Cavaliere CAV Series User manual

ISLAND MOUNT RANGE HOOD
CAV SERIES ISLAND HOOD Z01-36
Installation Manual
2019b
IMPORTANT:
Read and save these instructions.
NOTICE:
Installer: Leave this guide with the homeowner.
Homeowner: Keep this guide for future reference.

Important Safety Notice
READ ALL INSTRUCTIONS BEFORE INSTALLING AND OPERATING THIS APPLIANCE
The installation in this manual is intended for qualified installers, service technicians or persons
with similar qualified background. Installation and electrical wiring must be done by qualified
professionals and in accordance with all applicable codes and standards, including fire-rated
construction.
DO NOT attempt to install this appliance yourself. Damage or Injury could result from installing
the unit due to lack of appropriate electrical and technical background.
Due to the size and weight of this range hood, at least two people are recommended for
installation to reduce the risk of fire, electric shock, or injury to persons.
Range hood may have very sharp edges; wear protective gloves if it is necessary to remove any
parts for installing, cleaning or servicing.
Ensure any nearby electrical service are OFF and stay OFF until the completion of installation to
reduce the risk of electrical shock, short-circuit, electrical spark which may cause injury or damage.
For general ventilating use only. DO NOT use to exhaust hazardous or explosive materials and
vapors.
In order to ensure the safe operation of fuel-burning heating equipment, it's air flow needs to be to
be considered for proper combustion. Follow the heating equipment manufacturer’s guideline
and safety standards such as those published by the National Fire Protection Association (NFPA),
and the American Society of Heating, Refrigeration and Air Conditioning Engineers (ASHRAE), and
the local code authorities.
To reduce the risk of fire and to disperse air properly, make sure to vent air outside. Sufficient
household air flow is required for the proper combustion of fuel-burning heating equipment, and
the exhaustion of their gases.
Pg 1
•
•
•
•
•
•
•
•
This is the safety alert symbol. This symbol alerts you to potential hazards that can hurt you and
others. All safety messages will follow the safety alert symbol “ ” and the word “WARNING”.
The manufacturer and/or distributor/reseller declines all responsibility in the event of failure to observe the
instructions given here for installation, maintenance and suitable use of the product. The manufacturer
and/or distributor/reseller further declines all responsibility for injury due to negligence and the warranty
of the unit automatically expires due to improper maintenance. The manufacturer and/or
distributor/reseller will not be held responsible for any damages to personal property or real estate or any
bodily injuries whether caused directly or indirectly by the range hood.
Excessive Weight
Require three or more persons to
move and install this range hood.
Spinal or other bodily injuries
could occur if it is not followed.
Light bulb become extremely hot when turned on. DO NOT touch bulb until
switched off and cooled. Touching hot bulbs could cause serious burns.
Hazard of Burns!
Severe Injury
Rotating fan can cause severe
injury. Stay clear of fan when
power is present.
Hazard of electrical shock!
Do not perform service on an electrically live
system. Disconnect the main electrical supply
before servicing this device. Touching
electrical connectors or other exposed
electrical circuitry inside this range hood when
they are energized could result in death,
serious bodily injury, or property damage.
Your safety and the safety of others is very important. We have provided many important safety
messages in this manual and on your appliance. Always read and obey all safety messages. All
safety messages will tell you what the potential hazard is, tell you how to reduce the chance of
injury, and tell you what can happen if the instructions are not followed.

