ClassPad 330 PLUS
Hardware
User’s Guide
CASIO Education website URL
http://edu.casio.com
ClassPad website URL
http://edu.casio.com/products/classpad/
Access the URL below and register as a user.
http://edu.casio.com/dl/
E

GUIDELINES LAID DOWN BY FCC RULES FOR USE OF THE UNIT IN THE U.S.A. (not
applicable to other areas).
NOTICE
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates,
uses and can radiate radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications. However, there is
no guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning
the equipment off and on, the user is encouraged to try to correct the interference by one or
more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
• Consult the dealer or an experienced radio/TV technician for help.
FCC WARNING
Changes or modifications not expressly approved by the party responsible for compliance
could void the user’s authority to operate the equipment.
Proper connectors must be used for connection to host computer and/or peripherals in order to
meet FCC emission limits.
Connector SB-62 ClassPad to ClassPad
USB connector for the ClassPad ClassPad to Windows
®
compatible PC/Macintosh computer
Declaration of Conformity
Model Number: ClassPad 330 PLUS
Trade Name: CASIO COMPUTER CO., LTD.
Responsible party: CASIO AMERICA, INC.
Address: 570 MT. PLEASANT AVENUE, DOVER, NEW JERSEY 07801
Telephone number: 973-361-5400
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that
may cause undesired operation.
Windows and Windows Vista are registered trademarks or trademarks of Microsoft Corporation
in the United States and/or other countries.
Mac, Macintosh, and Mac OS are registered trademarks or trademarks of Apple Inc. in the
United States and/or other countries.
Fugue © 1999 – 2002 Kyoto Software Research, Inc. All rights reserved.
Company and product names used in this user’s guide may be registered trademarks or
trademarks of their respective owners.
Note that trademark ™ and registered trademark ®are not used within the text of this user’s guide.

20110901
Contents
Chapter 1 Getting Ready
1-1 Unpacking ............................................................................................. 1-1-1
1-2 Attaching and Removing the Front Cover ......................................... 1-2-1
1-3 Using the Stylus ................................................................................... 1-3-1
1-4 Replacing Batteries and Setting Up the ClassPad ............................ 1-4-1
1-5 Handling Precautions .......................................................................... 1-5-1
1-6 Adjusting Display Contrast ................................................................. 1-6-1
1-7 Configuring Power Properties ............................................................ 1-7-1
Auto Power Off ..................................................................................................1-7-1
Configuring Power Properties.............................................................................1-7-1
1-8 Optimizing “Flash ROM” ..................................................................... 1-8-1
1-9 Specifying the Ending Screen Image ................................................. 1-9-1
1-10 Adjusting Touch Panel Alignment ................................................... 1-10-1
1-11 Battery Settings ...................................................................................1-11-1
Chapter 2 Performing Data Communication
2-1 Data Communication Overview .......................................................... 2-1-1
Connectable Devices and Transferable Data.....................................................2-1-1
Select Connection Mode Dialog Box ..................................................................2-1-3
Using the ClassPad Communication Application ...............................................2-1-4
2-2 Connecting the ClassPad to Another Device .................................... 2-2-1
Connecting to Another ClassPad Unit ................................................................2-2-1
Connecting to an EA-200 Data Analyzer............................................................2-2-2
Connecting to a Computer (USB).......................................................................2-2-3
Connecting to a Projector (USB) ........................................................................2-2-4
2-3 Configuring Communication Parameters ........................................... 2-3-1
Wakeup ..............................................................................................................2-3-2
2-4 Transferring Data to Another ClassPad Unit ..................................... 2-4-1
Selecting Data for Transfer.................................................................................2-4-3
Sending a Screenshot of the Current Display Contents .....................................2-4-5
Communication Standby ....................................................................................2-4-6
Interrupting an Ongoing Data Communication Operation ..................................2-4-6
2-5 Transferring Data between ClassPad and a Computer .................... 2-5-1
2-6 VCP and XCP File Operations ............................................................. 2-6-1
2-7 Projecting ClassPad Screen Contents from a Projector .................. 2-7-1
Appendix
1 Resetting and Initializing the ClassPad .............................................. α-1-1
2 Deleting an Application ........................................................................ α-2-1
3 Power Supply ........................................................................................ α-3-1
4 Number of Digits and Precision........................................................... α-4-1
5 Specifications........................................................................................ α-5-1
1
Contents

