NetApp E Series Manual

Complete System Setup and Configuration | 4
Cable the Data Hosts
Cable the system according to your network topology.
Direct-attach topology
Option
NOT using the SANtricity Quick Connect Utility
(manual management port configuration)
Option
Connect each host adapter directly to the host ports on the controllers.
IP address: 192.168.128.101
IP address: 192.168.128.100
Subnet mask: 255.255.255.0
NOTE: If you are using AIX®, you must install the E-Series multipath driver on
the host before connecting it to the array.
Using an Ethernet cable, connect to controller A port 1 (P1).
to the ethernet port on your laptop.


Manually specify the following IP address and subnet mask on the laptop’s
Ethernet port that you have physically connected to the storage array:
2
Fabric topology
Option Connect each host adapter directly to the switch.
Connect each switch directly to the host ports on the controllers.

2
Connect and Configure the Management Connection
Option
Using the SANtricity Quick Connect Utility
(automated management port configuration)
In a compatible web browser, navigate to mysupport.netapp.com/quickconnect
to download the Quick Connect Utility. (User account required.)
NOTE: Do not use P2 port. This port is reserved for NetApp technical support.
NOTE: When configuring the Quick Install utility for the first time, enter the user name "admin"
and a password of your choosing.

Use an Ethernet cable to connect your controller’s P1 port to the network.
2
Use the laptop’s browser to access the storage array’s management software
using the following IP address:
3
After Installing the Hardware
Use the SANtricity software to configure and manage your storage arrays.

In the simplest network configuration, connect your controller to a web browser and use
SANtricity System Manager for managing a single E2800 or E5700 series storage array.
2
In a more complex environment, install the client package in SANtricity
Storage Manager and use the Enterprise Management Window (EMW) for
managing multiple storage arrays.
3
In the management software, go to the Hardware tab and select Show back
of shelf under Controller Shelf. Highlight controller B, and then select
Configure management ports to set the IP addresses for management
port 1 on controller B. Do not configure management port 2. This port is
reserved for NetApp technical support. After you have configured controller
B’s management port, repeat for controller A.
4
Disconnect your laptop from the storage array and connect an Ethernet
cable to management port 1 (labeled P1) on each E2800 or E5700 controller
and connect the other end to your network.
5

0a 0b
P1 P2
EXP1 EXP2
P1 P2
NetApp Inc.
1395 Crossman Ave.
Sunnyvale CA, 94089 U.S.A.
Telephone: [phone]
Fax: [phone]
Support Telephone: [phone]
Comments: [e-mail]
Copyright © 2018
NetApp Inc.
All rights reserved.
E5700 controller
E2800 controller
Prepare for Installation | 1
In the box
You provide
Resources
Create an account and register your hardware at mysupport.netapp.com.
Inventory cables and make note of the quantity.
Confirm that your location provides 240V AC power.
E-Series E2860, E5760
and DE460C Shelves
Installation and Setup Instructions
Shelf, bezel, and
rackmount hardware
Shelf handles
A supported browser
for the management
software
I/O cables
if ordered
Ethernet cables
if ordered
SAS cables
included only with
the drive shelves
Power cables
two for each shelf
× 4
Phillips №2 screwdriver,
flashlight, and ESD strap
Hardware Universe
hwu.netapp.com
Quick Connect Utility
mysupport.netapp.com/quickconnect
4U rack space
4U
A 19 in. (48.30 cm)
rack to fit 4U shelves of the
following dimensions:
Max Weight: 250 lb. (113 kg)
Depth: 38.25 in (97.16 cm)
Width: 17.66 in. (44.86 cm)
Height: 6.87 in. (17.46 cm)
NetApp Interoperability Matrix
mysupport.netapp.com/matrix
210-06769+A0
Prepare for Installation Install Hardware Connect the Cables Complete System Setup
and Configuration 4321
№2
Cabling Guide
http://docs.netapp.com/ess-11/topic/
com.netapp.doc.e-hw-cabling/home.html
E-Series Documentation Center
https://docs.netapp.com/ess-11/topic/
com.netapp.nav.siu/

