Casio CDP-200R Troubleshooting guide

ELECTRONIC KEYBOARD
(without price)
CDP-200R
JUL. 2008
Ver.1 : May. 2005
CDP-200R

CONTENTS
SPECIFICATIONS ------------------------------------------------------------------------------------------ 1
BLOCK AND WIRING DIAGRAM --------------------------------------------------------------------- 2
PCB LAYOUT ----------------------------------------------------------------------------------------------- 3
PRINTED CIRCUIT BOARDS -------------------------------------------------------------------------- 5
EXPLODED VIEW ----------------------------------------------------------------------------------------10
PARTS LIST ------------------------------------------------------------------------------------------------11
SCHEMATIC DIAGRAMS -------------------------------------------------------------------------------15

– 1 –
SPECIFICATIONS
Keyboard
Touch Response
Maximum Polyphony
Tones
Built-in Tones
Sampling Tones
Functions
Reverb
Chorus
Metronome
Beats per Measure
Tempo Range
Song Bank
Built-in Songs
User Songs
Step Up Lesson
Lessons
Lesson Part
Functions
Music Challenge
Auto Accompaniment
Built-in Rhythms
User Rhythms
Registration
Recorder
Keyboard Play
Playing Along with a
Built-in Songs
Memory Capacity
Other Functions
Transpose
Octave Shift
Tuning
Scale Tuning
Music Preset
One Touch Preset
Auto Harmonize
Arpeggiator
MIDI
Musical Information Function
Pitch Bend Wheel
Pitch Bend Range
88-key piano keyboard
3 types, Off
48 notes (24 for certain tones)
670
Up to 8 (Melody Sampling: 5, Drum Sampling: 3)*
Up to 10 seconds
Layer, Split
1 to 10, Off
1 to 5, Off
0, 2 to 6
30 to 255
152
Up to 10*
4 (Listen, Watch, Remember, Auto)
L, R, LR
Repeat, Voice Fingering Guide, Note Guide, Performance Evaluation
20 notes
200
Up to 10 (Accompaniment Edit)*
32 (4 setups × 8 banks)
Real-time recording, playback
5 songs, 6 tracks
1 song (L, R, LR)
Approximately 12,000 notes (total for 6 songs)
±1 octaves (12 semitones)
Upper/Lower ±2 octaves
A4 = approx. 440 Hz ±100 cents
Scale Fine Tune, Quarter Tone, Preset Scales
305
200
12 types
90 types
16 multi-timbre received, GM Level 1 standard
Tone, Rhythm, Song Bank, numbers and names; staff notation, fingering, pedal
operation, tempo, measure and beat number, chord name, etc.
0 to 12 semitones

– 2 –
SD Memory Cards
Supported SD Memory Cards
Functions
Inputs/Outputs
USB port
Sustain/Assignable jack
Phones/Output jack
Audio In jack
Mic In jack
Power Jack
Power Supply
AC Adaptor
Speakers
Output
Power Consumption
Dimensions
Weight
2GB or less
SMF playback, file storage, file recall, file delete, card format
TYPE B
Standard jack (sustain, sostenuto, soft, rhythm start/stop)
Stereo standard jack
Output Impedance: 20Ω, Output Voltage: 1.5V (RMS) MAX
Stereo mini jack
Input Impedance: 40kΩ, Input Sensitivity: 200mV
Standard jack
Input Impedance: 3kΩ, Input Sensitivity: 10mV
12V DC
AD-12
(12cm × 6cm oval) × 2
8W + 8W
12V 18W
133.3 × 27.8 × 13.3cm (52 1/2 × 10 15/16× 5 1/4 inch)
Approximately 12.0kg (26.4 lbs)

– 3 –
BLOCK AND WIRING DIAGRAM
Keyboard
Keyboard
Keyboard
Keyboard PCB
(MCZS-KYB1)
Main PCB
(M810-MDA1)
USB PCB (M810-CNA5)
CONSOLE PCB
(M810-LCA1)
CONSOLE PCB
(M810-CNA2)
SUB PCB
(M810-PSA2) SUB PCB (M810-PSA1) JACK PCB (M810-JKA1)
CONSOLE PCB
(M810-CNA1)
CONSOLE PCB
(M810-CNA4)
CONSOLE PCB
(M810-CNA3)
Keyboard PCB (MCZS-KYC1)
Keyboard PCB (MCZS-KYA1)
BENDER
SD CARD PCB (M810-SDA1)
MD0 ~ MD15
MA1 ~ MA18
MA1 ~ MA23 MPU
IC7
S-RAM (8Mbit)
IC9
P2-ROM (128Mbit)
IC1
Logic
IC751
LCD CONTOROLLER
IC42
LCD
PWSW
DB0~DB4,
E,RW,RS
ATXD0,
ARXD0,
GARST
BUTTON
CONTOROLLER
IC41
MAIN
VOL MIC VOL
Power Amplifier
IC11
Filter
IC14
CONSOLE PCB
(M810-CNA6)
Filter
IC501
Filter
IC15
Filter
IC16
Filter
IC5
VCP
VDP3
D/D converter
IC2
CN803
CN804 CN805
CN405CN15
CN13CN14
CN11
CN6
CN7 CN4 CN3
CN501
CN8 CN502
CN1
CN39
CN805
CN751CN16
CN12
CN43
CN41
CN31CN33 CN32
CN35 CN34CN36
CN42
CN805
CN802 CN801

