Casio CDP-S130 User manual

CDP-S110/CDP-S160/EP-S130
MIDI Implementation
CASIO COMPUTER CO., LTD.
Contents
I MIDI Message Overview 4
1 Product Configuration as a MIDI Device 4
1.1 Performance Controller Section . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
1.2 SoundGeneratorSection .................................... 4
2 Timbre Type Specific Operation 5
3 Conditions that Disable Message Send and Receive 6
II Channel Message 7
4 Receive Channel 7
5 Send Channel 7
6 Note Off 7
7 Note On 7
8 Control Change 7
8.1 BankSelect(00H,20H) ..................................... 8
8.2 Modulation wheel or lever (01H) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
8.3 PortamentoTime(05H)..................................... 8
8.4 DataEntry(06H,26H)...................................... 9
8.5 ChannelVolume(07H) ..................................... 9
8.6 Pan(0AH) ............................................ 9
8.7 ExpressionController(0BH) .................................. 9
8.8 Damper pedal (sustain) (40H) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
8.9 PortamentoOn/Off(41H).................................... 10
8.10 Sostenuto(42H) ......................................... 10
1

8.11 SoftPedal(43H)......................................... 10
8.12 FilterResonance(47H) ..................................... 11
8.13 ReleaseTime(48H) ....................................... 11
8.14 AttackTime(49H)........................................ 11
8.15 Filter Cutoff Frequency (4AH) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
8.16 PortamentoControl(54H) ................................... 12
8.17 ReverbSendLevel(5BH).................................... 12
8.18 ChorusSendLevel(5DH).................................... 12
8.19 RPN (Registered Parameter Number) LSB/MSB (64H,65H) . . . . . . . . . . . . . . . . 12
8.20 AllSoundOff(78H)....................................... 13
8.21 ResetAllControllers(79H)................................... 13
8.22 AllNotesOff(7BH)....................................... 14
8.23 Omni Mode Off (All Notes Off) (7CH) . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
8.24 Omni Mode On (All Notes Off) (7DH) . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
8.25 Mono Mode On (Poly Mode Off) (All Notes Off) (7EH) . . . . . . . . . . . . . . . . . . . 14
8.26 Poly Mode On (Mono Mode Off) (All Notes Off) (7FH) . . . . . . . . . . . . . . . . . . . 14
9 Program Change 14
10 Channel Pressure (Aftertouch) 15
11 Pitch Bend Change 15
III System Message 16
12 Active Sensing 16
13 System Exclusive Message 16
13.1 Universal Real Time System Exclusive Message . . . . . . . . . . . . . . . . . . . . . . . . 16
13.2 Universal Non Real Time System Exclusive Message . . . . . . . . . . . . . . . . . . . . . 17
IV Setting Values and Send/ Receive Values 18
14 Setting Value Tables 18
14.1 Off/OnSettingValueTable................................... 18
14.2 –64 - 0 - +63 Setting Value Table . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
14.3 PanSettingValueTable..................................... 18
14.4 Fine Tune Setting Value Table . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
14.5 Reverb Type Setting Value Table . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
14.6 Chorus Type Setting Value Table . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
2

V MIDI Implementation Notation 20
15 Value Notation 20
15.1 HexadecimalNotation...................................... 20
15.2 BinaryNotation ......................................... 20
3

Part I
MIDI Message Overview
1 Product Configuration as a MIDI Device
As a MIDI device, this Instrument consists of the Performance Controller Section and Sound Generator
Section described below. Each of these sections can send and receive specific MIDI Messages in accordance
with its function.
1.1 Performance Controller Section
The Performance Controller Section performs keyboard play, controller operations, etc., and generates
performance messages. Basically, generated performance messages are sent to external destinations while
also being transmitted to the Sound Generator Section. The channel number of the sent channel message
is in accordance with the Instrument’s instrument part number.
MIDI Output Performance Information The following describes the performance information
that is output and is not output as MIDI signals.
•Output performance
–Keyboard play and controller operations by the musician
•Non-output performance
–Demo Songs
–Recorded song playback(CDP-S160/EP-S130)
1.2 Sound Generator Section
The Sound Generator Section mainly performs receive of performance information and sound source
setting information. It consists of a common part that does not depend on the channel and a musical
instrument part that is independent of each channel.
1.2.1 Sound Generator Common Block
The common block consists of system effects, mixer master control, etc. A number of the parameters of
these items can be controlled by universal system exclusive messages.
1.2.2 Instrument Part Block
The instrument part section consists of a total of 32 instrument parts, divided into two groups, named
Group A and Group B of 16 instruments each. Each part can perform operations and setting changes
using channel messages. Only Group B can be controlled by external channel messages.
As shown in the following table, there is a fixed relationship between channel message receive channel
numbers and instrument parts.
4

