Casio QV-300 User manual

Liquid Crystal Digital Camera
QV-300
Owner's Manual
英
If you need help
with your camera,
please call:
1 800)435-7732
2
Introduction
Congratulations upon your selection of the QV-300 Liquid Crystal
Digital Camera. The QV-300 comes ith its o n built-in liquid crystal
color monitor that let’s you instantly vie the pictures you take.
To get the most out of the QV-300, be sure to carefully read this
manual and follo the instructions contained in it.
3
Contents
Precautions ..........................................................5
Unpacking.............................................................9
General Guide ....................................................10
Top and Display .................................................................. 10
Lens .................................................................................... 10
Bottom ................................................................................ 11
Terminals ............................................................................ 11
Power Supply ..................................................... 13
To load batteries ................................................................. 13
Using AC Po er ................................................................. 17
Recording Images .............................................. 19
To record an image............................................................. 19
Ho to avoid hand movement…......................................... 21
Fluorescent Lighting ........................................................... 21
Infrared Light....................................................................... 22
Shooting Images Outdoors ................................................. 22
Changing the Lens Orientation ........................................... 22
NORMAL/MACRO S itch .................................................. 24
S itching Bet een Lenses ................................................. 24
Resolution Modes ............................................................... 25
Exposure Adjustment.......................................................... 25
Changing the Aperture Setting ........................................... 27
Record Mode Displays........................................................ 27
Using the Self-Timer ........................................................... 30
Playing Back Images ......................................... 31
Displaying Images on the Camera’s LCD ........................... 31
Displaying Images on a TV Screen .................................... 32
Page Status Indicators........................................................ 33
Producing a Multi-Page Display.......................................... 34
4
Using the Zoom Function.................................................... 36
Using Auto Play .................................................................. 38
Protecting Memory Pages .................................................. 41
Unprotecting Memory Pages .............................................. 43
Hiding Protected Memory Pages ........................................ 45
Deleting Memory Pages ....................................46
Deleting Images From Memory .......................................... 46
Resolution Conversion......................................50
Connecting to Other Devices............................51
The camera terminals ......................................................... 51
Using the Camera with a Connected Device ...52
Troubleshooting.................................................59
Specifications.....................................................65
About the camera’s backlight… ....................... 66
• CASIO COMPUTER CO., LTD. assumes no responsibility for any
damage or loss resulting from the use of this manual.
• CASIO COMPUTER CO., LTD. assumes no responsibility for any
loss or claims by third parties hich may arise through the use of
the QV-300.
• CASIO COMPUTER CO., LTD. assumes no responsibility for any
damage or loss caused by deletion of data as a result of malfunc-
tion, repairs, or battery replacement. Be sure to back up all impor-
tant data on other media to protect against its loss.

5
General Precautions
Be sure to observe the follo ing important precautions henever us-
ing the QV-300.
All references in this manual to “this camera” and “the camera” refer
to the CASIO QV-300 Digital Camera.
• Never try to take pictures or use the built-in display hile operating
a motor vehicle or hile alking. Doing so creates the danger of
serious accident.
• Never try to open the case of the camera or attempt your o n re-
pairs. High-voltage internal components create the risk of electrical
shock hen exposed. Al ays leave maintenance and repair ork
up to authorized CASIO service providers.
• Keep the camera a ay from ater and other liquids, and never let it
get et. Moisture creates the danger of fire and electrical shock.
Never use the camera outdoors in the rain or sno , at the seashore
or beach, in the bathroom, etc.
• Should foreign matter or ater ever get into the unit, immediately
turn po er off, unplug the AC adaptor from the po er outlet, and
contact your dealer or nearest CASIO service provider. Using the
unit under these conditions creates the danger of fire and electrical
shock.
• Should you ever notice smoke or a strange odor coming out of the
unit, immediately turn po er off and unplug the AC adaptor from the
po er outlet. Using the unit under these conditions creates the dan-
ger of fire and electrical shock. After making sure there is no more
smoke coming from the unit, take it to your nearest CASIO service
provider for repair. Never attempt your o n maintenance.
• If the unit’s case should ever become cracked due to dropping it or
other ise subjecting it to rough treatment, immediately turn po er
off, unplug the AC adaptor from the po er outlet, and contact your
nearest CASIO service provider.
Precautions Liquid Crystal Digital Camera
6
• Never use the unit inside of an air craft or in any other areas here
its use is prohibited. Doing so can result in an accident.
• Physical damage and malfunction of this unit can cause the image
data stored in its memory to be deleted. Be sure to al ays keep
backup copies of data by transferring them to personal computer
memory.
• Never open the battery compartment cover, disconnect the AC
adaptor from the camera or unplug it from the all socket hile the
“WAIT” message is on the LCD. Doing so ill not only make storage
of the current image impossible, it can also corrupt other image data
already stored in camera memory.
MEMORY ERROR message
Any of the follo ing can cause data stored in the camera’s memory to
become corrupted.
• Removal of batteries or disconnection of the AC adaptor during a
record or data communication operation
• Disconnection of the connecting cable during data communication
• Continued use hile battery po er is lo
• Other incorrect operation
In each of the above cases, one of the memory error messages
(MEMORY ERROR #1 ~ MEMORY ERROR #4) appears, and further
operation of the camera ill become impossible. If this should
happen, contact your dealer or the nearest CASIO service provider
as soon as possible.
7
Operating conditions
• This camera is designed for use in temperatures ranging from 0°C
to 40°C (32°F to 104°F).
• Do not use or keep the camera in the follo ing areas.
— In areas subject to direct sunlight
— In areas subject to high humidity or dust
— Near air conditioners, heaters, or other areas subject to tem-
perature extremes
— Inside of a closed vehicle, especially one parked in the sun
— In areas subject to strong vibration
Condensation
• When you bring the camera indoors on a cold day or other ise ex-
pose it to a sudden change of temperature, there is the possibility
that condensation can form on the exterior or on interior compo-
nents. Condensation can cause malfunction of the camera, so you
should avoid exposing it to conditions that might cause condensa-
tion.
• To keep condensation from forming, place the camera into a plastic
bag before moving it into a location that is much armer or colder
than your current location. Leave it in the plastic bag until the air
inside the bag has a chance to reach the same temperature as the
ne location. If condensation does form, remove the batteries from
the camera and leave the battery compartment cover open for a fe
hours.
Precautions Liquid Crystal Digital Camera
8
NOTICE
This equipment has been tested and found to comply ith the lim-
its for a Class B peripheral, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency en-
ergy and, if not installed and used in accordance ith the instruc-
tions, may cause harmful interference to radio communications.
Ho ever, there is no guarantee that interference ill not occur in a
particular installation. If this equipment does cause harmful inter-
ference to radio or television reception, hich can be determined
by turning the equipment off and on, the user is encouraged to try
to correct the interference by one or more of the follo ing meas-
ures:
• Reorient or relocate the receiving antenna.
• Increase the separation bet een the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from
that to hich the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for
help.
GUIDELINES LAID DOWN BY FCC RULES FOR USE OF
THIS UNIT IN THE U.S.A. not applicable to other areas).
FCC WARNING
Changes or modifications not expressly approved by the party re-
sponsible for compliance could void the user's authority to operate
the equipment.
Properly shielded cables ith ferrite core must be used for con-
nection to host computer and/or peripherals in order to meet FCC
emission limits.
THE SPECIAL VIDEO CABLE THAT COMES WITH THE CAMERA ----- THE CAMERA TO A VIDEO IN TERMINAL OF A COMPUTER
THE SPECIAL CONNECTION CABLE THAT COMES WITH QV-Link SOFTWARE ----- THE CAMERA TO A PROPER TERMINAL OF A COMPUTER