– 4 –
PCB LAYOUT
PCB Components
MAIN PCB M810-MDA1 MPU, Reset IC, RAM(8Mbit), ROM(128Mbit), Key controller,
Power supply circuit
SUB PCB M810-PSA1 Power supply circuit, Power amplifer
SUB PCB M810-PSA2 Phones jack
CONSOLE PCBs
M810-CNA1 Button
M810-CNA2 Button
M810-CNA3 Button
M810-CNA4 Button
M810-CNA6 Main volume , Mic volume
M810-LCA1 LCD controller, Button controller
USB PCB M810-CNA5 USB
JACK PCB M810-JKA1 Mic, Audio IN, Pedal, DC 12V terminal
SD CARD PCB M810-SDA1 SD CARD
KEYBOARD
PCBs
MCZS-KYA1
KEYBOARDMCZS-KYB1
MCZS-KYC1
M810-SDA1 PCB
M810-CNA3 PCB
M810-MDA1 PCB
M810-LCA1 PCB
M810-CNA1 PCB
M810-PSA1 PCB
M810-PSA2 PCB M810-CNA5 PCB
M810-CNA6 PCB MCZS-KYB1 PCB
M810-JKA1 PCB
M810-CNA2 PCB
M810-CNA4 PCB
MCZS-KYA1 PCB MCZS-KYC1 PCB

– 5 –
PRINTED CIRCUIT BOARDS
Main PCB M810-MDA1
Top View
Bottom View

– 6 –
Sub PCB M810-PSA1
Top View
Bottom View

– 7 –
Console PCB M810-LCA1
Top View
Bottom View
JACK PCB M810-JKA1 SD CARD PCB M810-SDA1
SUB PCB M810-PSA2

– 8 –
Console PCB M810-CNA1
Console PCB M810-CNA4
Console PCB M810-CNA5Console PCB M810-CNA3
Console PCB M810-CNA6
Console PCB M810-CNA2

– 9 –
Keyboard PCB MCZS-KYA1
Keyboard PCB MCZS-KYB1
Keyboard PCB MCZS-KYC1

– 10 –
EXPLODED VIEW
63
66
67
71
80
79
78 77
76
75
74 73
69 72
68
70
64
84
19
22
18
65
51
51
33
30
34
32
11
28
12
26
29
27 15
16
9
17
24
19
20
35
58
60
58
55
60 59
55
55
55
56
57
57
50
49
49
25
21
21
23
10
10
31
14
14
13
8
5
6
61 62
1
4
3
2
38
44
36
48
37
39
7
41
43
54
53
81
40
44
42
43
83
82
46
52
45
47
45

– 11 –
Notes: This parts list does not include the cosmetic parts,
which parts are marked with item No. “R-X” in the
exploded view.
Contact our spare parts department if you need
these parts for refurbish.
1. Prices and specifications are subject to change
without prior notice.
2. As for spare parts order and supply, refer to
the “GUIDEBOOK for Spare parts Supply”,
published seperately.
3. The numbers in item column correspond to the
same numbers in drawing.
PARTS LIST
CDP-200R

