CCEA SIRIO Q User manual

1
ENGLISH
SIRIO Q
120 Vac
Installation Manual

ENGLISH
2
Table of contents
1. Product description ....................………………………………………… 3
2. Safety Warning ...........….......................................................... 4
2.1 Proper use ............................………………...………………….... 4
2.2 Product safety. ...…………………………………………………………. 4
2.3 Risk levels .........……………………………………………………………. 6
3. Available versions ………………………………………………………………… 7
4. Guide to installation …………………………………………………………… 8
4.1 Product sizes .........………………………………………………………. 8
4.2 Mounting accessories….……………………………………………...…8
4.3 Installation …………………………………...………………………………. 9
4.4 Installation with SRQFX01 ……………………………………………... 9
4.5 Adjustment of the light direction …………………………………... 10
5. Plug-in ……………………………………………………………………………...…... 11
5.1 Plug-in with M12 connector ……….…...…………………...…... 11
5.2 Plug-in with power cord ………………………………………………. 11
5.3 Power Connection …………………………………………………………. 11
6. Switch on-off ……...……………………………………………………………... 12
7. Troubleshooting ………………………………………………………………... 12
8. Light source replacement ................…………………………………… 12
9. Product maintenance and cleaning ……………………………………… 12
10. Repairs …….…………………………………………………………………………. 13
11. Warranty …………………………………………………………………………. 13
12. Product Disposal …………………………………………………………………. 14
13. Technical data....…………………………………………………………………… 14
14. Symbol keys ………………………………………………………………….……… 14
15. Declaration of conformity………...……………………………………………. 15
Table of contents

ENGLISH
3
1. Product Description
➢Sirio Q is the LED work light
applicable for tractors, trucks,
trailers, off-road vehicles, and
earth-moving machines.
➢Aluminum body and tempered
glass lens.
Features 820lxdaylight white
LED, 120V AC voltage.
➢bar Led Lighting Equipment
featuring:
➢Anodized aluminum Machine-
made body
➢Hardened glass front
protection
➢7x 3 mid powers Led
➢Two optics are available at 40°
- 60°
➢5000 K CRI 80 light color
Highly resistant to mechanical
vibrations and processing
shavings
➢IP 67-69 degrees of protection
➢Plug-in to 120 Vac 60 Hz
➢Suitable for wet location
➢Suitable for Under-Cabinet
Mount
➢Sirio Q cannot be installed in a
compartment smaller than 30
cm by 30 cm by the length of
the product.
➢10 ft (3 meters) power cord
➢SRQFX01 Up-Down, Swivel
brackets.
Product Description
instructions

ENGLISH
4
2. Safety instructions
“Q” Series Lighting has been
designed and manufactured
based on state-of-the-art
techniques.
It is made of well-selected,
high-quality materials. It is
carefully tested throughout the
production process, from the
raw material to packaging,
following a detailed production
schedule to guarantee that the
product is safe and reliable.
Material damages and bodily
injuries may still occur if not
used correctly.
➢This manual is part of the
luminaire and must always
be kept with it.
➢Please ensure that ALL
instructions/information in
this manual is carefully
read.
➢Strict compliance with the
instructions provided in
this manual and on the
luminaire is required for its
correct use.
➢Installation and use of Sirio
Q are recommended only if
it’s in perfect conditions
and the user is well-
acquainted with all safety
instructions.
➢CCEA waives any
responsibility in case of
product tampering or
improper use
2.1 Proper use of the product
➢This lighting equipment is
applicable for tractors, trucks,
trailers, off-road vehicles,
earth-moving machines. It is
suitable for wet environments.
2.2 Product Safety
Electrical Risks
Sirio Q's improper and incorrect
use may cause bodily injuries and
material damages.
➢A licensed electrician must
carry out all electrical
connection procedures.
➢Switch off the power supply
before installation,
maintenance, or reparation
procedures.
➢Please ensure that the power
supply rated tension and
frequency meets the
requirements shown on the
product label. Please respect
cable polarity.
➢Qualified electricians must only
carry out maintenance and
repairs.
Risk of explosion
The risk of the explosion might
occur upon installing and using this
product for applications with a high
Safety instructions