9
Unpacking
Check to make sure that all of the items sho n belo are included
ith your camera. If something is missing, contact your dealer as
soon as possible.
Soft case
Alkaline batteries (AA-size × 4)
Camera
Cleaning Cloth
Wrist Strap
Manual
Video cable
Getting Acquainted
10
General Guide
The follo ing illustrations sho the names of each component, but-
ton and s itch on the camera.
Top and Display
Lens
Lens
TELE(telephoto)/
WIDE(Wide-angle) s itch
LCD [–] (Reverse)
button
POWER s itch Function s itch
Aperture
s itch
[+] (For ard)
button
Shutter button
DEL (Delete) button
MODE button
EFFECT button DISP (Display)
button
NORMAL/
MACRO
s itch
/PROTECT
(Timer/Protect)
button
11
Important!
Make sure that the terminal panel cover is slid fully a ay as sho n in
step 2 above before trying to raise it. Forcing the cover up can seri-
ously damage it.
General Guide
Bottom
BRIGHT (brightness) control
• BRIGHT control adjusts the brightness of the image on the LCD.
The brightness is set at the factory to the optimum setting, and nor-
mally does not need adjustment.
Battery
compartment
lock
Battery compartment cover
Tripod
hole
Terminals
AC Po er terminal
VIDEO OUT terminal
DIGITAL
terminal
Terminal panel cover
Opening the Terminal Panel Cover
11
11
122
22
233
33
3
Getting Acquainted
12
Connecting the Wrist Strap
Pass the rist strap through the hole on
the side of the camera as sho n in the
illustration.
Using the Cleaning Cloth
Use the cleaning cloth to ipe finger-
prints and smudges from the LCD and
lens.
• Be sure to avoid applying too much
pressure hen iping the LCD. Too
much pressure can cause permanent
discoloration, abnormal images, and
cracks.
Using the Soft Case
Keep the camera in its soft case to pro-
tect it hen not in use.
22
22
2
11
11
1

13
The camera features a t o- ay po er supply that lets you use either
batteries (AA-size Alkaline or Lithium) or household AC current.
To load batteries
Be sure that camera po er is turned off henever loading or replac-
ing batteries.
1. Slide the battery compartment
lock on the bottom of the camera
in the direction indicated by arrow
11
11
1, and swing open the battery
compartment cover as indicated
by arrow 22
22
2.
2. Insert four batteries and close the
battery compartment cover.
2
1
Power Supply
A
Be sure to use Alkaline or Lithium batteries. Never use
manganese batteries (see precautions on the next page).
• Make sure that the positive + and negative - ends of the
batteries are facing correctly.
• Press do n on the battery compartment cover at the point
marked A in the above illustration until the cover locks into
place ith a click.
Getting Acquainted
14
Battery Handling Precautions
Incorrect use or handling of batteries can cause them to leak or burst
and seriously damage your camera. Be sure to note the follo ing
important precautions to avoid problems ith batteries.
• Use only LR6 (AM-3) type alkaline or
FR6 type lithium dry cell batteries
ith this camera. Never mix old bat-
teries ith ne ones. Failure to do so
can result in bursting or leaking of
batteries, creating the danger of fire
or personal injury.
• Al ays make sure that the positive
[+] and negative [–] ends of the bat-
teries are facing correctly, as noted
by the markings on the camera itself.
Improper loading of batteries can re-
sult in bursting or leaking of batteries,
creating the danger of personal injury
or soiling of objects nearby.
Caution
• Remove batteries from the camera if you do not plan to use it for
more than t o eeks.
• Never recharge batteries, never allo direct connection bet een
t o ends of a battery, and never try to take batteries apart.
• Do not expose batteries to direct heat or dispose of them by burn-
ing. Doing so can create the danger of explosion.
• Never mix batteries of different types.
15
Po er Supply
• Dead batteries are susceptible to leakage, hich can cause serious
damage to your camera. Remove batteries from the camera as
soon as you notice they are dead.
• The batteries that po er this camera normally become arm hen
they lose po er. This does not indicate malfunction.
Standard Battery Life
The battery life reference values given belo indicate the amount of
time at standard temperature (25°C) until po er automatically turns
off due to battery failure. They do not guarantee that batteries ill
perform the amount of service indicated. Battery life is reduced by lo
temperatures and continued use.
LR6 (AM3) AA-size alkaline batteries
Approximately 130 minutes continuous operation
Recording for about 96 images (one image per minute)
FR6 AA-size lithium batteries
Approximately 220 minutes continuous operation
Recording for about 180 images (one image per minute)
Low Battery Indicator
The lo battery indicator ( ) appears in the center of the LCD
henever remaining battery po er drops belo a certain level. It tells
you that po er ill soon turn off automatically if you continue using
the camera ithout replacing batteries. Be sure to replace all four
batteries ith a fresh set of ne ones.
Getting Acquainted
16
Flash Memory
The camera features flash memory for storage of images. Flash
memory does not require electrical po er to store data, so image
data is retained in memory even hen you turn camera po er off. If
batteries go dead, simply load a set of ne batteries or connect the
AC adaptor and you ill be able to vie images in camera memory.
Auto Power Off
Po er automatically turns off henever you do not perform any cam-
era operation for a period of time. Po er turns off after about t o
minutes in the Record Mode or after about five minutes in the Play-
back Mode.
• To restore po er, simply slide the POWER s itch to the right as
you normally do.
Important!
The Auto Po er Off function does not operate under the follo ing
conditions.
• During Auto Play (page 38)
• When operations are being performed on a computer connected to
the camera via the camera’s DIGITAL terminal.
• Whenever the AC adaptor is connected to the camera.

