Kontron KISS 2U V4 ADL User manual


USER GUIDE
www.kontron.com
KISS 2U V4 ADL
Doc. User Guide, Rev.1.0
Doc. ID: 1070-2163

KISS 2U V4 ADL - User Guide, Rev.1.0
www.kontron.com // 2
This page has been intentionally left blank

KISS 2U V4 ADL - User Guide, Rev.1.0
www.kontron.com // 3

KISS 2U V4 ADL
- USER GUIDE
Disclaimer
Kontron would like to point out that the information contained in this user guide may be subject to alteration,
particularly as a result of the constant upgrading of Kontron products. This document does not entail any guarantee on
the part of Kontron with respect to technical processes described in the user guide or any product characteristics set
out in the user guide. Kontron assumes no responsibility or liability for the use of the described product(s), conveys no
license or title under any patent, copyright or mask work rights to these products and makes no representations or
warranties that these products are free from patent, copyright or mask work right infringement unless otherwise
specified. Applications that are described in this user guide are for illustration purposes only. Kontron makes no
representation or warranty that such application will be suitable for the specified use without further testing or
modification. Kontron expressly informs the user that this user guide only contains a general description of processes
and instructions which may not be applicable in every individual case. In cases of doubt, please contact Kontron.
This user guide is protected by copyright. All rights are reserved by Kontron. No part of this document may be
reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any language or computer
language, in any form or by any means (electronic, mechanical, photocopying, recording, or otherwise), without the
express written permission of Kontron. Kontron points out that the information contained in this user guide is
constantly being updated in line with the technical alterations and improvements made by Kontron to the products and
thus this user guide only reflects the technical status of the products by Kontron at the time of publishing.
Brand and product names are trademarks or registered trademarks of their respective owners.
©2023 by Kontron Europe GmbH
Kontron Europe AG
Gutenbergstraße 2
85737 Ismaning
Germany
www.kontron.com

KISS 2U V4 ADL - User Guide, Rev.1.0
www.kontron.com // 4
Intended Use
THIS DEVICE AND ASSOCIATED SOFTWARE ARE NOT DESIGNED, MANUFACTURED OR INTENDED FOR USE
OR RESALE FOR THE OPERATION OF NUCLEAR FACILITIES, THE NAVIGATION, CONTROL OR
COMMUNICATION SYSTEMS FOR AIRCRAFT OR OTHER TRANSPORTATION, AIR TRAFFIC CONTROL, LIFE
SUPPORT OR LIFE SUSTAINING APPLICATIONS, WEAPONS SYSTEMS, OR ANY OTHER APPLICATION IN A
HAZARDOUS ENVIRONMENT, OR REQUIRING FAIL-SAFE PERFORMANCE, OR IN WHICH THE FAILURE OF
PRODUCTS COULD LEAD DIRECTLY TO DEATH, PERSONAL INJURY, OR SEVERE PHYSICAL OR
ENVIRONMENTAL DAMAGE (COLLECTIVELY, "HIGH RISK APPLICATIONS").
You understand and agree that your use of Kontron devices as a component in High Risk Applications is entirely at
your risk. To minimize the risks associated with your products and applications, you should provide adequate design
and operating safeguards. You are solely responsible for compliance with all legal, regulatory, safety, and security
related requirements concerning your products. You are responsible to ensure that your systems (and any Kontron
hardware or software components incorporated in your systems) meet all applicable requirements. Unless otherwise
stated in the product documentation, the Kontron device is not provided with error-tolerance capabilities and cannot
therefore be deemed as being engineered, manufactured or setup to be compliant for implementation or for resale as
device in High Risk Applications. All application and safety related information in this document (including application
descriptions, suggested safety measures, suggested Kontron products, and other materials) is provided for reference
only.
You find the most recent version of the “General Safety Instructions“ online in the download
area of this product.
This product is not suited for storage or operation in corrosive environments, in particular
under exposure to sulfur and chlorine and their compounds. For information on how to
harden electronics and mechanics against these stress conditions, contact Kontron Support.

KISS 2U V4 ADL - User Guide, Rev.1.0
www.kontron.com // 5
Revision History
Revision Brief Description of Changes Date of Issue Author/
Editor
1.0 Initial version 2023-Aug-11 CW
Terms and Conditions
Kontron warrants products in accordance with defined regional warranty periods. For more information about
warranty compliance and conformity, and the warranty period in your region, visit http://www.kontron.com/terms-
and-conditions.
Kontron sells products worldwide and declares regional General Terms & Conditions of Sale, and Purchase Order Terms
& Conditions. Visit http://www.kontron.com/terms-and-conditions.
For contact information, refer to the corporate offices contact information on the last page of this user guide or visit
our website CONTACT US.
Customer Support
Find Kontron contacts by visiting: http://www.kontron.com/support.
Customer Service
As a trusted technology innovator and global solutions provider, Kontron extends its embedded market strengths into
a services portfolio allowing companies to break the barriers of traditional product lifecycles. Proven product expertise
coupled with collaborative and highly-experienced support enables Kontron to provide exceptional peace of mind to
build and maintain successful products.
For more details on Kontron’s service offerings such as: enhanced repair services, extended warranty, Kontron training
academy, and more visit https://www.kontron.com/support-and-services/services.
Customer Comments
If you have any difficulties using this user guide, discover an error, or just want to provide some feedback, contact
Kontron Support. Detail any errors you find. We will correct the errors or problems as soon as possible and post the
revised user guide on our website.