ENGLISH
5
risk of explosion. It might cause
severe body injuries.
➢Do not install and use this
product in hazardous
environments (high risk of
explosion).
Installation and Safety
➢Handle the lamp with care and
avoid dropping or hit even if it
is still packed, which may cause
bodily injuries and material
damage.
➢Ensure the mounting accessory
is original from the
manufacturer.
➢Set up the mounting brackets
correctly.
➢The equipment must be
correctly fastened using the
proper screws according to the
application, place, and surface
where the product is being
mounted.
➢Ensure that the mounting
brackets are regularly checked.
The danger of dazzling glare due to
a white light source
Avoid staring directly at the light
source, as it may cause a temporary
reduction of vision. Irritation,
aches, damages, or accidents may
as well occur.
➢Avoid staring directly at the
light source.
➢The device must be adjusted to
avoid having the light flow
directed towards the eyes.
Using inappropriate spare parts
may cause bodily injuries and
material damage.
➢Do not use spare parts not
approved by the manufacturer.
Damage caused by the presence of
laser beams
The “Q” Series Led lighting
equipment is not allowed when a
high-power laser operates since it
may damage the Led source.
Danger due to high temperatures
Installing and using the equipment
in all the environments where the
temperature remarkably exceeds
the foreseen operating
temperature will considerably
reduce Led lifetime and damage
the built-in electronic components.
Danger due to repairs
Having the product disassembled
or repaired without technical and
electrical knowledge may cause
damage to persons and objects.
➢Do not try to repair or
disassemble the equipment.
Please apply to qualified
technicians for any issues.
➢Any product tampering or
modifications not having been
approved by the manufacturer
will null and void the warranty.
Safety Warnings

ENGLISH
6
Risk levels
2.3 Risk levels
Dangers where noncompliance
may immediately cause severe
injuries and eventually lead to
death.
Dangers who fail to satisfy
requirements may lead to severe
injuries or even death.
Dangers where failure to satisfy
requirements may lead to injuries.
Dangers where failure to satisfy
requirements may cause damage
to objects.

ENGLISH
7
3. Available versions
Please refer to the table hereunder listing all the luminaires to identify the
model you need and its main features to have the equipment correctly and
efficiently installed and used.
Note: The ID model is found by the laser stamp or printed label stuck on the
backside of the product.
▪Find the correct luminaire model comparing the Id Model printed on the
back of the luminaire with the table hereunder.
Week and year of production are found on the laser stamp or printed label
stuck on the backside of the product.
Avallabile versions
Model
Color
Optic
Power
Power Usage
E Connection
Weight
SR0924Q01
Silver
40 °
17 W
120 Vac 60 Hz
CABLE 10 ft (3 m)
1.40 lbs. (0,64 kg)
SR0924Q02
Silver
60 °
17 W
120 Vac 60 Hz
CABLE 10 ft (3 m)
1.40 lbs. (0,64 kg)
Complete Product
SR0924Q0101
Silver
40 °
17 W
120 Vac 60 Hz
CABLE 10 ft (3mt)
1.65 lbs. (0,75 kg)
SR0924Q0201
Silver
60 °
17 W
120 Vac 60 Hz
CABLE 10 ft (3mt)
1.65 lbs. (0,75 kg)

ENGLISH
8
4. Guide to installation
4.1 Product sizes and accessories
4.2 SRQFX01
Up-Down, Swivel brackets
Guide to installation
cod. SRQFX01
Bracket-set in stainless steel
Adjustment left and right rotation A = +90° /- 90°
Adjustment front and back inclination (B) = +90° /- 90°
SIRIO Q

ENGLISH
9
Fig. 1
4.3 Installation of SIRIO Q
4.4 Installation with SRQFX01
Up-Down, Swivel brackets
Switch off the power supply
before installation.
The Kit SRQFX01 IS made of:
➢N.1 Up-Down, Swivel Stainless
Steel brackets with M5 tighten
screws and steel handle
washers.
➢The direction of the light is
adjustable up to +90° / -90°
back-up-front and +90° /-90°
left-center-right.
Mount the bracket on the bottom
of the head using the supplied
2xM5 screws
➢Use 8/32 or M5 Bolts only.
➢The surface metal mount must
be at least 2 mm thick.
➢Using a 7/32- or 5.3-mm drill,
bore the mounting surface
according to the distance
between the center hole, as
shown in Fig 1
➢Use 8/32 or M5 bolts to fix the
luminaire. Bolts’ length must
be chosen according to the
surface thickness. The
threaded portion must stick
through the surface metal with
three threads out.
➢Drill the four holes for steady
mounting
➢Thread the four holes
Installation
The lamp fall-down may cause
damage to persons and objects
➢When mounting the lamp,
ensure that the original
fastenings are used, which
you may purchase from the
supplier.
➢Mounting Accessories must
be correctly mounted

