CCS LFX2 Series User manual

LFX2-50IR850
CCS Inc.
Copyright(c) 2009 CCS Inc. All rights reserved. Reproduction or photocopy without permission is prohibited.
Model name
LED color
Input voltage
Power consumption
Weight
Connector
Polarity and signal
LFX2-50IR850
Infrared
24VDC
6.6W
180g
SMR-03V-B
1: (+), 2: NC, 3: (-)
Third Angle Projection Units: mm
93
93
50(Emitting surface)
50(Emitting surface)
21. 5
7 79
7 79
21. 5
Screw holes for installation
Screw hole : 4-M4 x 0.7 through hole
Counterbore : Ø6 depth 4 (on rear sude)
12
36. 5 20
7
Screw holes for installation
4 x 2-M4 x 0.7 depth 6
(Same location for all four side)

10 04156 1004160 1004164 1004157 1004161 1004165 10 04158 1004162 1004166 1004159 1004163 1004167 100 4115 1004116 100 4117
11 W 6.1 W 6.6 W 11 W 9.1 W 14 W 16 W 13 W 14 W 21 W 19 W 20 W 31 W 25 W 27 W
635 nm 6600 K 850 nm 635 nm 6600 K 850 nm 635 nm 6600 K 850 nm 635 nm 6600 K 850 nm 635 nm 6600 K 850 nm
LFX2-50RD LFX2-50SW LFX2-50IR850 LFX2-75RD LFX2-75SW LFX2-75IR850 LFX2-100RD LFX2-100SW
LFX2-100IR850
LFX2-150RD LFX2-150SW
LFX2-150IR850
LFX2-200RD LFX2-200SW
50×50 mm 75×75 mm 100×100 mm 150×150 mm 200×200 mm
LFX2-200IR850
SMR-03V-B
Specifications
LFX2-75 Series LFX2-100 Series LFX2-150 Series LFX2-200 SeriesLFX2-50 Series
Series
Model
Direct number
LED color
Emitting surface size
Power consumption
Input voltage
Peak wavelength (typ.)
/ corresponding color
temperature (typ.)
Case materials
Cable
Connector
Polarity, signal
Cooling method
Operating temperature
and humidity
Storage temperature
and humidity
Weight
Red White Infrared Red White Infrared Red White Infrared Red White Infrared Red White Infrared
Aluminum alloy and PMMA
2-conductor cabtyre cable, 0.3 m (+35 mm,
- 0 mm)
1: Anode (+), brown; 2: NC; 3: Cathode (−), blue
Natural air cooling
Temperature: 0 to 40°C, humidity: 20% to 85%RH (with no condensation)
Temperature:
- 20 to 60°C, humidity: 20% to 85%RH (with no condensation)
Approx. 180 g Approx. 270 g Approx. 350 g Approx. 570 g Approx. 920 g
High-output Flat-Dome Light
The NEW LFX2 Series
Higher output for
high-speed
inspections.
Infrared light for
a wide range
of applications.
A Complete Lineup for
Ideal Imaging
Emitting Surface Size
LED Colors
50×50 mm, 75×75 mm,
100×100 mm, 150×150 mm,
200×200 mm
Red, white, and infrared
24 VDC
Dimensions by Light Size
Emitting surface size (mm)
A 21.5 21.5 21.5 21.5 23.5
C 93 118 143 193 247
E 36.5 41.5 41.5 46.5 43.5
50 75 100 150 200
B 50 75 100 150 200
D 79 104 129 179 233
F 20 35 60 100 160
Dimensions (mm)
C
7
A
A
D
C
7D
4-M4×0.7 tapped holes
6 diameter, counterbore depth: 4 (from rear)
(for installation)
(LFX2-200 Series: M5×0.8 tapped holes,
8 diameter, counterbore depth: 4)
B (emitting surface)
B (emitting surface)
12
E F
7
4×2-M4×0.7, tapped depth: 6
(for mounting, same on all four sides)
(LFX2-200 Series: 4×3-M4×0.7, tapped depth: 6)
Dimensional Diagrams (mm)