Important Safety Notice
Pg 2
•
•
•
•
•
•
•
•
•
•
•
TO REDUCE THE RISK OF A STOVE TOP GREASE FIRE:
•
•
•
•
•
•
•
•
TO REDUCE THE RISK OF INJURY TO PERSONS IN THE EVENT OF A STOVE TOP GREASE FIRE:
•
•
•
TO REDUCE THE RISK OF INJURY TO PERSONS IN THE EVENT OF A GAS LEAKS:
•
•
•
•
Ducted fans MUST always be vented to the outdoors.
DO NOT vent exhaust into spaces between walls, crawl spaces, ceiling, attics or garages.
Any old duct work should be cleaned or replaced if necessary to avoid the possibility of a grease
Check all joints on duct work to insure proper connection and all joints should be properly taped.
Use only metal ductwork and this unit MUST be grounded.
Before servicing or cleaning unit, switch power OFF at service panel and lock service panel to
prevent power from being switched ON accidentally.
When cutting or drilling into wall or ceiling, be careful not to damage electrical wiring or other
hidden utilities.
All electrical wiring must be properly installed, insulated and grounded.
Use this unit only in the manner intended by the manufacturer. If you have questions, contact
the vendor.
DO NOT touch the bottom side of the range hood directly after usage because it may be hot.
Wait until it has cooled.
Make sure to inspect shipment and it's contents as soon shipment is received.
Plug in and test range hood and all its functions, (refer to Range Hood Operations, Page 12),
directly after receiving shipment, and before scheduling an installer.
Clean grease laden surfaces frequently.
Clean ventilating fan frequently.
Keep all surfaces clean from grease or oil build up.
Grease should not be allowed to accumulate on fan, baffle, spaces, filter, grease tunnel and oil
container.
Always turn range hood ON when cooking at high heat or when cooking flaming foods. Use high
settings on cooking range only when necessary.
Never leave burners or cooktop at high settings unattended. Boil overs cause smoking and
greasy spillovers that may ignite. Heat oils slowly on low or medium settings.
Always use appropriate cookware and utensils size.
Always use cookware appropriate for the size of the surface element.
SMOTHER FLAMES with a close-fitting lid, cookie sheet, or metal tray, then turn OFF the burner.
BE CAREFUL TO PREVENT BURNS. NEVER PICK UP A FLAMING PAN—you may be burned.
KEEP FLAMMABLE OR COMBUSTIBLE MATERIAL AWAY FROM FLAMES. If the flames DO NOT
go out immediately, EVACUATE AND CALL THE FIRE DEPARTMENT or dial your local
emergency service immediately.
DO NOT USE WATER, including wet dishcloths or towels — a violent steam explosion may result.
Use an extinguisher ONLY if:
• You know you have a Class A, B, C extinguisher, and you already know how to operate it.
• The fire is small and contained in the area where it is started.
• The fire department is being called.
• You can fight the fire while maintaining a safe exit path.
Extinguish any open flame.
DO NOT turn on the range hood fan or any type of ventilator.
DO NOT turn on the lights or any type of appliance.
Open all doors and windows to disperse the gas. If you still smell gas, call the gas company and
fire department, or dial your local emergency service immediately.
fire.

Pg 3
Table of Contents
INSTALLATION
Tools needed
Parts Supplied
Venting Requirements
Height & Clearance
Duct Size Upgrade Calculator
Venting Methods
Charcoal Filter Installation
Electrical Requirements
Installation Overview
Preparation
Installation
...............................................................3
.............................................................4
..............................................5
................................................5-6
..............................6
........................................................7
.....................................8
..........................................8
................................................9
.................................................................10
..............................................................11-12
USE AND CARE
Range Hood Operations
Troubleshooting
Use and Care Information
Specifications
Electric Schematic
MAINTENANCE
Cleaning, Replacing Filter & Light Bulb
WARRANTY
Coverage & Exceptions
Disclaimer
Contact Information
....................................13-14
........................................................15
......................................16
.............................................................16
...................................................17
......18-19
..........................................20
....................................................................21
................................................21
Level
Powered
screwdriver
or drill
Flat-blade
and Phillips
screwdrivers
Measuring
tape
Utility knife
Marker
or pencil
Tools Needed
0 1 2 3
Adjustable
wrench

Lower Chimney Upper Chimney
Range Hood
Chimney Support Frame
Pg 4
Parts Supplied
Flexible Duct Tube
(Optional)
Draft Damper Flaps
Qty: 4 PCS
Qty: 18 PCS
Qty: 2 PCS
Qty: 16 PCS Charcoal Filter
Qty: 24 PCS
Qty: 24 PCS
E
F
Pre-Installed on
support frame