Part Number Part Name Channel Assigned Function
00 A01 01 Keyboard(Main)
01 A02 02 Keyboard(Layer)
02 A03 03 Keyboard(Duet function, Left side)*
03 A04 04 Recorded song playback(Main)*
04 A05 05 Recorded song playback(Layer)*
05 A06 06 Recorded song playback(Duet function, Left side)*
06 A07 07 Operation Tone
07 A08 08 Metronome
08 A09 09 -
09 A10 10 -
10 A11 11 -
11 A12 12 -
12 A13 13 -
13 A14 14 -
14 A15 15 -
15 A16 16 -
16 B01 01 MIDI/Demo Song
17 B02 02 MIDI/Demo Song
18 B03 03 MIDI/Demo Song
19 B04 04 MIDI/Demo Song
20 B05 05 MIDI/Demo Song
21 B06 06 MIDI/Demo Song
22 B07 07 MIDI/Demo Song
23 B08 08 MIDI/Demo Song
24 B09 09 MIDI/Demo Song
25 B10 10 MIDI/Demo Song
26 B11 11 MIDI/Demo Song
27 B12 12 MIDI/Demo Song
28 B13 13 MIDI/Demo Song
29 B14 14 MIDI/Demo Song
30 B15 15 MIDI/Demo Song
31 B16 16 MIDI/Demo Song
Note :* = CDP-S160/EP-S130 only.
2 Timbre Type Specific Operation
The sound source operation performed for a sound generator instrument receive message may depend
on the value of the Timbre Type (see “About the Timbre Type” in “9 Program Change”) of each part’s
operation mode. For details, see the explanation for each message.
5

3 Conditions that Disable Message Send and Receive
The main conditions when MIDI message send and receive are disabled by the Instrument are thosedescribed
below.
•While the instrument is accessing flash memory.
6

Part II
Channel Message
4 Receive Channel
The channel number of the channel message received by each part is shown in the table under “1.2.2
Instrument Part Block”.
5 Send Channel
Basically, the MIDI channel of the channel message sent when the Instrument is played coincides with
the MIDI channel of the part being played. Note, however, that the MIDI channel of the performance
information that corresponds to the keyboard main part depends on the MIDI Out Channel setting
value.
6 Note Off
Message Format: 8nH kkH vvH
9nH kkH 00H(receive only)
n: MIDI Channel Number
kk: Key Number
vv: Velocity(Send:40H, Receive:Ignored)
Transmit Sent when the keyboard is played. The key number changes in accordance with on the
Transpose function.
Receive Receipt stops a note being sounded by a note on message.
7 Note On
Message Format: 9nH kkH vvH
n: MIDI Channel Number
kk: Key Number
vv: Velocity
Transmit Sent when the keyboard is played. The key number changes in accordance with on the
Transpose function.
Receive Receipt sounds a note of the corresponding instrument part.
8 Control Change
7

Message Format: BnH ccH vvH
n: MIDI Channel Number
cc: Control Number
vv: Value
For details about messages, see each section of this manual that covers them.
8.1 Bank Select (00H,20H)
Message Format: BnH 00H mmH (MSB)
BnH 20H llH (LSB)
n: MIDI Channel Number
mm: MSB Value(Note1)
ll: LSB Value(Send:00H, Receive:Ignored)
Note1 :For details about the relationship between the MSB value and the tone, see the Tone List that comes with the
Instrument.
Transmit Sent when a tone is selected.
Receive Receipt causes a change in the tone bank number stored in Instrument memory, but the
tone is not actually changed until a Program Change message is received. For details, see “9 Program
Change”.
8.2 Modulation wheel or lever (01H)
Message Format: BnH 01H vvH
n: MIDI Channel Number
vv: Value
Receive Receipt adds, to the tone being sounded, modulation of a depth specified by the value. In
the case of a tone that already has modulation applied, receipt of this message increases the modulation
depth. The modulation effect differs according to the tone being used.
8.3 Portamento Time (05H)
Message Format: BnH 05H vvH
n: MIDI Channel Number
vv: Value
Receive Receipt changes the portamento application time.
8

