Arbor Technology ARES-1980 Series User manual

I
ARES-1980 Series
Fanless Rugged Controller with 11th Gen.
Intel®Core™ i7/i5/i3 Processor
User’s Manual
Version 1.0
2021.12
P/N: 4016198000100P

- II -
Revision History
Version Date Description
1.0 2021.12 Initial release

- i -
Contents
Revision History................................................................................II
Contents..............................................................................................i
Preface...............................................................................................iii
Copyright Notice .....................................................................................iii
Declaration of Conformity .......................................................................iii
CE....................................................................................................iii
FCC Class A....................................................................................iii
RoHS.............................................................................................. iv
SVHC / REACH.............................................................................. iv
Important Safety Instructions..................................................................v
Warning.................................................................................................. vi
Lithium Battery Replacement................................................................. vi
Technical Support .................................................................................. vi
Warranty.................................................................................................vii
Chapter 1 - Introduction....................................................................1
1.1. Features...........................................................................................2
1.2. About this Manual ............................................................................2
1.3. Specications...................................................................................3
1.3. Inside the Package ..........................................................................5
Chapter 2 - Getting Started...............................................................7
2.1. Dimensions......................................................................................8
2.2. Overview..........................................................................................9
2.2.1. Front View .............................................................................9
2.2.2. Left Side View........................................................................9
2.2.3. Right Side View ...................................................................10
2.3. Driver Installation Note...................................................................11
Chapter 3 - Engine of the Computer..............................................13
3.1. Boards Overview............................................................................14
3.2. Connectors ....................................................................................16
Chapter 4 - Installation and Maintenance......................................23
4.1. Disassembling and Assembling the Computer ..............................24
4.1.1. Disassembling the Computer...............................................24
4.1.2. Assembling the Computer....................................................25
4.2. Installing Hardware........................................................................26
4.2.1. Installing Memory Module....................................................26
4.2.2. Installing/Replacing a SSD or HDD.....................................28
4.2.3. Installing M.2 Module...........................................................30
4.2.4. Installing Encription Dongle.................................................31
4.2.5. Install/uninstall SIM Card and relative connection module..32
4.2.6. Install/uninstall WI-FI connection module............................35
Contents

- ii -
Contents
Chapter 5 - BIOS..............................................................................39
5.1. Main...............................................................................................42
5.2. Advanced.......................................................................................43
5.2.1. CPU Conguration...............................................................44
5.2.2. Power & Performance..........................................................45
5.2.3. Trusted Computing .............................................................48
5.2.4. ACPI Settings.......................................................................50
5.2.5. F81966 Super IO Conguration...........................................51
5.2.6. Hardware Monitor................................................................52
5.2.7. S5 RTC Wake Settings........................................................53
5.2.8. Serial Port Console Redirection...........................................54
5.2.9. USB Conguration ...............................................................55
5.2.10. Network Stack Conguration .............................................57
5.2.11. NVME Conguration ..........................................................58
5.3. Chipset...........................................................................................59
5.3.1. System Agent (SA) Conguration........................................60
5.3.2. PCH-IO Conguration..........................................................63
5.4. Security..........................................................................................66
5.4.1 Security Boot ........................................................................67
5.5. Boot................................................................................................68
5.6. Save & Exit ....................................................................................70

- iii -
Preface
Copyright Notice
All Rights Reserved.
The information in this document is subject to change without prior notice in
order to improve the reliability, design and function. It does not represent a
commitment on the part of the manufacturer.
Under no circumstances will the manufacturer be liable for any direct, indirect,
special, incidental, or consequential damages arising from the use or inability
to use the product or documentation, even if advised of the possibility of such
damages.
This document contains proprietary information protected by copyright.All rights
are reserved. No part of this document may be reproduced by any mechanical,
electronic, or other means in any form without prior written permission of the
manufacturer.
Declaration of Conformity
CE
The CE symbol on your product indicates that it is in compliance with the
directives of the Union European (EU). A Certicate of Compliance is available
by contacting Technical Support.
This product has passed the CE test for environmental specications when
shielded cables are used for external wiring. We recommend the use of shielded
cables. This kind of cable is available from ARBOR. Please contact your local
supplier for ordering information.
Warning
This is a class A product. In a domestic environment this product may cause
radio interference in which case the user may be required to take adequate
measures.
FCC Class A
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference
that may cause undesired operation.

