Chapter1 Preview
1.1 About This Manual
This manual contains all necessary information for configuration and testing of CAR-5050. The CAR-5050 is based on
the Intel® Skylake-SP series processors. If there is any information not included, please contact your sales person at
CASwell.
1.2 Audiences
This manual is intended for use by engineers who are evaluating and developing applications on CAR-5050 platform.
1.3 Contents Descriptions
This manual describes how to configure the CAR-5050 to meet various operating requirement, which is organized as
follows:
Chapter 1: Preview. This chapter provides an overview of this manual and contact information of customer support.
Chapter 2: Introduction. This chapter provides an overview of the components in the CAR-5050, detail of features,
and a description of the development environment.
Chapter 3: Hardware dismantling procedures. This chapter shows the procedures for how to dismantle the
hardware.
Chapter 4: BIOS Settings. This chapter introduces the functions and settings of CAR-5050 BIOS menu.
1.4 Technical or Customer Support
You can reach CASwell customer support in the following ways:
Visit the CASwell web site at http://www.cas-well.com/
E-mail your questions to [e-mail]

CAR-5050 Series User`s Manual
http://www.cas-well.com
Tel: [phone] Fax: [phone] E-mail: info@ cas-well.com
Address: 8F, No. 242, Bo-Ai St., Shu-Lin Dist., New Taipei City 238, Taiwan.
6
Chapter2 Introduction
2.1 Processor and chipset Overview
Built upon the functionality and the capability of the Intel® Skylake-SP processors, the CAPB-5050 provides the
performance and feature required for high-end server & carrier-grade platform.
2.2 Motherboard Features
2.2.1 System Hardware Specification
Product Name
CAR-5050
Intel® Purley Skylake-SP Platform, Support up to 48 SFP+ Fiber Port
Features
Intel Purley Skylake-SP platform
16x DDR4 ECC RDIMMs up to 2666MHz
Up to 6 front-access NIC module supported
RPSU, Smart LEDs, N+1 Fans solution, IPMI, System thermal integrate solution.
ICON(參考附件)
5,6,11,12,14,15,31,45,46,57,62,72,73
Specification
CPU
Intel® Xeon Scalable Processor-Purley
PCH/Chipset
Intel® Lewisburg C621 PCH
System Memory
16 DDR4 ECC RDIMMs up to 2666MHz
Ethernet Port
Up to 48 SFP+ Fiber Port
Bypass
Based on CASwell NIC Module or Standard add-on card
Expansion
Up to 5 PCIe Gen3 x 16 for CASwell NIC Module
Up to 1 PCIe Gen3 x 8 for CASwell NIC Module
Up to 1 PCIe Gen3 x 8 for Standard NIC Module
Storage Device
2x 3.5”or2.5”Swappable SATA/SAS HDDs
CF Socket
M.2 SSD 2280(PCIe)

CAR-5050 Series User`s Manual
http://www.cas-well.com
Tel: [phone] Fax: [phone] E-mail: info@ cas-well.com
Address: 8F, No. 242, Bo-Ai St., Shu-Lin Dist., New Taipei City 238, Taiwan.
7
Dimension
465(W) x 594(D) x 89(H)mm
18.31''(W) x 21.02''(D) x 3.5''(H)
Front Panel
Serial Port
Front-access RJ45 system console with micro USB for backup
LCD Panel
128x32/64 Graphic,2x16 Characters
LED
HDD/ Ethernet/ Customization LED
USB
Dual USB 3.0
VGA
Optional from LOM or VGA module
LOM
IPMI 2.0 w/ GbE speed
Power
800W CRPS Redundant PSU
Operation
Operating Environment
Temp: 0 to 40°C (32 to 104°F)
20 to 90%RH
Storage Environment
Temp: -10 to 70°C (14 to 158°F)
5 to 95%RH @ 55°C
Certification
CE/FCC/UL
OS Support
Linux Kernel
Option CPU
Model
Cores/ Threads
Frequency
Cache
TDP
Intel® Xeon® SP Platinum 8180
28C/56T
2.5GHz
38.5MB
205W
Intel® Xeon® SP Platinum 8176
28C/56T
2.1GHz
38.5MB
165W
Intel® Xeon® SP Platinum 8160T
24C/48T
2.1GHz
33MB
150W
Intel® Xeon® SP Gold 6138/6138T
20C/40T
2.0GHz
27.5MB
125W
Intel® Xeon® SP Gold 6130/6130T
16C/32T
2.1GHz
22MB
125W
Intel® Xeon® SP Gold 6126/6126T
12C/24T
2.6GHz
19.25MB
125W
Intel® Xeon® SP Gold 5120/5120T
14C/28T
2.2GHz
19.25MB
105W
Intel® Xeon® SP Gold 5119T
14C/28T
1.9GHz
19.25MB
85W
Intel® Xeon® SP Gold 5118
12C/24T
2.3GHz
16.5MB
105W
Intel® Xeon® SP Silver 4116/4116T
12C/24T
2.1GHz
16.5MB
85W
Intel® Xeon® SP Silver 4114/4114T
10C/20T
2.2GHz
13.75MB
85W
Intel® Xeon® SP Silver 4110
8C/16T
2.1GHz
11MB
85W

