Casio DT-930 Series User manual

DT-930
Hardware Manual
(Version 1.00)
CASIO Computer Co., Ltd.
Copyright ©2006. All rights reserved.
May 2006

2
Table of Contents
Chapter 1. Product Overview 5
Chapter 2. External Views 6
2.1. DT-930M51E 6
2.2. DT-930M50E 6
2.3. DT-964IOE Satellite Cradle 7
2.4. DT-923LIB Battery Pack 7
Chapter 3. System Configuration 8
3.1. Available Models 8
3.2. Accessories 8
3.3. Consumable Items 8
3.4. Options 9
Chapter 4. General Specifications 10
4.1. Hardware 10
4.2. Key Layout 12
4.3. Compliance 13
4.4. Electrical 13
4.5. Environment 13
4.6. Impact Durability 13
4.7. Reliability 14
Chapter 5. Cables 15
5.1. Signal and Wiring 15
Chapter 6. DT-960IOE Basic Cradle 18
6.1. Features at a Glance 18
6.2. External Views 19
6.3. Dimensions and Weight 20
6.4. Hardware Specifications 21
6.5. Electric 23
6.6. Environment 24
6.7. Impact Durability 24
6.8. Reliability 24
6.9. Compliance 25
6.10. Chain Connection 25
6.10.1. Configurations and Operating Conditions 25
6.10.2. Cable Specifications 28
6.10.3. Notes About Chain Connection 30
Chapter 7. DT-964IOE Satellite Cradle 31
7.1. Features at a Glance 31
7.2. External Views 32
7.3. Dimensions and Weight 33
7.4. Hardware Specifications 34
7.5. Electric 37
7.6. Environment 38
7.7. Impact Durability 38
7.8. Reliability 38
7.9. Compliance 39
7.10. Chain Connection 40
7.10.1. Configurations and Operating Conditions 40

3
7.10.2. Cable Specifications 44
7.10.3. Precautions 46
Chapter 8. HA-E60IO Bridge Basic Cradle 47
8.1. Features at a Glance 47
8.2. External Views 48
8.3. Dimensions and Weight 49
8.4. Hardware Specifications 49
8.5. Electric 50
8.6. Environment 50
8.7. Impact Durability 50
8.8. Reliability 50
8.9. Compliance 51
Chapter 9. DT-969CHGE Cradle-type Battery Charger 52
9.1. Features at a Glance 52
9.2. External Views 53
9.3. Dimensions and Weight 54
9.4. Circuit Block Diagram 54
9.5. Hardware Specifications 55
9.6. Electric 56
9.7. Environment 56
9.8. Impact Durability 56
9.9. Reliability 57
9.10. Compliance 57
Chapter 10. Product Identification and Reference Numbers 58
No part of this document may be produced or transmitted in any form or by any means, electronic or
mechanical, for any purpose, without the express written permission of CASIO Computer Co., Ltd.
in Tokyo Japan. Information in this document is subject to change without advance notice. CASIO
Computer Co., Ltd. makes no representations or warranties with respect to the contents or use of this
manual and specifically disclaims any express or implied warranties of merchantability or fitness for
any particular purpose.
© 2006 CASIO Computer Co., Ltd. All rights reserved.

