INSTRUCTION MANUAL
FP

Before you get started...
We’re confident you will be happy with your new Aspire bed frame.
However it is worth making sure before you unpackage and start to
put it together.
Please check the following:
A) CORRECT COLOUR
Please make sure you are happy with the colour. There is no need to fully
unpack, please just check the first component.
B) PACKAGING
If you’re satisfied, then its time to open. Start by laying out all components on
the cardboard. This will prevent the fabric getting stained or scuffed.
C) COMPONENTS
Finally, double check your components page and ensure you have all parts
listed. Please note some components may vary with frame size.
RETURNS
If you are not completely happy with the product, don’t worry.
We just need everything back in the original packaging.
DO
•Check nothing is missing.
•All loose components are contained within
the packaging provided
•Wrap all large components up in the
original packaging.
•Close and securely seal the original
packaging
DON’T
•Leave components assembled. All
components must be dismantled and
separately packed.
•Put loose fixtures and fittings straight in
the box.
•Carelessly repackage. This may cause
damage.
Contact info: [e-mail] 01484 949354
Tools Included: Tools Required:
Allen Key T-30 Torx Screw Driver Size 2 Positive Screwdriver

CONTENTS SUPPLIED –3ft
Name Appearance Quantity
Siderail 2
Head/Foot
Rail
2
Slat
(2 Rebates)
13
Adjustable
Slat
(1 Rebate)
4
Slat Mount 26
Adjustment
Sleeve
8
Support Rod 1
Screws
24 x Counter Sunk
Short
2 x Counter Sunk
Long
4 x Button Head Long

CONTENTS SUPPLIED –4ft to 4ft6
Name Appearance Quantity
Siderail 2
Centre Beam
1
Head/Foot
Rail
2
Slat 13
Half Slat 8
Slat Mount 26
Adjustment
Sleeve
16
Support Rod 2
Screws
32 x Counter Sunk
Short
4 x Counter Sunk
Long
4 x Button Head Long

CONTENTS SUPPLIED –5ft & 6ft
Name Appearance Quantity
Siderail 2
Centre Beam
1
Head/Foot
Rail
2
Slat 14
Half Slat 8
Slat Mount 28
Adjustment
Sleeve
16
Support Rod 2
Screws
32 x Counter Sunk -
Short
4 x Counter Sunk -
Long
4 x Button Head Long

1. Lay out components and check all are present.
For 3ft frame skip next steps and go to 4.
2. Line up Centre Beam bracket
with pre-drilled holes in
Head/Foot Beams

3. Screw in 4 Small Screws
at both ends.
4. Line up the Side Beams
with the Head/Foot Beams.

5. Screw in 3 corners using
the button head Torx screws
and Torx Screwdriver

6. Insert plastic Slat Mounts
into cut outs on Side
Beams.
7a. For 4ft to 6ft frame:
Build up adjustable slats. You will need 1 x Standard Slat, 2 x
Half Slats and 4 x Adjustment Sleeves per adjustable slat.

7b. For 3ft frame:
Build up adjustable slats. You will need 1 x Standard Slat with
2 rebates, 1 x Adjustable Slat with 1 rebate and 2 x
Adjustment Sleeves.
8. Position one Half Slat (4ft to 6ft)
or one adjustable slat (3ft) beneath
the Standard Slat as shown.

9. Slide over the
Adjustment Sleeves.
For 3ft frame skip next step
and go to 10.
10. Repeat with opposite
side of the slat. Repeat with
another 3 slats.

12. Using the same method
position the 4 adjustable
slats.
11. Begin to position slats
in frame. 4 Standard Slats
to begin with.

13. Position the remaining
Standard Slats using the
same method.

14. Using the Torx button
head screws, attach the
final corner of the frame
ensuring all slats slot into
Slat Mounts .
15. Flip the frame over and
screw in the remaining
Small Screws into the
corner mounts.

16. Repeat with all 4 corners.
For 3ft frame skip next step
and go to 19.
17. Insert the Countersunk
Long Screws into the centre
rail.

18. Screw Support Rod into
position on Centre Rail.
19. Screw Support Rod into
position on Side beams using
the Countersunk Long Screws.

20. Position Plastic Corner
Covers.
19. Slat frame is complete.

CONTENTS SUPPLIED - 3ft
Name Appearance Quantity
Headboard 1
Footboard 1
Sideboard 2
Legs 4
Slat Frame 1
M10 Bolts 4
Allen Key
Bolts 14

CONTENTS SUPPLIED - 4ft to 6ft
Name Appearance Quantity
Headboard 1
Footboard 1
Sideboard 2
Legs 4 x Corner
1 x Centre
Slat Frame 1
M10 Bolts 4
Allen Key
Bolts 16

1. Lay out components and
check all are present.
2. Attach legs to Slat Frame
using provided Bolts.
Repeat for all 4/5 legs.
