the LCD panel glass break, never touch the liquid inside. Doing so
can cause skin inflammation.
– Should liquid from the LCD panel accidentally get into your mouth,
immediately wash your mouth with water and then consult a physician.
– Should liquid from the LCD panel accidentally get into your eyes or onto
your skin, immediately rinse for at least 15 minutes with clean tap water
and then consult a physician.
•
•
•
•
•
•
•
DT-X7E2.indb5DT-X7E2.indb5 2007/09/1813:42:552007/09/1813:42:55
E-6
Optional Lithium-ion Battery Pack
Danger
Never allow the battery pack to become wet. Water can create the danger of
battery pack heat emission, explosion, and fire.
Never use or leave the battery pack next to open flame, near a stove, or any
other area exposed to high heat. Doing so creates the danger of battery pack
heat emission, explosion, and fire.
Never use the battery pack with any device other than the Handheld
Terminal. Doing so can create the danger of battery pack heat emission,
explosion, and fire.
Note that the battery pack’s positive (+) and negative (–) polarities must be
oriented correctly when it is loaded into battery charger or the Handheld
Terminal. Connecting the battery pack with its polarities reversed creates the
danger of battery pack fluid leakage, heat emission, explosion, and fire.
Never dispose of the battery pack by incinerating it or otherwise expose it to
heat. Doing so creates the danger of battery pack heat emission, explosion,
and fire.
Never allow the positive (+) and negative (–) terminals of the battery pack to
become connected (shorted) by metal. Doing so creates the danger of battery
pack heat emission, explosion, and fire.
Never transport or store the battery pack together with a necklace, hair pins
or other metal objects. Doing so can short battery pack terminals, creating
the danger of battery pack heat emission, explosion, and fire. Be sure to
place the battery pack in its case whenever transporting or storing it.
Never throw the battery pack or otherwise subject it to strong impact. Doing
so creates the danger of battery pack heat emission, explosion, and fire.
Never pierce the battery pack with nails, hit it with a hammer, or step on it.
Doing so can create the danger of battery pack heat emission, explosion, and
fire.
Never try to take apart the battery pack or modify it in any way. Doing so
creates the danger of battery pack heat emission, explosion, and fire.
Use only the specified battery charger to charge the battery pack. Use of
other type of battery charger creates the danger of battery pack heat
emission, explosion, and fire.
•
•
•
•
•
•
•
•
•
•
•
DT-X7E2.indb6DT-X7E2.indb6 2007/09/1813:42:552007/09/1813:42:55
E-7
Warning
Never place the battery pack in a microwave oven or any other high-voltage
device. Doing so creates the danger of battery pack heat emission,
explosion, and fire.
Should the battery pack emit a strange odor or heat, change color or shape, or
exhibit any other abnormal behavior, immediately stop using it. Continued
use creates the danger of battery pack heat emission, explosion, and fire.
If the amount of time period the battery pack can serve becomes
considerably short, stop using it. It may indicate the possibility of a
malfunction in the battery pack. Continued charging the battery pack creates
the danger of heat emission, explosion, and fire.
If the battery pack does not achieve full charge after the normal charging
time has passed, stop charging it. Continued charging creates the danger of
battery pack heat emission, explosion, and fire.
Should the battery pack start to leak or emit a strange odor, immediately
move it away from any nearby flame. Leaking battery fluid is combustible,
and exposure to flame creates the danger of explosion and fire.
Should fluid from the battery pack accidentally get into your eyes, do not
rub them. Immediately rinse your eyes with clean tap water and then
consult a physician immediately.
•
•
•
•
•
•
Caution
Never use or leave the battery pack in an area exposed to direct sunlight, in
a car parked in direct sunlight, or any other very hot area. Doing so creates
the danger of heat emission and fire, as well as deterioration of battery pack
performance and shortening of its service life.
Do not use the battery pack in areas where static electricity is being
generated. Doing so creates the danger of battery pack heat emission,
explosion, and fire.
Danger of explosion if the battery pack is incorrectly replaced.
Replace only with same or equivalent type recommended by CASIO.
Dispose of used batteries according to the local regulation.
Should fluid from the battery pack accidentally get onto clothing or your
skin, immediately rinse it off with clean tap water. Prolonged contact with
battery pack fluid can cause skin irritation.
Keep the battery pack out of the reach of small children. Do not let small
children remove the battery pack from battery charger or the Handheld
Terminal while it is powered on.