20110901
Getting Ready
This section contains important information you need to know before
using the ClassPad for the first time.
1-1 Unpacking
1-2 Attaching and Removing the Front Cover
1-3 Using the Stylus
1-4 Replacing Batteries and Setting Up the ClassPad
1-5 Handling Precautions
1-6 Adjusting Display Contrast
1-7 Configuring Power Properties
1-8 Optimizing “Flash ROM”
1-9 Specifying the Ending Screen Image
1-10 Adjusting Touch Panel Alignment
1-11 Battery Settings
Chapter
1

20120301
1-1 Unpacking
When unpacking your ClassPad, check to make sure that all of the items shown here are
included. If anything is missing, contact your original retailer immediately.
ClassPad
Stylus (Inserted in ClassPad.)
CD-ROM
3-pin Cable (SB-62)
Front Cover
(Attached to
ClassPad.)
USB Cable
.
7
4
1
0
23
56
89
=
(
)
,
(–)
xz
^
y
쎹
÷
−
+
EXE
EXP
Keyboard
ON/OFF
Clear
Touch Screen Protector Four AAA-size Batteries LR03
(AM4)
(The protector is already installed
on the touch screen when you
purchase the ClassPad.)
Quick Start Guide
ClassPad website URL
http://edu.casio.com/products/classpad/
Quick Start Guide
ClassPad 330 PLUS
CASIO Education website URL
http://edu.casio.com
E
Access the URL below and register as a user.
http://edu.casio.com/dl/
1-1-1
Unpacking
GY437HardEP03.pdf1 12.3.710:44:21AM

20110901
1-2 Attaching and Removing the Front Cover
uTo remove the front cover
Before using the ClassPad, remove the front cover and attach it to the back.
uTo attach the front cover
When you are not using the ClassPad, attach the front cover to the front.
Important!
• Always attach the front cover to the ClassPad whenever you are not using it. Otherwise,
accidental operation of the touch screen or the okey can cause the power to turn on and
run down the batteries.
1-2-1
Attaching and Removing the Front Cover

20110901
1-3 Using the Stylus
Slide the stylus from the slot provided for it on the ClassPad, and then use it to perform touch
panel operations.
Important!
• Be careful so that you do not misplace or lose the stylus. When you are not using it, always
keep the stylus in the slot provided for it on the ClassPad.
• Be careful so that you do not damage the tip of the stylus. A damaged tip can scratch or
otherwise damage the ClassPad touch panel.
• Use only the supplied stylus or a similar instrument to perform touch panel operations. Never
use a pen, pencil, or other writing instrument.
1-3-1
Using the Stylus

20110901
1-4 Replacing Batteries and Setting Up the
ClassPad
Precautions:
Incorrectly using batteries can cause them to burst or leak, possibly damaging the interior of the
ClassPad. Note the following precautions:
• Use only the batteries that are specifically listed in “Recommended Batteries” (shown below).
Never use any other type of batteries.
• Be sure that the positive (+) and negative (–) poles of each battery are facing in the proper
directions.
• Never mix batteries of different brands or
models.
• When using nickel-metal hydride batteries,
make sure to fully charge the batteries before
use.
• For details about how to charge nickel-metal
hydride batteries, see the user documentation
that comes with the batteries.
• Note that the amount of operation between charges provided by nickel-metal hydride batteries
may be shorter than the life of alkaline batteries.
• Never mix batteries of different types.
• Never mix old batteries and new ones.
• Never leave dead batteries in the battery compartment.
• Remove the batteries if you do not plan to use the ClassPad for long periods.
• Never try to recharge the batteries supplied with the ClassPad.
• Do not expose batteries to direct heat, let them become shorted, or try to take them apart.
• For details about how to use batteries, see the user documentation that comes with the
batteries.
(Should a battery leak, clean out the battery compartment of the ClassPad immediately, taking
care to avoid letting the battery fluid come into direct contact with your skin.)
Keep batteries out of the reach of small children. If swallowed, consult with a physician
immediately.
uRecommended Batteries
AAA-size alkaline batteries:
LR03 (AM4)
AAA-size nickel-metal hydride batteries:
Duracell rechargeable
Energizer rechargeable
SANYO eneloop
1-4-1
Replacing Batteries and Setting Up the ClassPad

