Casio EX-S2/EX-M2 User manual

EX-M2
All the illustrations in this manual show the
EX-M2. See the text that accompanies the
illustrations for information about how the
EX-S2 and EX-M2 differ from each other.
Thank you for purchasing this
CASIO Product. Before using
it, be sure to read the
precautions contained in this
User’s Guide, and keep the
User’s Guide in a safe place
for future reference.
E
Digital Camera
EX-S2/EX-M2
User’s Guide

INTRODUCTION
2
INTRODUCTION
Unpacking
Check to make sure that all of the items shown below are included with your camera. If something is missing, contact your dealer
as soon as possible.
Camera
Strap
LCD Remote Controller
Rechargeable lithium ion
battery (NP-20)
CD-ROM
Stereo Headphones
USB Cradle
Special USB Cable
Basic Reference
Special AC Adaptor
Dummy Card
*Comes with
EX-M2 only
Rechargeable Lithium Ion
Battery User’s Guide
EX-M2
AC power cord *
*The shape of the AC power cord plug varies according to country
or geographic area. The shape of the supplied AC power cord plug
is shown on the package.
Connector Cover
*Loaded in the camera when
you purchase it.
*Attached to the
camera when
you purchase it.
*Comes with
EX-M2 only

INTRODUCTION
3
Contents
2INTRODUCTION
Unpacking .................................................................... 2
Features ....................................................................... 8
Precautions .................................................................. 9
General Precautions 9
Data Error Precautions 11
Operating conditions 11
Condensation 12
LED Backlight 12
Lens 12
Other 13
14 QUICK START GUIDE
Getting Ready ............................................................ 14
Configuring Display Language and Clock Settings... 15
To record an image .................................................... 15
To view a recorded image.......................................... 16
To delete an image..................................................... 16
17 GETTING READY
General Guide ............................................................ 17
Camera 17
USB Cradle 18
Using the Controller ................................................... 19
Monitor Screen Contents ........................................... 20
Indicator Lamps.......................................................... 22
Attaching the Strap .................................................... 22
Power Requirements ................................................. 23
To load the battery 23
To charge the battery 24
Power Supply Precautions 28
Turning the Camera On and Off 29
Auto Power Off (APO) 29
Using the On-screen Menus ...................................... 30
Configuring Display Language and Clock Settings... 32
34 BASIC IMAGE RECORDING
Recording an Image................................................... 34
About the REC Mode Monitor Screen 35
Recording Precautions 35

INTRODUCTION
4
Using Zoom ................................................................ 36
Using the Flash .......................................................... 37
Flash Precautions 38
Using the Self-timer ................................................... 39
Specifying Image Size and Quality............................ 40
To specify the image size 40
To specify the image quality 41
42 OTHER RECORDING FUNCTIONS
Exposure Compensation (EV Shift)........................... 42
Adjusting the White Balance...................................... 43
Adjusting White Balance Manually 44
Using the Best Shot Mode ......................................... 45
Using the Movie Mode ............................................... 46
Recording Audio (EX-M2 Only).................................. 48
Adding Audio to a Snapshot 48
Recording Your Voice 49
REC Mode Camera Settings ..................................... 51
Turning the Monitor Screen On and Off 51
Turning Image Review On and Off 51
Assigning Functions to the Controller 52
Specifying Power On Default Settings 53
54 PLAYBACK
Basic Playback Operation.......................................... 54
Playing an Audio Snapshot (EX-M2 Only) 55
Zooming the Displayed Image ................................... 56
Resizing an Image ..................................................... 57
Playing a Movie .......................................................... 58
Adding Audio to a Snapshot (EX-M2 Only) ............... 59
To re-record audio 60
Playing Back a Voice Recording File (EX-M2 Only) ... 61
62 DELETING FILES
Deleting a Single File ................................................. 62
Deleting All Files ........................................................ 63
64 FILE MANAGEMENT
Folders ....................................................................... 64
Memory Folders and Files 64
Protecting Files .......................................................... 65
To protect a single file 65
To protect all files in memory 66