•
•
•
•
•
•
DT-X7E2.indb7DT-X7E2.indb7 2007/09/1813:42:552007/09/1813:42:55
E-8
AC Power Supply
Warning
Do not use the Handheld Terminal at a voltage other than the specified
voltage. Also, do not connect the Handheld Terminal to a multi-plug power
strip. Doing so creates the danger of fire and electric shock.
Avoid conditions that can cause damage or breaks in the power cord. Do not
place heavy objects on the power cord and keep it away from sources of
heat. Any of these conditions can damage the power cord, creating the
danger of fire and electric shock.
Never modify, sharply bend, twist, or pull on the power cord. Doing so
creates the danger of fire and electric shock.
Power cable (especially on the plug)
Never use a detergent to clean AC adaptor, especially on the plug and the
jack.
When using the battery chargers and the cradles, be sure to use the
respective AC adaptors (sold separately). Use of other AC adaptor model
creates the danger of fire and electric shock.
Should the power cord become severely damaged (to the point that wires are
exposed or broken), contact an authorized CASIO service provider about
repair or replacement. Use of a damaged electrical cord creates the danger of
fire and electric shock.
•
•
•
•
•
•
Caution
Keep the power cord away from stoves and other sources of extreme heat.
Heat can melt the covering of the power cord and create the danger of fire
and electric shock.
Never pull on the power cord when unplugging it. Doing so can damage the
cord and create the danger of fire and electric shock. (Always hold the plug
when unplugging it from the wall outlet.)
Never touch the plug while your hands are wet. Doing so can create the
danger of electric shock.
Be sure to unplug the power cord from the wall outlet before moving the
battery chargers and the cradles. Failure to do so can result in damage to
the power cord caused by pulling it, which creates the danger of fire and
electric shock.
Be sure to unplug the power cord from the wall outlet before cleaning the
battery chargers and the cradles.
Be sure to unplug the power cord after use.
Unplug the power cord from the wall outlet whenever leaving the battery
chargers and the cradles unattended for a long period.
•
•
•
•
•
•
•
DT-X7E2.indb8DT-X7E2.indb8 2007/09/1813:42:562007/09/1813:42:56
E-9
AC Adaptor
Caution
The housing of the AC adaptor can become warm during normal use.
Take normal precautions against electric shock.
At least once a year, unplug the AC adaptor from the wall outlet and clean
any dust that builds up between the prongs of the plug.
Dust built up between the prongs can lead to the danger of fire.
•
•
•
Backup Copies of All Important Data
Caution
Note that CASIO Computer Co., Ltd. shall not be held liable to you or any
third party for any damages or loss caused by deletion or corruption of data
due to use of the Handheld Terminal, malfunction or repair of the Handheld
Terminal or its peripherals, or due to the batteries going dead.
The Handheld Terminal employs electronic memory to store data, which
means that memory contents can be corrupted or deleted if power is
interrupted due to the batteries going dead or incorrect battery replacement
procedures. Data cannot be recovered once it is lost or corrupted. Be sure to
make backup copies of all important data. One way to do this is to use the
separately sold cradles to transfer data to a computer.
•
•
DT-X7E2.indb9DT-X7E2.indb9 2007/09/1813:42:562007/09/1813:42:56
E-10
Operating Precautions
Your Handheld Terminal and its options are precision. Improper operation or rough
handling can cause problems with data storage and other problems. Note and observe
the following precautions to ensure proper operation.
Do not continue operating the Handheld Terminal when battery power is low.
Doing so can cause data to be lost. When the battery goes low, charge it as soon as
possible.
Do not leave dead battery pack in the Handheld Terminal for a long period.
Dead battery pack can leak, leading to malfunction and damage to the Handheld
Terminal.
Use the Handheld Terminal and its options only within the specified
temperature range.
Use outside of the specified temperature range creates the risk of malfunction.
Avoid using the Handheld Terminal and its options in areas subject to the
following conditions.
The following conditions create the risk of damage to the Handheld Terminal.
— Large amounts of static electricity
— Extreme heat or extreme cold
— High humidity
— Sudden temperature extremes
— Large amounts of dust
Never use thinner, benzene, cosmetic cleaning fluids, or other volatile agents to
clean the Handheld Terminal.
To clean the Handheld Terminal, wipe it with a dry cloth, or a cloth moistened in
a weak solution of water and a mild neutral detergent. Wring all excess moisture
from the cloth before wiping.
Although the Handheld Terminal meets the IP54 level of the International
Standard IEC529, pay your attention to the following when using it in the rain.