Vent system must terminate to the outside
(roof or side wall).
DO NOT terminate the vent system in an
attic or other enclosed area.
DO NOT use 4” (10.2 cm) laundry-type
wall caps.
Use metal/aluminum ducting only. Rigid
metal/aluminum ducting is recommended.
Always keep the duct clean to ensure
proper airflow.
Calculate the following figures before
installation:
1. Distance from the floor to the ceiling.
*(less than 108").
2. Distance between the floor to the
countertop/stove. (Recommend* 28”
to about 36”).
3. Distance between the countertop/stove
to the range hood. (Recommended 28"
to ~31").
4. Height of range hood body and chimney
covers combined. (Extension available*)
A distance of 28” to 31” is recommended
between stove top and the bottom of
range hood.
"28" is the lowest recommended for safe
operation; 31" is only recommended for
efficient operation, but can be mounted
higher."
It is recommended that the range hood be
vented vertically through the roof through
6” (15.24 cm) or larger round
metal/aluminum vent work.
The size of the vent should be uniform.
Use no more than three 90° elbows.
For best results, attempt to make a
minimum of 24" (61 cm) of straight vent
between the elbows if more than one
elbow is used.
DO NOT install two elbows together.
The length of vent system and number of
elbows should be kept to a minimum to
provide efficient performance.
The vent system must have a damper.
If roof or wall cap already has a damper,
DO NOT use the supplied damper
(if applicable).
•
•
•
•
•
•
For the most efficient & quiet operation:
•
•
•
•
•
•
•
•
•
Pg 5
Venting Requirements Height & Clearance
Maximum* ceiling
clearance 108” at 31” hood
mounting height above
countertop/stove (may
vary with different model).
Chimney extensions
available for higher ceiling.
Standard
Upper
Chimney
Extension available*
Range Hood
Support
Structure
Standard
Lower
Chimney
Extension available*
Min: 28”
Max: ~31”
36” Base
Max: 108”
* Higher ceiling requires chimney extension.
Available at your local resellers.
Countertop/Stove
Use duct tape or equivalent to seal all joints
in the vent system.
Use caulking to seal exterior wall or roof
opening around the cap.
* Due to different ceiling height configurations,
recommended height may not be applicable.
•
•

Duct Deductions:
Each 90° bend 9 ft
Each 45° bend 5 ft
Each 6” to 3 ¼” x 10” transition 7 ft
Side wall cap with damper 1 ft
Roof Cap (with factory Damper) 1 ft
Duct Deduction Calculation Example:
A minimum of 6” round (standard for this range hood) or 3 ¼” x 10” rectangular duct
(purchased separately) must be used to maintain maximum airflow efficiency.
A flexible 6" round duct is provided for convenience and for use in difficult installations,
however always attempt to use a smooth metal/aluminum rigid type of ducting to maximize
airflow efficiency.
ALWAYS, when possible, reduce the number or transitions and turns. If long duct run is
required, increase duct size to 7” or 8”. If a reducer is used, install a long reducer instead of a
pancake reducer. Any reductions of duct size will restrict and decrease airflow; to maximize
airflow flow efficiency place any reducers furthest away from any bends or transitions.
If turns or transitions are required, install them as evenly distanced as possible, and as far
away from the range hood as possible.
Please use Duct Run Calculation below to compute the total available duct run when using
elbows, transitions and caps.
It is important to install the hood at the proper mounting height. Hoods mounted too low is
considered unsafe and could result in heat damage and fire hazard; while hoods mounted too
high are harder to reach and will loose general effectiveness.
Minimum mount height between stove top to hood bottom should be no less than 28“.
Any less is considered unsafe and not recommended.
Maximum mount height between stove top to hood bottom can be higher than 31 inch*, but
is recommended to be the best efficiency. (Extension available*)
If available, also refer to stove top manufacturer’s height clearance requirements and
recommended hood mounting height above range.
* Due to different ceiling height configurations, recommended height may not be applicable.
Minimum Duct Size:
Round - 6” minimum
Rectangular - 3 ¼” x 10” minimum (requires a 6” to 3 ¼” x 10” adaptor, not supplied)
IMPORTANT:
•
•
•
•
•
•
•
•
•
•
•
Pg 6
Height & Clearance
Duct Size Upgrade Calculator
Minimum duct size recommended is 6” round (or 3 ¼” x 10” rectangular). Maximum duct
length recommend is 50 ft. Any duct length over 50 ft is recommended to use a larger
diameter duct size.
Survey the installation application and record the estimated length of ducting required or
used for that application. Record the number of bends, angle of bends, and/or any
transitional pieces used. Each bend or transition will reduce air flow and reduce the
recommended duct length.
(1) 90° bend, (1) 3¼” x 10” transition, (2) 45°
bends, (1) sidewall cap with damper (with
factory damper not installed)
-9ft + -7ft + -5ft + -5ft + -1ft = -27ft
Deduct 27 ft from 50 ft, giving you 23 ft of
available straight ducting before it is
recommended to upgrade your ducting size.