17
Using AC Power
To po er the camera from standard AC po er, use the optional AC
adaptor (AD-C60).
AC Adaptor precautions
• Never use an electrical outlet hose
voltage is outside the rating marked
on the camera. Doing so can create
the danger of fire or electrical shock.
Use only the optional AC adaptor
specified for this camera.
• Should the cord of the AC adaptor
become damaged (exposed internal
iring or shorts), request a replace-
ment from an authorized CASIO
service provider. A damaged AC
adaptor cord creates the danger of
fire or electrical shock.
Caution
AC outlet
AC adaptor
Po er Supply
AC po er terminal
Getting Acquainted
18
• Al ays be sure to use the AD-C60
AC adaptor only. Using any other AC
adaptor can cause damage to the
camera not covered by the arranty.
• When unplugging the AC adaptor
from the all socket, be sure to
grasp the adaptor (not the cord).
• Avoid an undue bending, pulling,
and t isting of the AC adaptor's
cord, and never try to lengthen the
cord by splicing it ith other ire.
• Be sure to s itch po er off before connecting or disconnecting the
adaptor.
• Al ays turn camera po er off before disconnecting the AC adaptor,
even if the camera has batteries installed. If you don't, the camera
ill turn off automatically hen you disconnect the AC adaptor.
Even so, you run the risk of damaging the camera henever you
disconnect the AC adaptor ithout first turning po er off.
• The AC adaptor may become arm to the touch after extended pe-
riods of use. This is normal and is not cause for alarm.
• After use turn off the po er s itch of the camera and unplug adap-
tor from the AC outlet.
Caution
19
Recording Images
Recording Images
The follo ing procedure provides the basic steps for recording an
image.
To record an image
1. Enter the Record Mode.
• Slide the function s itch to the
REC position.
2. Turn on the camera.
• Slide the POWER s itch in the di-
rection indicated by the arro .
• The POWER s itch automatically
slides back to its original position
hen you release it.
• When po er comes on, the image of the object that is in
front of the camera’s lens appears on the LCD.
• You can perform steps 1 and 2 in either order (1 then 2, or 2
then 1).
3. Set the NORMAL/MACRO switch to the NORMAL position.
• If the object hose image you are
recording is about 10 centimeters
from the lens (about 4 inches), set
the TELE/WIDE s itch to WIDE
and the NORMAL/MACRO s itch
to MACRO. See page 24 for
details on using this s itch.
Note
• The camera is designed to refresh the image on the LCD about
seven times per second. Because of this, you may experience a
feeling of jerkiness in the changing image if you move the camera
quickly. This is normal and does not indicate malfunction.
MACRO NORMAL
REC
PLAY
Operation
20
4. Use MODE to enter the resolution mode FINE or NORMAL)
you want.
• Each press of MODE toggles bet een the Normal Mode
and Fine Mode.
• Note that the number of images that can be stored in
memory is different depending on hether images are
saved in the Normal Mode or Fine Mode. See “Resolution
Modes” on page 25 for details.
5. Record the image.
• Compose the image you ant to
record hile vie ing it on the
LCD.
• It is best to look at the LCD di-
rectly, and not from an angle.
• Take care that your finger is not
blocking the lens.
• Should the lens become dirty, use
the cloth that comes ith the cam-
era to clean it off.
• When the image is situated on the LCD as you ant it, press
the shutter button.
• Press the shutter button lightly to avoid moving the camera.
See page 21 for information on ho to avoid hand move-
ment.
• The message “WAIT” appears on the LCD for about six sec-
onds along ith the image that as recorded hen you
pressed the shutter button. You can use the camera to take
the next picture after the “WAIT” message disappears.
• Here you could change the function s itch to the PLAY posi-
tion and vie the image you just recorded.
MACRO NORMAL
REC
PLAY

21
Recording Images
Caution
• Never open the battery compartment cover, disconnect the
AC adaptor from the camera or unplug it from the all
socket hile the “WAIT” message is on the LCD. Doing so
ill not only make storage of the current image impossible, it
can also corrupt other image data already stored in camera
memory.
How to avoid hand movement…
Any hand movement hen you press the shutter button can causes
blurring of the recorded image. Note the follo ing points on avoiding
hand movement.
• Make sure there is no excessive movement of the image of the ob-
ject on the LCD.
• Use a tripod henever possible hen recording images in dim light-
ing. The camera automatically adjusts shutter speed in accordance
ith the brightness of the object hose image is being recorded.
Shutter speed is quite slo for dimly lit objects, increasing the pos-
sibility of blurring caused by hand movement.
Fluorescent Lighting
Fluorescent lighting actually flickers at a frequency that cannot be
detected by the human eye. When using the camera indoors under
such lighting, you may experience some brightness or color problems
ith recorded images. The actual extent of the problems depends on
hat cycle of the fluorescent light’s flicker is occurring hen the cam-
era’s shutter actually releases. For best results, use a commercially
available video lights.
Operation
22
Infrared Light
Infrared light generated by a flash or other source can create image
color problems, such as red areas being recorded as green. Such
color problems ill sho up in the LCD hile you are composing the
image.
Shooting Images Outdoors
Strong direct or reflected sunlight can cause recorded images to take
on a greenish tinge. This is due to the characteristics of the camera’s
charge-coupled device (CCD), and it does not indicate malfunction of
the camera. One ay you can try to minimize this problem is to set
the aperture to [●] (F8).
Changing the Lens Orientation
The lens of the camera is built into a lens body that is designed to
rotate. This means you can change the angle of the lens ithout mov-
ing the rest of the camera.
Rotates up to 90 °
to ards the front Rotates up to 180
°
to ards the back
23
Recording Images
• Any images recorded hile the lens body is rotated so the lens is
pointed from the back of the camera are stored as mirror images of
the image that appears in the LCD before the shutter button is
pressed.
AA
AA
A
BB
BB
B
Important!
• Do not apply excessive force hen rotating the lens body. Doing so
can cause serious damage to the lens.
• Do not carry the camera or move it around hile holding onto only
the lens body.
• Return the lens body to its normal position ( ith the lens pointing
from the front of the camera) before storing the camera.
AA
AA
ALCD when shutter button is
pressed in the Record Mode)
BB
BB
BLCD when image is played
back from camera memory
.......
.......
Operation
24
NORMAL/MACRO Switch
The NORMAL/MACRO s itch tells the
camera ho much distance there ill be
bet een the lens and the object hose
image you are recording. The follo ing
table describes the conditions covered by
each s itch setting.
Switching Between Lenses
This camera gives you a choice bet een
telephoto (TELE) and ide-angle (WIDE)
lenses. The follo ing sho s the optimum
distances at hich you should use each of
these lenses.
MACRO NORMAL
TELE
WIDE
Distances
* See page 27 for information on changing the aperture.
Lens Aperture Normal Macro
(NORMAL) (MACRO)
Wide Angle (WIDE) F2.6(○) 0.6m ~ ∞9cm ~ 11cm
f = 4.9mm (2' ~ ∞) (3.5" ~ 4.3")
F8 (●) 0.3m ~ ∞7cm ~ 14cm
(1' ~ ∞) (2.8" ~ 5.5")
Telephoto (TELE) F2.6(○) 3.4m ~ ∞52cm ~ 62cm
f = 11.0mm (11.2' ~ ∞) (1.7' ~ 2')
F8 (●) 1.7m ~ ∞44cm ~ 77cm
(5.6' ~ ∞) (1.4' ~ 2.5')