KISS 2U V4 ADL - User Guide, Rev.1.0
www.kontron.com // 6
Symbols
The following symbols may be used in this user guide
DANGER indicates a hazardous situation which, if not avoided,
will result in death or serious injury.
WARNING indicates a hazardous situation which, if not avoided,
could result in death or serious injury.
NOTICE indicates a property damage message.
CAUTION indicates a hazardous situation which, if not avoided,
may result in minor or moderate injury.
Electric Shock!
This symbol and title warn of hazards due to electrical shocks (> 60
V) when touching
products or parts of products. Failure to observe the precautions indicated and/or prescribed
by the law may endanger your life/health and/or result in damage to your material.
ESD Sensitive Device!
This symbol and title informs
that the electronic boards and their components are sensitive
to static electricity. Care must therefore be taken during all handling operations and
inspections of this product in order to ensure product integrity at all times.
HOT Surface!
Do NOT touch! Allow to cool before servicing.
Laser!
This symbol informs of the risk of exposure to laser beam and light emitting devices (LEDs)
from an electrical device. Eye protection per manufacturer notice shall review before
servicing.
This symbol indicates general information about the product and the user guide.
This symbol also indicates detail information about the specific product configuration.
This symbol precedes helpful hints and tips for daily use.

KISS 2U V4 ADL – User Guide, Rev.1.0
www.kontron.com
For Your Safety
Your new Kontron product was developed and tested carefully to provide all features necessary to ensure its
compliance with electrical safety requirements. It was also designed for a long fault-free life. However, the life
expectancy of your product can be drastically reduced by improper treatment during unpacking and installation.
Therefore, in the interest of your own safety and of the correct operation of your new Kontron product, you are
requested to conform with the following guidelines.
High Voltage Safety Instructions
As a precaution and in case of danger, the power connector must be easily accessible. The power connector is the
product’s main disconnect device.
Warning
All operations on this product must be carried out by sufficiently skilled personnel only.
Electric Shock!
Before installing a non hot-swappable Kontron product into a system always ensure that
your mains power is switched off. This also applies to the installation of piggybacks. Serious
electrical shock hazards can exist during all installation, repair, and maintenance operations
on this product. Therefore, always unplug the power cable and any other cables which
provide external voltages before performing any work on this product.
Earth ground connection to vehicle’s chassis or a central grounding point shall remain
connected. The earth ground cable shall be the last cable to be disconnected or the first
cable to be connected when performing installation or removal procedures on this product.
Special Handling and Unpacking Instruction
ESD Sensitive Device!
Electronic boards and their components are sensitive to static electricity. Therefore, care
must be taken during all handling operations and inspections of this product, in order to
ensure product integrity at all times.
Handling and operation of the product is permitted only for trained personnel within a work
place that is access controlled. Follow the “General Safety Instructions” supplied with the
product.
Do not handle this product out of its protective enclosure while it is not used for operational purposes unless it is
otherwise protected.
Whenever possible, unpack or pack this product only at EOS/ESD safe work stations. Where a safe work station is not
guaranteed, it is important for the operator to be electrically discharged before touching the product with his/her
hands or tools. This is most easily done by touching a metal part of your system housing.
It is particularly important to observe standard anti-static precautions when changing piggybacks, ROM devices,
jumper settings etc. If the product contains batteries for RTC or memory backup, ensure that the product is not placed
on conductive surfaces, including anti-static plastics or sponges. They can cause short circuits and damage the
batteries or conductive circuits on the product.