Option 2: Horizontal wall venting
Side wall
cap
Option 1: Vertical roof venting
Roof cap
This range hood is factory set for venting through the roof or wall.
Vent work can terminate either through the roof or wall. To vent through a wall, a 90° elbow
is needed.
NEVER exhaust air or terminate duct work into spaces between walls, crawl spaces, ceiling,
attics or garages. All exhaust must be ducted to the outside.
Use metal/aluminum duct work only.
Fasten all connections with sheet metal screws and tape all joints with certified duct tape or
equivalent.
Use caulking to seal exterior wall or roof opening around the cap.
•
•
IMPORTANT:
•
•
•
•
Pg 7
Venting Methods

Copies of the standards listed may be obtained from:
* National Fire Protection Association
Batterymarch Park
Quincy, Massachusetts 02269
** CSA International
8501 East Pleasant Valley Road
Cleveland, Ohio 44131-5575
Remove grease filters from the hood.
Position the charcoal filters onto the side of the motor, aligning the mounting points, turn
until it locks. Re-install aluminum filters.
Charcoal filters must be replaced after 120 hours of use (or approximately every 2 to 3
months based on the average of 1 to 2 hours of daily cooking time). Available at your local
resellers.
To contact a qualified electrical installer.
To assure that the electrical installation is adequate and in conformance with National
Electrical Code, ANSI/NFPA 70 — latest edition*, or CSA Standards C22. 1-94, Canadian
Electrical Code, Part 1 and C22. 2 No. 0-M91 - latest edition** and all local codes and
ordinances.
Provide a circuit protected power service; preferably a Ground Fault Circuit Interrupter
("G.F.C.I."): 120-volt, 60 Hz, AC, with at least 5-amps of available service.
Enlist a qualified electrician to ensure the range hood and electrical lines are adequately
grounded and properly protected. NEVER electrically ground to a gas pipe.
Wire sizes (copper wire only) and connections must conform with the rating of the appliance
as specified on the model/serial rating label. Wire sizes must conform to the requirements of
the National Electrical Code ANSI/NFPA 70 — latest edition*, or CSA Standards C22. 1-94,
Canadian Electrical Code Part 1 and C22. 2 No. 0-M91 - latest edition** and all local codes and
ordinances. A U.L. - or C.S.A. - listed conduit connector must be provided at each end of the
power supply cable (at the range hood and at the junction box).
NOTE:
1.
2.
3.
IMPORTANT: Observe all governing ordinances and local codes.
(Please consult with a qualified electrician for any electrical wiring)
It is the customer’s responsibility:
•
•
•
•
IMPORTANT: Save this Installation Guide for future reference and/or electrical inspector use.
The range hood should be connected with a circuit breaker protected power service.
Pg 8
Charcoal Filter Installation
Electrical Requirements

Pg 9
Installation Overview
Chimney support frame
(May look different
depending on model)
Support frame
extensions
(Hole to hole
distance: =⅝-inch)
Island mount
range hood
Motor housing
Electric circuit box
6” Round duct (exhaust)
Air Movement Direction
* Due to different ceiling height configurations,
recommended height may not be applicable.
NOTE:
•
•
•Always use first and second holes
on the support frame extensions to
secure lower support frame.
Lag bolts designed to be affixed
into structural support. Pre-drill holes
as to not split structural pieces.
A distance of 28” to *31” is
recommended between stove top and
the bottom of range hood.
Qty: 4 PCS
Qty: 18 PCS
Qty: 2 PCS
Qty: 16 PCS
Qty: 24 PCS
Qty: 24 PCS

Figure 1
Familiarize yourself with the controls of the range hood by
reading through Range Hood Operations, Page 12.
Place the range hood on a flat, stable surface. Connect the
range hood to a designated standard outlet (please refer
the product label for the suitable voltage of this unit) and
turn on the range hood. Verify all operations of the range
hood by referring to Range Hood Operations, Page 12.
Place all supplied parts and required hardware on a flat, stable surface and verify the
presence of all supplied parts listed on Page 4.
Carefully remove the white plastic protective coat from the chimney covers and range hood.
NOTE: To avoid damage to your hood, prevent debris from entering the vent opening.
Determine and mark the center line on the ceiling where the range hood will be installed.
Make sure there is proper clearance within the ceiling or wall for exhaust vent.
Due to the weight and size of this unit, please make sure that the support system or
framework being used is stable and secure in the wall or ceiling.
Put a thick, protective covering over counter top, cook top or range to protect from damage
or dirt. Remove any hazardous objects around the area when installing.
Mark the locations of the support mounting bracket holes, ducting cutout (if used) and
power supply cable cutout on the ceiling. Use drill and saber saw or keyhole saw to cut
openings for power supply cable and ducting (see Venting requirements and Electrical
requirements, Pages 5-8).
If venting to the outside install vent system (see Venting Methods, Page 7). Use caulking to
seal exterior wall or roof openings.
Disconnect main electrical supply, prepare and run electrical wiring through ceiling or wall.
Leave approximately 12” of electrical cord hanging from the ceiling. DO NOT restore power
until installation is completed.
Disconnect power cord, remove the aluminum filter by pressing on the latch toward the
direction of solid arrow while holding the metal handle, gently pull the aluminum filter toward
the direction of dashed arrow as shown in Figure 1.
Remove the grease cup by sliding it sideway, see Figure 2 for location of the grease cup.
Set aside the aluminum filters and grease cup until the range hood is properly installed.
If the range hood comes with a glass canopy and has not already been mounted to the hood,
loosen the four canopy screws and washers from the hood top, carefully place the canopy on
the hood top, and loosely tighten the four canopy screws along with washers. DO NOT put
excessive pressure against the glass.
Advanced Preparations:
1.
2.
3.
4.
Preparations:
1.
2.
3.
4.
5.
6.
7.
8.
9.
Pg 10
Preparation
Excessive Weight
Require three or more persons to
move and install this range hood.
Spinal or other bodily injuries
could occur if it is not followed.
10.
Figure 2
Severe Injury
Rotating fan can cause severe
injury. Stay clear of fan when
power is present.