8.4 Data Entry (06H,26H)
Message Format: BnH 06H mmH (MSB)
BnH 26H llH (LSB)
n: MIDI Channel Number
mm: MSB Value
ll: LSB Value
Transmit Sent when there is a change to the parameter assigned to RPN.
Receive Receipt changes the parameter assigned to RPN.
8.5 Channel Volume (07H)
Message Format: BnH 07H vvH
n: MIDI Channel Number
vv: Value
Receive Receipt changes the volume of the corresponding part.
8.6 Pan (0AH)
Message Format: BnH 0AH vvH
n: MIDI Channel Number
vv: Value(Note1)
Note1 :For information about the relationship between setting values and send/receive values, see “14.3 Pan Setting Value
Table” in “IV Setting Values and Send/Receive Values”.
Receive Receipt changes the pan of the corresponding part.
8.7 Expression Controller (0BH)
Message Format: BnH 0BH vvH
n: MIDI Channel Number
vv: Value
Receive Receipt changes the Expression value of the corresponding part.
8.8 Damper pedal (sustain) (40H)
Message Format: BnH 40H vvH
n: MIDI Channel Number
vv: Value (Note1)
Note1 :For information about the relationship between setting values and send/receive values, see the “14.1 Off/On Setting
Value Table” in “IV Setting Values and Send/Receive Values” of this document.
9

Transmit Sent when a pedal that has a sustain (damper) function is operated.
Receive Receipt performs an operation equivalent to a sustain pedal operation.
Timbre Type Specific Operation This operation differs in accordance with the Timbre Type (see
“About the Timbre Type” in “9 Program Change”) setting.
•Timbre Type: Melody
Sustain off/on control is performed in accordance with the value of the received message.
•Timbre Type: Drum
The received message does not affect sound source operation.
8.9 Portamento On/Off (41H)
Message Format: BnH 41H vvH
n: MIDI Channel Number
vv: Value (Note1)
Note1 :For information about the relationship between setting values and send/receive values, see the “14.1 Off/On Setting
Value Table” in “IV Setting Values and Send/Receive Values” of this document.
Receive Receipt changes the portamento on/off setting.
8.10 Sostenuto (42H)
Message Format: BnH 42H vvH
n: MIDI Channel Number
vv: Value (Note1)
Note1 :For information about the relationship between setting values and send/receive values, see the “14.1 Off/On Setting
Value Table” in “IV Setting Values and Send/Receive Values” of this document.
Transmit Sent when a pedal that has a sostenuto function is operated.(CDP-S160/EP-S130)
Receive Receipt performs an operation equivalent to a sostenuto pedal operation.
8.11 Soft Pedal (43H)
Message Format: BnH 43H vvH
n: MIDI Channel Number
vv: Value (Note1)
Note1 :For information about the relationship between setting values and send/receive values, see the “14.1 Off/On Setting
Value Table” in “IV Setting Values and Send/Receive Values” of this document.
Transmit Sent when a pedal that has a soft function is operated.(CDP-S160/EP-S130)
10

Receive Receipt performs an operation equivalent to a soft pedal operation.
8.12 Filter Resonance (47H)
Message Format: BnH 47H vvH
n: MIDI Channel Number
vv: Value
Receive Receipt changes the filter resonance intensity.
8.13 Release Time (48H)
Message Format: BnH 48H vvH
n: MIDI Channel Number
vv: Value (Note1)
Note1 :For information about the relationship between setting values and send/receive values, see the “14.2 –64 - 0 - +63
Setting Value Table” in “IV Setting Values and Send/Receive Values” of this document.
Receive Receipt makes a relative change in the time it takes for a note to decay to zero after a key is
released.
8.14 Attack Time (49H)
Message Format: BnH 49H vvH
n: MIDI Channel Number
vv: Value (Note1)
Note1 :For information about the relationship between setting values and send/receive values, see the “14.2 –64 - 0 - +63
Setting Value Table” in “IV Setting Values and Send/Receive Values” of this document.
Receive Receipt makes a relative change in the time it takes for a note to rise to its maximum level.
8.15 Filter Cutoff Frequency (4AH)
Message Format: BnH 4AH vvH
n: MIDI Channel Number
vv: Value (Note1)
Note1 :For information about the relationship between setting values and send/receive values, see the “14.2 –64 - 0 - +63
Setting Value Table” in “IV Setting Values and Send/Receive Values” of this document.
Receive Receipt changes the filter cut-off frequency.
11