INTRODUCTION
5
DPOF.......................................................................... 66
To insert the date during printing 67
To configure print settings for a single image 67
To configure print settings for all images 68
PRINT Image Matching II .............................................69
Exif Print ..................................................................... 69
Using the FAVORITE Folder ...................................... 70
To copy a file to the FAVORITE folder 70
To display a file in the FAVORITE folder 71
To delete a file from the FAVORITE folder 71
72 OTHER SETTINGS
Turning the Key Tone On and Off .............................. 72
Specifying an Image for the Startup Screen ............. 72
Changing the Date and Time Setting ........................ 73
Changing the Date Format 74
Changing the Display Language ............................... 74
Formatting Built-in Memory........................................ 75
76 USING A MEMORY CARD
Using a Memory Card ................................................ 77
To insert a memory card into the camera 77
To remove a memory card from the camera 77
Formatting a Memory Card 78
Memory Card Precautions 79
Copying Files ............................................................. 79
To copy all the files in built-in memory
to a memory card 79
To copy a file from a memory card
to built-in memory 80
81 USING THE CAMERA WITH A COMPUTER
Installing the Software from the CD-ROM ................. 81
About the bundled CD-ROM ...................................... 81
Computer System Requirements............................... 82
Installing Software from the CD-ROM in Windows ... 83
Getting Started 83
Selecting a Language 83
Viewing the Contents of the “Read me” File 84
Installing an Application 84
Viewing User Documentation (PDF Files) 85
Exiting the Menu Application 85
Installing Software from the CD-ROM
on a Macintosh........................................................... 85
Installing Software 85
Viewing User Documentation (PDF Files) 88

INTRODUCTION
6
Transferring Files to a Computer ............................... 89
Transferring Files Over a USB Connection 89
Using a Memory Card to Transfer Images
to a Computer 92
Memory Data 93
Memory Directory Structure 94
Image Files Supported by the Camera 95
Built-in Memory and Memory Card Precautions 95
96 PLAYING AN AUDIO FILE (EX-M2 Only)
Transferring Audio Files to the Camera..................... 96
Preparing the Camera for Audio Player Operation ... 97
Using the Camera as an Audio Player ...................... 98
General Guide 98
Basic Remote Controller Operations 100
Specifying the Audio Playback Mode 101
Selecting a Specify Track for Playback 101
Specifying the Track Playback Sequence 102
Disabling Remote Controller Button Operations 104
LCD Remote Control Error Messages..................... 105
Audio Playback Precautions .................................... 105
106 APPENDIX
Menu Reference....................................................... 106
Indicator Lamp Reference ....................................... 107
Camera Indicator Lamps 107
USB Cradle Indicator Lamps 109
Troubleshooting Guide..............................................110
Display Messages 113
Specifications ............................................................114
Main Specifications 114

INTRODUCTION
7
IMPORTANT!
• The contents of this manual are subject to change
without notice.
• CASIO COMPUTER CO., LTD. assumes no responsi-
bility for any damage or loss resulting from the use of
this manual.
• CASIO COMPUTER CO., LTD. assumes no responsi-
bility for any loss or claims by third parties which may
arise through the use of the EX-S2/EX-M2.
• CASIO COMPUTER CO., LTD. shall not be held liable
for any damages or losses suffered by you or any third
party due to the use of Photo Loader and/or
Photohands.
• CASIO COMPUTER CO., LTD. assumes no responsi-
bility for any damage or loss caused by deletion of
data as a result of malfunction, repairs, or battery re-
placement. Be sure to back up all important data on
other media to protect against its loss.
• The SD logo is a registered trademark.
• Windows, Internet Explorer, and DirectX are regis-
tered trademarks of Microsoft Corporation.
• Macintosh is a registered trademark of Apple Com-
puter, Inc.
• MultiMediaCard is a trademark of Infineon Technologies
AG of Germany, and licensed to the MultiMediaCard
Association (MMCA).
• Acrobat and Acrobat Reader are trademarks of Adobe
Systems Incorporated.
• The USB driver (mass storage) uses Phoenix Tech-
nologies Ltd. software.
Compatibility Software Copyright C 1997
Phoenix Technologies Ltd., All Rights Reserved.
• MPEG Layer-3 audio decoding technology licensed
from Fraunhofer IIS and Thomson multimedia.
• Other company, product and service names used
herein may also be trademarks or service marks of
others.
• Photo Loader and Photohands are the property of
CASIO COMPUTER CO., LTD. Except as stipulated
above, all copyrights and other related rights to these
applications revert to CASIO COMPUTER CO., LTD.
■Copyright Restrictions
Except for the purposes of your own personal enjoyment,
unauthorized copying of snapshot files, movie files, audio
files, and music files violates copyright laws and interna-
tional contracts. Distribution to third parties of such files over
the Internet without permission of the copyright holder,
whether for profit or for free, violates copyright laws and in-
ternational contracts.