Pg 11
Installation
Figure 3
Mark where you want your range hood
installed:
Measure and mark the location of where you
want your chimney and range hood installed,
and then align the upper support frame
within those marks. Make additional marks at
the locations of the mounting bolt holes.
Ensure there is enough clearance for the
range hood body to attach to the support
frame without colliding into any other
objects.
Predrill mounting holes:
Predrill the bolt hole locations, so the bolts
do not split apart or weaken any supporting
frames or joist.
Mount the upper support frame:
Align the upper support frame with the
predrilled holes in ceiling. Mount the upper
support frame to the ceiling using (4) four
“A” bolts (or fasteners that meet or exceed
the factory hardware). Ensure the upper
support frame is securely fastened to the
joist or support in the ceiling. Attach the
upper support frame to ceiling using
fasteners or anchors recommended for your
type of ceiling:
• Sheet rock or Wood ceilings: Attach
support frame to ceiling structural joists or
stud blockings if possible. If ceiling joists or
stud blockings are not available, it is required
to build a supporting structure behind the
sheet rock for the best support.
1.
2.
3.
4.
5.
• Concrete ceiling: Use designated concrete screws and/or anchors (not provided) that
meet or exceed the factory hardware specifications.
[OPTIONAL] Install Recirculation Kit:
Skip this step if the optional “non-venting kit” or “re-circulating kit” was not purchased.
Place the air diverter assembly inside upper support frame so that its 6-inch round hole
faces downward and then secure it with four “F” bolts onto the upper support frame.
Measure and mark the installation height of the support frame extensions:
Position the support frame extensions at the inside corners of the support frames, adjust
and mark each support frame extension as necessary to achieve the proper height for the
range hood to be set away from the cook top. (See “Height and Clearance” on Page 5 and
“Installation Overview” on Page 10).
• Some support frame extensions are made of multiple pieces fastened together
(depending on model) to adjust for length
• Adjust the support frame extensions as needed (depending on model)
Hazard of electrical shock!
Do not perform service on an electrically
live system. Disconnect the main
electrical supply before servicing this
device. Touching electrical connectors or
other exposed electrical circuitry inside
this range hood when they are energized
could result in death, serious bodily injury,
or property damage.
IMPORTANT: Remove the filters from the range
hood, so they do not get damaged during
installation.
Adjust
support
frame
extensions
Stud
joists
Secure upper
support frame
Insert lower
support frame
with extensions
(Optional
depending
on model)

