Casio ET-L10 Series User manual

Ver. 1.00

ET-L10 Series
Android 9
Quick Start Guide
This document is a Development Guide Book
for ET-L10 application developers.

No part of this document may be produced or transmitted in any form or by any means, electronic or mechanical,
for any purpose, without the express written permission of CASIO COMPUTER CO.,LTD. in Tokyo Japan.
Information in this document is subject to change without advance notice.
CASIO COMPUTER CO.,LTD. makes no representations or warranties with respect to the contents or use of this
manual and specifically disclaims any express or implied warranties of merchantability or fitness for any
particular purpose.
© 2019 CASIO COMPUTER CO.,LTD.
•The Bluetooth word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and any use of such
marks by CASIO COMPUTER CO.,LTD. is under license. Other trademarks and trade names are those of their
respective owners.
•Wi-Fi is a registered trademark of Wi-Fi Alliance.
•Android, Android Wear, Google, Google Play, Google Now and other marks are trademarks of Google LLC.
•Other company, product and service names used in this manual also may be trademarks or registered trademarks
of others.

- Table of contents -
1. Overview ·························································································2
1.1 Structure ······················································································3
1.2 Version·························································································4
1.3 Notes ···························································································4
2. Development requirement··································································5
2.1 Required system ············································································5
3. Development enviorment ···································································6
3.1 Recommended enviorment ······························································6
3.2 Construction steps ·········································································7
3.2.1 Android Studio ·········································································8
3.2.2 Android SDK and USB driver ····················································· 12
3.2.3 Application development ························································· 15

2
1. Overview
ET-L10 is the device that is suitable for light work which is located between the conventional
rugged handy terminal and a smart phone. This document is a development guidebook written
for the ET-L10 application developers.
ET-L10 was developed as the device for customers who want to use smartphones for work but
are not satisfied with smartphones.
Conventional rugged handy terminal required specialized knowledge to control barcode scanner,
but ET-L10 does not need it.
From the getting date, it is set to be able to read all barcodes with standard Android
application.
Customers who want to make advanced settings for the barcode scanner can use the setting
tool instead of modifying their application.
Of course, they can control the barcode scanner also from the application by issuing scanner
intents.
Refer to the "Barcode scanner control manual" for details on the setting tool and the intent for
controlling the barcode scanner from the application.

3
1.1 Structure
The following figure shows the structure of this kit.
Folder / File
Description
/MANUAL
This folder contains manuals.
QuickStartGuide.pdf
A guidebook for developers to read first.
Describes the application development
requirements and development enviorment.
SoftwareManual.pdf
This is a manual for the installed software.
Describes the basic specifications of the
software.
HardwareManual.pdf
This is a manual for the hardware.
Describes a note on handling and operation
of the device.
BarcodeScannerControlManual.pdf
This is a manual for the barcode scanner.
Describes how to control from the setting
tool and how to create a control application.
KittingManual.pdf
This is a manual for the "Kitting".
Describes the kitting procedure for making
the device ready for business use.
/SOFTWARE
This folder contains softwares
/Scanner
This folder contains about scanner
/Sample/SymbolScan.zip
Sample code for controlling the barcode
scanner.
/OSUpdateService
This folder contains about OSUpdateService
/bin/OSUpdateServiceXXXXXXXXXX.apk
(X means the version)
APK file of OSUpdateService
/Sample/OSUpdateSample.zip
Sample code for using the
OSUpdateService

4
1.2 Version
The version number of this development kit consists of a combination of major version and
minor version, as shown below.
The major number represents the version of Device (i.e. ET-L10).
If updates manuals etc., its minor version number is increased.
1.3 Notes
Notes for using this development kit are as follows.
There is a dependency between the version of Android Studio and the version of the Basic
Development Kit. For details, refer to "3.1 Recommended enviorment (p.6)".
Please contact the distributor to get the latest version of development Kit.
ET.1.00.0
Major version
Minor version

5
2. Development requirement
2.1 Required system
[Windows]
•Microsoft® Windows® 7/8/10 (32- or 64-bit)
•3 GB RAM minimum, 8 GB RAM recommended. plus 1 GB for the Android Emulator
•2 GB of available disk space minimum
•4 GB Recommended (500 MB for IDE + 1.5 GB for Android SDK and emulator system image)
•1280 x 800 minimum screen resolution
•For accelerated emulator: Intel® processor with support for Intel® VT-x, Intel® EM64T (Intel®
64), and Execute Disable (XD) Bit functionality
[Mac]
•Mac® OS X® 10.10 (Yosemite) or higher, up to 10.13 (macOS Sierra)
•3 GB RAM minimum, 8 GB RAM recommended; plus 1 GB for the Android Emulator
•2 GB of available disk space minimum
•4 GB Recommended (500 MB for IDE + 1.5 GB for Android SDK and emulator system image)
•1280 x 800 minimum screen resolution
[Linux]
•GNOME or KDE desktop
•Tested on Ubuntu® 18.04 LTS, Trusty Tahr (64-bit distribution capable of running 32-bit
applications)
•64-bit distribution capable of running 32-bit applications
•GNU C Library (glibc) 2.19 or later
•3 GB RAM minimum, 8 GB RAM recommended; plus 1 GB for the Android Emulator
•2 GB of available disk space minimum
•4 GB Recommended (500 MB for IDE + 1.5 GB for Android SDK and emulator system image)
•1280 x 800 minimum screen resolution
•For accelerated emulator: Intel® processor with support for Intel® VT-x, Intel® EM64T (Intel®
64), and Execute Disable (XD) Bit functionality, or AMD processor with support for AMD
Virtualization™ (AMD-V™)
Note!
The explanation after the next chapter is all for Windows (64bit). If using Mac or Linux as a
development environment, responsible for building the environment at own risk.