25
Recording Images
Resolution
Mode
FINE
NORMAL
Indicator Number of Images
64 (approximately 480-kbit com-
pressed)
192 (approximately 160-kbit com-
pressed)
• You can s itch bet een resolution modes at any time before re-
cording an image.
Exposure Adjustment
This camera features an automatic exposure (AE) function that auto-
matically changes the shutter speed in accordance ith lighting. In
addition, you can also manually adjust the exposure to compensate
for backlighting, indirect indoor lighting, dark backgrounds, and other
special conditions.
To manually adjust the exposure
1. Enter the Record Mode.
• Set the function s itch to the REC position.
Resolution Modes
In addition to a Normal Mode, this camera also has a Fine Mode for
saving images using higher resolution. Use the MODE button to
s itch bet een the Normal Mode and Fine Mode.
The follo ing table sho s ho many images can be stored in
memory using each resolution mode.
Operation
26
2. Use the [+] and [–] buttons to manually adjust the exposure.
• Pressing [+] makes the image on the LCD brighter. Use it to
adjust for dim indoor lighting and backlighting.
• Pressing [–] makes the image on the LCD darker. Use it to
adjust for bright sunlight.
3. After adjusting the exposure, press the shutter button to
record the image.
Notes
• Exposure adjustment is generally expressed in terms of an expo-
sure adjustment value. The exposure adjustment value is al ays
set to zero henever you turn on the camera.
• The exposure adjustment value is changed by 0.25 ith each press
of [+] or [–]. The range of the value is -2 to +2.
• The exposure adjustment value automatically reverts to zero hen-
ever the shutter button is pressed. You can manually reset the ex-
posure adjustment value by using [+] and [–] to change the value
back to zero, hich is indicated hen the +/– indicator disappears
from the monitor.
[+]
[–]
+ –
+ –
27
Recording Images
Changing the Aperture Setting
There are t o aperture settings you can use to match lighting condi-
tions. Use the aperture s itch to change the aperture setting.
• Use the [●] (F8) setting to decrease expo-
sure. This setting orks best outdoors.
• Use the [○] (F2.6) setting to increase ex-
posure. This setting orks best indoor and
ith back lit images.
Note
• Also see page 28 for information about exposure arning indica-
tors.
Record Mode Displays
The follo ing provides details on the images, indicators and mes-
sages that appear on the LCD in the Record Mode.
Image Display
An image of the object that is picked up by the camera’s lens appears
on the LCD. The camera is designed to refresh the image on the LCD
about seven times per second. Because of this, you may experience
a feeling of jerkiness in the changing image if you move the camera
quickly. This is normal and does not indicate malfunction.
Note
• The LCD image that appears in the Playback Mode is more detailed
than the image produced in the Record Mode. Because of this, you
should consider the Record Mode image to be a reasonable fac-
simile of the image that is actually stored in memory.
MACRO NORMAL
Operation
28
Remaining Pages/Resolution Mode Indicator
Pressing DISP in the Record Mode displays a value that sho s ho
many memory pages are available for recording images, along ith
the current resolution mode setting (FINE or NORMAL).
1. Enter the Record Mode.
• Set the function s itch to the REC position.
2. Press the DISP button.
• Press DISP again to clear the
number of remaining pages
and the resolution mode indica-
tor from the monitor screen.
Note
• The display/non-display status of the number of remaining pages
and the resolution mode indicator is linked to the page status
indicators(page 33) and the zoom indicator(page 36).
Exposure Warning Indicators
Exposure arning indicators appear on the LCD henever the light
being picked up by the lens ould result in under exposure or over
exposure of an image.
○......Under exposure
● ......Over exposure
Use the procedure described on page 27 to change the aperture or
change the lighting of the image so the indicator disappears from the
LCD.
remaining pages
resolution mode

29
Recording Images
Important!
• The exposure arning indicators also appear hen lighting is out-
side the range of the camera. In such a case, changing the aperture
ill not clear the indicator from the LCD.
• The manual exposure adjustment procedure (page 25) cannot be
used hen an exposure arning indicator is on the LCD. Clear the
arning indicator by changing the aperture s itch setting.
• Pressing the [+] or [–] button to adjust exposure hile an exposure
arning indicator is on the LCD causes a +/– exposure value to
appear. This is an EV value.
Low Battery Indicator
The lo battery indicator ( ) appears in the center of the LCD
henever remaining battery po er drops belo a certain level. It tells
you that po er ill soon turn off automatically if you continue using
the camera ithout replacing batteries. Be sure to replace all four
batteries ith a fresh set of ne ones.
Note that the camera is designed to automatically turn off po er
earlier hen a personal computer or other equipment is connected to
the camera’s DIGITAL terminal for data communications, in order to
protect against problems due to data corruption. Because of this, it is
recommended that your use the camera’s optional AC adaptor
henever performing data communications.
• See page 13 for details on ho to replace batteries.
Memory Full Message
If you are recording images in the Fine Mode and there is not enough
memory for further Fine Mode recording, the message “REMAIN”
appears on the monitor screen along ith a value that sho s ho
many images can still be recorded in the Normal Mode. You can
press MODE at this time to change to the Normal Mode and record
more image if you ant.
The message “MEMORY FULL” means that there is not enough
memory for further recording in any mode. In this case, you have to use
the follo ing procedures make room in memory for further recording.
• Delete some images from memory (page 46)
• Change the resolution of some of the stored images from FINE to
NORMAL (page 50)
Operation
30
Using the Self-Timer
With the Self-Timer, the shutter is released 10 seconds after you
press the /PROTECT button.
1. Enter the Record Mode.
• Set the function s itch to the REC position.
2. Start the Self-Timer operation.
• Place the camera securely on a tripod, desk or other stable
surface, ith the image to be recorded in the LCD.
• After composing the image, press the /PROTECT but-
ton.
• A 10-second countdo n starts on the LCD. The shutter ill
release automatically hen the end of the countdo n is
reached.
• To cancel on ongoing Self-Timer operation, press the /
PROTECT button or shutter button.
Note
• If you use the Self-Timer ith the lens body rotate 180° (page 22),
you can vie the countdo n on the LCD hile aiting for the shut-
ter to release.
Important!
• If battery po er is lo , camera po er may turn off hile a count-
do n is in progress. If this happens, replace the batteries ith ne
ones.
31
Playing Back Images
Playing Back Images
This section describes ho to recall and vie images stored in cam-
era memory.
Displaying Images on the Camera’s LCD
Camera memory is divided into “pages”, and each image is assigned
to page that is numbered sequentially from 1 through 192 (NORMAL
resolution images). Note that all 192 pages are available only if all
images are recorded using the NORMAL Mode (page 25).
The follo ing procedure describes ho to display images on the
camera’s built-in LCD.
1. Enter the Playback Mode and turn on the camera.
• Slide the function s itch to the
PLAY position.
• When po er comes on, the page
that as displayed hen you last
turned po er off appears on the
LCD.
2. Scroll through the memory pages until the image you want
to view is displayed.
• Press [+] to display the next memory page or [–] to display
the previous memory page.
• To jump to the first (lo est numbered) image in memory,
press the shutter button and [–] button at the same time.
• Holding do n [+] or [–] for about t o seconds starts high-
speed scrolling of images.
REC
PLAY
[–]
[+]
[–]
[+]
Operation
32
Notes
• If you set the function s itch to PLAY after recording an image, that
image appears on the LCD first.
• The message “MEMORY EMPTY” appears on the LCD if there are
no images stored in memory hen you enter the Playback Mode.
Displaying Images on a TV Screen
Use the special video cable that comes ith the camera to connect it
to a television as illustrated belo , and you can then vie the images
stored in camera memory on the TV’s screen.
Important!
• The camera can be connected only to a TV that is equipped ith a
VIDEO IN terminal.
• Make sure that the po er of both the camera and the TV are turned
off hen making connections.
• The signal output through this camera's VIDEO OUT terminal is an
NTSC signal. An image output through this terminal ill not look
normal if the camera is connected to a PAL or other type of TV or
video deck.
INPUT
VIDEO
LR
AUDIO
VIDEO IN terminal
TV Accessory video cable VIDEO OUT terminal
After connecting the camera and TV, set the channel of the TV to the
channel used for video input.
After connecting the camera and TV, use the same procedures as
those described under “Displaying Images on the Camera’s LCD” on
page 31.

