CBM LUMIX User manual

LUMIX
Advanced Lighting Controller
for dual color LED lights
User’s Manual V1.0
The LUMIX offers an intuitive and easy to use touch screen interface.
This lighting controller allows you to precisely control light intensity as well as
the K-Color of dual color LED lights with the use of the light sensor.
Program the schedule with up to 24 different periods of 24 steps each.
The LUMIX has two 10A lighting outputs
compatible with American and European standards
(120V / 240V, 50Hz / 60Hz)
and an alarm relay
© 2018 - 2019 8032319 Canada Inc.
Lux and
K-Color
Light Sensor
10A Outputs
to control
dual color
LED lights
Alarm
Relay
Touch
Screen
Transistor
outputs
to avoid
flickering
Day: 2/10 - Period: 1
12:00
40 LUX
42 LUX
4200 K
4230 K

Description:
The LUMIX is a lighting dimmer with a programmable schedule,
specifically designed for livestock applications.
It has a light sensor that measures the light intensity in Lux as well
as the color of the lighting in Kelvins. This allows it to maintain a
steady light intensity and color.
The LUMIX schedule contains 24 different programmable periods.
Each period can contain up to 24 lighting steps per cycle.
The LUMIX can also operate as a slave system for a master controller
using its 0-10V inputs. It then acts as a power module that converts
a 0-10V signal into power applied to the lighting outputs.
A manual mode allows you to control your lighting manually,
regardless of the schedule, whether in master or slave mode.
The LUMIX allows you to protect your programmed schedule and
settings with two functions:
- A 4-digit access code can be used to lock the system. When the
system is locked, no changes can be made to the schedule or
settings.
- A non-volatile internal memory allows you to make a backup copy
of your schedule and settings.
Presentation of the LUMIX

How the LUMIX works
Lexicon:
Step: a step is a specific point in time. Each step consists of one
hour, a set point for the luminous intensity and a set point for the
color.
Period: The period is a group of steps, on a 24h cycle. It starts at
00:00 and ends at 23:59. The periods are repeated a certain number
of days.
Schedule: The schedule is composed of all the periods. The total
duration of the schedule is the sum of the number of days in each
period.
How the schedule works:
Throughout the schedule, every minute of the day is a point in time
that matches with a step, or that is between 2 steps. The system
automatically calculates the intensity and color set points to be
applied for each moment of the day according to the steps
programmed in the schedule.
Each period will be run sequentially, starting with period 1 on day 1.
A period with the number of days at 0 will be ignored. When the last
day of the schedule is over, the system will repeat the last period,
until the clock is reset to day 1.

The interface:
The LUMIX is fully programmed using its touch screen. Each screen
displays different controls that can be operated by a simple touch of
the finger, such as buttons or progress bars. The touch screen of the
LUMIX detects only one touch at a time. The interface is very intuitive
and easy to master.
Lights:
The LUMIX is specially designed to work with dual color LED lights. It
can adjust each color independently, and thus create any light
intensity of any color that lies within the limits of the lights used. It
can also be used in monochrome mode with standard light fixtures. In
that case, only the intensity in Lux will be used and both outputs will
operate at the same level at all time, except in manual mode.
Light Sensor:
The light sensor is able to measure the light intensity as well as the
color of the light that shines on it with great precision. Keep in mind
that emitted light as well as reflected light will be detected by the
sensor. Avoid mounting the sensor near brightly colored objects.
Alarm Relay:
The alarm relay detects a malfunction of the light sensor that could
prevent the LUMIX from functioning properly. A jumper on the
electronic board allows to choose a NO (normally open) or NC
(normally closed) contact. When the sensor is operating normally, the
relay is in its “normal” state: the NO contact is open and the NC
contact is closed. When the LUMIX detects that the sensor is not
working, the state of the relay is reversed.
How the LUMIX works

Parameters:
Parameter Lock: The lock allows you to prevent changes to the
parameters and schedule. A padlock icon will flash to indicate that
the system is locked. You have to unlock the system by entering the
correct code in order to change the parameters or schedule. You can
use a different code each time you lock the system. Only the last
code entered will be accepted to unlock. If you forget the code, refer
to the “Reset to Default Parameters” section.
Language: Lets you to choose the language of the interface.
Mode: To choose whether the control operates in master mode or in
slave mode. In master mode, the system schedule is used to control
the lighting outputs. In slave mode, it is a 0-10V voltage supplied by
an external source that controls the lighting outputs.
Phase Dimming: Determines the compatibility of the dimmer with
the installed lights. Some lights work best with one mode or the
other. It's up to you to find out which of the two modes best suits
your lighting.
Chromatic Lighting: Allows you to enable or disable color control.
Disable color lighting if your fixtures do not support this technology.
How the LUMIX works

