1. General
In this chapter, how to check the hardware of IT-G600 is explained.
The general fl ow to start up the test program is as follows:
1
HARDWARE TEST / SETTING
Prepare equipment required.
Insert a microSD card and nanoSIM card into the device.
Start the test program.
Perform function tests.
Perform Initial Settings. (When the Main PCB is replaced)
Perform resetting.
Remove the microSD card and nanoSIM card.

IT-G600
２. Test Equipment
The following shows the major equipment used for function test.
NOTE: For equipment used for the special test, see respective test items.
２
Test Object IT-G600
USB cable
Type-C(male)
Type-A(male)
Cradle
ＰＣ
nanoSIM
card
microSD
card
USB cable
Type-C (male) Type-A (female)
USB memory
Head set

IT-G600
3. List of Tests
検査項目 備考
MIC/SP/Receiver You can check the MIC/SP/Receiver.
LED/VIBRATOR You can check the LED/VIBRATOR.
VERSION CHECK You can check the PRODUCT VERSION.
BATTERY COVER DETECT You can check the BATTERY COVER DETECT.
TOUCH You can check the TOUCH PANEL.
LCD/BACKLIGHT You can check the LCD/BACKLIGHT.
SCANNER You can check the SCANNER.
WLAN You can check the WLAN.
KEY You can check the KEY.
EARJACK You can check the Earphones JACK.
IO USB DETECT
You can check IT-G600’s I/O connector correctly
communicate with your PC.
IO USB HOST
You can check IT-G600’s I/O connector correctly
working with USB HOST device.
MicroUSB DETECT
You can check IT-G600’s MicroUSB connector correctly
communicate with your PC.
MicroUSB HOST
You can check IT-G600’s MicroUSB connector correctly
working with USB HOST device.
CAMERA You can check the CAMERA.
NFC You can check the NFC.
SENSOR You can check the SENSOR.
BLUETOOTH You can check the BLUETOOTH.
IMAGEDEMO Do not inspect
MIC Loop Do not inspect
3
Do not inspect
CHECK MAIN SPEAKER Do not inspect
BATTERY TEMPERTURE You can check the BATTERY.
SIM
EXT B
2D AIMER
Do not inspect
Do not inspect
WAN You can check the WAN

IT-G600
4. Preparation for inspection
4-1. Insert a microSD card and SIM card into the device.
4-2. Running the Diagnostic Program
＜ W-LAN model＞
＜ WAN model＞
4
Tap about 10 times
Scroll up

IT-G600
5. Test Procedures
■ SDcard
5
INPUT[＊#＊#1277#＊#＊]

IT-G600
■ MIC/SP/Receiver
6
Click [Success] if the test
result is satisfactory.
Click [Record] button.
Speak to the microphone.
Click [Play] button.
Check the recorded voice.
Check [Second MIC]
in the same way
Press "Play Reciver
Sound" to hear the sound

IT-G600
■ LED/VIBRATOR
7
Check that the LED lights in the
same color as the screen display
Check that the key
backlight is on
Click "Touch screen"
Check the vibration
of the vibrator
Click [Success] if the test
result is satisfactory.

IT-G600
■ BATTERY COVER DETECT
8
Check that it is "Closed" Release the right
lock lever
Click [Success] if the test
result is satisfactory.
Close the right
lock lever Check to be "Opened"

IT-G600
■ TOUCH
9
Click [Success] if the test
result is satisfactory.
Draw an outline with silver
line on the screen.
Draw a silver line,
Click Next
Draw freely,
Click Exit

IT-G600
■ LCD/BACKLIGHT
10
Increase number
to 10 level.
←FLICK
Click [Success] if the test
result is satisfactory.
There is no display
abnormality
in each color.
Click [Complete]

IT-G600
■ SCANNER
11
Trigger Onを押して
任意のバーコードを読み取る
正常なら"SUCCESS"
をクリック

IT-G600
■ WLAN
12
Connect to any
connection destination
Click [Success] if the test
result is satisfactory.

IT-G600
■ KEY
13
Click [Success] if the test
result is satisfactory.
Press all the keys

IT-G600
■ EARJACK
Attach the headset to the IT-G600.
14
Click [Success] if the test
result is satisfactory.
Press the "Record" button
to record the voice
Press the "Play" button to
play the recorded voice

IT-G600
■ IO USB DETECT
System configuration
15
Click [Success] if the test
result is satisfactory.
When the cradle is attached,
it changes from red to green
Changeover switch set to "A"

IT-G600
■IO USB HOST
System configuration
16
Click [Success] if the test
result is satisfactory.
When the cradle is attached,
it changes from red to green
Changeover switch set to "B"

IT-G600
■ MicroUSB DETECT
System configuration
17
Click [Success] if the test
result is satisfactory.
Changing from red to
green when connected
to a computer

IT-G600
■ MicroUSB HOST
System configuration
18
Click [Success] if the test
result is satisfactory.
Changing from red to
green when connected
to USB memory

IT-G600
■ CAMERA
19
The image taken by the
camera is displayed
Click [Success] if the test
result is satisfactory.
The camera flash can
be turned off / on

IT-G600
■ NFC
20
Click [Success] if the
test result is satisfactory.
Contact the “NFC Test card”
near scanner(NFC Antenna).