– 12 –
1 CDP-200R_DI_120V
2 CDP-200R_DI_230V
3 CDP-200R_EU
4 CDP-200R_UI_UK
5 CDP-200R_US
12345
Main PCB MDA1
N 1 10310729 PCB ASSY/MDA1 TK-RJM508883*001 1 1 1 1 1 A
D1,2,3,5 10276977 DIODE L1SS400T1G 4 4 4 4 4 AA X
IC5 10211950 IC NJM2068M-D(TE1) 1 1 1 1 1 AC X
IC10 10123002 IC TC74VHC174FT(EL) 1 1 1 1 1 AD X
IC8 10197554 IC TC7SZ126FU(TE85L.F 1 1 1 1 1 AE X
IC4 10197809 IC TC7WH123FU(TE12L.F 1 1 1 1 1 AE X
IC2 10098821 IC XC6202P332PR 1 1 1 1 1 AD X
IC6 10269340 IC XC6403FY51PR 1 1 1 1 1 AE X
N IC9 10299049 LSI LP62S16256GV55LLIF 1 1 1 1 1 X
N IC1 10306295 MEMORY MR27T12802L11GTA3A 1 1 1 1 1 BN X
L11 10193074 COIL DLW21HN181SQ2L 1 1 1 1 1 AC X
L13,14 10122963 FERRITE BEAD BLM21AG102SN1D 2 2 2 2 2 AC X
L2,4,10 10089941 FERRITE BEAD BLM21PG221SN1D 3 3 3 3 3 AA X
L1,3,5,6,7,9,16 10238668 FERRITE BEAD EBMS160808A102 7 7 7 7 7 AA X
Q2,6 10202670 TRANSISTOR KTA2014-GR-RTK/P 2 2 2 2 2 AA X
Q1,5 10207675 TRANSISTOR KTC4075-GR-RTK/P 2 2 2 2 2 AA X
N X1 10302397 RESONATOR 7A48000118 1 1 1 1 1 C
Sub PCB PS1
N 2 10310730 PCB ASSY/PSA TK-RJM508885*001 1 1 1 1 1 B
IC13 10201503 IC PQ1CG21H2FZH 1 1 1 1 1 AO X
N IC11 10306512 IC TDA7297 1 1 1 1 1 X
L11 10231919 COIL RB53-856396NP 1 1 1 1 1 AA X
L12,13 10231920 COIL RB53-856397NP 2 2 2 2 2 AA X
N L14 10232457 COIL RII7-860400NP 1 1 1 1 1 X
D12,14,15 10276977 DIODE L1SS400T1G 3 3 3 3 3 AA X
D13 10210387 DIODE RSX101VA-30TR 1 1 1 1 1 AA X
D11 10294394 DIODE SK34A 1 1 1 1 1 AD X
N IC12 10306415 IC BH3547F-E2 1 1 1 1 1 X
IC14,15,16 10211950 IC NJM2068M-D(TE1) 3 3 3 3 3 AC X
N IC17 10265568 IC TC7SB66FU(TE85L.F) 1 1 1 1 1 AA X
Q14 10216428 TRANSISTOR KTA1666-Y-RTF/P 1 1 1 1 1 AB X
Q16,18 10202670 TRANSISTOR KTA2014-GR-RTK/P 2 2 2 2 2 AA X
Q11,12,13,15,17,19 10207675 TRANSISTOR KTC4075-GR-RTK/P 6 6 6 6 6 AA X
N VR1 10273794 VARIABLE R F-09KGH1-CASIO-2 1 1 1 1 1 X
N VR2 10304718 VARIABLE R F-09KH1-CASIO-1 1 1 1 1 1 X
SDA PCB
N 3 10310734 PCB ASSY/SDA1 TK-RJM508899*001 1 1 1 1 1 C
Console PCB
N 4 10310732 PCB ASSY/CNA1 TK-RJM508890*001 1 1 1 1 1 C
N 5 10310733 PCB ASSY/CNA3 TK-RJM508891*001 1 1 1 1 1 C
D1-D3 10209564 LED KPTD-3216SURCK 3 3 3 3 3 AA X
N 6 10310731 PCB ASSY/CNA5 TK-RJM508893*001 1 1 1 1 1 C
CN408 10236622 CONNECTOR USB-4FBRS30NB2 1 1 1 1 1 AC X
N 7 10310727 PCB ASSY/CNA6 TK-RJM508895*001 1 1 1 1 1 C
L31 10231919 COIL RB53-856396NP 1 1 1 1 1 AA X
RemarksSpecification Q'TY Price
Code RN Item Parts NO. Parts Name