CAR-5050 Series User`s Manual
http://www.cas-well.com
Tel: [phone] Fax: [phone] E-mail: info@ cas-well.com
Address: 8F, No. 242, Bo-Ai St., Shu-Lin Dist., New Taipei City 238, Taiwan.
8
Intel® Xeon® SP Silver 4109T
8C/16T
2.0GHz
11MB
70W
Intel® Xeon® SP Bronze 3106
8C/8T
1.7GHz
11MB
85W
2.2.2 System Block Diagram
2.3 Jumper Setting
CAPB-5050
˙Components Map
TOP Layer

CAR-5050 Series User`s Manual
http://www.cas-well.com
Tel: [phone] Fax: [phone] E-mail: info@ cas-well.com
Address: 8F, No. 242, Bo-Ai St., Shu-Lin Dist., New Taipei City 238, Taiwan.
9
CPU SOCKET
U45
CPU0
U46
CPU1
DIMM SOCKET
CPU0

CAR-5050 Series User`s Manual
http://www.cas-well.com
Tel: [phone] Fax: [phone] E-mail: info@ cas-well.com
Address: 8F, No. 242, Bo-Ai St., Shu-Lin Dist., New Taipei City 238, Taiwan.
10
J15
CPU 0, CH A DIMM0
J18
CPU 0, CH D DIMM0
J16
CPU 0, CH A DIMM1
J17
CPU 0, CH D DIMM1
J14
CPU 0, CH B DIMM0
J19
CPU 0, CH E DIMM0
J13
CPU 0, CH C DIMM0
J20
CPU 0, CH F DIMM0
CPU1
J23
CPU 1, CH G DIMM0
J26
CPU 1, CH K DIMM0
J24
CPU 1, CH G DIMM1
J25
CPU 1, CH K DIMM1
J22
CPU 1, CH H DIMM0
J27
CPU 1, CH L DIMM0
J21
CPU 1, CH J DIMM0
J28
CPU 1, CH M DIMM0
Jumper & Connector List
Connector
Function
Remark
JP9
NMI Button
˙Open★
JP10
Watchdog Timer Reset
˙1-2：Enable★
˙Open：Disable
JP11
Auto Power Button
˙1-2：Enable★
˙Open：Disable
JP17
CMOS Clear Jumper
˙1-2：Clear RTC Register
˙2-3：Normal★
J1/J2/J3/J4
FAN module Slots
J5/J6/J7/J8
FAN Headers
J11/J12
CPU Power connector
J29
PMBus Connector
J30
PCH SMBus Connector
J32
Debug Port
J35
GPIO Header
J36
VGA Header
J37
IPMI connector
J39
ATX 24 pin Connector
J40
CPU0 Fan Header
J41
CPU1 Fan Header
J43
SATA Port 1 (6Gb/s) or SATA DOM
J44
SATA Port 0 (6Gb/s)
J45
TPM Header
J48
SATA Port 2 (6Gb/s)
J49
M.2 PCIex4 Connector