Pg 12
Installation (Continued)
Install the support frame extensions onto the
range hood body:
Fasten the adjusted (Step 5) support frame
extensions onto the lower support frame
using “B” screws and “C” nuts as shown in
Figure 3. Each end of support frame
extension should be installed with at least (2)
two “B” and “C” fasteners. Repeat this step
for all the support frame extensions.
• If your specific model does not have a
lower support frame, then the support frame
extensions will fasten directly onto the range
hood body, using the same “B” and “C”
fasteners. IMPORTANT: Always use at least 1
bolt and nut set on each side of the support
frame extensions, (2-sides on each) on both
ends (2-ends on each).
Install the flexible duct tube:
Install and affix the flexible duct tube onto the household ducting (or Air Diverter assembly)
at the top of the chimney; extend the ducting down and ensure there is approximately 6” of
ducting to install onto the vent ducting. Only use approved ducting tape or fastening
devices.
Partially install the chimney covers onto the range hood:
Position the chimney covers over the support frame extensions, resting onto the range
hood. Ensure they are the correct orientation as if they fully installed.
Install the support frame extensions and range hood assembly onto the upper support
frame:
Have multiple people lift, hold and position the range hood assembly (with chimney covers)
to install the open end of support frame extensions onto the upper support frame (already
installed into your ceiling). Fasten each extension with “B” screws and “C” nuts as shown in
Figure 3. IMPORTANT: Always use at least 1 bolt on each side of the support frame
extensions, on both ends.
Connect the ducting the power plug:
Ensure there is no power present at the power outlet, plug in the unit, and also affix the
flexible ducting. Only use approved ducting tape or fastening devices.
Affix the upper chimney cover onto the upper support frame:
Using the “D” screws, separate, lift and position the upper chimney cover over the upper
support frame, aligning the mounting holes, and then affixing the upper chimney into place.
Re-install grease cup, grease filters and also remove all protective wrapping, and then check
all range hood functions. Clean stainless steel surfaces with stainless steel cleaner.
6.
7.
8.
9.
10.
11.
12.
Figure 4
Slide up and secure
upper chimney
Slide up, hold in
position and secure
lower chimney
to range hood

Pg 13
Control Panel, Display and Functions:
Power Button
Decrease Button
Light Button
Increase Button
Range Hood Operations
Clock / Digital Display
General Note: For the best results, turn on the vent prior to any cooking and keep vent
running while cooking. Adjust the vent power as needed.
Power ON / OFF
Press the Power Button to turn ON the range hood. To turn it OFF, press the
Power Button again, and the system will automatically delay the shutoff for 3-minutes,
displaying a countdown timer. If you want the vent to turn off immediately, press the
Power Button again.
Three-Minute Power Off Delay
While the vent is on, press the Power Button once to enter the Delayed Shutoff
Mode. The Digital Display will then flash and the vent function will turn off after
3-minutes. To cancel the Delayed Shutoff Mode, press the Power Button again and the
vent will shut off immediately. When the Delayed Shutoff Mode is entered, changing
the vent speed level will not affect the countdown.
Speed Control
While the vent is on, press the Increase Button to increase the speed level. Press
the Decrease Button to decrease the vent speed level. The highest speed setting is
indicated by an “F6”, and the lowest by “F1”.
Light Control
Press the Light Button to turn the lights on; press it again to turn the lights off.
Clock Function
To enter clock setting, while the vent system is off, press and hold the Power Button.
Press the Increase / Decrease Buttons to adjust the ‘hour’ setting. Press the Power
Button again to enter ‘minute’ setting; press the Increase / Decrease Buttons to adjust
the ‘minute’ settings. The system will automatically exit the clock setting mode after
3-seconds.

Note: For all other inquiries, please contact us. Our contact information can be found on the back cover page.
Troubleshooting
If the range hood or light
does not operate after
installation:
Check if the range hood has been plugged in, make
sure that all power has been turned back ON, and all
electrical wiring are properly connected.
Swap out light bulb to working ones to determine
whether it is caused by defective bulbs. See
Replacing the light bulbs on Page 17.
•
•
•
•
The suction or fan seems
weak:
Check that the duct sized used is at least 6” or
3 ¼” x 10”. Range hood WILL NOT function
efficiently with insufficient duct size. For example:
7” duct over 6” hole and loosely secured.
Check if duct is clogged or if damper unit
(half-circular flapper) is not installed correctly or
opening properly. A tight mesh on a side wall cap
unit might also cause restriction to the air flow.
•
•
•
The hood is not venting out
properly:
Make sure the distance between the stove top and
the bottom of the hood is within 28” and 31” in
distance. *Due to different ceiling height
configurations, recommended height may not be
applicable.
Reduce the number of elbows and length of duct
work. Check if all joints are properly connected,
sealed, and taped.
Make sure the power is on high speed for heavy
cooking.
•
The range hood vibrates
when the suction is on:
The range hood might not have been secured
properly on to the ceiling or wall. Check with your
installer
•
The lights work but the
suction is not spinning, is
stuck or is rattling.
The blower might be jammed or scraping the
bottom due to shipping damage. Please contact us
immediately.
•
Purpose of the
slots/holes/openings near the
top of the upper chimney:
These slots/holes/openings are used to exhaust
filtered air.
Pg 14