8.16 Portamento Control (54H)
Message Format: BnH 54H vvH
n: MIDI Channel Number
vv: Source Key Number
Receive Receipt of this message first stores the Source Note Number for the next note. When the next
Note On is received, the portamento effect is applied to the note using this Source Note Number as the
pitch start point and the Note On event key number as the end point. If there already is a note being
sounded by Source Note Number at this time, the new note on is not performed and the portamento
effect is applied to the pitch of the note being sounded. That is to say that legato play is performed.
8.17 Reverb Send Level (5BH)
Message Format: BnH 5BH vvH
n: MIDI Channel Number
vv: Value
Receive Receipt changes the reverb send level of the corresponding part.
8.18 Chorus Send Level (5DH)
Message Format: BnH 5DH vvH
n: MIDI Channel Number
vv: Value
Receive Receipt changes the chorus send level of the corresponding part.
8.19 RPN (Registered Parameter Number) LSB/MSB (64H,65H)
Message Format: BnH 64H llH (LSB)
BnH 65H mmH (MSB)
n: MIDI Channel Number
ll: LSB Value
mm: MSB Value
8.19.1 Pitch Bend Sensitivity
Message Format: BnH 64H 00H
BnH 65H 00H
BnH 06H mmH
BnH 26H llH
n: MIDI Channel Number
mm: MSB Value(00H - 0CH)
ll: LSB Value(Send:00H, Receive:Ignored)
12

Receive Receipt changes Bend Range of the corresponding part.
8.19.2 Channel Fine Tuning
Message Format: BnH 64H 01H
BnH 65H 00H
BnH 06H mmH
BnH 26H llH
n: MIDI Channel Number
mm: MSB Value
ll: LSB Value
Receive Receipt changes the fine tune of the corresponding part.
8.19.3 Channel Coarse Tuning
Message Format: BnH 64H 02H
BnH 65H 00H
BnH 06H mmH
BnH 26H llH
n: MIDI Channel Number
mm: MSB Value
ll: LSB Value
Receive Receipt changes the coarse tune of the corresponding part. Does not affect sound source
operation when the Timbre Type (see “About the Timbre Type” in “9 Program Change”) is Drum.
8.19.4 RPN Null
Message Format: BnH 64H 7FH
BnH 65H 7FH
n: MIDI Channel Number
Receive Receipt de-selects RPN.
8.20 All Sound Off (78H)
Message Format: BnH 78H 00H
n: MIDI Channel Number
Receive Receipt stops all voices that are sounding.
8.21 Reset All Controllers (79H)
Message Format: BnH 79H 00H
n: MIDI Channel Number
13

Receive Receipt initializes each performance controller.
8.22 All Notes Off (7BH)
Message Format: BnH 7BH 00H
n: MIDI Channel Number
Receive Receipt releases (key release) all voices that are sounding.
8.23 Omni Mode Off (All Notes Off) (7CH)
Message Format: BnH 7CH 00H
n: MIDI Channel Number
Receive Receipt performs the same operation as when All Notes Off is received.
8.24 Omni Mode On (All Notes Off) (7DH)
Message Format: BnH 7DH 00H
n: MIDI Channel Number
Receive Receipt performs the same operation as when All Notes Off is received.
8.25 Mono Mode On (Poly Mode Off) (All Notes Off) (7EH)
Message Format: BnH 7EH 00H
n: MIDI Channel Number
Receive Receipt performs the same operation as when All Notes Off is received.
8.26 Poly Mode On (Mono Mode Off) (All Notes Off) (7FH)
Message Format: BnH 7FH 00H
n: MIDI Channel Number
Receive Receipt performs the same operation as when All Notes Off is received.
9 Program Change
Message Format: CnH ppH
n: MIDI Channel Number
pp: Program Number (Note1)
Note1 :For details about the relationship between the program number and the tone, see the Tone List that comes with
the Instrument.
14

