CDA CDI6241 User guide

CDI6241
Integrated dishwasher
Use and maintenance

2
Contents
3 Important information
5 Important notes
7 Before first use
7 Using your dishwasher
9 Starting a programme
9 Changing a programme
10 Cancelling a programme
11 Buzzer sound control
11 Save Power Mode
12 Detergent information
13 Salt information
14 Softener adjustment
15 Rinse aid information
17 Dishwasher basket information
19 Standard loading and test data
20 Programme listing
21 Care and Maintenance
23 Error codes
24 Troubleshooting
25 Electrical Information
27 Installation
30 Fitting a (non-standard) decor door (additional to template)
31 Warranty and service

3
Important
The CDA Group Ltd cannot be held responsible for injuries or losses
caused by incorrect use or installation of this product. Please note
that CDA reserve the right to invalidate the guarantee supplied with
this product following incorrect installation or misuse of the appliance.
This appliance is not designed to be used by people (including
children) with reduced physical, sensorial or mental capacity, or
who lack experience or knowledge about it, unless they have had
supervision or instructions on how to use the appliance by someone
who is responsible for their safety.
Under no circumstances should any external covers be removed for
servicing or maintenance except by suitably qualified personnel.
Appliance information:
Please enter the details on the appliance rating plate below for
reference, to assist CDA Customer Care in the event of a fault with
your appliance and to register your appliance for guarantee purposes.
Appliance Model
Serial Number
This appliance has been designed for domestic use only. Commercial
use will invalidate the warranty.

4
EU Declarations of Conformity:
This product meets the requirements of all applicable EU directives
with the corresponding harmonised standards, which provide for CE
marking.
Availability of this manual in an alternative format:
A soft copy of this manual is available for download from www.cda.eu.
IMPORTANT INFORMATION FOR CORRECT DISPOSAL OF THE
PRODUCT IN ACCORDANCE WITH EC DIRECTIVE 2012/19/EU.
At the end of its working life, the product must be taken to a special
local authority waste collection centre or to a dealer providing appli-
ance recycling services.
Disposing of a household appliance separately avoids possible nega-
tive consequences for the environment and health. It also enables
the constituent materials to be recovered, saving both energy and
resources. As a reminder of the need to dispose of household appli-
ances separately, the product is marked with a crossed-out wheeled
dustbin .

5
Important
•Read the instructions prior to installation and use of the
appliance.
•Do not lean or climb on the open dishwasher door, to
prevent damage.
•Close the dishwasher door after use to prevent accidents.
•Use only detergents, salt and rinse aid specifically
designed for dishwashers.
•Do not put solvents in the dishwasher detergent
compartment to prevent risk of explosion.
•Only put dishwasher safe items into the dishwasher. If in
doubt, check with the manufacturer of the items.
•Take care when loading the dishwasher to observe the
recommendations for best loading practice, and also to
ensure that sharp objects such as knives are placed blade
down to prevent accidents.
•Do not open the dishwasher door when a programme
is running. If it is necessary to do so, then open it only
slightly to allow the dishwasher to pause the programme
and prevent any water spilling out. Remember that
the water in the dishwasher can be very hot when the
programme is running.
•When the dishwasher is not in use, we recommend
that you turn o the water supply at the supply tap and
disconnect the main supply.
•If you are leaving the dishwasher for an extended period
you should leave the door slightly open to prevent the
formation of unpleasant smells.

6
•This appliance can be used by children aged from 8
years and above and persons with reduced physical,
sensory or mental capabilities or lack of experience
and knowledge if they have been given supervision or
instruction concerning use of the appliance in a safe way
and understand the hazards involved. Children shall not
play with the appliance. Cleaning and user maintenance
shall not be made by children without supervision.
•The plastic housing on the water inlet pipe contains an
electrically operated valve. The wires that connect to this
valve are inside the inlet hose. Do not cut through the inlet
hose and do not put the plastic housing in water.
•Children could get locked inside the appliance. Therefore,
when disposing of an old appliance cut o the plug and
set aside. Damage the door lock so that the door can no
longer be closed.
Recommendations
•To reduce energy and water consumption, remove all dirt residues
from the dishes prior to loading the dishwasher.
•Loading the dishwasher to the capacity indicated by the
manufacturer will save energy and water.
•Place hollow items (bowls, glasses and pans) face down in the basket.
•Do not put dishes, cutlery or other items with tobacco ash, wax,
lubricating grease or paint residues in the dishwasher.
• It is not recommended to pre-rinse the tableware, as this leads to an
increase in water and energy consumption.
• Washing tableware in a household dishwasher usually uses less
energy and water than washing up by hand.