Schedule Programming:
The LUMIX schedule consists of up to 24 periods, each of which can
contain up to 24 steps. You can use the programming worksheet in
this manual to help you visualize the lighting curves you want to
program.
Periods
The schedule is a series of periods that follow one after the other.
Each period is repeated for a number of days which is programmed
for each period.
The Period Scheduling screen allows you to add or remove periods in
the schedule and configure the number of days each of these periods
will be repeated. This screen also shows you the total duration of
your schedule. The schedule can contain up to 12 periods in total.
Press the “Edit” button to access the step programming screen.
Steps
Each period is programmed by placing steps to places which define
the desired light level and color adjustments. The system will
calculate the dimming slope between the steps automatically. If two
steps are at the same level, the intensity will not vary between these
two steps. The same goes for color.
How the LUMIX works

0h 1h 2h 3h 4h 5h 6h 7h 8h 9h
10h
11h
12h 13h 14h 15h 16h 17h 18h 19h 20h 21h 22h 23h
100%
80%
60%
40%
20%
0%
Based on the following example:
For lighting that gradually turns on at 8h00 and turns off gradually at
22h00 with a 30-minute slope:
You need to program the following 4 steps:
Step 1 at 8h00 - Light level 0%
Step 2 at 8h30 - Light level 100%
Step 3 at 21h30 - Light level 100%
Step 4 at 22h00 - Light level 0%
This programming will have the following effect:
From 8h00 to 8h30, the intensity of the lighting will increase from
0% to 100% gradually.
From 8h30 to 21h30 the lighting will stay at the same level, 100%
From 21h30 to 22h00 the intensity of the lighting will decrease from
100% to 0% gradually.
From 22h to 8h the lighting will stay at the same level, 0%
By adjusting these values and adding steps, you can create the ideal
lighting curve for your needs.
You can use up to 24 steps in a period.
Use the on screen visualization bar as a guide, it shows you a
preview of light variations throughout the period as you modify the
steps parameters. You can also use the following page to draw your
lighting curve and set the required steps.
step 1
step 2 step 3
step 4

Programming Worksheet
0h 1h 2h 3h 4h 5h 6h 7h 8h 9h
10h
11h
12h 13h 14h 15h 16h 17h 18h 19h 20h 21h 22h 23h
100%
80%
60%
40%
20%
0%
Period: Number of days:
0h 1h 2h 3h 4h 5h 6h 7h 8h 9h
10h
11h
12h 13h 14h 15h 16h 17h 18h 19h 20h 21h 22h 23h
100%
80%
60%
40%
20%
0%
Period: Number of days:
0h 1h 2h 3h 4h 5h 6h 7h 8h 9h
10h
11h
12h 13h 14h 15h 16h 17h 18h 19h 20h 21h 22h 23h
100%
80%
60%
40%
20%
0%
Period: Number of days:
0h 1h 2h 3h 4h 5h 6h 7h 8h 9h
10h
11h
12h 13h 14h 15h 16h 17h 18h 19h 20h 21h 22h 23h
100%
80%
60%
40%
20%
0%
Period: Number of days:

Reset to Default Parameters:
The procedure to reset the system to the default values is as follows:
1- Turn the main power off
2- Remove the battery
3- Wait about 30 seconds
4- Replace the battery
5- Turn the main power back on
This procedure clears all parameters from memory and the system
will return to default values.
The schedule is completely erased for both zones.
Touch screen calibration is reset.
The lock code is removed.
After restarting the system, you will need to calibrate the touch
screen before you can use it.
Resetting to default values does not affect the internal nonvolatile
memory. If you have saved your data, you can always recover it after
a reset to default values.

12:00
Day: 2/10 - Period: 1
40 LUX
42 LUX
4200 K
4230 K
Big characters, the light intensity measured in Lux by the sensor.
Smaller characters is the calculated setpoint for
this specific moment in the schedule.
Big characters, the lighting color measured in Kelvins by the sensor.
Smaller characters is the calculated setpoint for this specific
moment in the schedule. If the color mode is
disabled this information is not visible.
Day: 2/10 - Period: 1
12:00
40 LUX
42 LUX
4200 K
4230 K
1: 25% 2: 12%
1: 25%
2: 12%
MAIN SCREEN - MASTER MODE
Press to access the main menu
Current Time
Schedule Progression:
current day: 2
total schedule duration: 10 days
current period: 1
Graphical visualization of the 24h period in progress
which begins from 0h00 left to 23h59 to the right.
Cursor that indicates the current time on the visualization bar.
Bars that indicate the power applied to the outputs.