20110901
uClassPad Operation
(1) Making sure that you do not accidentally press the okey, attach the front cover to the
ClassPad and then turn the ClassPad over. Remove the battery cover from the ClassPad by
pulling with your finger at the point marked 1.
1
(2) Load the four batteries that come with ClassPad.
• Make sure that the positive (+) and negative (–) ends of
the batteries are facing correctly.
(3) Replace the battery cover, making sure that its tabs enter
the holes marked 2and turn the ClassPad front side up.
(4) Remove the front cover from the ClassPad.
(5) Align the touch panel.
a. Your ClassPad should turn on automatically and display
the Touch Panel Alignment screen.
1-4-2
Replacing Batteries and Setting Up the ClassPad

20110901
b. Tap the center of each of the four cross marks as they appear on the display.
If the Touch Panel Alignment screen does not appear,
use the stylus to press the RESTART button on the
back of the ClassPad.
Important!
• It may take a little time for your ClassPad to start up after
you press the RESTART button.
•
RESTART
Button
(6) Adjust the display contrast.
a. Tap the button to make contrast darker, or the
button to make it lighter.
b. After the contrast setting is the way you want, tap [Set].
Tapping [Initial] on the Contrast dialog box returns contrast to its initial factory default
setting.
•
(7) Specify the display language.
a. On the list that appears, tap the language you want to
use.
You can select German, English, Spanish, French, or
Portuguese.
•
b. When the language you want is selected, tap [Set].
Tapping [Cancel] selects English and advances to the next dialog box.•
1-4-3
Replacing Batteries and Setting Up the ClassPad

20110901
(8) Specify the soft keyboard key arrangement.
a. On the list that appears, tap the key arrangement you
want to use.
b. When the key arrangement you want is selected, tap [Set].
Tapping [Cancel] selects QWERTY arrangement and advances to the next dialog box.•
(9) Specify the battery type.
a. On the list that appears, tap the battery type that
matches the batteries loaded in the ClassPad.
If you are using the batteries that came with the
ClassPad, select “Alkaline batteries”.
•
b. Tap [Set].
This displays the confirmation dialog box.•
c. Tap [OK].
Tapping [Cancel] returns to Battery Settings dialog box.•
1-4-4
Replacing Batteries and Setting Up the ClassPad

20110901
1-5 Handling Precautions
• Your ClassPad is made of precision components. Never try to take it apart.
• Avoid dropping your ClassPad and subjecting it to strong impact.
• Do not store the ClassPad or leave it in areas exposed to high temperatures or humidity, or
large amounts of dust. When exposed to low temperatures, the ClassPad may require more
time to display results and may even fail to operate. Correct operation will resume once the
ClassPad is brought back to normal temperature.
• Your ClassPad supports use of both alkaline batteries and rechargeable nickel-metal hydride
batteries. Note that the amount of operation between charges provided by nickel-metal hydride
batteries is shorter than the life of alkaline batteries. Use only batteries that are specifically
recommended for this ClassPad.
• Replace the batteries once every one year regardless of how much the ClassPad is used during
that period. Never leave dead batteries in the battery compartment. They can leak and damage
the ClassPad. Immediately remove nickel-metal hydride batteries from the ClassPad after their
charge is used up. Leaving uncharged nickel-metal hydride batteries in the ClassPad can cause
them to deteriorate.
• Keep batteries out of the reach of small children. If swallowed, consult a physician immediately.
• Avoid using volatile liquids such as thinners or benzine to clean the ClassPad. Wipe it with a
soft, dry cloth, or with a cloth that has been moistened with a solution of water and a neutral
detergent and wrung out.
• Always be gentle when wiping dust off the display to avoid scratching it.
• In no event will the manufacturer and its suppliers be liable to you or any other person for any
damages, expenses, lost profits, lost savings or any other damages caused by loss of data
and/or formulas arising out of malfunction, repairs, or battery replacement. It is up to you to
prepare physical records of data to protect against such data loss.
• Never dispose of batteries, the liquid crystal panel, or other components by burning them.
• When the “Batteries are extremely low!” message appears on the display, replace the batteries
as soon as possible.
• Be sure to turn off the ClassPad before replacing the batteries.
• If the ClassPad is exposed to a strong electrostatic charge, its memory contents may be
damaged or the keys may stop working. In such a case, perform the reset operation to clear the
memory and restore normal key operation.
• If the ClassPad stops operating correctly for some reason, use the stylus to press the
RESTART button on the back of the ClassPad. Note, however, that this clears all the data in
ClassPad memory.
• Note that strong vibration or impact during program execution can cause execution to stop or
can damage the ClassPad’s memory contents.
• Using the ClassPad near a television or radio can cause interference with TV or radio reception.
• Before assuming malfunction of the ClassPad, be sure to carefully reread this user’s guide to
ensure that the problem is not due to insufficient battery power, programming, or operational
errors.
1-5-1
Handling Precautions

