CEBEK RJ-5 User manual

OPERATING.
1
TECHNICALCHARACTERISTICS.
CONNECTION.
Common
PowerSupply
NormallyClosed
NormallyOpen
RJ-5
Voltage...................................................................................................12V.D.C.
MaximumConsumption........................................................................50mA.
MaximumOutputLoad.........................................................................5A.(220VAC)
MaximumReach....................................................................................8m.
ProtectionAgainstPolarityInversions.....................................................Yes.
Sizes.......................................................................................................70x55x30mm
OPERATING
INSTALLATION
TheRJ-5hastobesuppliedby12VDC,andwesuggestyouourFE-2modulewhichhavebeenspeciallydesignedto
answertothecircuitneeds.
Connectthepositiveterminalofthepowersupplytothepositiveterminalofthemoduleanddothesamethingwith
thenegativeterminal.PlacethepowersupplyasnearaspossibleoftheRJ-5module.Verifythattheassemblyhave
beencorrectlydone.
Donotforgetthattheplaceandthecircuitconnectionwillbeessentialtoobtainaperfectmodule'soperating.Place
thecircuitonasolidandplanesurfaceandbringtheemitterintoalignmentwiththereceiver.Thisalignmenthasto
beverticalandhorizontal(atthesameheightthatthereceiver).Seethe"wiringmap"
ThedirectlightcoulddamagetheRJ-5,mainlyifitisthesunlight ;forthisreason,wesuggestyoutoprotectthe
ELECTRONIC CIRCUITS
TheRJ-5moduleisaninfra-redreceivercouldreceivesignalfromRJ-4receiverupto8metersasmaximum.
Outputwithrelay,themaximumloadattheoutputis5A.
Becauseallhereafterinformationareimportant,pleasereadcarefullytheinstructionmanualtoobtainacorrect

PHOTOCELLES Ref.Full9748_Ang.
2
WIRINGMAP.
LOADCONNECTION.
OPERATING :
POWERSUPPLY :
Donotinstallanyobjectbeforethephototransistor(includingglass)toavoidtoreduceorsuppressits
receptioncapacities.
Theusedpowersupplyforemitterandreceiverhavetobedifferent.Ifyoucouldnotuse2
differentpowersupply,trytoinstallthepowersupplyasnearaspossibleoftheRJ-5andusecablestillRJ-4emitter.
TRANSFO
0
15
0
220
RJ-4
FE-2
NO.
Common
Imaginaryaxis NC.
RJ-5
12V.D.C.CONNECTION
12V.
NormallyOpen NormallyOpen
Common Common
NormallyClosed NormallyClosed
220V.A.C.CONNECTION 220V.
TECHNICALSUPPORTANDINFORMATION.
Foranyquestionormoreinformation:E-Mail:[email protected]
