Espresso Grinder
Instruction Manual
Model: HC-600

2
Contents
1) Preface Pg. 3
2) Technical Specications Pg. 3
3) General Description Pg. 3
4) Unpacking and installation Pg. 4
5) Operation Pg. 4
6) Safety devices Pg. 5
7) Safety instructions Pg. 6
8) Maintenance and service Pg. 6
9) Cleaning Pg. 6
10) Schematic Pg. 7
10) Parts List Pg. 8

3
1) Preface
Congratulations for purchasing the HC-600 grinder-doser. The HC-600 is a commercial appliance to be used in
coffee shops, espresso bars, hotels, restaurants, etc. The HC-600 will grind whole been coffee into variable, user
selectable (from super ne to course) coffee powder and will dose it to your espresso machine's Porta-Filter. Read
this manual from cover to cover before using the appliance as it contains important instructions for the safety,
operation, and maintenance of the appliance. Keep the manual in a safe place for future use and reference. The
manufacturer reserves the right to modify the appliance and the manual accordingly.
2) Technical Specifications HC-600:
Dimensions:
Height: 22"
Width: 8.5"
Length: 13"
Weight: 30 lbs
Stainless Steel Burrs Diameter: 64mm
Hopper capacity: 3 lbs. of beans
Timer: 5 min
Electrical Specications:
USA 110V/60Hz
Power: 350w @1600RPM
Duty Cycle: 50%
Materials
Metallic: Aluminum alloy cast.
Stainless steel screws and metal-sheet.
Brass alloy cast
Steel Blades
Non metallic: ABS, PC, PP
3) General Description
Bean Hopper Lid
Bean Hopper
Hopper Safety Screw
Grinding Dial
Grinder Body
Doser Handle
Indication Lamp
Main Switch / Timer
Bean Hopper Door
Doser Lid
Coffee Outlet Guard
Dosing Adjusting Screw
Dosing Feeding Mechanism
Coffee Press
Porta Handle Support
Residue Tray

4
4) Unpacking and Installation
Warning: All appliances’ technical handling operations such as installation, maintenance, or service
should be performed by certified personnel or by your local dealer.
• After opening the box, make sure that the appliance is intact and that there is no visible damage. If there is
any doubt, DO NOT use the appliance and call your local dealer for further assistance.
• Unpack both boxes carefully. For your convenience we suggest storing all packaging materials where they
can be used in the future, whenever the appliance’s transportation is necessary.
• Place the grinder on a stable at counter in a dry area away from water or water splashes.
• Position the coffee residue tray underneath the body in front of the appliance.
• Install the bean hopper rmly on top of the body inside the top blade holder.
• Fasten the hopper to the appliance body by means of the supplied screw.(g. 4.1) Make sure that the screw is
inserted completely through both holes in the hopper and in the top blade holder.
• NEVER OPERATE THE GRINDER IF THE BEAN HOPPER IS NOT FULLY SECURED IN ITS POSITION.
• Before plugging in the electrical cord, make sure:
o The appliance voltage and frequency rating (according to the back side label) is the same as the supply
mains.
o The wall socket is tted with an efcient ground contact. DO NOT plug the appliance into the supply
mains if the ground system was not positively checked to be in compliance with current safety rules. IT
IS COMPULSORY TO GROUND THE APPLIANCE. The manufacturer cannot be held responsible in the
event that this regulation is not complied with.
o The power consumption of the appliance (according to the back side label) is consistent with the
relevant wall socket capacity.
o The wall socket is protected against short-outs and power surges.
o Do not use extension cables, plug adapters for multiple sockets, or makeshift connections.
• Plug in the appliance.
• Upon rst time operation, and before placing beans into the hopper, VISUALLY check that the blade rotation
direction is clockwise by switching the appliance ON for a few seconds.
• Should the rotation direction be wrong, do not use the appliance and contact your local dealer for further
instructions.
5) Operation
Switching ON and OFF
• The appliance is equipped with a 5 minute timer.
• Switch ON the appliance by turning the timer knob clockwise to the desired time of operation.
• The appliance will switch OFF automatically when the preset time is over or it can be switched OFF manually
by turning the timer knob all the way counterclockwise.
!
Figure 4.1