Transmit Sent when a tone is selected.
Receive Receipt changes the tone of the corresponding part. The selected tone is determined by the
program value of this message and the Bank Select message value received prior to this message. Also
note that receipt of this message also may change the Timbre Type that corresponds to the selected
tone. For more information, see “About the Timbre Type” below.
About the Timbre Type Tones that are selected by each Instrument part have an attribute that
depends on the sound source operation type. This attribute is called the “timbre type,” which is one of
the types described below.
•Melody
This timbre type optimizes for normal melody tones.
•Drum
This setting optimizes for drum sounds. The damper pedal does not function. The Hold1, Channel
Coarse Tune, and Master Coarse Tune messages are ignored if they are received.
10 Channel Pressure (Aftertouch)
Message Format: DnH vvH
n: MIDI Channel Number
vv: Value
Receive Receipt adds, to the tone being sounded, modulation of a depth specified by the value. In
the case of a tone that already has modulation applied, receipt of this message increases the modulation
depth. The modulation effect differs according to the tone being used.
11 Pitch Bend Change
Message Format: EnH llH mmH
n: MIDI Channel Number
ll: Value LSB
mm: Value MSB
Receive Receipt changes the pitch of the currently sounding note. The range of the pitch change
depends on the Pitch Bend Range value setting.
15

Part III
System Message
12 Active Sensing
Message Format: FEH
Receive Once this message is received, the Active Sensing mode is entered. If no MIDI message is
received for a specified amount of time, voices being sounded by this Instrument’s sound source are
released, the controller is reset, and the Active Sensing mode is exited.
13 System Exclusive Message
Message Format: F0H....F7H
The Instrument sends and receives universal system exclusive messages.
13.1 Universal Real Time System Exclusive Message
Message Format: F0H 7FH....F7H
13.1.1 Master Volume
Message Format: F0H 7FH 7FH 04H 01H llH mmH F7H
ll: LSB Value(Send:00H, Receive:Ignored)
mm: MSB Value
Receive Receipt changes the Master Volume.
13.1.2 Master Fine Tuning
Message Format: F0H 7FH 7FH 04H 03H llH mmH F7H
ll: LSB Value(Note1)
mm: MSB Value(Note1)
Note1 :For information about the relationship between setting values and send/receive values, see “14.4 Fine Tune Setting
Value Table” in “IV Setting Values and Send/Receive Values” of this document.
Transmit This message is sent when the Tuning setting is changed.
Receive Receipt changes the Master Fine Tuning.
13.1.3 Master Coarse Tuning
Message Format: F0H 7FH 7FH 04H 04H llH mmH F7H
ll: LSB Value(Send:00H, Receive:Ignored)
mm: MSB Value
16

Receive Receipt changes the Master Coarse Tune parameter. Does not affect sound source operation
when the Timbre Type (see “About the Timbre Type” in “9 Program Change”) is Drum.
13.1.4 Reverb Type
Message Format: F0H 7FH 7FH 04H 05H 01H 01H 01H 01H 01H 00H vvH F7H
vv: Value(Note1)
Note1 :For information about the relationship between setting values and send/receive values, see “14.5 Reverb Type
Setting Value Table” in “IV Setting Values and Send/Receive Values” of this document.
Transmit Sent when Reverb Type is changed.
Receive Receipt changes the Reverb Type.
13.2 Universal Non Real Time System Exclusive Message
Message Format: F0H 7EH 7FH....F7H
13.2.1 GM System On
Message Format: F0H 7EH 7FH 09H 01H F7H
Receive Receipt puts the sound source into a GM sound source mode.
13.2.2 GM System Off
Message Format: F0H 7EH 7FH 09H 02H F7H
Receive Receipt changes the sound source setting to the Instrument presetting.
13.2.3 GM2 System On
Message Format: F0H 7EH 7FH 09H 03H F7H
Receive Though the Instrument does not support GM2, receipt of the GM2 System On message has
the same result as receipt of the GM System On message.
17