— After a large amount of rain or water falls on the Handheld Terminal, wipe off it
immediately.
— Do not use it in the rain for a long period of time.
— Make sure the battery cover and connect cover are closed securely before using it.
— Do not press on the screen or keys with excessive force when using it in the rain.
•
•
•
•
•
•
DTX7EP1015.indd10DTX7EP1015.indd10 2007/09/2513:24:202007/09/2513:24:20
E-11
Important
The contents of this guide are subject to change without notice.
Note that CASIO COMPUTER CO., LTD. shall not be held liable to you or any third
parties for any losses or damages arising from the use of this guide.
This guide does not include any information about programming and download
procedures. See the applicable separate documentation for information about the
procedures.
After Service
Should this product ever malfunction, contact your original retailer providing
information about the product name, the date you purchased it, and details about the
problem.
This mark applies to EU countries only.
•
•
•
•
DTX7EP1015.indd11DTX7EP1015.indd11 2007/09/2513:24:212007/09/2513:24:21
E-12
Regulatory Information
The USA and Canada
GUIDELINES LAID DOWN BY FCC RULES FOR USE OF THIS UNIT IN THE U.S.A. (not
applicable to other areas).
NOTICE
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant
to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television reception, which can
be determined by turning the equipment off and on, the user is encouraged to try to correct the interference
by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
FCC WARNING
Changes or modifications not expressly approved by the party responsible for compliance could void
the user’s authority to operate the equipment.
Proper connectors must be used for connection to host computer and/or peripherals in order to meet FCC
emission limits.
Caution Exposure to radio frequency radiation (below is for portable device)
To comply with FCC RF exposure compliance requirements, this device must not be co-located or
operating in conjunction with any other antenna or transmitter.
•
•
•
•
Declaration of Conformity
Model Number: HA-F60IO, HA-F62IO
Trade Name: CASIO
Responsible party: Casio America, Inc. Industrial Handheld Division
Address: 2700 Augustine Drive Suite 155, Santa Clara, California 95054
Telephone number: 408-737-6300
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
For Customers in Canada
These Class B digital apparatuses comply with Canadian ICES-003.
Cet appareil numériqué de la classes B est conformé à la norme NMB-003 du Canada.
These devices comply with RSS 210 of Industry Canada (IC).
Operation is subject to the following two conditions:
(1) These devices may not cause interference, and
(2) These devices must accept any interference, including interference that may cause undesired opera-
tion of this device.
DT-X7E2.indb12DT-X7E2.indb12 2007/09/1813:42:562007/09/1813:42:56
E-13
L’ utilisation de ce dispositif est autorisée seulement aux conditions suivantes :
(1) il ne doit pas produire de brouillage et
(2) I’ utilisateur du dispositif doit étre prêt à accepter tout brouillage radioélectrique reçu, même si ce
brouillage est susceptible de compromettre le fonctionnement du dispositif.
Exposure to radio frequency radiation
The installer of this radio equipment must ensure that the antenna is located or pointed such that it does
not emit RF field in excess of Health Canada limits for the general population;
consult Safety Code 6, obtainable from Health Canada's website at www.hc-sc.gc.ca/rpb.
Europe
We, the undersigned.
Company CASIO Europe GmbH
Address, City Bornbarch 10, 22848 Norderstedt
Country Germany
Phone number +49(0)40-528-65-0
Fax number +49(0)40-528-65-424
certify and declare under our sole responsibility that the following equipments:
Product description/Intended use
EU/EFTA member states intended for use EU: Austria, Belgium, Bulgaria, Cyprus,
Czech Republic, Denmark, Estonia, Finland,
France, Germany, Greece, Hungary, Ireland, Italy,
Latvia, Lithuania, Luxembourg, Malta,
Netherlands,
Poland,
Portugal,
Romania, Slovakia, Slovenia,
Spain, Sweden, United Kingdom
EFTA: Switzerland, Iceland, Lichtenstein, Norway
Member states with restrictive use NONE
Manufacturer CASIO COMPUTER CO., LTD.