INTRODUCTION
8
Features
• 2.0 million Effective Pixels
A high-resolution megapixel CCD provides 2.0 million ef-
fective pixels (2.11 million total pixels) for images that print
beautifully.
• Fixed focus lens for quick operation
Fixed focus eliminates the need for lens movement, which
shortens startup time and shooting time.
• 1.6-inch TFT color LCD monitor screen
• 4X digital zoom
• 12MB flash memory
Images can be recorded without using a memory card.
• Support for SD memory cards and MMC (MultiMedia
Cards) for memory expansion
• Easy Charging
Just place the camera onto the USB cradle to charge its
battery.
• Easy Image Transfer
Transfer images to a computer simply by placing the cam-
era onto the USB cradle.
• Best Shot
Simply select the sample scene that matches the type of
image you are trying to record and the camera performs
troublesome setups automatically for beautiful pictures ev-
ery time.
• DCF Data Storage
DCF (Design rule for Camera File system) data storage
protocol provides image inter-compatibility between the
digital camera and printers.
• Digital Print Order Format (DPOF)
Images can be printed easily in the sequence you want
using a DPOF compatible printer. DPOF can also be used
when specifying images and quantities for printing by pro-
fessional print services.
• PRINT Image Matching II Compatible
Images include PRINT Image Matching II data (mode set-
ting and other camera setup information). A printer that
supports PRINT Image Matching II reads this data and ad-
justs the printed image accordingly, so your images come
out just the way you intended when you recorded them.
• Bundled with Photo Loader and Photohands
Your camera comes bundled with the latest version of
Photo Loader, the popular application that automatically
loads images from your camera to your PC. Also included
is Photohands, an application that makes image retouch-
ing quick and easy.

INTRODUCTION
9
*EX-M2 Only
• Snapshot + Audio Mode
Adds audio to a snapshot.
• Movie + Audio Mode
• Voice Recording
Quick and easy recording of voice input.
• After Recording
Adds audio to images after they are recorded.
• Audio Player Capabilities
Use the camera to play back music data from standard
MP3 (MPEG-1 Audio Layer-3) files.
Precautions
General Precautions
Be sure to observe the following important precautions
whenever using the EX-S2/EX-M2.
All references in this manual to “this camera” and “the cam-
era” refer to the CASIO EX-S2/EX-M2 Digital Camera.
• Never try to take pictures or use the built-in display while
operating a motor vehicle or while walking. Doing so cre-
ates the danger of serious accident.
• Never try to open the case of the camera or attempt your
own repairs. High-voltage internal components create the
risk of electric shock when exposed. Always leave mainte-
nance and repair work up to CASIO authorized service
center.
• Never look at the sun or any other bright light through the
camera’s viewfinder. Doing so can damage your eyesight.
• Keep the connector cover and the other small parts and
accessories of this camera out of the reach of small chil-
dren. If swallowed accidentally, contact your physician im-
mediately.
• Never fire the flash in the direction of a person operating a
motor vehicle. Doing so can interfere with the driver’s vi-
sion and create the danger of accident.