Part IV
Setting Values and Send/ Receive Values
14 Setting Value Tables
14.1 Off/On Setting Value Table
Transmit Value Receive Value Parameter
00H 00H - 3FH Off
7FH 40H - 7FH On
14.2 –64 - 0 - +63 Setting Value Table
Transmit Value Receive Value Parameter
00H 00H -64
: : :
40H 40H 0
: : :
7FH 7FH +63
14.3 Pan Setting Value Table
Transmit Value Receive Value Parameter
00H 00H Left
: : :
40H 40H Center
: : :
7FH 7FH Right
14.4 Fine Tune Setting Value Table
Transmit Value Receive Value Parameter
(LSB, MSB) (LSB, MSB) - (LSB, MSB)
(43H, 00H) (00H, 00H) - (5FH, 00H) 415.5 Hz
(65H, 00H) (60H, 00H) - (7FH, 00H) 415.6 Hz
(07H, 01H) (00H, 01H) - (1FH, 01H) 415.7 Hz
(29H, 01H) (20H, 01H) - (3FH, 01H) 415.8 Hz
: : :
(40H, 3FH) (30H, 3FH) - (4FH, 3FH) 439.8 Hz
(60H, 3FH) (50H, 3FH) - (6FH, 3FH) 439.9 Hz
(00H, 40H) (70H, 3FH) - (1FH, 40H) 440.0 Hz
(20H, 40H) (20H, 40H) - (3FH, 40H) 440.1 Hz
(40H, 40H) (40H, 40H) - (5FH, 40H) 440.2 Hz
: : :
(54H, 7EH) (50H, 7EH) - (6FH, 7EH) 465.6 Hz
(73H, 7EH) (70H, 7EH) - (0FH, 7FH) 465.7 Hz
(11H, 7FH) (10H, 7FH) - (2FH, 7FH) 465.8 Hz
(30H, 7FH) (30H, 7FH) - (7FH, 7FH) 465.9 Hz
18

14.5 Reverb Type Setting Value Table
Transmit Value Receive Value Parameter
00H 00H Off
04H 04H Reverb 1
06H 06H Reverb 2
08H 08H Reverb 3
0BH 0BH Virtual Hall
14.6 Chorus Type Setting Value Table
Transmit Value Receive Value Parameter
00H 00H Chorus1
- 01H Chorus2
02H 02H Chorus3
03H 03H Chorus4
04H 04H FB Chorus
- 05H Flanger
19

Part V
MIDI Implementation Notation
15 Value Notation
15.1 Hexadecimal Notation
MIDI implementation sometimes requires that data be expressed in hexadecimal format. Hexadecimal
values are indicated by the letter “H” after the value. The hexadecimal equivalents of decimal values 10
through 15 are expressed as the letters A through F.
The table below shows the hexadecimal equivalents for decimal values 0 through 127, which are often
used in MIDI messages.
Decimal Hexadecimal Decimal Hexadecimal Decimal Hexadecimal Decimal Hexadecimal
0 00H 32 20H 64 40H 96 60H
1 01H 33 21H 65 41H 97 61H
2 02H 34 22H 66 42H 98 62H
3 03H 35 23H 67 43H 99 63H
4 04H 36 24H 68 44H 100 64H
5 05H 37 25H 69 45H 101 65H
6 06H 38 26H 70 46H 102 66H
7 07H 39 27H 71 47H 103 67H
8 08H 40 28H 72 48H 104 68H
9 09H 41 29H 73 49H 105 69H
10 0AH 42 2AH 74 4AH 106 6AH
11 0BH 43 2BH 75 4BH 107 6BH
12 0CH 44 2CH 76 4CH 108 6CH
13 0DH 45 2DH 77 4DH 109 6DH
14 0EH 46 2EH 78 4EH 110 6EH
15 0FH 47 2FH 79 4FH 111 6FH
16 10H 48 30H 80 50H 112 70H
17 11H 49 31H 81 51H 113 71H
18 12H 50 32H 82 52H 114 72H
19 13H 51 33H 83 53H 115 73H
20 14H 52 34H 84 54H 116 74H
21 15H 53 35H 85 55H 117 75H
22 16H 54 36H 86 56H 118 76H
23 17H 55 37H 87 57H 119 77H
24 18H 56 38H 88 58H 120 78H
25 19H 57 39H 89 59H 121 79H
26 1AH 58 3AH 90 5AH 122 7AH
27 1BH 59 3BH 91 5BH 123 7BH
28 1CH 60 3CH 92 5CH 124 7CH
29 1DH 61 3DH 93 5DH 125 7DH
30 1EH 62 3EH 94 5EH 126 7EH
31 1FH 63 3FH 95 5FH 127 7FH
15.2 Binary Notation
When a MIDI implementation data value is expressed in binary, the letter “B” (for “binary”) is affixed
at the end of the value. The table below shows the binary equivalents for the decimal values 0 through
127, which are often used for settings.
20