ENGLISH
10
➢Place the luminaire assembled
with the two side brackets on
the metal surface near the four
previously drilled and threaded
holes.
➢Tighten the four bolts firmly.
➢Adjust the light direction by
tilting and rotating the body
head up to +/- 90° see “A” and
“B.”
4.5 Adjustment of the light
direction
A. For Front and back adjustment.
Untighten the M5 bolt on the
bottom head, choose the position,
and tighten again.
B. For side left adjustment:
untighten the M5 bolt on the rear
head, choose the position, and
tighten again.
Damaged or broken lamp.
➢The Bolts M5 allowing rotation
mustn’t be loosened entirely,
for the luminaire may fall.
➢Regularly check the bracket,
screws, and bolts condition to
ensure the luminaire is safely
tightened.
NOTE: The mounting accessories
may be purchased separately. To
know more, please visit
www.ccealights.com or
www.ccealights-usa.com for North
America.
Installation
M5
Back
+ 90°
Front
+90°
Left
+90°
Right
+90°
M5

ENGLISH
11
Liquid Leakage causes damages to
the luminaire
5. Plug-in
5.1 Plug-in with M12 connector
➢Sirio Q comes with a standard
10 ft power cord, free end
terminals. To assemble an M12
connector, make sure it has the
same degree of protection as
the luminaire, if not greater.
➢Ensure that the power cord is
correctly wired to the male
connector.
5.2 Plug-in with power cord
Wrong wiring may cause damage
to the luminaire.
➢Qualified electricians must
carry out all electrical
connections
➢Ensure that the supply voltage
is respected to avoid damage
to the Led drivers
➢The voltage range is 100÷120
Vac 60 Hz.
➢Respect polarity of conductors
➢Supply wiring: located in class
3, any wiring, rated min. 18
AWG, min. 300V, min. 80°C.
5.3 Power Connection
Conductor
Number
Black 1
Hot 120V
Black 1
Black 2
NEUTRAL 0V
Black 2
Yellow/green
GROUND
Yellow/green
Power Cord features
PVC outer sheath
18 AWG 3G1 mm2
10 ft - (3 m)
Plug-in
PVC 2x0,75mmq
20AWG
PVC 3G1 mm2

ENGLISH
12
Liquid leakage may damage the
luminaire.
➢Regular cleaning according
to the use and application
helps to avoid luminaire
damage
➢Cleaning operations should
be carried out at the end of
any working cycle if the
luminaire works in
environments where
lubricants or coolers are
present.
6. Switch on–off
➢The luminaire is not equipped
with an independent switch on
and off.
➢The luminaire turns on when
plugged in and switches off
when the power is off.
7. Troubleshooting
In case the lamp doesn’t turn on:
➢Check that the luminaire is
correctly wired to the supply
voltage.
➢Check that polarity wiring has
been carried out correctly.
8. Replacing the Led light
source
The outstanding lifetime of the LED
light source, over 60.000 hours,
makes it unnecessary to replace
the PCB LED when the luminaire is
correctly installed and used
following the instructions in this
manual. Contact CCEA’s Technical
Support service - or your Reseller –
if replacing the PCB LED is needed
for any defects not covered by the
warranty.
9. Product maintenance and
cleaning
This product is maintenance-free.
➢Luminaire cleaning is carried
out only after switched off and
the surfaces have cooled down.
➢Carefully rinse the luminaire
housing with a mild cleanser
and then wipe off using a soft
cloth to avoid scouring it.
Switch 0n/off
Pleasecontact
CCEATechnicalsupportServicefordefectiveluminaire
Phone: [phone]
Email: [email protected]
For North America & Canada, Contact:
CCEA Technical Lighting Corp.
Phone: [phone]
Email: [email protected]
www.ccealights.com
Disconnect power before
servicing