INTRODUCTION
10
• Never fire the flash while it is too close to the subject’s
eyes. Intense light from the flash can cause eye damage if
it is fired too close to the eyes, especially with young chil-
dren. When using the flash, the camera should be at least
one meter from the eyes of the subject.
• Keep the camera away from water and other liquids, and
never let it get wet. Moisture creates the danger of fire and
electric shock. Never use the camera outdoors in the rain
or snow, at the seashore or beach, in the bathroom, etc.
• Should foreign matter or water ever get into the camera,
immediately turn power off, unplug the AC adaptor power
cord from the power outlet, and contact your dealer or
nearest CASIO authorized service center. Using the cam-
era under these conditions creates the danger of fire and
electric shock.
• Should you ever notice smoke or a strange odor coming
out of the camera, immediately turn power off and unplug
the AC adaptor power cord from the power outlet. Using
the camera under these conditions creates the danger of
fire and electric shock. After making sure there is no more
smoke coming from the camera, take it to your nearest
CASIO authorized service center for repair. Never attempt
your own maintenance.
• Never use the AC adaptor to power any other device be-
sides this camera. Never use any other AC adaptor be-
sides the one that comes with this camera.
• Never cover the AC adaptor with a quilt, blanket, or other
cover while it is in use, and do not use it near a heater.
• At least once a year, unplug the AC adaptor power cord
from the power outlet and clean the area around the prongs
of the plug. Dust build up around the prongs can create the
danger of fire.
• If the camera’s case should ever become cracked due to
dropping it or otherwise subjecting it to rough treatment,
immediately turn power off, unplug the AC adaptor power
cord from the power outlet, and contact your nearest
CASIO authorized service center.
• Never use the camera inside of an aircraft or in any other
areas where its use is prohibited. Doing so can result in an
accident.
• Physical damage and malfunction of this camera can
cause the data stored in its memory to be deleted. Be sure
to always keep backup copies of data by transferring them
to personal computer memory.
• Never open the battery cover, disconnect the AC adaptor
from the camera or unplug it from the wall socket while re-
cording images. Doing so will not only make storage of the
current image impossible, it can also corrupt other image
data already stored in camera memory.

INTRODUCTION
11
Operating conditions
• This camera is designed for use in temperatures ranging
from 0°C to 40°C.
• Do not use or keep the camera in the following areas.
— In areas subject to direct sunlight
— In areas subject to high humidity or dust
— Near air conditioners, heaters, or other areas subject to
temperature extremes
— Inside of a closed vehicle, especially one parked in the
sun
— In areas subject to strong vibration
Data Error Precautions
• Your digital camera is manufactured using precision digital
components. Any of the following creates the risk of cor-
ruption of data in camera memory.
— Removing the battery while image recording or data
communication is in progress.
— Removing a memory card while image recording is in
progress.
— Removing the battery, removing the memory card, or
placing the camera onto the USB cradle while the op-
eration/flash charge lamp is still flashing after you turn
off the camera.
— Disconnecting the USB cable, removing the camera
from the USB cradle, or disconnecting the AC adaptor
from the USB cradle while a data communication opera-
tion is being performed.
— Using low battery.
— Other abnormal operations.
Any of the above conditions can cause an error message to
appear on the monitor screen (page 113). Follow the instruc-
tions provided by the message to correct the situation.

INTRODUCTION
12
LED Backlight
• The monitor screen is illuminated by an LED backlight. A
dark monitor screen indicates that the LED backlight has
reached the end of its service life, and needs to be re-
placed by a CASIO authorized service center. Note that
you will be charged for LED backlight replacement. The
LED backlight brightness is reduced by half after about
1,000 hours of use.
Lens
• Never apply too much force when cleaning the surface of
the lens. Doing so can scratch the lens surface and cause
malfunction.
• Fingerprints, dust, or any other soiling of the lens can inter-
fere with proper image recording. Never touch the lens with
your fingers. You can remove dust particles from the lens
surface by using a lens blower to blow them off. Next, wipe
the surface of the lens with a soft lens cloth.
Condensation
• When you bring the camera indoors on a cold day or other-
wise expose it to a sudden change of temperature, there is
the possibility that condensation can form on the exterior or
on interior components. Condensation can cause malfunc-
tion of the camera, so you should avoid exposing it to con-
ditions that might cause condensation.
• To keep condensation from forming, place the camera into
a plastic bag before moving it into a location that is much
warmer or colder than your current location. Leave it in the
plastic bag until the air inside the bag has a chance to
reach the same temperature as the new location. If con-
densation does form, remove the battery from the camera
and leave the battery cover open for a few hours.

INTRODUCTION
13
Other
• The camera may become slightly warm during use. This
does not indicate malfunction.

