1506/1507-2
•Seethedocumentation that comes with your cell phone forinformation about which
type it is.
•Module1507maynotbecompatiblewithcertainnon-GSMnetworkphone systems.
Paging Interval
Presettinga start time and end time definesthe “paging interval”.VIVCEL is activated
each day during the paging interval and deactivated outside the paging interval (as
long as VIVCEL is turned on). You can specify the hour only for these times, within
the range of 1 (1 o’clock) to 24 (midnight).
Telephone System
Digital cell phone
Analog cell phone
Digital/analog cell
phone switching
Watch Setting
DIGTL
ANLOG
DUAL
Telephone System
GSM network cell
phone
Non-GSM network
cell phone
Watch Setting
DIGTL
ANLOG
Module 1506 (AMPS compatible) Module 1507 (GSM compatible)
VIVCEL
The VIVCEL function performs a vibration paging operation when your cell phone
receives a call. The vibration paging operation lasts for up to 10 seconds, or until you
press any watch button.
VIVCEL Settings
The following explains the settings you need to make to use the VIVCEL functions.
See “To make VIVCEL settings” for details on actually making the settings.
Cell Phone System
VIVCEL can be used with cell phones only. It cannot be used with other (non-cell)
telephones.
Cell phone system compatibility depends on your watch’s “module” number, which
can be found on its back cover. The following shows telephone system compatibility
for each module.
To make VIVCEL settings
1. Hold down Awhile in the Timekeeping Mode until
the seconds digits start to flash on the display.
2. Press Lto display the cell phone system setting
screen.
•At this time the current cell phone system indicator
(DIGTL, ANLOG, or DUAL) flashes on the
display.
3. Press Ror Fto scroll through the available cell
phone system indicators until the one you want is
displayed.
4. Press Mto advancetothestarttimesettingscreen.
•At this time the current start time setting flashes on
the display.
5. Press Fto increase the time or Rto decrease it.
Holding down either button changes the start time
setting at high speed.
A
L
REV FWD
MODE
24
DST
VIB
P
P
FMR
24
DST
VIB
P
P
Sensitivity
The VIVCEL paging function operates by picking up signals from your cell phone.
The sensitivity setting determines how close a cell phone has to be from the watch for
it to pick up these signals.
Watch Setting
HIGH
LOW
Approximate Distance
1 meter (40 inches)
50 centimeters (20 inches)
When to use
When your phone is in a pocket that is
away from the watch.
When your phone is located near the
watch.
When there are other cell phone users
nearby.
To turn VIVCEL on and off
In the Timekeeping Mode, hold down Ffor about
one second to toggle VIVCEL on ( displayed in the
animation area) and off ( displayed).
•When VIVCEL is turned off, the animation area
shows a sleeping figure ( ).
•While VIVCEL is turned on, it becomes activated
when the current time is within the paging interval
defined by the VIVCEL start and end times. The
animation area of the display shows a moving
antennafigure( )and is displayed while VIVCEL
is activated. Outside the paging interval defined by
the VIVCEL start and end times, VIVCEL is
deactivated and the animation area of the display
shows a non-moving antenna figure ( ).
6. PressMtoadvanceto the end time setting screen.
•At this time the current end time setting flashes on
the display.
7. Press Fto increase the time or Rto decrease it.
Holding down either button changes the end time
setting at high speed.
8. Press Mto advance to the sensitivity setting
screen.
•At this time the current sensitivity setting flashes on
the display.
9. Press Ror Fto toggle between the sensitivity
settings.
10. After you make the settings you want, press Ato return to the Timekeeping
Mode.
•Pressing Minstead of Areturns to the screen in step 2.
•If you do not operate any button for a few minutes while a selection is flashing, the
watch goes back to the Timekeeping Mode automatically.
24
DST
VIB
P
P
24
DST
VIB
P
P
A
L
REV FWD
MODE
24
DST
VIB
P
P
FMR
Animation area
Start time
Manual VIVCEL Activation
Press Rin the Timekeeping Mode to add two to the current paging interval hour and
round the minutes digits to zero. This means that if it is 10:58 p.m. when you press
R, the paging interval is extended up to 00:00 a.m. Each press of Radds two
hours, up to a total of eight hours.
•Pressing Rwhile VIVCEL is deactivated (outside the paging period), activates
VIVCEL. The watch vibrates when VIVCEL is activated.
•The Rbutton can be used to extend the paging interval for up to eight hours (four
Rbutton operations).
•Any extension of the paging interval with the Rbutton is automatically cancelled
whenever you turn off VIVCEL or change any of its settings.
VIVCEL Precautions
•Since VIVCEL operates by picking up signals from your cell phone, a paging
operationmayalsobe triggered by an outgoing call or evenwhileacallisinprogress.
A paging operation can also be triggered by another cell phone or other device
operating on the same frequency as your cell phone.
•Anyof the followingconditionscancause interferencewithVIVCELpaging operations.
Obstruction between the watch and cell phone
Sensitivity set to
LOW
while the watch is located away from the cell phone
Use with a non-compatible telephone system
•Frequent use of VIVCEL paging can shorten battery life.
•Turn off VIVCEL before operating a motor vehicle or bicycle to avoid the
chance of accident caused by a paging operation while operating a vehicle.
VIVCEL Operation Note that for VIVCEL to operate correctly, it must be
turned on (by holding down F) and activated (the
current time is within the paging interval defined by
the VIVCEL start and end times).
•Pressing Ain the Timekeeping Mode toggles the
animation area between the day of the week and
the paging interval.
•The paging interval is indicated by a bar graph in
the animation area. The nearby illustration indicates
a paging interval of 10 am to 11 pm.
•VIVCEL automatically activates and deactivates
during the defined paging interval.
A
L
REV FWD
MODE
24
DST
VIB
P
P
FMR
6
012
Paging Interval
Current time (flashing)
AM
PM
WORLD TIME MODE
The World Time Mode shows the current time in 27
cities (29 time zones) around the world.
Timekeeping in the World Time Mode
The current time in all the World Time zones is
calculated in accordance with the Greenwich Mean
Time (GMT) differential for each zone, based on the
current home time setting in the Timekeeping Mode.
You can also turn Daylight Saving Time (DST) on or
off separately for each time zone. Turning on daylight
savingtimeautomatically advances the corresponding
time setting by one hour.
•Thesecondscount of the WorldTimeissynchronized
with the seconds count in the Timekeeping Mode.
•The12-hour/24-hour format of the World Timematches theformat youselect in the
Timekeeping Mode.
•With daylight saving time, clocks are set one hour forward in order to better take
advantage of daylight hours during the summer, when days are longer. Whether or
not daylight saving time is used depends on the country you are in.
To view the Time in Another Zone
Press Fwhile in the World Time Mode to scroll forward through the city codes (time
zones) and Rto scroll back.
•Holding down either button scrolls through the city codes at high speed.
•For full information on city codes, see the “CITY CODE TABLE” at the back of this
manual.
•The time zone that is displayed when you leave the World Time Mode will still be
displayed when you enter the World Time Mode again.
A
L
REV FWD
MODE
FMR
24
DST
VIB
P
P
City code
Current time in
the selected city
Current time