KISS 2U V4 ADL - User Guide, Rev.1.0
www.kontron.com // 8
Lithium Battery Precautions
If your product is equipped with a lithium battery, take the following precautions when replacing the lithium battery.
CAUTION: Risk of Explosion if the lithium battery is replaced by an incorrect type. Dispose of
used lithium batteries according to the Instructions.
ATTENTION: Risque d'explosion si la pile au lithium est remplacée par une pile de type
incorrect. Éliminez les piles au lithium usagées conformément aux instructions.
General Instructions on Usage
In order to maintain Kontron’s product warranty, this product must not be altered or modified in any way. Changes or
modifications to the product, that are not explicitly approved by Kontron and described in this user guide or received
from Kontron Support as a special handling instruction, will void your warranty.
This product should only be installed in or connected to systems that fulfill all necessary technical and specific
environmental requirements. This also applies to the operational temperature range of the specific board version
that must not be exceeded. If batteries are present, their temperature restrictions must be taken into account.
In performing all necessary installation and application operations, only follow the instructions supplied by the
present user guide.
Keep all the original packaging material for future storage or warranty shipments. If it is necessary to store or ship
the product then re-pack it in the same manner as it was delivered.
Special care is necessary when handling or unpacking the product. See Special Handling and Unpacking Instruction.
Quality and Environmental Management
Kontron aims to deliver reliable high-end products designed and built for quality, and aims to complying with
environmental laws, regulations, and other environmentally oriented requirements. For more information regarding
Kontron’s quality and environmental responsibilities, visit http://www.kontron.com/about-kontron/corporate-
responsibility/quality-management.
Disposal and Recycling
Kontron’s products are manufactured to satisfy environmental protection requirements where possible. Many of the
components used are capable of being recycled. Final disposal of this product after its service life must be
accomplished in accordance with applicable country, state, or local laws or regulations.
WEEE Compliance
The Waste Electrical and Electronic Equipment (WEEE) Directive aims to:
Reduce waste arising from electrical and electronic equipment (EEE)
Make producers of EEE responsible for the environmental impact of their products, especially when the product
become waste
Encourage separate collection and subsequent treatment, reuse, recovery, recycling and sound environmental
disposal of EEE
Improve the environmental performance of all those involved during the lifecycle of EEE
Environmental protection is a high priority with Kontron.
Kontron follows the WEEE directive
You are encouraged to return our products for proper disposal.

KISS 2U V4 ADL - User Guide, Rev.1.0
www.kontron.com // 9
Table of Contents
Symbols.................................................................................................................................................................................................................6
For Your Safety...................................................................................................................................................................................................7
High Voltage Safety Instructions ..................................................................................................................................................................7
Special Handling and Unpacking Instruction ............................................................................................................................................7
Lithium Battery Precautions.......................................................................................................................................................................... 8
General Instructions on Usage..................................................................................................................................................................... 8
Quality and Environmental Management................................................................................................................................................ 8
Disposal and Recycling.................................................................................................................................................................................... 8
WEEE Compliance.............................................................................................................................................................................................. 8
Table of Contents...............................................................................................................................................................................................9
List of Tables ......................................................................................................................................................................................................11
List of Figures....................................................................................................................................................................................................12
1/ Introduction .........................................................................................................................................................................................13
2/ General Safety Instructions ...........................................................................................................................................................15
Instructions générales de sécurité......................................................................................................................................................16
Electrostatic Discharge (ESD) ..............................................................................................................................................................17
Grounding Methods .................................................................................................................................................................................17
Instructions for the Lithium Battery..................................................................................................................................................18
Operation of Laser Source Devices.....................................................................................................................................................19
3/ Shipment and Unpacking ...............................................................................................................................................................20
Packaging....................................................................................................................................................................................................20
Unpacking...................................................................................................................................................................................................20
Scope of Delivery.....................................................................................................................................................................................20
Accessories and Spare Parts...............................................................................................................................................................20
Product Identification Type Label .......................................................................................................................................................21
4/ Product Features...............................................................................................................................................................................22
Front Panel.................................................................................................................................................................................................22
4.1.1. Front Flap.................................................................................................................................................................................................23
4.1.2. Drive Bays ...............................................................................................................................................................................................23
4.1.3. Handle Brackets....................................................................................................................................................................................24
4.1.4. Fans Assembly......................................................................................................................................................................................24
4.1.5. Power Button......................................................................................................................................................................................... 25
4.1.6. Power LED and HDD LED....................................................................................................................................................................25
4.1.7. USB Ports.................................................................................................................................................................................................26
Rear Panel.................................................................................................................................................................................................. 27
4.2.1. Display Port (DP)...................................................................................................................................................................................28
4.2.2. USB 3.2.....................................................................................................................................................................................................29
4.2.3. LAN............................................................................................................................................................................................................29
4.2.4. Serial Ports (COM)...............................................................................................................................................................................30
4.2.5. Audio ........................................................................................................................................................................................................30
4.2.6. Power Supply Unit...............................................................................................................................................................................30
4.2.7. Potential Equalization Stud ..............................................................................................................................................................32
4.2.8. PCIE/PCI Expansion Card Slots........................................................................................................................................................32
Side...............................................................................................................................................................................................................33
Cover ...........................................................................................................................................................................................................33
System Configuration ............................................................................................................................................................................35
5/ System Expansion ............................................................................................................................................................................36