33
Playing Back Images
Important!
• Note that only images already stored in camera memory can be
vie ed on the TV screen. If you change to the camera’s Record
Mode, the image picked up by the camera’s lens ill not appear on
the TV screen.
Page Status Indicators
Pressing DISP in the Playback Mode causes page status indicators
to appear on the monitor display indicating page number, protect sta-
tus, and resolution mode.
1. Enter the Playback Mode.
• Set the function s itch to the PLAY position.
2. Press the DISP button.
• The page number and resolution
mode are sho n at the top of the
screen. If the page is protected
(page 41), a protect indicator ( )
is sho n in the upper left corner.
• Press DISP again to clear the
page status indicators from the
screen.
Note
• The display/non-display status of the page status indicators is
linked to the remaining pages and resolution mode indicator (page
28) and to the zoom area indicator (page 36).
resolution mode
page number
Operation
34
Producing a Multi-Page Display
Four or nine memory pages can be displayed at the same time. This
feature can be used to display multiple memory pages on the cam-
era's built-in LCD, or on the screen of a connected TV.
Multi-Page Display EFFECT Menu)
1. Enter the Playback Mode.
• Slide the function s itch to the PLAY position.
2. Display the EFFECT Menu.
• Press the EFFECT button to dis-
play the EFFECT Menu.
• At this time either a 4-page or a 9-
page display format appears.
• Note that you cannot use the
multi-page display hile protected
memory pages are hidden (page
45).
3. Specify the screen size.
• Use the [+] and [–] buttons to specify the screen size.
• To clear the selection screen and quit this procedure, select
the EXIT icon.
4. Press the shutter button.
35
Playing Back Images
12
34
56
78
910
11
[+]
[–]
[+]
[–]
5. Scroll through the images.
• Use the [+] and [–] buttons to scroll images for ard and
back. Each press sho s a ne screen of four or nine ne
images.
Unused pages are colored gray.
• To clear the multi-page display and return to the normal sin-
gle-page display, press any button besides [+] or [–].
Selecting a Memory Page in a Multi-Page Display
You can use the follo ing procedure to select one of the memory
pages in a multi-page display. Then hen you return to the 1-page
display, the memory page you selected ill be the one displayed. The
follo ing procedure uses the 4-page display as an example, but you
can use the same procedure ith the 9-page display.
1. While a multi-page display either 4-page or 9-page) is on
the screen, press the DISP button.
• This causes the image in the up-
per left to be surrounded by a
frame.
In this example, e ill select this page.
Operation
36
2. Move the frame to the image you want to select.
• Use the [+] and [–] buttons to move the frame around the
screen.
3. Press the shutter button.
• The selected image (the one ith
the frame around it) appears on a
single-page display.
Using the Zoom Function
This function lets you select a specific part of a stored image and
enlarge it to t ice its normal size.
1. Enter the Playback Mode.
• Slide the function s itch to the PLAY position.
2. Display the EFFECT Menu.
• Press the EFFECT button to dis-
play the EFFECT Menu.
3. Select image enlargement.
• Use [+] and [–] to select “ZOOM”.
• To clear the selection screen and quit this procedure, select
the EXIT icon.

37
Playing Back Images
[+] [+] [+]
[+] [+] [+]
[+] [+] [+]
4. Press the shutter button.
• At this time the image is doubled in size. The portion that
appears on the screen is the center of the image.
5. Scroll the image on the screen.
• Use [+] and [–] to scroll as sho n in the illustration belo .
6. To clear the zoomed display and return to the normal size
display, press any button besides [+], [–], or DISP.
Changing the Location of the Zoom Area
• Pressing [–] moves the zoom area in the opposite direction.
Operation
38
Notes
• If the page number is displayed in the upper right corner of the
screen hen you perform a zoom operation, the number is replaced
by a zoom area indicator ( ). This indicator sho s you hat part
of the image is currently enlarged on the display. You can turn the
zoom area indicator on and off by pressing the DISP button.
• Note that turning display of the zoom area indicator on and off dur-
ing a zoom operation also affects the display of the image number
in the Record Mode (page 27), and the memory page number in the
Playback Mode (page 33).
Using Auto Play
Auto play lets you automatically scroll through the camera’s memory
pages quickly and easily. You can specify the speed of the scroll.
Important!
• The camera’s Auto Po er Off function (page 16) does not function
hile an auto play operation is in progress. If you forget to turn the
camera off, there is the danger that auto play ill continue until bat-
teries are dead. To avoid this, make sure that you stop the auto play
operation and turn the camera off hen you finish vie ing.
To start the auto play operation
1. Enter the Playback Mode and turn on the camera.
2. Start the auto play operation.
• Hold do n the [+] and [–] buttons until the message “AUTO
PLAY START” appears.
39
Playing Back Images
• Auto play continues to loop through the memory pages. This
means that hen it reaches the last page, it starts again
from the first page.
3. Press the shutter button to stop the auto play operation.
• Pressing any button except the MODE button stops the auto
play operation.
• Note that the buttons of the camera do not operate hile a
page change operation is in progress. Make sure that an
image is sho n on the display hen you press a button to
stop the auto play operation.
To set auto play speed
Use the follo ing procedure to specify ho long each image remains
on the display, ithin the range of 3 to 30 seconds.
1. Perform steps 1 and 2 under “To start the auto play opera-
tion” on page 38 to start auto play.
3 seconds 3 seconds
Operation
40
2. Press MODE to enter the Auto Play Setting Mode.
• Be sure to press MODE hile an image is stopped on the
monitor, and not hile images are changing.
3. Use [+] increase) and [–] decrease) to change the current
speed setting.
• You can set the speed ithin a range of 3 to 30 seconds, in
three-second increments.
4. To start auto play using your newly set speed setting,
press the shutter button.
• To exit the auto play setting mode at any time, change the
function s itch position to REC and then back to PLAY, or
turn po er off. Either of these methods cancels any settings
you made and returns to the settings in effect hen you en-
tered the Auto Play Setting Mode.
• You can use auto play in combination ith the multi-page
display (page 34). First change to the multi-page format, and
then perform the auto play operation (page 38).
• You cannot use auto play in combination ith the multi-page
display hile protected pages are hidden (page 45).
Speed (number of
seconds each
image is displayed)

41
Playing Back Images
Protecting Memory Pages
You can protect specific memory pages to ensure that they are not
accidently deleted.
• Note that you cannot protect or unprotect memory pages hen pro-
tected memory pages are hidden (page 45).
To protect a single memory page
1. Enter the Playback Mode.
• Slide the function s itch to the PLAY position.
2. Display the PROTECT Menu.
• Press the /PROTECT button
to display the PROTECT Menu.
• This menu lets you specify either
single-page protection or all-page
protection.
3. Select “PAGE”.
• Use [+] and [–] to select “PAGE”.
• To clear the selection screen and quit this procedure, select
the EXIT icon.
4. Press the shutter button.
Operation
42
5. Display the page you want to protect.
• Use [+] and [–] to scroll through the pages until the one you
ant to protect is displayed.
6. Press the shutter button to protect the displayed image.
• A protect indicator ( ) appears in the upper left corner of
the display to indicate it is protected.
7. To protect some more images, repeat steps 5 and 6 above.
• To clear the page protect screen, press any button besides
[+], [–], or the shutter button. The page protect screen is also
cleared automatically if you do not perform any button op-
eration for about 20 seconds.
To protect all pages in memory
1. Select the Playback Mode and turn on power.
• Slide the function s itch to the PLAY position.
2. Display the PROTECT Menu.
• Press the /PROTECT button
to display the PROTECT Menu.
• This menu lets you specify either
single-page protection or all-page
protection.
3. Select “ALL”.
• Use [+] and [–] to select “ALL” and then press the shutter
button.
• When you select “ALL”, the message “PROTECT ALL?” ap-
pears on the screen.
43
Playing Back Images
4. Specify all-page protection.
• Use [+] and [–] to select “ALL” and
then press the shutter button.
• A protect indicator ( ) appears
in the upper left corner of all
memory pages hen you display
the page status indicators.
Unprotecting Memory Pages
You can unprotect specific memory pages or all pages currently
stored in memory.
To unprotect a single memory page
1. In the Playback Mode, display the PROTECT Menu.
• Press the /PROTECT button to display the PROTECT
Menu.
• This menu lets you specify either a single page or all pages.
2. Select “PAGE”.
• Use [+] and [–] to select “PAGE”.
• To clear the selection screen and quit this procedure, select
the EXIT icon.
3. Press the shutter button.
• This causes the “PROTECT PAGE” menu to appear.
4. Display the page you want to unprotect.
• Use [+] and [–] to scroll through the pages until the one you
ant to unprotect is displayed.
Operation
44
5. Press the shutter button to unprotect the displayed image.
• The protect indicator disappears from the upper left corner
of the display to indicate the image is no longer protected.
6. To unprotect some more images, repeat steps 4 and 5
above.
• To clear the page protect screen, press any button besides
[+], [–], or the shutter button. The page protect screen is also
cleared automatically if you do not perform any button op-
eration for about 20 seconds.
To unprotect all pages in memory
1. In the Playback Mode, display the PROTECT Menu.
• Press the /PROTECT button to display the PROTECT
Menu.
• This menu lets you specify either a single page or all pages.
2. Select “ALL”.
• Use [+] and [–] to select “ALL” and then select the shutter
button.
• When you select “ALL”, the message “PROTECT ALL?” ap-
pears on the screen.
3. Specify all-page unprotection.
• Use [+] and [–] to select “CANCEL” and then press the shut-
ter button.
• The protect indicator ill not appear in the upper left corner
of any of the memory pages hen you display the page sta-
tus indicators.