– 13 –
1 CDP-200R_DI_120V
2 CDP-200R_DI_230V
3 CDP-200R_EU
4 CDP-200R_UI_UK
5 CDP-200R_US
12345
Case unit
N 8 10310728 BL ASSY TK-RJM508735*001 1 1 1 1 1 C
9 10247802 REFRECTOR RJM506719-001V01 1 1 1 1 1 AG X
10 10255738 LED UY4067S-9B1 4 4 4 4 4 X
N 11 10308372 LCD TY11276N-A0158/08 1 1 1 1 1 C
12 10248658 CONNECTOR RJM506848-001V01 2 2 2 2 2 AJ X
13 10037738 SPONGE M441167-1 2 2 2 2 2 AA X
14 10244704 TOP PIECE RJM506943-001V01 2 2 2 2 2 AA X
15 10244703 FILM RJM506942-001V01 1 1 1 1 1 AA X
16 10244501 PLATE/BL RJM506777-001V01 1 1 1 1 1 AO X
N 17 10310735 COVER ASSY/SP/LEFT TK-RJM508736*001 1 1 1 1 1 X
N 18 10310736 COVER ASSY/SP/RIGHT TK-RJM508737*001 1 1 1 1 1 X
19 10284878 SPEAKER C0612J01 2 2 2 2 2 BO B
N 20 10308815 HARNESS EH-2P-15-M810 1 1 1 1 1 X L
N 21 69264590 SPONGE M440564-1 2 2 2 2 2 AA X L,R
N 22 10308814 HARNESS EH-2P-85-M810 1 1 1 1 1 X R
23 10216001 SPONGE RJM506430-001V01 1 1 1 1 1 AE X R
24 10269765 KNOB/RTR M341109-008V01 2 2 2 2 2 AD C
N 25 10306474 PLATE/DISPLAY RJM508552-001V01 1 1 1 1 1 C
N 26 10306479 RUBBER KEY/A RJM508560-001V01 1 1 1 1 1 AA C
N 27 10306480 RUBBER KEY/B RJM508561-001V01 1 1 1 1 1 AD C
N 28 10306481 RUBBER KEY/C RJM508562-001V01 1 1 1 1 1 AC C
N 29 10306482 RUBBER KEY/D RJM508563-001V01 1 1 1 1 1 AA C
N 30 10306483 RUBBER KEY/E RJM508564-001V01 1 1 1 1 1 AB C
N 31 10306484 RUBBER KEY/F RJM508565-001V01 1 1 1 1 1 AB C
N 32 10306485 RUBBER KEY/G RJM508566-001V01 1 1 1 1 1 AC C
N 33 10306486 RUBBER KEY/H RJM508567-001V01 1 1 1 1 1 AF C
N 34 10306487 RUBBER KEY/J RJM508568-001V01 1 1 1 1 1 AA C
N 35 10314505 PANEL ASSY TK-RJM505332*010 1 1 1 1 1 C
N 36 10306459 HOLDER/JACK RJM505667-002V01 1 1 1 1 1 X
N 37 10310738 PCB ASSY/JKA1 TK-RJM508897*001 1 1 1 1 1 C
J504 10210582 DC JACK HEC2305-016920 1 1 1 1 1 AC C
J501 10206815 CONNECTOR JY-6314*01-030 1 1 1 1 1 AA C
J502 10206816 CONNECTOR JY-6314*01-130 1 1 1 1 1 AA C
N J503 10305131 CONNECTOR ST-3529B 1 1 1 1 1 X
L502 10231919 COIL RB53-856396NP 1 1 1 1 1 AA X
L501,503 10231920 COIL RB53-856397NP 2 2 2 2 2 AA X
IC501 10211950 I.C NJM2068M-D(TE1) 1 1 1 1 1 AC X
N 38 10306472 SIDE CASE/IL RJM508550-001V01 1 1 1 1 1 C
N 39 10310726 BENDER ASSY TK-RJM504468*005 1 1 1 1 1 C
N 40 10306473 SIDE CASE/IR RJM508551-001V01 1 1 1 1 1 C
N 41 10306467 SIDE CASE/L RJM508548-001V01 1 1 1 1 1 C
N 42 10306470 SIDE CASE/R RJM508549-001V01 1 1 1 1 1 C
43 10203785 SCREW S-TRMA-6X30B3 4 4 4 4 4 AA C
N 44 10179177 HIMELON RJM505229-001V01 2 2 2 2 2 X
N 45 10209201 PACKING RJM506148-001V01 2 2 2 2 2 X
N 46 10214405 PACKING RJM506367-001V01 1 1 1 1 1 X
N 47 10305236 HIMELON M411136-003V03 1 1 1 1 1 X
N 48 10214401 PACKING RJM506159-001V01 1 1 1 1 1 X
49 69255770 HIMELON M440339-1 2 2 2 2 2 X
N 50 10219387 HIMELON RJM506468-001V01 55555 X
N 51 10306463 SIDE BRACKET RJM508544-001V01 4 4 4 4 4 X
52 69265870 SPONGE M440591-1 1 1 1 1 1 AB X For FFC
N 53 10306477 HOLDER/SP/A RJM508556-001V01 1 1 1 1 1 X
N 54 10306478 HOLDER/SP/B RJM508557-001V01 1 1 1 1 1 X
RemarksSpecification Q'TY Price
Code RN Item Parts NO. Parts Name