QUICK START GUIDE
14
QUICK START GUIDE
Getting Ready
1
1. Load the battery (page 23).
2
3
2. Place the camera onto the USB cradle to charge the
battery (page 24).
• It takes about two hours to achieve a full charge.
1
2

QUICK START GUIDE
15
1. Press the power button to turn on the camera.
2. Align the mode selector with “REC”.
3. Point the camera at the subject, and use the
monitor screen or viewfinder to compose the
image.
4. Holding the camera still, gently press the shut-
ter release button.
1
4
2
3
To record an image
(See page 34 for details.)
1. Press the power button to turn on the camera.
2. Rock the controller up or down to select the
language you want (page 33).
3. Click the controller to register the language
setting and advance to the clock settings.
4. Set the date and the time (page 33).
5. Click the controller to register the clock set-
tings and exit the setting screen.
1
2, 3, 4, 5
Configuring Display Language and Clock Settings
(See page 32 for details.)

QUICK START GUIDE
16
1. Press the power button to turn on the camera.
2. Align the mode selector with “PLAY”.
3. Rock the controller down to select .
4. Rock the controller left or right to scroll through
images and display the one you want to delete.
5. Rock the controller up or down to select “Delete”.
• To exit the image delete operation without deleting any-
thing, select “Cancel”.
6. Click the controller to delete the selected image.
To delete an image
(See page 62 for details.)
1
3, 4, 5, 6
1. Press the power button to turn on the camera.
2. Align the mode selector with “PLAY”.
3. Rock the controller left (back) or right (for-
ward) to scroll through images on the monitor
screen.
3
1
To view a recorded image
(See page 54 for details.)

GETTING READY
17
GETTING READY
5
6
123
4
■Front
This section contains about things you need to know about and do before trying to use the camera.
General Guide
The following illustrations show the names of each component, button, and switch on the camera.
Camera
1Power button
2Shutter release button
3Flash
4Lens
5Microphone
(EX-M2 only)
6Self-timer lamp
D
9
8
7
0
A
E
C
B
7Operation/Flash charge
lamp
8Viewfinder
9MENU button
0Mode selector
AStrap bar
BBattery cover
CSpeaker (EX-M2 only)
DController
*Rock the controller up,
down, left, or right to select
items. To execute a
function, click by pressing
straight down on the
controller.
EMonitor Screen
■Back

GETTING READY
18
FG
FConnector cover
GMemory card slot
If you are not using a memory card, be sure to insert the
dummy card into this slot to protect against dust and
damage.
■Bottom
H
Be sure to replace the
connector cover whenever
the connector is not being
used.
HConnector
*Connection of an LCD
remote controller is
supported by the EX-M2
only.
USB Cradle
Simply placing your CASIO digital camera onto the USB
cradle lets you perform the following tasks.
• Battery charging (page 24)
• Automatic transfer of images to a computer (page 89)
Removing the Connector Cover
1Camera connector
2USB lamp
3CHARGE lamp
123
4
5
■Back
4USB
(USB port)
5DC IN 5.3V
(AC adaptor connector)
■Front

GETTING READY
19
Using the Controller
The controller is used to select on-screen items and to ex-
ecute functions. The following are the terms used in this
manual to describe controller operations.
Meaning
Use your thumb to push the
controller up, down, left, or right.
Use your thumb to press straight
down on the controller until it clicks.
Term
Rock
Click
Rock Click
• While a menu is on the display, rock the controller to select
a tab or menu item. When the item you want is selected,
click to execute or apply it.
NOTE
• See “Using the Camera as an Audio Player” on page
98 for information about the LCD remote controller
that comes with the EX-M2.

GETTING READY
20
Monitor Screen Contents
The monitor screen uses various indicators and icons to keep you informed of the camera’s status.
■REC Mode
White balance indicator
None Auto
Sunlight
Shade
Light Bulb
Fluorescent
Manual
Quality
FINE
NORMAL
ECONOMY
Battery capacity
Image size
1600 x1200 pixels
1280 x 960 pixels
640 x 480 pixels
Date and time
EV value
Memory capacity
(Remaining number
of storable images)
Flash Mode indicator
None Auto Flash
Flash Off
Flash On
Red-eye reduction
Built-in memory selected
for data storage.
Memory card selected for
data storage.
Digital zoom factor
Self-timer Recording Mode indicator
Snapshot
Best Shot
Movie
Snapshot Audio (EX-M2 only)
Voice Recording (EX-M2 only)
NOTE
• You can turn
display of monitor
screen information
on and off. See
“Turning the Monitor
Screen On and Off”
on page 51 for more
information.