45
Playing Back Images
Hiding Protected Memory Pages
This function makes it possible for you to hide protected memory
pages so their images do not appear on the monitor during playback.
To hide protected memory pages
While holding do n the [+] button, turn on the camera.
Important!
• You cannot protect or unprotect pages (pages 41~44) hile pro-
tected pages are hidden.
• You cannot display multiple images (page 34) hile protected
pages are hidden.
• The message “ALL DATA IS PROTECTED!” appears on the moni-
tor hen you hide protected memory pages and all pages currently
in memory are protected. It also appears if you delete all unpro-
tected memory pages hile protected memory pages are hidden.
To unhide protected memory pages
While holding do n the [–] button, turn on the camera.
46
Operation
Deleting Memory Pages
Use the procedures described in this section to delete memory
pages. You can delete individual pages, or all the pages currently
stored in memory.
Warning!
The delete operation cannot be undone!
Before performing any of the procedures described in this section,
make sure that you really do not need the images recorded on the
memory pages you are deleting. Be especially careful hen you are
using the all delete operation.
Deleting Images From Memory
• Note that you cannot delete images if they are protected. See page
43 for details on ho to unprotect images.
• You cannot delete images from a multi-page display, a display of an
enlarged image, or hile Auto Playback is operating.
To delete a single image
1. Select the Playback Mode and turn on power.
• Slide the function s itch to the PLAY position.
• Slide the POWER s itch in the direction indicated by the
arro .
2. Display the DELETE Menu.
• Press the DEL button to display
the DELETE Menu.
47
Deleting Memory Pages
3. Select “PAGE”.
• Use [+] and [–] to select “PAGE”.
• To clear the selection screen and quit this procedure, select
the EXIT icon.
4. Press the shutter button.
5. Use [+] and [–] to display the image you want to delete.
• Any images that are protected
(page 41) do not appear on the
screen during this operation.
6. Double check to make sure that you really want to delete
the image that is on the screen.
• To abort the delete operation ithout deleting anything,
press any button other than [+], [–], or the shutter button.
7. Press the shutter button to delete the page.
• After you delete an image, the image on the next page ap-
pears on the screen.
8. To delete more images, repeat steps 5 through 7.
• After you finish deleting all the images you ant, press any
button other than [+], [–], or the shutter button to clear the
image delete screen.
48
Operation
Note
• Deleting a page causes the remaining pages to be renumbered.
Blank pages are not left inserted bet een non-blank pages.
123 4
123

49
Deleting Memory Pages
To delete all images in memory
1. Enter the Playback Mode.
• Slide the function s itch to the PLAY position.
2. Display the DELETE Menu.
• Press the DEL button to display
the DELETE Menu.
3. Select “ALL”.
• Use [+] and [–] to select “ALL” and press the shutter button.
4. Select “ALL”.
• Use [+] and [–] to select “ALL”.
• To clear the selection screen and
quit this procedure, select the
EXIT icon.
5. Press the shutter button to delete all images from memory.
• After all images are deleted, the message “MEMORY
EMPTY” appears on the screen.
• If you perform the above operation hile protected images
are hidden, the message “ALL DATA IS PROTECTED!” ap-
pears on the screen.
50
Operation
Use the follo ing procedure to convert an image converted in the
FINE Mode to a NORMAL Mode image.
• After you convert a FINE image to a NORMAL image, the FINE
image is automatically deleted.
1. Select the Playback Mode and turn on power.
• Slide the function s itch to the PLAY position.
• Slide the POWER s itch in the direction indicated by the
arro .
2. Display the FINE NORMAL Menu.
• Press the MODE button to display
the FINE NORMAL Menu.
3. Display the image you want to convert.
• Use [+] and [–] to scroll through the images.
• Any images that are protected (page 41) do not appear on
the screen during this operation.
4. Press the shutter button to start the conversion.
5. After the conversion is complete, you can repeat steps 3
and 4 to convert more images.
• After you are finished converting images, press any button
besides [+], [–], or the shutter button to clear the conversion
screen.
Resolution Conversion
51
DIGITAL – Use this terminal to connect to a personal computer (re-
quires optional Connection Kit), another CASIO Digital
Camera, or a QV Color Printer. The illustration belo
sho s ho to connect to another digital camera.
The camera terminals
The follo ing describes hich the camera terminal you should use
for each type of connection.
VIDEO OUT – Use this terminal hen connecting to the VIDEO IN
terminal of a TV, video tape deck, video printer, or
other similar devices. Use the special video cable
that comes ith the camera for such connections.
Connecting to Other Devices
* The type of connecting cable you should use depends on the type
and shape of the terminals equipped on the digital camera you are
connecting to. See pages 52 through 58 for details.
VIDEO
LR
INPUT
AUDIO
Special video
cable that comes
ith camera
VIDEO IN
terminal of other
device
VIDEO OUT
terminal
DIGITAL terminal DIGITAL terminal*
Connecting
cable*
Using the Camera ith a Connected Device
52
Using the Camera with a Connected Device
The follo ing section provides specific information on ho you can
use the camera after connecting to various types of devices. In each
case, the camera terminal you should connect to is indicated in the
title as
VIDEO
and
DIGITAL
.
Important!
• Make sure that the po er of all devices is turned off before connect-
ing them.
• You should also check the o ner’s manuals of the device you are
connecting to the camera for precautions and other information.
Television
VIDEO
• See page 32 of this manual for details about connecting to a televi-
sion and displaying images from camera memory on a TV screen.
Video Tape Deck
VIDEO
You can use the video tape deck to record images from the camera.
To record camera images on video tape
1. Use the special video cable that comes ith the camera to connect
to the VIDEO IN terminal of the video tape deck.
2.Set up the video tape deck to record images input through its
VIDEO IN terminal.
• Consult the o ner’s guide that comes ith the tape deck for details
about ho to set up for recording.
3. Enter the camera Playback Mode and start the video deck record
operation.
• It is probably best to use auto play hen recording camera images
to video tape, because it changes pages automatically at a preset
speed.