7
Before First Use
•Set the water softener level as required by the water hardness in the
area (see pages 13-14).
•Add 1kg of salt into the salt compartment and then fill with water to the
top of the salt compartment.
•Remove all the packaging materials from the interior of the dishwasher.
•Fill the rinse aid compartment.
•Run a hot programme without any dishes in the dishwasher.
Control Panel
On/O button
To switch the power to the dishwasher on or o, press the ‘On/O’
button (2). When you switch on the dishwasher, two dashes will
appear on the programme display (1).
Programme selection button
To select an alternative programme, press the ‘Programme selection’
button (3) several times, until the programme display (1) shows the
desired programme. The dishwasher will store, in its memory, the last
programme used.
Programme Delay Timer Half Load
Rinse Aid
SaltHalf Load
On/O
1 2 3 4 5 678
1 2 3 4 5 6 7
50 C
eco
65 C
70 C 65 C
50
40 C
40 C

8
Delay timer button
The dishwasher is equipped with a variable delay timer which can
be set between 1 hour and 19 hours. Pressing this button (4) once will
delay the start time for 1 hour, and continuing to press will increase the
delay time. Press the Delay button to change or cancel the delayed
start. If you switch o the machine while delay timer is active, the
delayed time is cancelled.
Half load button and indicator light
The dishwasher is equipped with a half-load function that allows for
small numbers of dishes to be washed, spread between both baskets.
This reduces the amount of water and electricity used.
To use this function, press the half-load button (5). The indicator light (6)
will illuminate and shows that this function is selected.
If you have selected the half-load function for a programme, then this
function will automatically be selected the next time the dishwasher
is used. To cancel the selection of this function, press the half-load
button (5) until the indicator light goes out.
Salt and rinse aid warning lights
When the dishwasher salt or rinse aid begins to run out, the relevant
warning light (7 or 8) will illuminate to advise that it needs refilling
•Then close the door. The dishwasher will begin the new programme
from the point at which the old programme stopped.

9
Starting a programme
•Press the ‘On/O’ button.
•Press the ‘Programme selection’ button until the required
‘Programme’ light is illuminated.
•If required, press the ‘Delay Timer’ button.
•Once a programme is selected, the display will show the desired
programme.
•When you close the dishwasher door the programme will start
automatically.
Please note: The dishwasher stores the most recently used
programme in its memory. To change the programme, simply
press the ‘Programme selection’ button.
At the end of a programme
If possible, do not open the dishwasher door once the programme has
started.
During the programmes cycle the InfoLed will illuminate a red light
underneath the appliance door on to the floor. Once the program has
finished the light illumination will be green.
Changing a programme
It is possible to change the programme if necessary once the
programme has started.
•First open the door slightly to reduce the risk of water spillage.
•Press the ‘Programme selection’ button until the required
programme is shown on the display.
•Then close the door. The dishwasher will begin the new programme
from the point at which the old programme stopped.

10
Cancelling a programme
It is possible to cancel the programme once the programme has
started.
•First open the door slightly to reduce the risk of water spillage.
•Press and hold the ‘Programme selection’ button for approximately
three seconds and a ‘1’ shows on the display.
•Then close the door. The dishwasher will drain for approximately
thirty seconds. Once this is complete, the dishwasher will beep five
times and the display will show ‘00’.
Switching the dishwasher o
•Once the dishwasher beeps five times, the dishwasher can be
switched o by pressing the ‘On/O’ button.
•Then, turn o the water tap and remove the plug from the power
socket.
Please note: The dishwasher will automatically continue on the
programme it has started if operation is interrupted.