CAR-5050 Series User`s Manual
http://www.cas-well.com
Tel: [phone] Fax: [phone] E-mail: info@ cas-well.com
Address: 8F, No. 242, Bo-Ai St., Shu-Lin Dist., New Taipei City 238, Taiwan.
11
J50
SATA Port 3 (6Gb/s)
J54/J57/J58
NIP Module Fan
J55/J56
Upper Layer NIP Connector
J59
USB3.0 Header
J62
PCI-E Slot C x16 (CASwell NIP)-CPU0
J63
PCI-E Slot E x16 (CASwell NIP)-CPU1
J64
PCI-E Slot G x16 (CASwell NIP)-CPU1
J65/J76
Manager Board Slot
J77
BT module Header
BAT1
Battery
BZ1
Buzzer
U85
PCH (C621)
ATX1/2
Power Connector
U71
BIOS 0 Socket
U72
BIOS 1 Socket
(Default Setting:“★”)
˙Pin Header definition
J29/J30：PMBus / PCH SMBus Connector
1 2 3 4 5

CAR-5050 Series User`s Manual
http://www.cas-well.com
Tel: [phone] Fax: [phone] E-mail: info@ cas-well.com
Address: 8F, No. 242, Bo-Ai St., Shu-Lin Dist., New Taipei City 238, Taiwan.
12
Pin No.
Signal Description
1
CLOCK
2
DATA
3
ALERT
4
GND
5
3.3V
J32：Debug Port
Pin No.
Signal Description
Pin No.
Signal Description
1
LPC_LAD0
2
P3V3
3
LPC_LAD1
4
RST_PLTRST_B_N
5
LPC_LAD2
6
LPC_FRAME_N
7
LPC_LAD3
8
CLK_33M
9
NC
10
GND
J40：CPU0 Fan
J41：CPU1 Fan
1 2 3 4
Pin No.
Signal Description
1
GND
2
12V
3
NO SENSE Function
4
NC
J36：VGA
2 4 6 8 10
1 3 5 7 9
Pin No.
Signal Description
Pin No.
Signal Description
1
RED
2
DDC_CLOCK

CAR-5050 Series User`s Manual
http://www.cas-well.com
Tel: [phone] Fax: [phone] E-mail: info@ cas-well.com
Address: 8F, No. 242, Bo-Ai St., Shu-Lin Dist., New Taipei City 238, Taiwan.
13
3
GREEN
4
GND
5
BLUE
6
DDC_DATA
7
V-SYNC
8
GND
9
H-SYNC
10
NC
J45：TPM
2 4 6 8 10 12 14 16 18 20
1 3 5 7 9 11 13 15 17 19
Pin No.
Signal Description
Pin No.
Signal Description
1
TPM_CLK
2
GND
3
LFRAME#
4
NC
5
TPM_RESET#
6
5V
7
LAD3
8
LAD2
9
VCC3
10
LAD1
11
LAD0
12
GND
13
SMB_CLK
14
SMB_DATA
15
3VSB
16
SERIRQ
17
GND
18
GND
19
3VSB
20
LDRQ#1
J54/J57/J58：NIP Module Fan
1 2 3
Pin No.
Signal Description
1
GND
2
12V
3
NC
J7/J8/J5/J6：Smart Fan
1 2 3

CAR-5050 Series User`s Manual
http://www.cas-well.com
Tel: [phone] Fax: [phone] E-mail: info@ cas-well.com
Address: 8F, No. 242, Bo-Ai St., Shu-Lin Dist., New Taipei City 238, Taiwan.
14
Pin No.
Signal Description
1
GND
2
PWM Control
3
Sense
J59：USB3.0
1 2 3 4 5 6 7 8 9 10
20 19 18 17 16 15 14 13 12 11
Pin No.
Signal Description
Pin No.
Signal Description
20
KEY
1
+5V
19
+5V
2
SSRX2_N
18
SSRX1_N
3
SSRX2_P
17
SSRX1_P
4
GND
16
GND
5
SSTX2_N
15
SSTX1_N
6
SSTX2_P
14
SSTX1_P
7
GND
13
GND
8
D1_N
12
D2_N
9
D1_P
11
D2_P
10
GND
J35：GPIO
2 4 6 8 10
1 3 5 7 9
Pin No.
Signal Description
Pin No.
Signal Description
1
GP67
2
GP60
3
GP66
4
GP61
5
GP65
6
GP62