53
• Remaining pages (page 28) are also recorded on the video tape if
they are turned on. Be sure to turn off display of remaining pages if
you do not ant them in the taped images.
• If the lo battery indicator (page 29) is displayed hile you are re-
cording to video tape, it ill also be recorded ith the image. If this
happens, either replace batteries or use the AC adaptor.
Video Printer
VIDEO
You can use Video Printer to print copies of images in camera
memory.
To print camera images on a Video Printer
1. Use the special video cable that comes ith the camera to connect
to the VIDEO IN terminal of the video printer.
2. Set up the video printer to print images input through its VIDEO IN
terminal.
• Consult the o ner’s guide that comes ith the video printer for de-
tails about ho to set up for printing.
3. Enter the camera Playback Mode and display the image you ant
to print.
4. Start the video printer’s print operation.
• Remaining pages (page 28) are also included on the print if they are
turned on. Be sure to turn off display of remaining pages if you do
not ant them in the print.
• If the lo battery indicator (page 29) is displayed hile you are print-
ing, it ill also be printed ith the image. If this happens, either re-
place batteries or use the AC adaptor.
Using the Camera ith a Connected Device Using the Camera ith a Connected Device
54
Connecting to another CASIO Digital Camera
DIGITAL
You can connect the camera to another CASIO digital camera and
exchange image data bet een them. Connect the DIGITAL terminals
of the t o cameras using the optionally available SB-62 connecting
cable.
To connect the two cameras
1. Turn both cameras off.
2. Connect the t o cameras by plugging the optional SB-62 connec-
tion cable into their DIGITAL terminals.
3. Turn both cameras on.
To send data from this camera to another camera
1. Set the function s itches of both cameras to PLAY.
2.Use the [+] and [–] buttons of this camera to find the image you
ant to send.
• You cannot send images bet een t o cameras hile either of their
function s itches is set to REC.
• You cannot send images hile using the multi-page display or
zoom function.
3. Press the shutter button of this camera.
Return to previous display
Receive icon
Send icon
55
4. Use the [+] and [–] buttons to move the pointer to the send icon.
5.After you make the setting you ant, press the shutter button
again.
• Pressing the shutter button sends the selected image to the other
camera.
• You can send only one image at a time. To send more images,
repeat steps 2 through 5.
To receive data to this camera from another camera
1. Set the function s itches of both cameras to PLAY.
2. Use the [+] and [–] buttons of other camera to find the image you
ant to receive.
• You cannot receive images bet een t o cameras hile either of
their function s itches is set to REC.
• You cannot receive multi-page display or zoomed images.
• If you try to receive a multi-page display or zoomed images, other
camera’s monitor automatically changes to normal display of page
1.
3. Press the shutter button of this camera.
Using the Camera ith a Connected Device
Return to previous display
Receive icon
Send icon
Using the Camera ith a Connected Device
56
4. Use the [+] and [–] buttons to move the pointer to the receive icon.
• As soon as you perform the above step, all of the buttons and con-
trols on the other camera become disabled.
5.After you make the setting you ant, press the shutter button
again.
• Pressing the shutter button receives the selected image from the
other camera.
* You can receive only one image at a time. To send more images,
repeat steps 2 through 5.
Important!
Never disconnect the cable, turn po er off, or change the function
s itch setting hile a data communication operation is in progress.
Doing so can damage the camera.
How data transfer affects resolution
• QV-300 QV-300/QV-100 ...........FINE FINE
NORMAL NORMAL
• QV-300 QV-10/QV-10A/QV-11/QV-30 .... FINE NORMAL
NORMAL NORMAL
• QV-300 QV-10/QV-10A/QV-11/QV-30..... NORMAL NORMAL

57
Using QV-Link Software and a Connection Cable
The optionally available QV-Link Soft are and connection cable lets
you transfer images from your digital camera to a personal computer.
The follo ing are the models of QV-Link soft are that support this
camera.
Windo s Version: LK-10V
Macintosh Version: LK-2V
Important!
• This camera does not fully support the soft are that comes ith the
LK-1 and LK-1A connection kits for Windo s, and the LK-2 and LK-
2A connection kits for the Macintosh. Never try to use the soft are
that comes ith these connections kits ith this digital camera.
Connecting to a QV color Printer
DIGITAL
You can connect this camera to a CASIO QV color Printer and print-
out images that are in camera memory. Use the communication cable
that comes ith the QV Color Printer to connect camera's DIGITAL
terminal to the QV Color Printer's terminal.
Applicable printer model: CASIO QG-100
After connecting the t o units, turn on camera po er and slide the
function s itch to the PLAY position. For details on ho to perform
the QV Color Printer procedures required for printing, see the docu-
mentation that comes ith the QV Color Printer.
Using the Camera ith a Connected Device Using the Camera ith a Connected Device
58
Computer Video Capture)
VIDEO
You can use the special video cable that comes ith the camera to
connect directly to the VIDEO IN terminal of a personal computer
equipped ith video capture capabilities.
To transfer camera images to a personal computer video
capture)
1. Use the special video cable that comes ith the camera to connect
to the VIDEO IN terminal of the computer.
2. Enter the camera Playback Mode and display the image you ant
to send.
3. Perform the required operation on the computer.
• Consult the o ner’s guide that comes ith the computer or its video
capture board for details about ho to set up to capture images.
Important!
• With this configuration, you cannot send images from the personal
computer to the camera.
• The camera can be connected directly to a personal computer or
video capture board that is equipped ith a VIDEO IN terminal
(RCA pin jack). It cannot be connected directly to an S-VIDEO ter-
minal.
59
Troubleshooting
No po er
Sudden po er
failure
indicator
on LCD
No recording
hen shutter
button is
pressed
Po er failure
during self-timer
operation
● indicator on
LCD
○ indicator on
LCD
1. Correctly load batter-
ies (page 13).
2. Replace batteries ith
ne ones (page 13).
3. Use only recom-
mended AC adaptor .
1. Turn po er back on.
2. Replace batteries ith
ne ones (page 13).
Replace manganese
batteries ith alkaline
batteries.
Replace all four batteries
ith a set of ne ones
(page 13).
Set function s itch to
REC.
Replace batteries (page
13).
Change aperture s itch
setting to [●] (page 27).
Change aperture s itch
setting to [○] (page 27).
Symptom Probable Cause Action
Po er Supply
1. Batteries not loaded
correctly.
2. Dead batteries
3. Wrong AC adaptor
1. Operation of Auto
Po er Off
2. Lo battery po er
Use of manganese
batteries.
Po er ill automatically
turn off shortly.
Function s itch sets to
PLAY.
Lo battery po er
Over exposure
Under exposure
Recording
60
Reference
Sympton Probable Cause Action
Poor LCD image
focus
Poor color and
brightness hen
indoors
Recorded image
has greenish
tinge.
Color of
recorded image
is strange.
No +/– button
operation during
multi-page dis-
play
All pages do not
appear during
auto play.
Use NORMAL for scen-
ery and group photos,
and MACRO for close-
ups (page 24).
Shoot under incandes-
cent or other non-fluores-
cent lighting (page 21).
Change aperture setting
to [●]. Note that this con-
dition is due to CCD char-
acteristics, and does not
indicate camera malfunc-
tion.
1. Reorient the camera
so that light is not shin-
ing directly into lens.
2. This difference does
not indicate a problem
or malfunction.
Wait until an image is on
the LCD before perform-
ing a button operation.
Unhide protected memo-
ry pages (page 45).
Incorrect NORMAL/
MACRO s itch setting
Indoor fluorescent lighting
Strong direct or reflected
sunlight
1. Reflection from sun-
light or light from an-
other source
2. Difference bet een
Record Mode and
Playback Mode char-
acteristics.
Button operation during
page change
Protected memory pages
are hidden.
Recording
Playback