11
Buzzer sound control
To change the buzzer sound level, follow the below steps:
1. Open the door and press Programme (2) and Delay (4) buttons
simultaneously for 3 seconds.
2. When sound setting is recognized, buzzer gives a long sound
and machine will display last set level, from “S0” to “S3”.
3. To decrease sound level press Programme button (2). To
increase sound level, press Delay button (4).
4. To save the selected sound level, turn o the machine. ’’S0’’
level means all sounds are o. The factory setting is “S3”
Save Power Mode
To activate or deactivate Save Power Mode, follow the below steps:
1. Open the door and press Delay (4) and Half Load (5) buttons
simultaneously for 3 seconds.
2. After 3 seconds, the machine will display last Setting, “IL1” or “IL0”.
3. When Save Power Mode is activated, “IL1” will be displayed. On this
mode, interior lights will turn o 4 minutes after the door is opened,
and the machine will turn o after 15 minutes of no activity in order to
save energy.
4. When Save Power Mode is deactivated “IL0” will be displayed. If
Save Power Mode is deactive, interior lights will be on as long as
the door is open, and the machine will always be on unless it is
turned o by the user.
5. To save the selected setting, turn o the machine.
In factory setting, Save Power Mode is active.

12
Detergent
To fill the detergent compartment
1. Push the latch to open the compartment.
2. Add the required amount of detergent. The
main detergent compartment (b in Fig. 2)
has lines to allow for specific amounts of
detergent.
These are marked at either 15cm3or
25cm3, depending on how dirty the dishes
are.
If your dishes are in need of an intensive
wash, then add 5cm3of detergent into the
prewash section of the compartment (a in
Fig 2).
3. Then close the detergent compartment lid
until the latch locks.
Please note: You should only use
detergents designed specifically for use in
dishwashers.
If using dishwasher tablets, always use the detergent compartment.
Do not put them in the main body of the dishwasher or in the cutlery
basket.
The solubility of dishwasher tablets can vary depending on the
temperature and duration of the programme. As a result, it is
recommended that powder detergents (and not 3-in-1 tablets) should
be used in the quick wash and half-load programmes to allow better
performance.
Fig. 2
Fig. 4
Fig. 3
DETERGENT

13
CDA recommends the use of separate detergent, rinse aid and
dishwasher salt rather than combination tablets as separates achieve
better wash performance.
If you do use combination detergents, add salt and rinse aid to the
dishwasher and then adjust the water hardness setting and rinse aid
setting to the minimum. When you then use separate detergents
again, you should fill the salt and rinse aid compartments, adjust the
water hardness setting to the maximum and run an empty wash, then
adjust the water hardness setting and the rinse aid setting to the
appropriate level.
Salt
To ensure the best eciency, the dishwasher needs soft water. Hard
water means that lime residues remain on the dishes and the interior
of the dishwasher, aecting performance. The softener system is
designed to remove the ions that make the water hard to provide the
best quality wash performance. This is achieved by using dishwasher
salt.
To add dishwasher salt
1. Remove the lower dishwasher basket and then unscrew the salt
compartment cap, as shown in Fig. 3 (page 12).
2.Fill the compartment with dishwasher salt (do not use table salt),
carefully to prevent unnecessary spillage. Before first use, you should
fill the compartment with 1kg of dishwasher salt and then fill up the salt
compartment with water (up to the brim of the compartment) as shown
in Fig. 4 (page 12).

14
3.Replace the cap and the lower basket.
When the ‘Salt’ light on the control panel illuminates, you should refill
the salt compartment with salt only – do not add water to the salt
compartment after the first use.
You should run a programme immediately after adding dishwasher
salt, to prevent any damage to the dishwasher systems.
Fill the salt compartment with just water on first use.
Softener Adjustment
The eciency of your dishwasher depends on the softness of the
tap water. To ensure best eciency, the dishwasher is equipped with
a system that reduces the hardness in the mains water supply. The
eciency will increase when the system is correctly set. To find out
the water hardness level of your water supply you can use the test
strip supplied or alternatively contact your local water board.
1. Open the testing strip.
2. Run water through the tap for one minute.
3. Hold the testing strip in water for one second.
4. Shake the testing strip after taking it out of the water.
5. Wait for one minute.
6. Check the number of marks on the strip to see the level of water
hardness.
1 minute 1 second
1 minute
Level 1
Level 2
Level 3
Level 4
Level 5
Level 6