KISS 2U V4 ADL - User Guide, Rev.1.0
www.kontron.com // 10
Before Expanding.....................................................................................................................................................................................36
Mass Storage (internal) ........................................................................................................................................................................36
Drive Bays (front panel or internal) ..................................................................................................................................................36
Expansion Cards ...................................................................................................................................................................................... 37
5.4.1. Reference PCIe Expansion Cards..................................................................................................................................................... 37
6/ Thermal Management.....................................................................................................................................................................39
Active Cooling............................................................................................................................................................................................39
Temperature Sensor ..............................................................................................................................................................................39
Minimum Thermal Clearance..............................................................................................................................................................39
Third Party Components.......................................................................................................................................................................40
7/ Assembly...............................................................................................................................................................................................41
Before Assembling the Product............................................................................................................................................................41
Opening and Closing the Cover ............................................................................................................................................................41
Installing and Removing PCIe/PCI Expansion Cards (low profile variant) ...........................................................................42
Installing and Removing PCIe Expansion Cards (riser card variant)......................................................................................43
Installing and Removing the Handle Brackets...............................................................................................................................44
Installing and Removing the Front Flap...........................................................................................................................................45
Installing the Rubber Feet.....................................................................................................................................................................45
Installing Slide Rails................................................................................................................................................................................45
8/ Mounting..............................................................................................................................................................................................46
Before Mounting ......................................................................................................................................................................................46
Mounting on a Desktop .........................................................................................................................................................................47
Mounting in a 19” Industrial Rack Cabinet.......................................................................................................................................47
9/ Starting Up...........................................................................................................................................................................................49
Before Starting..........................................................................................................................................................................................49
Connecting the Power Supply.............................................................................................................................................................49
Connecting to the Redundant Power Supply (option) ................................................................................................................50
Switching On .............................................................................................................................................................................................50
Operating System and Hardware Component Drivers ................................................................................................................51
10/ BIOS........................................................................................................................................................................................................52
Starting the BIOS ....................................................................................................................................................................................52
BIOS Setup Menus ................................................................................................................................................................................. 52
BIOS Navigation......................................................................................................................................................................................53
BIOS Update.............................................................................................................................................................................................53
Updating the BIOS.................................................................................................................................................................................. 53
Recover BIOS...........................................................................................................................................................................................54
11/ Product Specification ...................................................................................................................................................................... 55
Block Diagram .......................................................................................................................................................................................... 55
Hardware Specification.........................................................................................................................................................................57
Software Specification..........................................................................................................................................................................58
Power Specification...............................................................................................................................................................................58
Environmental Specification...............................................................................................................................................................59
Mechanical Specification.....................................................................................................................................................................60
Compliance ...............................................................................................................................................................................................60
12/ Standard Interfaces- Pin Assignment.......................................................................................................................................62
DP Port Pin Assignment........................................................................................................................................................................62
USB 3.2 Gen 2/1 Pin Assignment.......................................................................................................................................................62
USB-C 3.2 Gen 2 Port Pin Assignment.............................................................................................................................................63
2.5 GbE/1.0 GbE Pin Assignment.......................................................................................................................................................63

KISS 2U V4 ADL - User Guide, Rev.1.0
www.kontron.com // 11
COM Port Pin Assignment ...................................................................................................................................................................64
Audio Jack Connector Pin Assignment (Line-in, Line-out, Mic-in) ........................................................................................64
M.2 Key M (NVME SSD) Socket Pin Assignment ..........................................................................................................................65
Jumpers.....................................................................................................................................................................................................66
12.8.1. Recover BIOS Jumper.........................................................................................................................................................................66
13/ Maintenance and Prevention........................................................................................................................................................67
Before Maintaining the Product ........................................................................................................................................................ 67
Cleaning the Product ............................................................................................................................................................................ 67
Cleaning the Filter Pad......................................................................................................................................................................... 67
Replacing the System Fans................................................................................................................................................................68
Replacing the Lithium Battery ...........................................................................................................................................................69
Replacing the Internal 2.5” SSD Drive .............................................................................................................................................70
Replacing a M.2 SSD Module...............................................................................................................................................................71
Replacing a Faulty Redundant PSU Unit .........................................................................................................................................71
14/ Technical Support............................................................................................................................................................................. 73
Returning Defective Merchandise.................................................................................................................................................... 73
15/ Warranty ..............................................................................................................................................................................................74
Limitation/Exemption from Warranty Obligation.......................................................................................................................74
List of Acronyms ..............................................................................................................................................................................................75
About Kontron .................................................................................................................................................................................................. 76
List of Tables
Table 1: Scope of Delievy...............................................................................................................................................................................20
Table 2: Accessories and Spares Parts ....................................................................................................................................................20
Table 3: Power LED and HDD LED .............................................................................................................................................................. 25
Table 4: Display Resolution .........................................................................................................................................................................28
Table 5: Display Order Priority....................................................................................................................................................................28
Table 6: Redundant PSU LED Description.................................................................................................................................................31
Table 7: Mass Storage (internal)................................................................................................................................................................36
Table 8: Drive Bays .........................................................................................................................................................................................36
Table 9: PCIe/PCI Expansion Cards Slot Allocation.............................................................................................................................. 37
Table 10: Reference KISS 2U V4 ADL PCIe Expansion Cards.............................................................................................................. 37
Table 11: Navigation Hot Keys in the Legend Bar .................................................................................................................................. 53
Table 12: Hardware Specification................................................................................................................................................................57
Table 13: Software Specification................................................................................................................................................................58
Table 14: Electrical Specification................................................................................................................................................................58
Table 15: Environmental Specification .....................................................................................................................................................59
Table 16: Mechanical Specification............................................................................................................................................................60
Table 17: CE Compliance................................................................................................................................................................................60
Table 18: International Compliance............................................................................................................................................................61
Table 19: DP V1.4a Pin Assignment............................................................................................................................................................62
Table 20: USB 3.2 Gen 2 Pin Assignment .................................................................................................................................................62
Table 21: USB 3.2 Gen 2 Type C Pin Assignment....................................................................................................................................63
Table 22: LAN (RJ45) Connector Pin Assignment..................................................................................................................................63
Table 23: RS232 Connector Pin Assignment ..........................................................................................................................................64
Table 24: Audio Jack Pin Assignment........................................................................................................................................................64
Table 25: M.2 Key M Socket Pin Assignment..........................................................................................................................................65
Table 26: Recover BIOS Jumper ..................................................................................................................................................................66
Table 28: List of Acronyms............................................................................................................................................................................75