- iv -
Preface
NOTE:
This equipment has been tested and found to comply with the limits for a
Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference when the
equipment is operated in a commercial environment. This equipment generates,
uses, and can radiate radio frequency energy and, if not installed and used in
accordance with the instruction manual, may cause harmful interference to radio
communications. Operation of this equipment in a residential area is likely to
cause harmful interference in which case the user will be required to correct the
interference at his own expense.
RoHS
ARBOR Technology Corp. certies that all components in its products are
in compliance and conform to the European Union’s Restriction of Use of
Hazardous Substances in Electrical and Electronic Equipment (RoHS) Directive
2002/95/EC.
The above mentioned directive was published on 2/13/2003. The main purpose
of the directive is to prohibit the use of lead, mercury, cadmium, hexavalent
chromium, polybrominated biphenyls (PBB), and polybrominated diphenyl
ethers (PBDE) in electrical and electronic products. Member states of the EU are
to enforce by 7/1/2006.
ARBOR Technology Corp. hereby states that the listed products do not contain
unintentional additions of lead, mercury, hex chrome, PBB or PBDB that exceed
a maximum concentration value of 0.1% by weight or for cadmium exceed
0.01% by weight, per homogenous material. Homogenous material is dened as
a substance or mixture of substances with uniform composition (such as solders,
resins, plating, etc.). Lead-free solder is used for all terminations (Sn(96-96.5%),
Ag(3.0-3.5%) and Cu(0.5%)).
SVHC / REACH
To minimize the environmental impact and take more responsibility to the earth
we live, Arbor hereby conrms all products comply with the restriction of SVHC
(Substances of Very High Concern) in (EC) 1907/2006 (REACH --Registration,
Evaluation, Authorization, and Restriction of Chemicals) regulated by the
European Union.
All substances listed in SVHC < 0.1 % by weight (1000 ppm)

- v -
Preface
Important Safety Instructions
Read these safety instructions carefully
1. Read all cautions and warnings on the equipment.
2. Place this equipment on a reliable surface when installing. Dropping it or
letting it fall may cause damage
3. Make sure the correct voltage is connected to the equipment.
4. For pluggable equipment, the socket outlet should be near the equipment
and should be easily accessible.
5. Keep this equipment away from humidity.
6. The openings on the enclosure are for air convection and protect the
equipment from overheating. DO NOT COVER THE OPENINGS.
7. Position the power cord so that people cannot step on it. Do not place
anything over the power cord.
8. Never pour any liquid into opening. This may cause re or electrical shock.
9. Never open the equipment. For safety reasons, the equipment should be
opened only by qualied service personnel.
10. If one of the following situations arises, get the equipment checked by
service personnel:
a. The power cord or plug is damaged.
b. Liquid has penetrated into the equipment.
c. The equipment has been exposed to moisture.
d. Theequipmentdoesnotworkwell,oryoucannotgetittoworkaccording
to the user’s manual.
e. The equipment has been dropped or damaged.
f. The equipment has obvious signs of breakage.
11. Keep this User’s Manual for later reference.

- vi -
Preface
Warning
The Box PC and its components contain very delicately Integrated Circuits (IC).
To protect the Box PC and its components against damage caused by static
electricity, you should always follow the precautions below when handling it:
1. Disconnect your Box PC from the power source when you want to work on
the inside.
2. Use a grounded wrist strap when handling computer components.
3. Place components on a grounded antistatic pad or on the bag that came
with the Box PC, whenever components are separated from the system.
Lithium Battery Replacement
Incorrect replacement of the lithium battery may lead to a risk of explosion.
The lithium battery must be replaced with an identical battery or a battery type
recommended by the manufacturer.
Do not throw lithium batteries into the trash can. It must be disposed of in
accordance with local regulations concerning special waste.
Technical Support
If you have any technical di󰀩culties, please consult the user’s manual rst at:
https://www.arbor-technology.com
Please donot hesitate tocall or e-mail ourcustomer servicewhen you stillcannot
nd out the answer.
https://www.arbor-technology.com
E-mail:[e-mail]

- vii -
Preface
Warranty
This product is warranted to be in good working order for a period of one year
from the date of purchase. Should this product fail to be in good working order
at any time during this period, we will, at our option, replace or repair it at no
additional charge except as set forth in the following terms. This warranty does
not apply to products damaged by misuse, modications, accident or disaster.
Vendor assumes no liability for any damages, lost prots, lost savings or any
other incidental or consequential damage resulting from the use, misuse of, or
inability to use this product. Vendor will not be liable for any claim made by any
other related party.
Vendors disclaim all other warranties, either expressed or implied, including but
not limited to implied warranties of merchantability and tness for a particular
purpose, with respect to the hardware, the accompanying product’s manual(s)
and written materials, and any accompanying hardware. This limited warranty
gives you specic legal rights.
Return authorization must be obtained from the vendor before returned
merchandise will be accepted.Authorization can be obtained by calling or faxing
the vendor and requesting a Return Merchandise Authorization (RMA) number.
Returned goods should always be accompanied by a clear problem description.

- viii -
This page is intentionally left blank.