15
If the hardness of the water you use is above 90dF or if you are using
well water; you are recommended to use filter and water refinement
devices.
Please note: The level of water hardness is preset to level 3.
1. Press and hold down the ‘Programme Selection’ button.
2. Press the ‘On/O’ to switch on the dishwasher.
3. Keep the ‘Programme Selection’ button pressed until ‘SL’ shows
on the display and then disappears.
4. After the ‘SL’ disappears, the machine displays the last water
hardness setting entered.
5. To adjust the level, press the ‘Programme selection’ button
until the required level is selected. The programme display will
illuminate with certain figures as in the table of water hardness
settings below.
6. To store the selected water hardness level, press the ‘On/O’
button.
Rinse aid
Rinse aid helps to ensure better quality wash results and increased
drying performance.
To fill the rinse aid compartment, open the rinse aid compartment lid.
Fill the compartment with rinse aid to the MAX level and then close
the lid. Be careful not to overfill the rinse aid compartment and ensure
that you wipe up any spillages.

16
In order to change the rinse aid level,
follow the steps below before turning
on the machine:
1. Press and hold down the ‘Programme
selection’ button
2. Press the ‘On/O’ button to switch on
the dishwasher
3. Keep the programme selection button
pressed until “rA” shows on the
display and then disappears
4. To adjust the level, press the
programme selection button until the required level is shown on
the display, as listed in the table on below.
5. To store the selected rinse aid level, press the ‘On/O’ button.
If the dishes are not drying properly or are spotted with food
debris, dirt etc., increase the rinse aid level. If blue stains appear
on your dishes, decrease the rinse aid level.
Always refill the rinse aid when the rinse aid indicator light on the
control panel is illuminated.
Level Brightener Dose Indicator
1 Rinse-aid not dispensed r1 is shown the on display.
2 1 dose is dispensed r2 is shown the on display.
3 2 doses are dispensed r3 is shown the on display.
4 3 doses are dispensed r4 is shown the on display.
5 4 doses are dispensed r5 is shown the on display.

17
Fig. 7
Fig. 8
Many brands of rinse aid (as well as detergents) contain
phosphates which escape sewage treatment and can cause
excessive algae growth in waterways. This in turn can pollute
drinking water and cause marine life ‘dead zones’ which
are underwater environments deprived of oxygen that are
subsequently unable to support life. Please consider the
environment and, if you wish to use rinse aid, try to source an
environmentally friendly brand.
Dishwasher Baskets
To adjust the height of the upper basket:
1. Open the basket retaining clips, as shown
in Fig. 7, by turning them to the side.
2. Remove the upper basket, and relocate
the alternate set of wheels on the runner,
as shown in Fig. 8, pushing the basket
back into place.
3. Close the basket retaining clips.
The following images are designed
as guidance as to best practice (and
malpractice) for loading the
dishwasher.
Upper basket

18
Upper cutlery basket
Poorly stacked loads
Lower basket
The upper cutlery basket is
designed for the placement of
large and small cutlery utensils.
WARNING: Knives and other
sharp objects must be placed
horizontally in the cutlery
basket

19
Glass Guards
The upper basket racks come with a ‘GlassGuard’ feature. These
allow you to place wine glasses securely into the dishwasher and
help to prevent the glasses from causing or receiving damage. They
are simple to use and involve placing the stem of the glass into the
blue grooves along the outside edge of the racks. These are pictured
below:
Glass Guards

20
Standard Loading and Test Data
Capacity
•Upper and lower baskets: 15 place settings.
•The upper basket should be adjusted to high position.
•Cups should be placed onto the dish rack pins.
Detergent / Rinse aid
•5 + 25cm³, in accordance with EN50242-DIN 44990 IEC 436
(international norms) / Rinse aid dosage adjustment: 5.
Programme test
• Eco 50°C, in accordance with EN50242 (international norms.).
Fig. 8
P1 P2 P3 P4 P5 P6 P7
Programme
Name Eco 50°C Intensive
65°C
Hygiene
70°C
Super
50’ 65°C
Delicate
40°C
Quick 30’
40°C Prewash
Level of soil Medium Heavy Heavy Medium Light Light Light
Amount of
detergent:
A = 25cm³
B = 15cm³
A A A A A A A
Programme
Duration
(h:mm)
03:41 01:57 02:07 00:50 01:14 00:30 00:15
Electricity
consumption
(kWh/cycle)
0.965 1.700 1.900 1.100 0.880 0.740 0.020
Water
consumption
(l/cycle)
9.0 17.2 16.0 12 16 12.4 4.5