CAR-5050 Series User`s Manual
http://www.cas-well.com
Tel: [phone] Fax: [phone] E-mail: info@ cas-well.com
Address: 8F, No. 242, Bo-Ai St., Shu-Lin Dist., New Taipei City 238, Taiwan.
15
7
GP64
8
GP63
9
GND
10
3.3V
ATX1/2：Power Connector
1 2 3 4
Pin No.
Signal Description
1
12V
2
GND
3
GND
4
5V
CB-5050-2
˙Components Map
TOP Layer
Jumper & Connector List
Connector
Function
Remark
J4
Power connector
J7
PCI-E Slot B x16 (CASwell NIP)-CPU0
J8
PCI-E Slot D x16 (CASwell NIP)-CPU0
J9
PCI-E Slot F x16 (CASwell NIP)-CPU0
J10/J11
Board to Board Connector
ABM-5050-0

CAR-5050 Series User`s Manual
http://www.cas-well.com
Tel: [phone] Fax: [phone] E-mail: info@ cas-well.com
Address: 8F, No. 242, Bo-Ai St., Shu-Lin Dist., New Taipei City 238, Taiwan.
16
˙Components Map
TOP Layer
BOT Layer

CAR-5050 Series User`s Manual
http://www.cas-well.com
Tel: [phone] Fax: [phone] E-mail: info@ cas-well.com
Address: 8F, No. 242, Bo-Ai St., Shu-Lin Dist., New Taipei City 238, Taiwan.
17
˙Jumper & Connector List
Connector
Function
Remark
J3
Standard PCIe x8 Slot
J4
CF Slot
J5
COM2 Header
J6
COM2 Slot
J7
USB 3.0 Connector
J8
USB 3.0 Connector
J9
Management Port 01 RJ45
J10
Management Port 02 RJ45
J11
IPMI connector ( RJ45 Interface )

CAR-5050 Series User`s Manual
http://www.cas-well.com
Tel: [phone] Fax: [phone] E-mail: info@ cas-well.com
Address: 8F, No. 242, Bo-Ai St., Shu-Lin Dist., New Taipei City 238, Taiwan.
18
J12
Consol port ( RJ45 Interface )
J14
Micro-USB Console Port
D15
Customized LED
Green / Red
D16
Customized LED
Green / Red
D17
Customized LED
Green / Red
SW1
Power Button
SW2
Reset Button / Reset to default
˙TOP-Reset Button
˙BOT-Reset to default
(Default Setting:“★”)
˙Pin Header definition
J5：COM2 Pin Header
Pin
Signal Name
Pin
Signal Name
1
GND
2
NC
3
C2_SIN
4
NC
5
C2_SOUT
6
NC
7
VCC
8
NC
9
NC
10
NC
Chapter3 HardwareInstallationProcedures
3.1 The Chassis
The system is integrated in a customized 2U chassis . on the front panel you will find , two LAN port , two types
of console port(default baud rate 115200), two USB ports, one IPMI port, one NIC module, and six LAN module
slot.

CAR-5050 Series User`s Manual
http://www.cas-well.com
Tel: [phone] Fax: [phone] E-mail: info@ cas-well.com
Address: 8F, No. 242, Bo-Ai St., Shu-Lin Dist., New Taipei City 238, Taiwan.
19
CAR-5050 Front view of the chassis
CAR-5050 Rear view of the chassis

CAR-5050 Series User`s Manual
http://www.cas-well.com
Tel: [phone] Fax: [phone] E-mail: info@ cas-well.com
Address: 8F, No. 242, Bo-Ai St., Shu-Lin Dist., New Taipei City 238, Taiwan.
20
3.2 Open The Chassis
1. Loosen the 12 screws of the chassis.
Take off screws
2. The top lead can be removed from the base stand