61
Sympton Probable Cause Action
1. Set function s itch to
PLAY (page 31).
2. Connect correctly us-
ing the special video
cable that comes ith
the camera (page 32).
3. Set up the TV cor-
rectly.
Unhide protected memo-
ry pages by holding do n
[–] hile turning po er on
(page 45).
Unhide protected memo-
ry pages by holding do n
[–] hile turning po er on
(page 45).
Unhide protected memo-
ry pages by holding do n
[–] hile turning po er on
(page 45).
Unhide protected memo-
ry pages by holding do n
[–] hile turning po er on
(page 45).
Troubleshooting
1. Function s itch set to
REC
2. Incorrect camera-TV
connection
3. Wrong TV set up
Protected memory pages
are hidden.
Protected memory pages
are hidden.
Protected memory pages
are hidden.
Protected memory pages
are hidden.
Camera is con-
nected to a TV,
but LCD monitor
contents do not
appear on TV
screen.
Some images
are missing.
Cannot use
multi-page dis-
play.
Cannot protect
memory pages.
ALL DATA IS
PROTECTED!
stays on monitor
and images do
not appear.
Playback
62
Reference
Sympton Probable Cause Action
1. Unprotect the page
you ant to delete
(page 43).
2. Change to a normal-
size, 1-page display
format.
Remove batteries and
disconnect the AC adap-
tor if you are using one.
Restore po er and turn
the camera on. If this
does not ork, contact
your dealer or an author-
ized CASIO service pro-
vider.
Adjust the BRIGHT set-
ting (page 11).
Remove batteries and/or
unplug the AC adaptor.
Reload batteries and/or
plug in AC adaptor and try
operation again.
Adjust the BRIGHT
(brightness) setting.
1. Connect correctly
(page 51).
2. Turn po er on after
connecting cable.
3. Set function s itch to
PLAY (page 31).
1. All pages are pro-
tected.
2. Multi-page display
(page 34) or zoom dis-
play (page 36)
Malfunction due to static
electrical charge or strong
impact
Wrong BRIGHT setting
Malfunction due to expos-
ing camera to electro-
static charge.
Incorrect BRIGHT setting
1. Incorrect cable con-
nection
2. Camera connected to
is not turned on.
3. Function s itch sets to
REC.
Delete opera-
tion does not
start hen DEL
is pressed.
All buttons and
s itches do not
operate.
Very bright or
very dark LCD
image.
No buttons or
s itches oper-
ate.
LCD monitor is
too bright or too
dark.
Cannot ex-
change data be-
t een t o cam-
eras
Other Deletion
63
Sympton Probable Cause Action
Pressing MODE
does not change
the FINE
NORMAL Menu.
Cannot transfer
data (error
keeps occurring)
Keys of con-
nected camera
are disabled.
1. Correct the situation
and try again.
2. Correct the situation
and try again.
3.Change function
s itch setting of re-
ceiving camera to
PLAY (page 31).
4. The sending camera’s
protected memory
pages are hidden. Un-
hide protected memory
pages by holding do n
[–] hile turning po er
on (page 45).
5. Replace batteries or
use the AC adaptor
(page 13).
6. Securely reconnect the
cable.
Normal operation ill re-
turn hen you exit data
communications by press-
ing EXIT.
There are no convertible
images in memory.
1. Sending camera’s
memory is empty.
2. Receiving camera’s
memory is full
3. Receiving camera’s
function s itch is in
REC position.
4. The message “ALL
DATA IS PROTECT-
ED” is on the monitor
of the sending camera.
5. Lo battery (indicated
by )
6. Disconnection of cable
during data communi-
cation
Connected camera op-
eration is disabled during
data communications.
Troubleshooting
Other
64
Reference
Messages
Camera is set up to hide protected images, and all
images are protected.
ERROR Error during data communication. Check cable con-
nections and mode settings.
REMAIN No more memory for FINE images. Use MODE to
change to NORMAL Mode, delete some images, or
change resolution of existing images from FINE to
NORMAL.
MEMORY FULL Not enough memory for further recording. Delete
some images from memory or change resolution of
stored images from FINE to NORMAL.
MEMORY EMPTY No images are stored in memory.
Problem ith internal memory. Contact your dealer or
an authorized CASIO service provider.
ALL DATA IS
PROTECTED
MEMORY ERROR
#1~#4
CONSULT THE
OWNER’S MANUAL!

65
Specifications
General
Recording System... Digital (JPEG based)
Signal System ......... NTSC
Recording Medium .. Built-in 32-Mbit flash memory
Number of Memory Pages
FINE(VGA) ............ 64 (approximately 480-kbit compressed)
NORMAL(Q-VGA) ... 192 (approximately 160-kbit compressed)
Delete Functions ..... Single page; All pages ( ith page protect feature)
Imaging Device ....... 1/4-inch CCD (Total Number of Pixels: 360,000)
Lens ........................ 2 focal points ith macro position: F2.6 f=4.9mm/
f=11.0mm
Aperture .................. F2.6/F8 manual s itching
Focal Length
f=4.9mm F2.6 F8
Normal 0.6m(2') ~ ∞0.3m(1') ~ ∞
Macro 9cm(3.5") ~ 11cm(4.3") 7cm(2.8") ~ 14cm(5.5")
f=11.0mm F2.6 F8
Normal 3.4m(11.2') ~ ∞1.7m(5.6') ~ ∞
Macro 52cm(1.7') ~ 62cm(2') 44cm(1.4') ~ 77cm(2.5')
Light Metering ......... TTL center point by photographic element
Exposure Metering .. Aperture priority AE
Exposure Range ..... EV +5 to 18
Exposure Adjustment .. -2EV to +2EV
Shutter System ....... Electronic
Shutter Speed ......... 1/8 to 1/4000 second
White Balance ......... Automatic
Self-timer................. 10-second
Resolution ............... FINE, NORMAL
Monitor .................... 61,380-pixel 2.5-inch TFT lo -glare color LCD;
doubles as finder
PC Output Image .... 480 X 640 dots (FINE)
240 X 320 dots (NORMAL) 66
Reference
Terminals ................ DIGITAL; VIDEO OUT; DC IN 6V
Po er Supply .......... Batteries (AA-size Alkaline or Lithium batteries X 4)/
AC Adaptor (AD-C60)
Battery Life .............. LR6 (AM3) AA-size alkaline batteries
Approximately 130 minutes continuous operation
Recording for about 96 images (one image per
minute)
FR6 AA-size lithium batteries
Approximately 220 minutes continuous operation
Recording for about 180 images (one image per
minute)
Dimensions ............. 72 (H) X 162 (W) X 49 (D)mm /
2.8" (H) X 6.4" (W) X 1.9" (D)
Weight ..................... Approximately 250g / 8.8oz (excluding batteries)
Accessories............. Wrist strap; soft case; video cable; Alkaline batteries
(LR6 X 4); cleaning cloth; o ner’s manual
• The liquid crystal panel built into this camera is the product of preci-
sion engineering, ith an effective pixel rate of 99.99%. This also
means, ho ever that 0.01% of the pixels can be expected to fail to
light or to remain lit at all times.
About the camera’s backlight…
• The camera is equipped ith a fluorescent light source to provide
the back lighting for its LCD.
• The normal service life of the backlight is approximately six years,
hen the camera is used for about t o hours a day.
• Should the LCD image appear abnormally dark, take the camera to
your dealer or an authorized CASIO service provider to have the
light source replaced. Note that you ill be charged for this replace-
ment.
• Under very cold conditions, the backlight may require more time
than normal to light, or reddish bands may appear in the image.
These conditions do not indicate malfunction, and normal operation
should return at higher temperatures.