– 14 –
1 CDP-200R_DI_120V
2 CDP-200R_DI_230V
3 CDP-200R_EU
4 CDP-200R_UI_UK
5 CDP-200R_US
*1 : Three kinds of plugs(Euro, Austrailia, Korea) are bundled.
12345
55 10175759 PACKING RJM504745-001V01 5 5 5 5 5 AA X
N 56 10175758 PACKING RJM504744-001V01 1 1 1 1 1 X
57 10209204 PACKING RJM506160-001V01 4 4 4 4 4 AA X
58 10216009 PACKING RJM506422-001V01 4 4 4 4 4 AA X
N 59 10209203 PACKING RJM506157-001V01 1 1 1 1 1 X
60 69321322 PACKING M441333-1 4 4 4 4 4 AA X
61 10268012 FERRITE CORE K5ARH16X9X17 1 1 1 1 1 AX C
N 62 69264590 SPONGE M440564-1 1 1 1 1 1 AA X
Key board assy
63 10294094 PCB ASSY/KEY/RUBBE
R
TK-RJM506061*003 1 1 1 1 1 CU C
N D801-D888 10294400 DIODE LM1MA142WKT1G 88 88 88 88 88 X
64 37195442 CABLE N30315B1B05-UL2896 1 1 1 1 1 AO C
65 10133656 RUBBER/CONATCT/AG RJM502920-001V01 7 7 7 7 7 AK B
66 10133635 RUBBER/CONATCT/GC RJM502921-001V01 1 1 1 1 1 AG B
67 10135317 BLACK KEY RJM502797-001V01 36 36 36 36 36 AC C
68 10135426 WHITE KEY/CEGB RJM502862-001V01 7 7 7 7 7 AT C
69 10135427 WHITE KEY/DFA RJM502863-001V01 7 7 7 7 7 AQ C
70 10135428 WHITE KEY/B RJM502794-001V01 1 1 1 1 1 AG C
71 10135429 WHITE KEY/SA RJM502795-001V01 1 1 1 1 1 AJ C
72 10135430 WHITE KEY/SC RJM502796-001V01 1 1 1 1 1 AJ C
73 10208265 HAMMER ASSY/W1 TK-RJM506035*001 13 13 13 13 13 AF C
74 10208266 HAMMER ASSY/W2 TK-RJM506036*001 13 13 13 13 13 AF C
75 10208267 HAMMER ASSY/W3 TK-RJM506037*001 13 13 13 13 13 AF C
76 10208269 HAMMER ASSY/W4 TK-RJM506038*001 13 13 13 13 13 AF C
77 10208275 HAMMER ASSY/B1 TK-RJM506039*001 9 9 9 9 9 AE C
78 10208281 HAMMER ASSY/B2 TK-RJM506040*001 9 9 9 9 9 AE C
79 10208286 HAMMER ASSY/B3 TK-RJM506041*001 9 9 9 9 9 BJ C
80 10208290 HAMMER ASSY/B4 TK-RJM506042*001 9 9 9 9 9 AE C
N 81 10310740 CHASSIS ASSY TK-RJM506053*007 1 1 1 1 1 C
N 82 10311215 CUSHION/HAMMER RJM509043-001V01 1 1 1 1 1 BI C
N 83 10310741 CASE ASSY/LOWER TK-RJM505967*005 1 1 1 1 1 C
N 84 10314506 KEY ASSY TK-RJM506464*007 1 1 1 1 1 A
ACCESSORY
- 10133504 PEDAL ASSY TK-RJM503195*001 1 1 1 1 1 BN C
- 10303050 AC ADAPTOR AD-12ML(E)-FC1(D) 1 DE C For UK
- 10303048 AC ADAPTOR AD-12ML(U)-FC1(D) 1 1 CW C For US
- 10303049 AC ADAPTOR AD-12MLGKA-FC1(D) 1 1 DE C *1
N - 10306488 STAND/MUSIC RJM508666-001V01 1 1 1 1 1 C
N Item Parts NO. Parts Name Specification Q'TY Price
Code R Remarks

– 15 –
SCHEMATIC DIAGRAMS
Main PCB M810-MDA1

– 16 –
Sub PCB M810-PSA1

– 17 –
Sub PCB M810-PSA2

– 18 –
Console PCB M810-LCA1