KISS 2U V4 ADL - User Guide, Rev.1.0
www.kontron.com // 12
List of Figures
Figure 1: KISS 2U V4 ADL.................................................................................................................................................................................13
Figure 2: Type Label Examples ....................................................................................................................................................................21
Figure 3: Front Panel ......................................................................................................................................................................................22
Figure 4: Front Flap.........................................................................................................................................................................................23
Figure 5: Handle Brackets.............................................................................................................................................................................24
Figure 6: Power Button.................................................................................................................................................................................. 25
Figure 7: LED indicators.................................................................................................................................................................................25
Figure 8: USB 3.2 Gen 1 Port .........................................................................................................................................................................26
Figure 9: Rear Panel (low profile).............................................................................................................................................................. 27
Figure 10: Rear Panel (riser card)...............................................................................................................................................................28
Figure 11: Single PSU (400 W).......................................................................................................................................................................31
Figure 12: PSU, 550 W (redundant) .............................................................................................................................................................31
Figure 13: Left Side ..........................................................................................................................................................................................33
Figure 14: Right Side........................................................................................................................................................................................33
Figure 15: Cover Top Side (low profile).....................................................................................................................................................34
Figure 16: Cover Underside (low profile).................................................................................................................................................34
Figure 17: Example of KISS 2U V4 ADL Configuration.......................................................................................................................... 35
Figure 18: Push Button (left and right side)............................................................................................................................................42
Figure 19: Installing Low Profile Expansion Cards...............................................................................................................................43
Figure 20: Installing Riser Card Expansion Cards.................................................................................................................................44
Figure 21: Input Power Socket .....................................................................................................................................................................49
Figure 22: Redundant Power Sockets.......................................................................................................................................................50
Figure 23: Power Button................................................................................................................................................................................50
Figure 24: BIOS FTP Server...........................................................................................................................................................................53
Figure 25: Block Diagram KISS 2U V4 ADL (low profile) ..................................................................................................................... 55
Figure 26: Block Diagram KISS 2U V4 ADL (riser card)........................................................................................................................56
Figure 27: Recover BIOS Jumper .................................................................................................................................................................66
Figure 28: Removing the Filter Pad ...........................................................................................................................................................68
Figure 29: Removing a System Fan ...........................................................................................................................................................69
Figure 30: Lithium Battery (CR2032).........................................................................................................................................................70

KISS 2U V4 ADL - User Guide, Rev.1.0
www.kontron.com // 13
1/ Introduction
This user guide focuses on describing the special features of the KISS 2U V4 ADL scalable 2U rackmount system also
know as product within this user guide. This user guide includes detailed information and guidelines how to set up,
install, operate and maintain the product properly. New users are recommended to study the instructions and any
warning notices within this user guide before handling or switching on the product.
The KISS 2U V4 ADL is a scalable 2U industrial rackmount system designed for high performance, reliability in a 19”
industrial rack cabinet, or flexibly installed in harsh industrial environments. Based on Kontron’s industrial series of
ATX motherboards, with Intel®12th/13th Generation Core™ i9, i7, i5 und i3 processors the product supports multiple
expansion capabilities and external interfaces. Two product variants (low profile and riser card) support different
PCIe/PCI expansion card sizes and combinations.
Figure 1: KISS 2U V4 ADL
General KISS 2U V4 ADL features are:
ATX motherboard
Intel® 12th and 13th Gen Core-i ™ i9, i7, i5 und i3 processor series
Intel® R680E chipset
Up to 128 GB max. system memory with four DIMM sockets DDR5-4800 MHz
2x M.2 2280 PCIe drive (internal)
Drive bay options
2x 3.5” drive bays (per drive bay one 3.5” or two 2.5” drives)
1x DVD R/W slim (option)
RAID support
Expansion slots options
Low profile: 6x PCIe slots + 1x PCI slot (low profile) or
Riser card: 2x PCIe slots (full height, full length)
External interfaces front:
2x USB 3.2 Gen 1
External interfaces rear
4x USB 3.2 Gen 1 (Type A), 2x USB 3.2 Gen 2 (Type A), 1x USB 3.2 Gen 2 (Type C)
4x DP 1.4 @ 4K
1x 1 Gb Ethernet
2x 2.5 Gb Ethernet
1x RS 232 Serial port
1x audio (Line-in, Line-out, Mic)