Brand CASIO
Type DT-X7M10E, DT-X7M10R
are tested and found to conform with the essential requirements for protection of health and the safety of
the user and any other persons and Electromagnetic Compatibility, as included in following standards:
Standard lssue date
EN 60950-1
EN 301 489-17
EN 50371
(for DT-X7M10R)
2001
v1.2.1: 2002.08
2002
and are tested and found to conform with the essential radio test suites so that they effectively use the
frequency spectrum allocated to terrestrial/space radio communication and orbital resources so to as to
avoid harmful interference, as included in following standards:
DT-X7E2.indb13DT-X7E2.indb13 2007/09/1813:42:562007/09/1813:42:56
E-14
Standard lssue date
EN 300 328 v1.7.1: 2006.10
EN 50371
(for DT-X7M10R)
2002
and therefore comply with the essential requirements and provisions of the Directive 1999/5/EC of the
European Parliament and of the council of March 9, 1999 on Radio equipment and Telecommunications
Terminal Equipment and the mutual recognition of their conformity and with the provisions of Annex III
(Conformity Assessment procedure referred to in article 10).
The technical documentation as required by the Conformity Assessment procedure is kept at the following
address:
Company CASIO Europe GmbH
Address, City Bornbarch 10, 22848 Norderstedt
Country Germany
Phone number +49(0)40-528-65-0
Fax number +49(0)40-528-65-424
Products are for distribution within
all member states of the EU.
France limited to 2446.5-2483.5 Mhz Indoor use.
Belgium limited to 2400-2483.5 Mhz Indoor, 2460-2483.5 Mhz Outdoor use.
0984
0984
The information described above dates from January 2003 and may be subjected to future
changes.
Manufacturer:
CASIO COMPUTER CO., LTD.
6-2, Hon-machi 1-chome, Shibuya-ku, Tokyo 151-8543, Japan
Representative within the European Union:
CASIO EUROPE GmbH
Bornbarch 10, 22848 Norderstedt, Germany
DT-X7E2.indb14DT-X7E2.indb14 2007/09/1813:42:572007/09/1813:42:57
E-15
The CASIO DT-X7M10E, DT-X7M10R, and DT-X7M10U models are designed, tested and
found to meet the relevant regulatory standards described below.
DT-X7M10E, DT-X7M10R
International standards:
IEC 60825-1
IEC 60529, IP54 level
Europe standards:
EN 60950-1
EN 60825-1
EN 300 328
EN 301 489-17
China standards:
GB 4943
GB 9254
GB 17625.1
[2002] 353
Taiwan standards:
CNS 14336
CNS 13438
LP 0002
Australia and New Zealand standards:
AS/NZS CISPR22
DT-X7M10U
International standards:
IEC 60529, IP54 level
IEC 60825-1
USA standards:
FCC Part 15B
FCC Part 15C
UL 60950-1
Canada standards:
RSS-GEN, RSS-210
ICES-003
cUL 60950-1
The DT-X7M10R for the destination of China only is designed and built to meet the Chinese radio related regulations. It does not
permanently integrate a microphone described in this guide which disables the capability of voice data transmission via Internet
Protocol including the "VOIP". The description about the microphone is thus intended for other models which are not available
in China.
DTX7EP1015.indd15DTX7EP1015.indd15 2007/12/1710:43:172007/12/1710:43:17
E-16
Checking in the Box
Please check the contents of the box before using the Handheld Terminal for the first
time.
Open the box and make sure that all the items shown here are included.
User's Guide (this manual)
Large-capacity Battery
Pack Cover
Hand Strap
Handheld Terminal
Contact Scanning Guide*
* the accessory does not accompany with
DT-X7M10U model.
DT-X7E2.indb16DT-X7E2.indb16 2007/09/1813:43:022007/09/1813:43:02
E-17
Handheld Terminal System Configuration
Options
USB Cradle
HA-F60IO
Cradle-type Dual Battery Charger
HA-F36DCHG
DT-X7 Series
Ethernet Cradle
HA-F62IO
Cradle-type Battery Charger
HA-F30CHG
The illustration shows the
USB Cradle(HA-F60IO).
DT-X7M10E
DT-X7M10R
DT-X7M10U
DT-X7E2.indb17DT-X7E2.indb17 2007/09/1813:43:022007/09/1813:43:02
E-18
HA-F20BAT
(Battery Pack)
HA-F21LBAT
(Large-capacity Battery Pack)
Dual Battery Charger
HA-F32DCHG
Battery Pack
AC Adaptor for USB Cradle/Ethernet Cradle/
Dual Battery Charger
AD-S42120BE
Options
DT-X7E2.indb18DT-X7E2.indb18 2007/09/1813:43:022007/09/1813:43:02
Other manuals for DT-X7 Series
2
This manual suits for next models
3
Table of contents
Other Casio Barcode Reader manuals