4
Editorial Record
Manual
Version
no.
Date edited Page Content
1.00 May 2006 Original version

5
1. Product Overview
Applications developed for existing the CASIO DT-900 series handheld terminal widely known as
the prominent model amongst logistics and distribution business can be ported into the new DT-930
series. The new series has been designed and developed for software compatibility with the DT-900
series in mind.
Handheld Operability
Table 1.1
DT-930M51E DT-930M50E
Dimensions 173 (D) x 69 (W) x 31.6 (H) mm 180 (D) x 69 (W) x 40.2 (H) mm
Weight Approx. 210 g Approx. 225 g
Approx. 200 hours with AA-size alkaline battery x 2 pcsOperating hour
Approx. 30 hours with lithium-ion battery pack
Note:
The dimensions in the table above are values measured for each largest part on the respected models.
Improved Compatibility and Development Environment
•Compatibility with application software for the DT-900 series
•Supports multi-drop protocol communication software used by the DT-700 series
•Supports FLINK protocol communication software used by the DT-900 series
Improved Durability and Resistance
•Drop proof : Fall from a height of 1.8 m
•Water-splash proof : Conforms to IP54 level of IEC60529 standard
Systematization
•OS : µITRON version 2.0
•Infrared high-speed communication : IrDA Ver 1.1 and Casio original infrared
communication
•2-way power supply source : Lithium-ion rechargeable battery and two AA-size
alkaline batteries
Improved Ease of Operation
•High resolution display (compatible with DT-900)
128 x 64 dots and easy-to-see icons
9 different font modes (6x6, 8x8, 10x10, 6x12, 12x12, 8x16, 16x16, 10x20, 20x20 dots)
•Measures for adjacent bar codes
Laser beam swing angle control
•Ease of key operation
Multi-function keys and side trigger keys
Basic Performance
•High-performance CPU
CPU: SH1 32-bit RISC
•Large-capacity memory
Main RAM (D-RAM) --------------------------------------- 4 MB
Executable code + user data storage memory (F-ROM) ----- 16 MB

6
2. External Views
2.1. DT-930M51E
Fig. 2.1
2.2. DT-930M50E
Fig. 2.2

7
2.3. DT-964IOE Satellite Cradle
2.4. DT-923LIB Battery Pack
Fig. 2.3
Fig. 2.4

8
3. System Configuration
3.1. Available Models
Table 3.1
Model No. Reader Port
DT-930M50E Angle shape (downward at 60º)
DT-930M51E Straight shape
3.2. Accessories
Table 3.2
Item Quantity
AA-size (LR6) alkaline battery 2 pcs
Wrist strap 1 pc
Desktop guides L and R 1 set
Wall mount guides L and R 1 set
Backup battery (CR2032) 1 pc
User’s guide 1 pc (in English and Chinese)
3.3. Consumable Items
Table 3.3
Item Specification
AA-size alkaline battery LR6
Button-type lithium battery (for memory backup) CR2032

9
3.4. Options
Table 3.4 List of the options
Model No. Product Specification
DT-964IOE Satellite Cradle
DT-960IOE Basic Cradle
HA-E60IO Bridge Basic Cradle
DT-969CHGE Cradle-type Battery
Charger
DT-923LIB Battery pack Lithium-ion battery pack
DT-9020ADP-GS AC adaptor Input 230VAC For DT-960IOE and DT-969CHGE
DT-9020ADP-US AC adaptor Input 120VAC For DT-960IOE and DT-969CHGE
AD-S42120AE AC adaptor Input 120VAC to 230VAC. For DT-964IOE
AD-S15050AE AC adaptor Input 120VAC to 230VAC. For HA-E60IO
DT-782RSC RS-232C cable Cross cable for DT-960IOE 14-pin/25-pin male
DT-783RSC RS-232C cable Cross cable for DT-960IOE 14-pin/25-pin female
DT-787AX RS-232C cable Cross cable for DT-960IOE 14-pin/19-pin female
DT-881RSC RS-232C cable Straight cable for DT-964IOE 9-pin female/25-pin male
DT-882RSC RS-232C cable Cross cable for DT-964IOE/PC 9-pin female/25-pin male
DT-883RSC RS-232C cable Cross cable for DT-964IOE/PC 9-pin female/25-pin
female
DT-887AXA RS-232C cable Cross cable for DT-964IOE/PC 9-pin female/9-pin female
DT-788RSC RS-485 cable Cable for DT-960IOE (connection under daisy-chain)
DT-888RSC RS-422 cable Cable for DT-964IOE (connection under daisy-chain)
DT-380USB USB cable Cable for HA-E60IO
DT-891WH Wall mount unit Wall mount unit for HA-E60IO