- 1 -
1Chapter 1
Introduction
Chapter 1 - Introduction

- 2 -
Introduction
1.1. Features
•Onboard Intel® Core™ i Processor (Tiger Lake UP3)
•Support 2 x 260-pin DDR4 SO-DIMM sockets
•Support 5G (Sub-6G) module, M.2 NVMe SSD Gen3x4, USB 3.2 Gen2,
and 2.5 GbE LAN
•Rich I/O: 4 x COM/ 3 x LAN/ 4 x USB3.2 Gen 2/ Remote PWR
•Support Triple-display (DVI-D/HDMI/DP)
•Wide Power Input: 9~36 VDC
•Power on/o󰀨 delay control / congurable ignition power control
•Support DirectX 12
1.2. About this Manual
This manual is meant for the experienced users and integrators with hardware
knowledge of personal computers. If you are not sure about the description in
this manual, consult your vendor before further handling.
We recommend that you keep one copy of this manual for the quick reference
for any necessary maintenance in the future. Thank you for choosingARBOR
products.

- 3 -
Introduction
1.3. Specications
System
CPU Soldered onboard Intel®i7/ i5/ i3 Processor
(Default: i5 CPU Tiger Lake-U)
Memory 2 x 260-pin DDR4 SO-DIMM sockets, supporting 3200MHz SDRAM
up to 64GB
Chipset SoC
Graphics Intel®Iris®Xe Graphics
LAN Chipset 2 x Intel®i211AT PCIe controller
1 x Intel®225LM PCIe controller
Watchdog Timer 1~255 levels reset
I/O
Serial Port 2 x RS232 (DB-9 male connector) 2 x RS232(Default)/422/485 (RI/5V/12V)
(DB-9 male connector/ Switch via BIOS)
USB Port 4 x USB 3.2 Gen2 (2 w/ independent full speed)
1 x USB 2.0 onboard for encryption dongle (Type A)
LAN 2 x RJ-45 ports for GbE LAN (PoE complies with IEEE802.3af)
1 x RJ-45 ports for 2.5 GbE LAN (iAMT support w/ i5/i7 skus)
Video Port
1 x HDMI 2.0b connector, supporting 4K/2K resolution
1 x DisplayPort 1.4 connector, supporting 4K/2K resolution
1 x DVI-D connector, supporting Full HD resolution
Expansion Bus
1 x full mPCIe slot (PCIe x1+ USB2.0, Full size)
w/ 1 x nano SIM card slot
1 x M.2 B-Key 2242/3042/3052 (PCIe x2 + USB3.0)
w/ 2 x nano SIM card slots
Digital I/O 8 x DI & 8 x DO w/ 1.5KV isolation
Multi-Serial Bus I2C/SPI/UART/GPIO (w/ 3.3 or 5V) via DB-26
Others 10 x Antenna Holes are reserved

- 4 -
Introduction
Storage
Type
1 x M.2 M-Key 2242/2280
(PCIe Gen III x4 + SATAIII)
1 x 2.5” HDD/SSD tray
(SATA III + SATA PWR connector)
Environmental
Operating Temp. -20 ~ 60°C (-4 ~ 140°F), ambient w/ air ow
Storage Temp. -40 ~ 70°C (-40 ~ 158°F)
Operating
Humidity 10-95% @ 60°C (non-condensing)
Vibration 5~500Hz 3 Grms X,Y,Z axis w/ SSD, according to IEC 60068-2-64
Shock
40G peak acceleration (11 m sec. duration), operation w/ SSD
80G peak acceleration (11 m sec. duration), nonoperation w/ SSD
According to IEC 60068-2-27
Qualication
Certication CE/ FCC ClassA
Power Requirement
Power Input DC 9~36V
(3-pin terminal block: V+, V-, GND)
Remote Control 1x3-pin terminal block for remote control
and PWR LED output
Power Ignition IGN +/-
Mechanical
Construction Sheet Metal +Aluminum Alloy
Mounting Wall-mount (standard)
DIN-rail or VESAmount (optional w/ CTOS bracket)
Weight 3.7kg
Dimensions
(W x D x H) 210 x 180 x 70 mm

- 5 -
Introduction
OS Support
Windows 10 IoT
Ubuntu 18.04
1.3. Inside the Package
Upon opening the package, carefully inspect the contents. If any of the items
is missing or appears damaged, contact your local dealer or distributor. The
package should contain the following items:
1 xARES-1980
StandardAccessories that contains the following
items:
• User’s manual

- 6 -
This page is intentionally left blank.

- 7 -
2Chapter 2
Getting Started
Chapter 2 - Getting Started

- 8 -
Getting Started
2.1. Dimensions
250
210

- 9 -
Getting Started
2.2. Overview
2.2.1. Front View
Power Button/
Power LED
Mic in
Audio Out RJ-45 ports
GbE LAN
(PoE)
RJ-45 ports
2.5 GbE LAN
HDMI 2.0b
Reset
RS232/422/485
DB-9 connectors
RS232
DB-9 connectors
DisplayPort 1.4
USB 3.2 Gen 2
2.2.2. Left Side View Digital In
Digital Out Ignition Switch

- 10 -
Getting Started
2.2.3. Right Side View
DVI-D Ports DC-IN
Remote On/Off ControlMulti-Serial Bus