Install Hardware | 2
Unpack the Hardware
Unpack the contents and inventory the contained hardware against
the packing slip. Read through all the instructions before proceeding.
Install the Rails
See the enclosed document,
Installing SuperRail into a four-post rack
for instructions on how to install the rails.
NOTE: For square hole cabinets, you must first
install the provided cage nuts to secure the front
and rear of the shelf with screws.
Install the Shelf
Secure the Shelf
Insert screws into the first and third holes from
the top of the shelf on both sides to secure it to
the front of the cabinet.
Place two back brackets on each side of the
upper rear section of the shelf. Insert screws
into the first and third holes of each bracket to
secure the back of the cabinet.
Install the Drives
Starting at the front left slot of the top drawer, install each drive by gently
positioning into the drive slot and lowering the raised drive handle until it
clicks into place.
Wrap the strap end of the ESD wristband around your wrist, and
secure the clip end to a metal ground to prevent static discharges.
NOTE: If you are installing fewer than 60 drives, if you have
solid-state drives (SSDs), or if your drives have dierent capacities:
Maintain a minimum of 20 drives per shelf. Install drives in the front four
slots in each drawer first, for adequate airflow for cooling.
Distribute any remaining drives across the drawers. If possible, install an equal
number of each type of drive in each drawer to allow for the creation of
Drawer Loss Protected volume groups or disk pools.
Distribute any SSDs evenly across the drawers.
Supporting the shelf from the bottom, slide it into the
cabinet. If the lift handles are used, remove them one
set at a time as the shelf slides into the cabinet.
To remove the handles, pull back on the release latch,
push down, then pull away from the shelf.
If lifting the shelf by hand, attach the four lift handles.
Push up on each handle until it clicks into place.
4
Person
Team Lift
CAUTION: An empty shelf weighs approximately
132 lb (60 kg). A mechanized lift or four people using lift
handles are required to safely move an empty shelf.





2
Carefully slide the drawer back in by pushing the center
and gently closing both latches.
3
Attach the front bezel.
4
Connect the Cables | 3
0a 0b
P1 P2
EXP1 EXP2
0c 0d 0f 0e
0a 0b
P1 P2
EXP1 EXP2
0c 0d 0f 0e
21 43
21 43
Example A: An E2860 controller shelf with two DE460C disk shelves in a standard SAS configuration
Example B: An E2860 controller shelf with one DE460C disk shelf in a standard SAS configuration
Example: Power connections are on the rear of the shelf.
Cable the Shelves
Cable the system according to your configuration.
Examples are shown in this section. For more cabling
options, see Cabling E-Series Hardware.
Power the Drive Shelves
Example
Cable a controller shelf and
two drive shelves
docs.netapp.com/ess-11/index.jsp
Storage cables
Cable a controller shelf and
one drive shelf
Cable controller A to IOM A of the first drive shelf.

Cable IOM A of the first drive shelf to IOM A of the
second drive shelf.

Cable IOM B of the first drive shelf to IOM B of the
second drive shelf.
3
Cable controller B to IOM B of the second
drive shelf.
4
CAUTION: Confirm the drive shelf power switches are o.
Turn on the two power switches on the controller shelf.
Check the LEDs and seven-segment display on each controller.
During boot, the seven-segment display shows the repeating
sequence of OS, Sd, blank to indicate the controller is
performing start-of-day processing. After the controller
has booted up, the shelf ID is displayed.
Connect the two power cables for each shelf to dierent
power distribution units (PDUs) in the cabinet or rack.
If you have drive shelves, turn on their two power switches
first. Wait 2 minutes before applying power to the
controller shelf.

2
3
4
| Power Cables
0a 0b
P1 P2
EXP1 EXP2
0c 0d 0f 0e
0a 0b
P1 P2
EXP1 EXP2
0c 0d 0f 0e
21 43
21 43
21 43
21 43

2
3
4

2
Example Storage cables
Cable controller A to IOM A.

Cable controller B to IOM B.


2
3
4
5
ATTENTION: Risk of equipment damage — Stop
pushing the drawer if you feel binding. Use the release
levers at the front of the drawer to slide the drawer
back out. Then, carefully reinsert the drawer into the slot.