6
3. Development enviorment
3.1 Recommended enviorment
To develop the application for ET-L10, it needs the development environment of Android.
Development language
Development platform (Recommended)
Java
Android Studio 3.0 or above
Android SDK (API level 28 -)
Google USB driver
JDK7 or above (Bundled with Android Studio)
Note!
The basic development kit was confirmed to work with the following Android Studio
combination. Use the following combination or above version.
However, there is a possibility that something wrong with work if use the latest unconfirmed
Android Studio version. If there is something wrong with work, try with the confirmed below
combination.
All released versions of Android Studio are available at the following web site.
https://developer.android.com/studio/archive
Software
Version
Android Studio
3.5.2
Gradle version (Android Studio)
5.4.1
Android Plugin Version (Android Studio)
3.5.2
Development Kit
ET.1.00.0
The default development language for Android Studio 3.4 or above is Kotlin.
Select Java in case of creating a new project.

7
3.2 Construction steps
The followings are the basic steps to construct the development environment.
Due to version upgrade of Android Studio, environment may not be constructed by the
following procedure. In that case, refer to the procedure described on Google's website etc. and
construct the environment.
(1) Android Studio
Download and Install the Android Studio to the PC.
About the version of the Android Studio, refer to the "3.1 Recommended enviorment (p.6)".
Refer to the "3.2.1 Android Studio (p.8)" for the construction method.
(2) Android SDK and USB driver
Download the Android SDK and USB driver from Google via Android Studio.
The Android SDK will be installed automatically after downloading.
The USB driver is installed when the device is connected to the PC for the first time.
About the version of the Android SDK, refer to the "3.1 Recommended enviorment (p.6)".
Refer to the "3.2.2 Android SDK and USB driver (p.12)" for the construction method.
(3) Application development
Develop an application with the installed Android Studio.
To debug an application, connect the PC and the ET-L10 via the ADB (Android Debug Bridge)
interface.
Refer to the "3.2.3 Application development (p.15)" for development.

8
3.2.1 Android Studio
Android Studio can be downloaded from the following site of Google.
https://developer.android.com/studio/
Agree to the dialog shown below and start downloading.
Executing the downloaded file, follow the instructions to proceed the installation.

9
Prompted to specify the installation destination. Change it if necessary.
When the below dialog is displayed, installation of Android Studio is completed.

10
When start the installed Android Studio first time, select whether to use the previous setting or
not. If do not want to use the previous setting, select "Do not import settings".
The Setup Wizard will start, so follow the instructions.

11
If do not have any problem after confirming "Finish".
Downloading Components begins. When completed, Android Studio will start up.

12
3.2.2 Android SDK and USB driver
Launch the Android Studio, and chose "SDK Manager" from Configure tab.
Select "SDK Platform" tab, then check "Android 9.0 (API Level 28)".

13
Next, select "SDK Tools" tab and check "Google USB Driver" and press [OK].
The following dialog will be displayed, press "OK".

14
Agree to the "License Agreement", then press "OK" to start installation.
The USB driver is stored in "extras\google\usb_driver" under "Android SDK Installation
Location".
e.g.) C:\Users\xxx\AppData\Local\Android\Sdk\extras\google\usb_driver
(xxx: username of computer)

15
3.2.3 Application development
To develop / debug the applications with ET-L10, the following preparation is necessary.
(1) Enable USB debugging (ADB connection) of ET-L10.
(2) Install ET-L10 USB driver to the PC.
Enabling USB debugging
Since USB debugging is a function for developers, need to activate the Developer options by the
following procedure first.
Open [Settings] -> [About phone] and tap "Build number" on the bottom line seven times,
[Developer options] is added above [About phone].
Tap on here
7times

16
Open [Settings] -> [About phone] -> [Developer options] and enable "USB debugging".
Enable

17
Installing USB driver
Install the USB driver for connecting the ET-L10 and PC with the ADB (Android Debug Bridge)
protocol.
Files necessary for installation are downloaded as described in "3.2.2 Android SDK and USB
driver (p.12)".
Skip from this procedure to "Debugging on ET-L10 (p.21)" in case of recognizing ET-L10 as ADB
on PC.
Connect the ET-L10 to a PC using a USB cable.
Then, open the Device Manager by [Control Panel] -> [Hardware and Sound] -> [Device
Manager].
In the Device Manager, "ADB Interface" is displayed as an unknown device as shown below.
By right-click the red frame ("Android") in the above figure, displays its properties, and press
[Update Driver].

18
Press "Let me pick from a list of drivers on my computer " at the bottom. In the driver list, with
"Show All Devices" is highlighted and press [Next].
When click [Hard Disk…] in the displayed dialog, a dialog box for specifying the location of the
driver opens, so click [Browse…] to open the file dialog box.
In the file dialog box, specify the downloaded USB driver in "3.2.2 Android SDK and USB driver
(p.12)". (e.g. "extras\google\usb_driver\android_winusb.inf")