12:00
0-10V Input: 1.27V
40 LUX
42 LUX
4200 K
4230 K
0-10V Input: 1.27V
12:00
40 LUX
42 LUX
4200 K
4230 K
1: 25% 2: 12%
1: 25%
2: 12%
MAIN SCREEN - SLAVE MODE
Big characters, the light intensity measured in Lux by the sensor.
Smaller characters is the calculated setpoint based
on the 0-10V Input configuration.
Big characters, the lighting color measured in Kelvins by the sensor.
Smaller characters is the calculated setpoint based
on the 0-10V Input configuration. If the chromatic mode is
disabled this information is not visible.
Press to access the main menu
Current Time
Bars that indicate the power applied to the outputs.
Reading of the measured voltage at the 0-10V input

0-10V
0-10V
MAIN MENU
Schedule Programming
Manual Mode
Clock Adjustment
Data Backup / Recovery
Configuration Settings
Low level lighting adjustment
Previous Menu (Main Screen)
0-10V Input Configuration

Configuration
Parameter Lock: Off
Language: English
Mode: Master
Phase Dimming: LED
Chromatic Lighting: Yes
CONFIGURATION MENU
Press a parameter button to access the parameter adjustment window.
Press the left arrow to go back.

LOCK / UNLOCK CODE
- - - -
The code entered is displayed at the top center. The number of lines indicates
the number of digits requested for a valid code (4 in this version).
The requested action is displayed at the bottom center. Lock, Confirm or Unlock.
Press the numbers to enter the code.
Press to delete the last digit entered.
Press the checkmark to accept the entered code. If the code is invalid,
the code will be erased and you will have to start again.
Press the X to cancel and return to the previous menu.
Enter code to lock
87 9
5
46
21 3
0

PARAMETER ADJUSTMENT
Language
English
The parameter name is displayed at the top.
The current value of the parameter is displayed in the center square.
Press the up / down arrows to adjust the parameter value.
Press the checkmark to accept the new value and return to
the previous menu.
Press the X to cancel and return to the previous menu.
The value of the parameter will be unchanged.

CLOCK ADJUSTMENT
Clock Adjustment
12:00
Adjust the current day using the arrows above and below the day.
Adjust the hours and minutes using the arrows above and below
the time.
Press the checkmark to accept the new time.
Press the X to cancel. The time will remain unchanged.
Day: 1

4 3
Edit
SCHEDULE PROGRAMMING
The total duration of the schedule is displayed at the top center.
Use the left and right arrow buttons to select the period to want to
program and the number of days for the duration of this period.
Use and to add or remove periods in the schedule. You have to
hold these buttons for a few seconds to confirm the addition or removal of
periods.
Press to view the details of the period and program
the different steps for that period.
The view bar gives you an overview of the selected period.
Press the checkmark to accept and return to the main menu.
Edit
Schedule Programming
Period Number of days
Total Duration: 20 days
Number of periods: 1

Number of periods: 1
15:00
4
Step 120 LUX 4200K
Period 1
EDIT PERIOD
Use the left and right arrows to select the step to edit.
For each step, adjust the time of the step, as well as the intensity and color
using the up and down arrows that are above and below the parameters.
Use and to adjust the number of steps for this period.
You have to hold these buttons for a few seconds to confirm the addition
or removal of steps.
The visualization bar changes in real time as you adjust the step parameters.
The slider above the visualization bar shows the time of the selected step
on a 24-hour cycle.
Press the checkmark to accept and return to the schedule programming screen.
If the chromatic mode is disabled, you can’t program the color

Manual Mode
1: 25%
2: 12%
Auto Manual
MANUAL MODE
The buttons at the bottom allow you to select Automatic or Manual mode
The top bar controls the red lights (lights connected to output 1).
The bottom bar controls the blue lights (lights connected to output 2).
Move your finger on the bar in the center to adjust the power of
the output in manual mode.
Press the arrows on either side of the bar for more precision.
Press the arrow on the bottom left to return to the previous menu

Config
24.0 18.0
LIGHTS CONFIGURATION
The "config" button enables or disables the configuration mode.
In configuration mode, the system goes into manual mode and sets the
light level at 0.1% to allow you to adjust the minimum level.
Press the up and down arrows to adjust the minimum level
for zone 1 on the left and zone 2 on the right.
Press the arrow on the bottom left to return to the previous menu.
Note: A light level of 0.1% is the lowest level that can be achieved.
Below 0.1%, the outputs are completely disabled.
Lights Configuration
- Activate the config button
to set lighting in manual mode
at 0.1%
- Adjust the output levels for
the desired 0.1% lighting