10
4. General Specifications
4.1. Hardware
Table 4.1 DT-930 hardware specifications
Block Item Specification Remark
CPU and memory
SH1 (32-bit RISC type)CPU
Clock frequency 4.92/2.46/1.23 MHz
RAM 4 Mbytes
F-ROM 16 Mbytes
Clock
Calendar
Clock Year/month/day/hour/minute/
second/day of the week/leap year
with auto self-start
function
Built-in chip CB-09FP
Step/Setup 4 steps (Loud/Middle/Low/OFF)/
Software setup
Buzzer
Sound
volumes
Max. volume 75 dB or more
Type STN with phase compensation
film
No. of dots 128 x 64 dots
LCD panel
Dot pitch 0.33 x 0.38 mm
Displayed character types ANK/JIS Level I, II Kanji/Extra
/User-defined characters
6x6 dots 210 characters 21 digits x 10 lines
6x12 dots 105 characters 21 digits x 5 lines
6-dot
12x12 dots 50 characters 10 digits x 5 lines
8x8 dots 128 characters 16 digits x 8 lines
8x16 dots 64 characters 16 digits x 4 lines
8-dot
16x16 dots 32 characters 8 digits x 4 lines
10x10 dots 72 characters 12 digits x 6 lines
10x20 dots 36 characters 12 digits x 3 lines
No. of
characters
10-dot
20x20 dots 18 characters 6 digits x 3 lines
Icons Shift/Low main battery voltage/
Low sub-battery voltage
Contrast adjustment 16-step electronic control
Display
Backlight LED
Type Rubber-sealed contact type Power key,
Numeric keys,
Function keys, L, R
keys
Location Front
Type Push-in type INIT key
Location On the rear side
Type Rubber-sealed contact type
Input
Trigger key
Location Right and Left sides
Method Semi-conductor laser
Wave length 650±10 nm
Laser output <1 mW
Number of scans 100±20 scans per second
Resolution 0.127 mm or more
PCS 0.45 or more
Straight 0 to 450 mm Readable depth
Angle 0 to 400 mm
Straight 65 mm max. (at depth of 0 mm)
Angle 60 mm max. (at depth of 0 mm)
Straight 390 mm max. (at depth of 450
mm)
Laser scanner
Readable width
Angle 360 mm max. (at depth of 400
mm)
Continue.

11
Filament bulb/luminescent tube
3,000 Lux or less
Resistance to external disturbance
Sunlight 80,000 Lux or less
Readable bar code symbologies EAN, UPCA, UPCE, NW7, ITF,
MSI, Industrial 2of5, CODE39,
CODE93, CODE128, EAN128,
IATA
Laser scanner
LED for confirmation In green color
Communication
Communication mode IrDA Ver. 1.1 compatible and
Casio original infrared
communication
Synchronization Async, Frame
Protocol Half-duplex
IrDA
Baud rate (bps) 2400/9600/19200/38400/57600/11
5200/4M
Standard Bluetooth Specification Ver.1.2
Profile Serial profile
Communication range Approx. 5m
Bluetooth
Output power 3dBm ( Power Class2)
Power supply
Standard OptionBattery type
AA-size alkaline
battery x 2
DT-923LIB Lithium-ion
battery pack x 1
Nominal voltage DC 1.5 V x 2 DC 3.6 V
Operating hours (Note 1) Approx. 200 Approx. 50
Operating
battery
Backup period (with only main
battery (Note 2)
5.0 months 1.5 months
Battery type Button-type lithium battery (CR2032) x 1Memory
backup
battery
Backup hours (with only backup
battery)
1 month
Type Function Operation status
LB0 (main battery) Absence of battery Forced OFF
LB1 (main battery) Battery used Operable
Low
battery
voltage
warning
LB2 (sub-battery) Battery used or not
present
Backup not possible
Pin No. 1 VCHG Recharging Terminal
4.2V, 300 mA max.
Pin No.2 XIRCNT Basic cradle control
signal
Pin No.3 VADP Power supply terminal
5 V, 400 mA max.
Pin No.4 GND Ground
Power
contacts
Layout of terminals
Notes:
1. At ambient temperature 25۫۫ºC, and scanning twice in every 10 seconds.
2. At ambient temperature 25ºC, and with fully charged Lithium-Ion battery pack (or two new
AA-size alkaline batteries).