ENGLISH
13
Bad repairs may damage the
luminaire.
➢All repairs must be carried out by
the manufacturer or by qualified
technicians.
➢Only use spare parts approved by
the manufacturer.
10. Repairs
11.Warranty
Terms of warranty
CCEA warrants that each new
fixture of Sirio Q manufactured and
sold is free from material,
workmanship, and construction
defects.
THIS WARRANTY DOES NOT APPLY
TO EQUIPMENT OR GOODS WHICH
ARE MISUSED, ABUSED, OR
DAMAGED FROM INSTALLATION
OR NOT USED FOLLOWING THE
SELLER’S INSTRUCTIONS. NORMAL
WEAR OF EQUIPMENT OR GOODS
IS NOT INCLUDED IN THIS
WARRANTY.
Suppose an examination by CCEA
discloses that the fixture has
defective components. In that case,
CCEA's obligation is limited to
repair or replacement, at CCEA's
option, of the defective unit(s) or
its parts.
CCEA is not responsible for fixtures
that have been subject to misuse,
alteration, accident, or repairs not
performed by CCEA. The buyer may
incur additional charges for
diagnostic and repair functions
performed by CCEA staff.
The preceding warranty constitutes
CCEA's sole liability.
Given the above, hold the product
label to be submitted if any repair
or complaints are needed.
Repair and spare parts costs will be
notified after the defects have
been examined.
The warranty does not cover:
•Transport, packaging, or shipping
costs.
• damages or deterioration caused
by:
-Installation and operation are
carried out in different ways.
-Any unauthorized repairs or
attempts to repair the
product.
-Equipment operation under
environmental conditions
other than those specified in
the user manual.
-Liquid leakages inside the
luminaire within the warranty
period.
-Failure to follow the safety
precautions related to
transport and shipping the
product back for repair (make
sure to have it shipped back
in its original case).
Period of warranty
When used under the installation
manual and technical instruction
provided, it will perform to
applicable specifications for 24
months from purchase.
Repairs and warranty

ENGLISH
14
12. Product disposal
All the electrical and electronic
equipment (WEEE) must be
managed with selective waste
sorting and cannot be disposed of
as municipal waste, as provided in
Directive 2012/19/UE.
Given the above, all its
components, subsystems, and
consumables that are an integral
part of the product must be
conveyed to the local collection
facilities to dispose of them by the
current legislation.
Please apply to the council offices
of your place of residence to know
where the collection facilities are
located.
13. Technical data
NOTE: Please refer to the date
printed on the label stuck on the
backside of the luminaire.
Power supply
120 VAC 60 Hz
Power input
17 W (see label)
IEC Class
I
Degree of
protection
IP67 –IP69
Driver
I.D.S. Integrated
System Driver
Light temperature
5000 K
Chromatic Index
80
For any further information please refer to
the table at page 7
14.Symbol keys
CE Conformity marking
Protection class I device
Degree of protection IP67
Degree of protection IP69
Resistant against water
and some coolant,
emulsion, oil
IK06
Impact resistant EN 62262
Technical data and Symbol keys
IP67
IP69

ENGLISH
15
C.C.E.A SRL, via Piave, 2 - 36077 Altavilla Vicentina (VI), Italy –VAT and Tax
number 02374040240 hereby declares that the light equipment named SIRIO Q,
to which the present Declaration of Conformity is related - was manufactured by
CCEA SRL by the following Directives: 2014/35/UE on Low Voltage Equipment
Safety and the Directive of Electromagnetic Compatibility 89/336/CEE (EMC)
2014/30/UE. The unit complies with the following regulations:
•Directives:
•
•Harmonized Standards
-CEI EN 60598-1 “Lighting equipment. Part 1: General instructions and tests”
-CEI EN 60598-2-4 “Lighting equipment part 2: particular requirements –
part 4 Portable general-purpose luminaries”.
-CEI EN 62031 “LED modules for general lighting. Safety specifications”.
-CEI EN 62384 “DC or AC supplied electronic control gear for LED
modules. Performance requirements”.
This is a standard product manufactured following a detailed production
schedule, ensuring that inspections and destructive tests were carried out to
deliver a safe, functional, and sustainable development.
C.C.E.A. SRL disclaims any responsibility resulting from tampering and improper
device use.
Date: ______________________
Week of production: __________
Product code: _______________
CCEA Srl
Via Piave 2, 36077 Altavilla Vicentina (VI), Italy
Tel. [phone] – fax [phone]
SIRIO Q120_installation manual–rev0 30/06/22
15. Declarationofconformity
Machinery Directive 2006/42/EC
Low Voltage Directive 2014/35/EU
EMC Directive 2014/30/EU
Declaration of conformity
UL 1598, Luminaire
CSA C22.2. No.250.0:21