20110901
1-5-2
Handling Precautions
Be sure to keep physical records of all important data!
Low battery power or incorrect replacement of the batteries that power the ClassPad can cause
the data stored in memory to be corrupted or even lost entirely. Stored data can also be affected
by strong electrostatic charge or strong impact. It is up to you to keep back up copies of data to
protect against its loss.
Backing Up Data
ClassPad data can be converted to a VCP file or XCP file and transferred to a computer for
storage. For details, see “2-5 Transferring Data between ClassPad and a Computer” and “2-6 VCP
and XCP File Operations”.
In no event shall CASIO Computer Co., Ltd. be liable to anyone for special, collateral, incidental,
or consequential damages in connection with or arising out of the purchase or use of these
materials. Moreover, CASIO Computer Co., Ltd. shall not be liable for any claim of any kind
whatsoever against the use of these materials by any other party.
• Be sure to keep all user documentation handy for future reference.
• The contents of this user’s guide are subject to change without notice.
• No part of this user’s guide may be reproduced in any form without the express written
consent of the manufacturer.
• The options described in Chapter 2 of this user’s guide may not be available in certain
geographic areas. For full details on availability in your area, contact your nearest CASIO
dealer or distributor.
• Make sure nothing gets between the front cover and the touch screen. Besides creating the
risk of scratching the touch screen, an object coming into contact with the screen can cause the
power to turn on and run down the batteries.
• Always attach the front cover to the ClassPad whenever you are not using it. Otherwise,
accidental operation of the touch screen or the okey can cause the power to turn on and
run down the batteries.

20110901
(3) Adjust display contrast.
To do this: Tap this button:
Make the display lighter
Make the display darker
Return contrast to its initial factory default setting Initial
• Tapping and holding or continually performs the applicable operation until you
release the button.
(4) To close the Contrast dialog box, tap [Set].
1-6 Adjusting Display Contrast
Use the following procedure to display the Contrast dialog box and adjust display contrast.
uClassPad Operation
(1) On the application menu, tap Y.
• This starts up the System application.
(2) Tap
Zto display the Contrast dialog box.
1-6-1
Adjusting Display Contrast

20110901
1-7 Configuring Power Properties
Use the Power Properties dialog box to configure the auto power off (APO) setting.
Auto Power Off
The Auto Power Off (APO) feature helps conserve battery power by turning off the ClassPad
unit automatically whenever you do not perform any operation for specified amount of time.
You can specify 10 or 60 minutes for the Auto Power Off trigger time. The initial default APO
setting is 10 minutes.
Configuring Power Properties
uClassPad Operation
(1) On the application menu, tap Y.
• This starts up the System application.
(2) Tap Xto display the Power Properties dialog box.
(3) Configure the Auto Power Off setting.
(4) After the Auto Power Off setting is the way you want, tap [Set] to apply it and close the
Power Properties dialog box, or tap [Cancel] to close without changing the setting.
1-7-1
Configuring Power Properties