12
4.2. Key Layout
The following illustration shows the keyboard viewed from the front on the terminal. Two trigger keys
are located on the left and right sides.
Ｌ
７８９
４５ ６
１２ ３
０.ENT
F1
Ｒ
F5
F2
F6
F3
F7
F4
F8
SP ▲ ▼ BL
- ← → DEL
＄/+ ％：＊
STU VWX YZ-
JLK MNO POR
ABC DEF GHI
S BS CLR PW
Fig. 4.1 Key layout

13
4.3. Compliance
Table 4.2 List of the applicable compliance standards
Standard Remark
EMI EN55022:1998+A1:2000+A2:2003
EMS EN55024:1998+A1:2001+A2:2003
FCC Part 15 Subpart B
compatible
Safety EN60950-1 UL60950 compatible
Bluetooth type approval EN300.328-1/EN300.328-2
EN301.489-1/EN300.489-17
FCC Part 15 Subpart
C/RSS-210 compatible
Laser EN60825 FDA compatible
4.4. Electrical
Table 4.3
Item Specification Remark
Power consumption 0.7 W
LR6 alkaline dry cell x 2Power supply
Lithium-ion battery pack
Static-electricity strength
Malfunction ±5 KV Compliant with EN61000-4-2
Destruction ±10 KV
Noise radiant intensity CE marking
4.5. Environment
Table 4.4 Recommended environment for operation and storage
Item Specification Remark
Temperature
Operation -20 ºC to 50 ºC 0 ºC to 40 ºC with Cradle
Storage -20 ºC to 60 ºC
Humidity
Operation 10% to 80% RH
Storage 90% RH
No condensation
Dust and water-splash proof Conforms to IP54 level IEC60529 standard
4.6. Impact Durability
Table 4.5
Item Specification Remark
Resistance to vibration 1.5 G or less Conditions:
•At frequency between 10 and 55 Hz
•In the X,Y, and Z directions
•Reciprocally for 30 minutes
Shock-proof 180 cm Fall onto concrete slab from height of 180 cm

14
4.7. Reliability
Table 4.6
Item Specification Remark
MTBF of electronic parts 20,000 hours
Backlight 5,000 hours Until the brightness of the
backlight becomes half-value of
the full brightness.
Laser scanner 10,000 hours
Key
Power switch 300,000 times
Trigger key 1,000,000 times Right and Left sides
Other keys 300,000 times
Battery compartment lid 5,000 times Including the lock button
Power supply section
Installing and removing the
operating battery pack (or
AA-size alkaline batteries)
5,000 times
Mounting and removing the terminal
on/from cradle
5,000 times

15
5. Cables
5.1. Signal and Wiring
•DT-881RSC (Straight)
Cradle (9-pin female) side External peripheral (25-pin male) side
Signal Pin Pin Signal
SD 3 2 SD
RD 2 3 RD
RS 7 4 RS
CS 8 5 CS
DR 6 6 DR
SG 5 7 SG
CD 1 8 CD
ER 4 20 ER
CI 9 22 CI
1 FG
Case
Case
•DT-882RSC (Cross)
Cradle (9-pin female) side External peripheral (25-pin male) side
Signal Pin Pin Signal
SD 3 2 SD
RD 2 3 RD
RS 7 4 RS
CS 8 5 CS
DR 6 6 DR
SG 5 7 SG
CD 1 8 CD
ER 4 20 ER
CI 9 22 CI
1 FG
Case
Case
•DT-883RSC (Cross)
Cradle (9-pin female) side External peripheral (25-pin male) side
Signal Pin Pin Signal
SD 3 2 SD
RD 2 3 RD
RS 7 4 RS
CS 8 5 CS
DR 6 6 DR
SG 5 7 SG
CD 1 8 CD
ER 4 20 ER
CI 9 22 CI
1 FG
Case
Case
Fig. 5.1
Fig. 5.2
Fig. 5.3