KISS 2U V4 ADL - User Guide, Rev.1.0
www.kontron.com // 14
Active cooling
Power Supply
100 VAC to 240 VAC, 400 W PSU
100 VAC to 240 VAC, 550 W redundant PSU (option)
To ensure you have the latest version of this user guide, visit Kontron at Products | Kontron
Embedded Computers 2U

KISS 2U V4 ADL - User Guide, Rev.1.0
www.kontron.com // 15
2/ General Safety Instructions
Please read this passage carefully and take careful note of the instructions, which have been compiled for your safety
and to ensure to apply in accordance with intended regulations. If the following general safety instructions are not
observed, it could lead to injuries to the operator and/or damage of the product; in cases of non-observance of the
instructions Kontron Europe is exempt from accident liability, this also applies during the warranty period.
The product has been built and tested according to the basic safety requirements for low voltage (LVD) applications
and has left the manufacturer in safety-related, flawless condition. To maintain this condition and to also ensure safe
operation, the operator must not only observe the correct operating conditions for the product but also the following
general safety instructions:
The product must be used as specified in the product documentation, in which the instructions for safety for the
product and for the operator are described. These contain guidelines for setting up, installation and assembly,
maintenance, transport or storage.
The on-site electrical installation must meet the requirements of the country's specific local regulations.
If a power cable comes with the product, only this cable should be used. Do not use an extension cable to connect
the product.
To guarantee that sufficient air circulation is available to cool the product, please ensure that the ventilation
openings are not covered or blocked. If a filter mat is provided, this should be cleaned regularly. Do not place the
product close to heat sources or damp places. Make sure the product is well ventilated.
Only connect the product to an external power supply providing the voltage type (AC or DC) and the input power
(max. current) specified on the Kontron Product Label and meeting the requirements of the Limited Power Source
(LPS) and Power Source (PS2) of UL/IEC 62368-1 .
Only products or parts that meet the requirements for Power Source (PS1) of UL/IEC 62368-1 may be connected
to the product’s available interfaces (I/O).
Before opening the product, make sure that the product is disconnected from the mains.
Switching off the product by its power button does not disconnect it from the mains. Complete disconnection is
only possible if the power cable is removed from the wall plug or from the product. Ensure that there is free and
easy access to enable disconnection.
The product may only be opened for the insertion or removal of add-on cards (depending on the configuration of
the product). This may only be carried out by qualified operators.
If extensions are being carried out, the following must be observed:
all effective legal regulations and all technical data are adhered to
the power consumption of any add-on card does not exceed the specified limitations
the current consumption of the product does not exceed the value stated on the product label
Only original accessories that have been approved by Kontron Europe can be used.
Please note: safe operation is no longer possible when any of the following applies:
the product has visible damages or
the product is no longer functioning
In this case the product must be switched off and it must be ensured that the product can no longer be
operated.
Handling and operation of the product is permitted only for trained personnel within a work place that is access
controlled.
CAUTION: Risk of explosion if the battery is replaced incorrectly (short-circuited, reverse-poled, wrong battery
type). Dispose of used batteries according to the manufacturer’s instructions.
This product is not suitable for use in locations where children are likely to be present
Additional Safety Instructions for DC Power Supply Circuits
To guarantee safe operation, please observe that:
the external DC power supply must meet the criteria for LPS and PS2 (UL/IEC 62368-1)
no cables or parts without insulation in electrical circuits with dangerous voltage or power should be
touched directly or indirectly
a reliable protective earthing connection is provided