Body Material Stainless Steel, Brushed Satin Finish
Overall Voltage 115V/60Hz
Maximum Power Usage LED: 132W
Motor Power 120W
Motor Speed 600 to 1800 RPM, 6 Levels
Maximum Airflow 900 CFM
Air Pressure 320 pa
Noise Level (dB / Sone) Approx. 32 / 0.3 to 72 / 7.0
Motor Type Induction, Ultra Quiet
Fan Type Centrifugal
Control Type Dual Electronic Control Panels with LCD Display
Filtration Type Stainless Steel Baffle Filter
Lighting Wattage LED: 3W (x4)
Lamp Type SV12-LED
Ducting / Venting 6 inches, Round, Top Venting
Protections Electrical Short Fuse, Radio Frequency Interference
* Subject to change without notice, please contact your local reseller for details.
Read and understand all instructions and warnings in this manual before operating the
appliance. Save these instructions for future reference.
Always leave safety grills and filters in place. Without these components, operating blowers
could catch on to hair, fingers and loose clothing.
NEVER dispose cigarette ashes, ignitable substances, or any foreign objects into blowers
NEVER leave cooking unattended. When frying, oil in the pan can easily overheat and catch
fire. The risk of self combustion is higher when the oil has been used several times.
NEVER cook using “open” flames under the range hood. Check deep-fryers during use:
Superheated oil may be flammable.
The saturation of greasy residue in the blower and filters may cause increased inflammability.
Keep unit clean and free of grease and residue build-up at all times to prevent possible fires.
Filters must be cleaned periodically and free from accumulation of cooking residue (see
cleaning instructions on Page 17). Old and worn filters must be replaced immediately.
DO NOT operate blowers when filters are removed. Never disassemble parts to clean
without proper instructions. Disassembly is recommended to be performed by qualified
personnel only. Read and understand all instructions and warnings in this manual before
proceeding.
Operations:
•
•
•
•
•
Cleaning:
•
•
•
Use and Care Information
Specifications
Pg 15Pg 15

Pg 16
Electric Schematic
* Subject to change without notice, please contact your local reseller for details.
Black
MOTOR
Blue
White
Pink
Red
Fan 6
Fan 5
Fan 4
Fan 3
Fan 2
Fan 1
Fan (-)
Neutral
Live
Orange
Purple
Green
Yellow
Yellow
12uf/250v (110v)
4uf/500v (220v)
Brown
MO_1
MO_2
MO_3
MO_4
MO_5
MO_6
Lamp (-)
Lamp (+)
AC_L
AC_N
MO_n
White
White
Black

SAFETY WARNING: Never put your hand into area housing the fan while the fan is operating!
For optimal operation, clean range hood and all baffle/spacer/filter/grease tunnel/oil container
regularly. Regular care will help preserve the appearance of the range hood.
Clean periodically with hot soapy water and clean cotton cloth. DO NOT use corrosive or
abrasive detergent (e.g. Comet Power Scruv®, EZ-Off® oven cleaner), or steel wool/scoring
pads, which will scratch and damage the stainless steel surface. For heavier soil use liquid
degrease such as “Forumla 409®” or “Fantastic®” brand cleaner.
If the finish looks splotchy (stainless steel hood), use a stainless steel cleaner to clean the
surface of the hood. Use a dry soft towel to dry the hood. CAUTION: Do not leave the
cleaning solution on the surface too long as this may damage the finish. Avoid getting
cleaning solutions into or onto the control panel, computer components, wires or wired plugs.
Always wipe/clean/polish in the same direction as the brushed stainless steel finish. Never
wipe against the grain.
After cleaning, you may use non abrasive stainless steel polish such as 3M® or ZEP®, to
polish and buff out the stainless luster and grain. Always scrub lightly, with clean cotton
cloth, and with the grain.
DO NOT allow deposits to accumulate or remain on the hood, as they will become harder to
clean, and may cause scratching of the finish.
DO NOT use ordinary steel wool or steel brushes. Small bits of steel may adhere to the
surface and cause rusting.
DO NOT allow salt solutions, disinfectants, bleaches, or cleaning compounds to remain in
contact with stainless steel for extended periods. Many compounds contain chemicals, which
may be damaging. Rinse with water after exposure and wipe dry with a clean cloth.
The metal filters are intended to help filter grease, residue and moisture from cooking.
They are required to be kept clean for performance and safety concerns, and may require
replacement if neglected.
Filters should be cleaned after every 30 hours of use or sooner depending on usage
conditions.
Remove and clean by hand or dishwasher. NOTE: Some newer dish detergents may cause
marking or blackening of aluminum metals, such as the mesh aluminum filters. Spray
“Formula 409®” or equivalent degreasing detergent and allow to soak if heavily soiled. Rinse
with warm water, allow the filters to dry and then and re-install before using hood.
Should filters wear out due to age and prolonged use, please contact your local reseller for
replacement filters. Consider preemptively purchasing an extra set of filters to store on hand,
or upgrading to stainless steel baffle filters.
Note: Also replace damaged filter that has punctured or broken mesh, bent or broken frame.
Cleaning Exterior Surfaces:
•
•
•
•
•
•
•
Cleaning Aluminum Grease Filter / Stainless Steel Filterless Grill:
IMPORTANT: Drain oil from oil containers before potential residue overflow!
•
•
•
Replacing Filters:
•
•
Maintenance
Pg 17