16
•DT-887AX (Cross)
Cradle (9-pin female) side External peripheral (9-pin female) side
Signal Pin Pin Signal
SD 3 3 SD
RD 2 2 RD
RS 7 7 RS
CS 8 8 CS
DR 6 6 DR
SG 5 5 SG
CD 1 1 CD
ER 4 4 ER
CI 9 9 CI
Case
Case
•DT-888RSC (Cross for RS-422)
Cradle (C-OUT ) side Cradle (C-IN) side
Signal Pin Pin Signal
ORS+ 1 1 IRS+
ORS- 2 2 IRS-
OSD+ 3 3 ISD+
OSD- 4 4 ISD-
IRD+ 5 5 ORD+
IRD- 6
6 ORD-
•DT-782RSC (Cross)
Cradle (14-pin female) side External peripheral (25-pin male) side
Signal Pin Pin Signal
FG 1 1 FG
SD 3 2 SD
RD 5 3 RD
RS 7 4 RS
CS 9 5 CS
CD 13 8 CD
ER 8 20 ER
DR 11 6 DR
SG 14 7 SG
FG Case
1 FG
•DT-783RSC (Cross)
Cradle (14-pin female) side External peripheral (25-pin female) side
Signal Pin Pin Signal
FG 1 1 FG
SD 3 2 SD
RD 5 3 RD
RS 7 4 RS
CS 9 5 CS
CD 13 8 CD
ER 8 20 ER
DR 11 6 DR
SG 14 7 SG
FG Case
1 FG
Fig. 5.4
Fig. 5.5
Fig. 5.6
Fig. 5.7

17
•DT-787AX (Cross)
Cradle (14-pin female) side External peripheral (9-pin female) side
Signal Pin Pin Signal
FG 1 Case FG
SD 3 3 SD
RD 5 2 RD
RS 7 7 RS
CS 9 8 CS
CD 13 1 CD
ER 8 4 ER
DR 11 6 DR
SG 14 5 GND
FG Case
Case FG
Fig. 5.8
•DT-788RSC (Cross for RS-485)
Signal Pin Pin Signal
TRUE (INVERT) 3 3 INVERT (TRUE)
INVERT (TRUE) 4 4 TRUE (INVERT)
Fig. 5.9

18
6. DT-960IOE Basic Cradle
The DT-960IOE Basic Cradle is a cradle dedicated for DT-930. It facilitates non-contact data
transfer between a PC and the terminal, and if multiple cradles are chain-connected, each cradle
facilitates connecting the terminal mounted on the cradle to a single PC. It has an RS-232C interface
for connection to PC and an IR interface using the CASIO original protocol for connection to the
terminal. Also, it can supply power to the mounted terminal.
6.1. Features at a Glance
•Casio original protocol optical communication with the terminal.
•Chain links multiple Basic Cradles. The RS-485 driver/receiver is integrated to connect a
maximum of sixteen DT-960IOEs with a total line length of 1 Km.
•Power supply capability to the terminal. The built-in circuit has a capability of supplying power
to the terminal preventing the battery power from being consumed by the terminal during
communication.
•Wall mount configuration or desk top configuration is possible.

19
6.2. External Views
LED
indicator
DT-930
detection
switch
RS-232C connector
RS-485 connector
AC adaptor jack
EIAJ TYPE3
Power switch
DIP switch
Power supply
terminal
Wall-mounting
unit
Rating lable
Fig. 6.1
Note:
If this page is not printed properly, change the printer graphic property from "Vector Graphic" to
"Raster Graphic".

20
6.3. Dimensions and Weight
Table 6.1 Dimensions and weight
Item Specification
Desk top configuration 110 (W) mm x 220 (D) mm x 100 (H) mm
Wall mounting configuration 110 (W) mm x 220 (D) mm x 110 (H) mm
Weight Approx. 355 g (see notes)
Notes:
•If the hook and cover for wall mounting are used, the product weight is increased by
approximately 10 g.
•If the nose guide for straight opening is used, the product weight is increased by approximately
5 g.