5
Operating intervals:
• The manufacturer does not recommending using the appliance continuously for a period of time exceeding
30 minutes.
• It is a normal occurrence that during long grinding periods the grinding chamber will heat up. In order to
achieve best grinding results, it is recommended to grind coffee in short intervals of a few minutes each.
Adjusting coffee grind
• The grinding blades’ distance was factory pre-adjusted to satisfy different common coffee grinds from super
ne to coarse) corresponding gap distance from 0.05mm to 0.5mm.
• Turning the grinding dial incrementally counterclockwise will make the grind ner and turning it clockwise will
make the grind coarser.
• Grind a small amount of coffee and test its coarseness with your espresso machine.
• As coffee beans’ qualities and characteristics are changing from time to time it is recommended repeating
this adjustment once in a while.
Adjusting coffee dosing
• The doser is equipped with a portion displacement controlling knob.
• In order to increase the dosed amount the knob should be turned counterclockwise and vice versa (Fig 5.2).
• Test the portioned amounts by inserting a porta lter handle (not supplied) all the way into the fork shaped
support and dose one or two portions.
• In order to achieve repeatable and consistent portioned amounts:
o Make sure that the feeding star shaped mechanism is always over lled with coffee.
o Always retract the dosing lever all the way to the end of its stroke.
Pressing
• Place the porta lter holder against the underside of the pressing device and push it upwards.
6) Safety Devices
A) Thermal Overload Protection
In order to eliminate the risk of re the motor is equipped with an over-heat protection device which will cut-off
the motor’s power supply should it reach a high temperature.
• In the event that the thermal protection is tripped as a result of malfunction (e.g.: jammed blades, worn out
bearings, foreign object in grinding chamber, etc.) the appliance main switch should be turned off
immediately and the main power plug must be disconnected. For further handling of the device contact your
local service provider, and allow the appliance to cool down before any further maintenance.
• In the event that the thermal protection is tripped as a result of a long continuous operation (read section 5,
for operating intervals) allow the appliance to cool down and reset the thermal cut off protection by
unplugging the main cable from the socket. On the rst operation after resetting a tripped over-heat
Figure 5.1
Safety Screw
Figure 5.2

6
protection device observe the grinding quality and noise level, and if there are any irregularities shut down the
appliance and call a certied technician for a complete analysis of the appliance.
B) Grinding Chamber Safety Screws
The grinding chamber can be a hazardous area if the proper precautions aren’t observed. The hopper safety
screw (g 4.1) and the grinding dial safety screw (g 5.1) should never be removed during normal operation of
the appliance unless the appliance is disconnected from the power source.
C) Coffee Outlet Guard
The coffee outlet guard (g 6.3) must always be xed to the doser. Never remove the securing screws.
7) Safety Instructions
• NEVER OPERATE THE GRINDER IF THE BEAN HOPPER IS NOT FULLY SECURED TO THE TOP BLADE
HOLDER. BEFORE REMOVING THE HOPPER FOR ANY REASON MAKE SURE TO DISCONNECT THE
POWER SUPPLY.
• AVOID CLEARING FOREIGN OBJECTS FROM THE GRINDING CHAMBER OR HOPPER WHEN THE
APPLIANCES PLUGGED INTO A POWER SOCKET.
• Never attempt to insert your ngers or any foreign objects into the grinding chamber or blades.
• Be aware that grinding blades continue rotating for a short while after the grinding operation has ended.
• BEFORE ANY MAINTENANCE, EVEN FOR CLEANING, ALWAYS DISCONNECT THE POWER SUPPLY.
• In the event that the appliance has a malfunction or the blades need to be replaced, do not attempt to service
the appliance by yourself.
• Do not change or tamper with the appliance.
• Do not use the appliance barefoot or if your hands or feet are damp.
• Do not use the cable wire to pull and disconnect the power plug.
• Always keep the appliance dry (internally and externally).
• Never put ground coffee into the hopper.
• Never attempt grinding anything else other than coffee beans.
8) Maintenance and Service
Warning: All appliances’ technical handling operations, such as installation, maintenance, or
service should be performed by certified personnel or by your local dealer.
Following this rule will ensure long-lasting and reliable performance of your appliance. Check the state of the
grinding blades periodically (approximately every 110 lbs. ground coffee). Good condition blades will result in
a high quality grind and prevent the appliance’s over-heating. Replace grinding blades every 900 lbs. of
ground coffee (with normal hardness blades).
Be aware of the appliance’s noise level. In case the noise level is higher than normal or irregular noises are
coming from within the appliance, get certied personnel to perform an overall check of the appliance.
9) Cleaning
BEFORE ANY CLEANING ROUTINE DISCONNECT THE APPLIANCE POWER SUPPLY. NEVER USE
RUNNING WATER TO CLEAN THE MAIN BODY AND DOSER. USE ONLY PERFECTLY CLEAN CLOTHS OR
BRUSHES TO CLEAN THE APPLIANCE. DO NOT USE ABRASIVE CLEANING PRODUCTS AS THEY MAY
WEAR OUT THE APPLIANCE COATING.
• Cleaning the bean hopper
Take off the bean hopper and rinse it thoroughly with water and soap. Before reinstalling the hopper to the
upper blade holder, make sure it is dried thoroughly.
Figure 6.3
Outlet Guard
!