KISS 2U V4 ADL - User Guide, Rev.1.0
www.kontron.com // 16
a suitable, easily accessible disconnecting device is used in the application (e.g. overcurrent protective
device), if the product itself is not disconnectable
a disconnect device, if provided in or as part of the product, shall disconnect both poles simultaneously
interconnecting power circuits of different products cause no electrical hazards
A sufficient dimensioning of the power cable wires must be selected – according to the maximum electrical
specifications on the product label – as stipulated by EN62368-1 or VDE0100 or EN60204 or UL61010-1
regulations.
Instructions générales de sécurité
Veuillez lire attentivement ce passage et prendre bonne note des instructions, qui ont été compilées pour votre
sécurité et pour assurer une application conforme aux réglementations prévues. Le non-respect des consignes de
sécurité générales suivantes peut entraîner des blessures pour l'utilisateur et/ou des dommages pour le produit. En
cas de non-respect des consignes, Kontron Europe est exonéré de la responsabilité en cas d'accident, ceci s'applique
également pendant la période de garantie.
Le produit a été construit et testé conformément aux exigences de sécurité de base pour les applications basse
tension (DBT) et a quitté le fabricant dans un état impeccable en matière de sécurité. Pour maintenir cet état et pour
garantir également un fonctionnement sûr, l'opérateur doit non seulement respecter les conditions d'utilisation
correctes du produit, mais aussi les consignes de sécurité générales suivantes :
Le produit doit être utilisé conformément à la documentation du produit, dans laquelle sont décrites les
instructions de sécurité pour le produit et pour l'opérateur. Celles-ci contiennent des directives pour la mise en
place, l'installation et le montage, la maintenance, le transport ou le stockage.
L'installation électrique sur place doit répondre aux exigences des réglementations locales spécifiques du pays.
Si un câble d'alimentation est fourni avec le produit, seul ce câble doit être utilisé. N'utilisez pas de rallonge pour
connecter le produit.
Afin de garantir une circulation d'air suffisante pour refroidir le produit, veuillez vous assurer que les ouvertures
de ventilation ne sont pas couvertes ou obstruées. Si un élément filtrant est fourni, celui-ci doit être nettoyé
régulièrement. Ne placez pas le produit à proximité de sources de chaleur ou d'endroits humides. Veillez à ce que
le produit soit bien ventilé.
Ne connectez le produit qu'à une alimentation externe fournissant le type de tension (AC ou DC) et la puissance
d'entrée (courant max.) spécifiés sur le Label Produit Kontron et répondant aux exigences de la source
d'alimentation limitée (LPS) et de la source d'alimentation (PS2) de la norme UL/IEC 62368-1 .
Seuls les produits ou les pièces qui répondent aux exigences de la source d'alimentation (PS1) de la norme UL/IEC
62368-1 peuvent être connectés aux interfaces (E/S) disponibles du produit.
Avant d'ouvrir le produit, assurez-vous qu'il est bien débranché du secteur.
Le fait d'éteindre le produit par son bouton de mise en marche ne le déconnecte pas du secteur. Une déconnexion
complète n'est possible que si le câble d'alimentation est retiré de la prise murale ou du produit. Veillez à ce que
l'accès soit libre et facile pour permettre la déconnexion.
Le produit ne peut être ouvert que pour l'insertion ou le retrait de cartes supplémentaires (selon la configuration
du produit). Cette opération ne peut être effectuée que par des opérateurs qualifiés.
Si des extensions sont effectuées, les points suivants doivent être respectés :
toutes les réglementations légales en vigueur et toutes les données techniques sont respectées
la consommation électrique d'une carte supplémentaire ne dépasse pas les limites spécifiées
la consommation actuelle du produit ne dépasse pas la valeur indiquée sur l'étiquette du produit.
Seuls les accessoires d'origine approuvés par Kontron Europe peuvent être utilisés.
Veuillez noter que la sécurité des opérations n'est plus possible lorsque l'une des conditions suivantes
s'applique.
le produit présente des dommages visibles ou
le produit ne fonctionne plus. Dans ce cas, le produit doit être éteint et il faut s'assurer que le produit ne
puisse plus être utilisé.

KISS 2U V4 ADL - User Guide, Rev.1.0
www.kontron.com // 17
La manipulation et le fonctionnement du produit ne sont autorisés que pour le personnel formé dans un lieu de
travail dont l'accès est contrôlé.
ATTENTION: Risque d'explosion si la batterie est remplacée de manière incorrecte (court-circuit, inversion de
polarité, mauvais type de batterie). Éliminez les piles usagées conformément aux instructions du fabricant.
Ce produit n'est pas adapté à une utilisation dans des endroits où des enfants sont susceptibles d'être présents
Instructions de sécurité supplémentaires pour les circuits d'alimentation en courant continu
Pour garantir un fonctionnement sûr, veuillez observer ce qui suit:
l'alimentation électrique externe en courant continu doit répondre aux critères des LPS et PS2 (UL/IEC
62368-1)
aucun câble ou pièce non isolée dans les circuits électriques ayant une tension ou une puissance dangereuse
ne doit être touché directement ou indirectement
une connexion fiable à la terre de protection est fournie
un dispositif de déconnexion approprié et facilement accessible est utilisé dans l'application (par exemple,
un dispositif de protection contre les surintensités), si le produit lui-même n'est pas en mesure d'être
déconnecté.
un dispositif de déconnexion, s'il est prévu dans le produit ou s'il en fait partie, doit déconnecter les deux
pôles simultanément
l'interconnexion des circuits électriques de différents produits ne présente aucun risque électrique
Un dimensionnement suffisant des fils du câble d'alimentation doit être choisi - en fonction des spécifications
électriques maximales figurant sur l'étiquette du produit - comme stipulé par les réglementations EN62368-1 ou
VDE0100 ou EN60204 ou UL61010-1.
Electrostatic Discharge (ESD)
A sudden discharge of electrostatic electricity can destroy static-sensitive devices.
Proper packaging and grounding techniques are necessary precautions to prevent damage. Always observe the
following precautions:
1. Transport ESD sensitive parts in ESD safe containers such as boxes or bags, until they arrive at an ESD safe
workplace.
2. Always be properly grounded when touching sensitive components, or assembly.
3. Store ESD sensitive components in protective packaging or on antistatic mats.
Grounding Methods
To avoid electrostatic damage, observe the following grounding guidelines:
1. Cover workstations with approved antistatic material/mat. Always wear a wrist strap connected to workplace or
heel straps.
2. Use properly grounded tools and equipment such as field service tools that are conductive.
3. Always handle ESD sensitive components by their edge or by their casing.
4. Avoid contact with pins, leads, or circuitry.
5. Switch off power and input signals before inserting and removing connectors or connecting test equipment.
6. Keep work area free of non-conductive materials such as ordinary plastic assembly aids and Styrofoam.