Check the range hood tag for lamp specifications. Halogen bulbs will not work on "LED"
models (they will lightly pulse or flash).
Before performing any task outside of basic operation, turn off the power supply and/or
unplug the unit.
Before attempting to handle the light bulbs, ensure the bulbs are cool to the touch,
including any adjacent working surfaces
Replacing The Light Bulb:
•
•
•
Light bulb become extremely hot when turned on. DO NOT touch bulb until
switched off and cooled. Touching hot bulbs could cause serious burns.
Hazard of Burns!
Maintenance (Continued)
Replacing LED Light Fixture:
•This range hood uses LED light fixture: 3W Max 12V LED
•Make sure the range hood is unplugged or turn OFF breaker and the lights are cool to
touch.
•Place a flat-head screwdriver between light housing and hood body, gently pry up the light
housing and search for the metal clip. (Recommended: use multiple layers of tape over the
screwdriver head to prevent any scratching of the finish)
•Apply force to the metal clip and pull out the light fixture. Disconnect the power cable and
discard the old light fixture.
•Reverse the steps to install a new halogen light fixture. Turn ON breaker and range hood
to test for operation.
Pg 18

Pg 19
The information in this document is subject to change without notice, please contact your local reseller for updated details.
For one year from the date of original purchase, your local reseller will provide free of
charge, non-consumable replacement parts or components that failed due to manufacturing
defects. Subject to the conditions and limitations set forth below, your local reseller will, at
its option, either repair or replace any part of its products that prove defective by reason of
improper workmanship or materials. Repaired parts or replacement products will be
provided by your local reseller on an exchange basis, and will be either new or refurbished to
be functionally equivalent to new. The consumer is responsible for all shipping costs.
Consumable parts not covered by this warranty include but not limited to: Light bulbs, metal,
aluminum and charcoal filters.
One Year Parts Warranty:
This warranty is extended to the original purchaser for products purchased for ordinary
home use.
Who is Covered:
Product damaged through negligence, improper installation, accident, abuse, misuse, natural
disaster, insufficient or excessive electrical supply, abnormal mechanical or environmental
conditions, or any unauthorized disassembly, repair, modification, or failure to follow
installation instructions. When product is used commercially or other than its intended
purpose. Damaged because of improper connection with equipment of other manufacturers.
Repaired or modified by anyone other than your local reseller’s authorized agents. This
limited warranty also does not apply to any product on which the original identification
information has been altered, obliterated or removed, has not been handled or packaged
correctly or has been sold as second-hand.
This Warranty Will Be Voided When:
Consumable parts such as light bulbs, metal and charcoal filters. The natural wear of finish,
and wear due to improper maintenance, use of corrosive and abrasive cleaning products,
pads, and oven cleaner products. Chips, dents or cracks due to abuse, misuse, freight
damage, or improper installation. Damage of product caused by accident, fire, floods or act
of God. The manufacturer and/or distributor/reseller is not liable for, and does not cover
under warranty, any loss of properties or any costs associated with removing, servicing,
installing, or determining the source of problems with this product.
This warranty is valid in the country of the original purchase at retail. It is non-transferable and
applies only to the original purchaser and does not extend to subsequent owners of this
product. Any applicable implied warranties, including the warranty of merchantability, are
limited in duration to a period of express warranty as provided herein beginning with the date
of original purchase at retail and, no warranties, whether express or implied, shall apply to this
product thereafter.
To obtain warranty service, you may contact your local reseller from which you purchased this
product. Please confirm the terms of your local reseller’s policies prior to contacting.
Typically, you must include product identification information, including model number and
serial number with a detailed description of the problem you are experiencing. You must also
include proof of the date of original retail purchase as evidence that the product is within the
applicable warranty period.
What is Not Covered:
Warranty