7
To ensure great coffee taste, clean the bean hopper periodically.
• Cleaning the grinding chamber
Take off the grinding dial (use a screwdriver to take out the dial safety screw). Pull out the upper blade
holder; make sure not to lose the upper blade support springs (3).
Use a brush, a cloth, and a vacuum cleaner to clean the grinding chamber thoroughly. Do not use sharp
objects to scrape coffee residue off of the blades.
Examine both of the blades’ condition and replace them if necessary. The replacement and assembly of a
new set of blades is a delicate task. Only skilled technical personnel should be allowed to perform blade
removal and assembly.
After all cleaning and replacing tasks are through make sure to assemble all of the parts and safety screws
the same way as they were disconnected. If anything does not t back together or there are left over parts,
do not attempt to operate the appliance, call for the assistance of your technician.
• Cleaning the doser
Discharge all ground coffee; use a clean brush to brush the dosing chambers (by rotating it one by one). Use
a clean cloth to remove stains and hard to remove marks. If a more thorough clean is required, than the
operation must be performed by skilled technician.

8
Dia. # Part # Description
1 01400 Cone Lid
2 01401 Cone Ring
3 01402 Cone
4 01403 Cone Door
5 01404 Dial
6 01405 Top Knife Housing
7 01406 Top Knife
8 01407 Bottom Knife
9 01408 Bottom Knife Holder
10 01409 O Ring
11 01410 Dust Cover
12 01411 Top Bearing
13 01412 Body
14 01413 Rotor
15 01414 Winding
16 01415 Bottom Bearing
17 01416 Back Flange
18 01417 Capacitor
19 01418 Capacitor Holder
20 01419 Leg
21 01420 Bottom Cover
22 01421 Dispenser Handle Shaft 1
23 01422 Dispenser Handle Shaft 2
24 01423 Latch Spring
25 01424 Tray
26 01425 Espresso Handle Holder
27 01426 Time Knob
28 01427 Timer Cover
Dia. # Part # Description
29 01428 Timer
30 01429 Lamp
31 01430 Coffee Tightener
32 01431 Dispenser MTL Cover
33 01432 Dispenser Screw FML
34 01433 Dispenser Lid
35 01434 Dial Stopper
36 01435 Dispenser Window
37 01436 Dispenser
38 01437 Portion Revolver UM
39 01438 Portion Revolver Top
40 01439 Portion Revolver Cover
41 01440 Portion Revolver
42 01441 Revolver Spring
43 01442 Dispenser Top 2
44 01443 Dispenser Washer
45 01444 Dispenser Cover 2
46 01445 Wave Spring
47 01446 Actuator
48 01447 Dispenser Main Shaft
49 01448 Latch Spring
50 01449 Latch Pin
51 01450 Washer
52 01451 Dispenser Bottom Cover
53 01452 Latch Pin Spring
54 01453 Spring Pin
55 01454 Handle