KISS 2U V4 ADL - User Guide, Rev.1.0
www.kontron.com // 18
Instructions for the Lithium Battery
When replacing the motherboard’s lithium battery observe the instructions described in Chapter 13.5: Replacing the
Lithium Battery.
Danger of Explosion if the lithium battery is incorrectly placed!
Replace only with the same or equivalent type recommended by the manufacturer
Dispose of used batteries according to the manufacture’s instructions
VORSICHT- Explosionsgefahr bei unsachgemäßem Austausch der Batterie!
Ersatz nur durch denselben oder einen vom Hersteller empfohlenen gleichwertigen Typ
Entsorgung gebrauchter Batterien nach Angaben des Herstellers
ATTENTION- Risque d'explosion avec l'échange inadéquat de la batterie!
Remplacement seulement par le même ou un type équivalent recommandé par le
producteur
L'évacuation des batteries usagées conformément à des indications du fabricant
PRECAUCION- Peligro de explosión si la batería se sustituye incorrectamente!
Sustituya solamente por el mismo o tipo equivalente recomendado por el fabricante
Disponga las baterías usadas según las instrucciones del fabricante
ADVARSEL- Lithiumbatteri -- Eksplosionsfare ved fejlagtig håndtering!
Udskiftning må kun ske med batteri af samme fabrikat og type
Levér det brugte batteri tilbage til leverandøren
ADVARSEL- Eksplosjonsfare ved feilaktig skifte av batteri!
Benytt samme batteritype eller en tilsvarende type anbefalt av apparatfabrikanten
Brukte batterier kasseres i henhold til fabrikantens instruksjoner
VARNING- Explosionsfara vid felaktigt batteribyte!
nvänd samma batterityp eller en ekvivalent typ som rekommenderas av
apparattillverkaren
assera använt batteri enligt fabrikantens instruktion
VAROITUS- Paristo voi räjähtää, jos se on virheellisesti asennettu!
Vaihda paristo ainoastaan lalteval- mistajan suosittelemaan tyyppiln
Hävitä käytetty paristo valmistajan ohjeiden mukaisesti
Do not dispose of lithium batteries in general trash collection. Dispose of the lithium battery
according to the local regulations dealing with the disposal of these special materials, (e.g.
collecting points for dispose of batteries).

KISS 2U V4 ADL - User Guide, Rev.1.0
www.kontron.com // 19
Operation of Laser Source Devices
The optional DVD drive contains light-emitting diodes (LEDs) (classified in accordance with IEC 60825-1:2007: LASER
CLASS 1) and therefore must not be opened. If the enclosure of such a drive is opened, invisible laser radiation is
emitted. Do not allow yourself to be exposed to this radiation.
The laser system meets the Code of Federal Regulations (CFR), Title 21, 1040 -Performance standards for light-
emitting products.
Laser!
Risk of exposure to laser beam and light emitting devices (LEDs) from DVD
•Do not open DVD drive due to invisible laser radiation
•Check manufacture instructions eye protection maybe required

KISS 2U V4 ADL - User Guide, Rev.1.0
www.kontron.com // 20
3/ Shipment and Unpacking
Packaging
All parts are delivered together in a product specific cardboard package designed to provide adequate protection to
absorb shock. Kontron recommends keeping the packaging to store or transport the KISS 2U V4 ADL.
Unpacking
To unpack the product, perform the following:
1. Remove packaging.
2. Do not discard the original packaging. Keep the original packaging for future transportation or storage.
3. Check the delivery for completeness by comparing the delivery with the original order.
4. Keep the associated paperwork. It contains important information for handling the product.
5. Check the product for visible shipping damage.
If you notice any shipping damage or inconsistencies between the contents and the original order, contact your
dealer.
Scope of Delivery
Check that the delivery is complete, and contains the items listed in Table 1: . If damaged or missing items are
discovered, contact the dealer.
Table 1: Scope of Delievy
Part Qty. Part Description
KISS 2U V4 ADL 1 System configuration as ordered:
KISS 2U V4 ADL low profile or KISS 2U V4 ADL riser card
AC power cable 1 With European rating, other cable ratings are optional
Rubber feet 4 Four rubber feet
Safety instructions 1 General Safety Instructions
Accessories and Spare Parts
The parts and accessories that can be purchased for the product are described in Table 2: Accessories and Spares
Parts.
Table 2: Accessories and Spares Parts
Part Number Part Description
TBD Two 19” handle brackets with four screws
TBD Slide rails
TBD Mounting kit slide rails
TBD Front flap kit with access key
TBD Filter pad
1068-7355 One Fan replacement unit