20110901
1-8 Optimizing “Flash ROM”
Use the following procedure to perform a “garbage collection” operation that optimizes
eActivity area and mass storage area (USB Flash Drive). Optimizing Flash ROM increases
the amount of memory available for storage.
uClassPad Operation
(1) On the application menu, tap Y.
• This starts up the System application.
(2) Tap
<.
• This displays a confirmation asking if you really want
to optimize eActivity area and mass storage area.
(3) Tap [Yes] to optimize eActivity area and mass storage area, or [No] to cancel.
• After you tap [Yes], the message “Now Optimizing...” remains displayed while
optimization is in progress. The message “Complete!” appears when optimization is
complete.
(4) Tap [OK] to close the “Complete!” message dialog box.
Tip
• You can interrupt the “garbage collection” operation by tapping on the icon panel.
Important!
• Never press the RESTART button on the back of the ClassPad while a “garbage collection”
operation is in progress. Doing so can damage memory, resulting in loss of all memory
contents and malfunction of your ClassPad. If this happens, you will need to request repair
from your CASIO Maintenance Service Provider. Note that repair of your ClassPad will not
recover any lost memory contents.
1-8-1
Optimizing “Flash ROM”

20110901
1-9 Specifying the Ending Screen Image
Whenever you press the okey to turn off the ClassPad unit, it copies any data currently
in RAM to Flash ROM, and then turns off power. The ending screen is what appears on the
display while the RAM data save operation is being performed, until power is actually turned
off. You can specify the image data you want to appear as the ending screen.
uClassPad Operation
(1) On the application menu, tap Y.
• This starts up the System application.
(2) Tap
Nto display the Ending Screen dialog box.
• To see this icon, you must first tap the right arrow
button on the toolbar to scroll.
(3) Tap the down arrow button. On the list that appears, tap the ending screen image you
want to use.
• To see the list, open the drop down list near the top of the dialog box. The list shows
the images in the file you created with the Presentation application.
• Tapping the [View] button displays a preview of the currently selected screen image.
Tap [OK] to close the preview image and others (see Tip below).
(4) After the image you want is selected, tap [Set] to apply it and close the Ending Screen
dialog box, or tap [Cancel] to close the dialog box without changing the setting.
Tip
• A bitmap you create and save with the Picture application can be used as an ending screen
image. The allowable bitmap size for an ending screen image is 160 × 240 pixels.
• A bitmap of a Graph window can also be created in the Graph & Table and 3D Graph
applications. Draw a graph and then select [Store Picture]from the amenu.
1-9-1
Specifying the Ending Screen Image

20110901
1-10 Adjusting Touch Panel Alignment
You should adjust touch panel alignment whenever you find that the wrong operation or no
operation is performed when you tap the ClassPad screen.
uClassPad Operation
(1) On the application menu, tap Y.
• This starts up the System application.
(2) Tap
Mto display the touch panel alignment screen.
• To see this icon, you must first tap the right arrow
button on the toolbar to scroll.
(3) Use the stylus to tap the center of each of the four crosses as they appear on the
screen.
• When aligning your ClassPad try to tap the exact center of each cross.
1-10-1
Adjusting Touch Panel Alignment

20110901
1-11-1
Battery Settings
1-11 Battery Settings
Use these settings to specify the battery type you will use.
uClassPad Operation
(1) On the application menu, tap Y.
• This starts up the System application.
(2) Tap to display the Battery Settings dialog box.
• To see this icon, you must first tap the right arrow
button on the toolbar to scroll.
(3) Tap the type of battery you loaded and then tap [Set].
• This displays the confirmation dialog box.
(4) Tap [OK].
• This registers the selected battery type and closes the confirmation dialog box.
• If you tap [Cancel] instead of [OK], the confirmation dialog box will close without
registering the selected battery type.

20110901
Performing Data
Communication
You can use the SB-62 data communication cable to connect
your ClassPad to another ClassPad unit or to a CASIO Data
Analyzer, and transfer data between them.
To transfer data between a ClassPad and a personal computer,
you need to use the special USB cable that comes with
ClassPad.
You can also use the USB cable to connect a ClassPad to a
CASIO projector and project its screen contents.
This chapter explains how to perform data communication
operations and exchange data.
2-1 Data Communication Overview
2-2 Connecting the ClassPad to Another Device
2-3 Configuring Communication Parameters
2-4 Transferring Data to Another ClassPad Unit
2-5 Transferring Data between ClassPad and a Computer
2-6 VCP and XCP File Operations
2-7 Projecting ClassPad Screen Contents from a Projector
Chapter 2
