cecotec ProClean 6110 User manual

Instruction manual
PROCLEAN 6110
Microwave

INDEX
1. Parts and components
2. Before use
3. Operation
4. Tips
5. Cleaning and maintenance
6. Technical specications
7. Disposal of old electrical appliances
8. Technical support and warranty

PROCLEAN 6110
3
SAFETY INSTRUCTIONS
Read these instructions thoroughly before using the appliance.
Keep this instruction manual for future reference or new users.
-Make sure that the mains voltage matches the voltage
stated on the rating label of the appliance and that the wall
outlet is grounded.
- Do not operate outdoors.
-This product is designed only for household use.
-Use this appliance only for its intended purpose, as described
in this manual. Do not use corrosive chemicals or vapours in
this appliance, it is not designed for industrial or laboratory
use.
-If the door or door seals are damaged, the product must
not be operated until it has been repaired by a competent
person.
- Do not operate the microwave when empty.
-Do not operate this appliance if it has a damaged cord or
plug or if it is not operating properly. If the cord is damaged,
it must be replaced by the ocial Technical Support Service
of Cecotec in order to avoid any type of danger.
-Only use utensils that are suitable for microwaves. Make
sureutensilsdo nottouchthe interiorwallsduring operation.
- Do not use the cavity for storage purposes.
- Do not attempt to deep-fry in this oven.
-In order to reduce re risk:
- Do not overcook food.
-Remove wire twist-ties from paper or plastic bags before
placing them inside the microwave.
-Do not heat liquids or other foods in sealed containers.
-In case of smoke or re inside the device, keep the door
closed, turn the product o and disconnect it from the power
supply.

PROCLEAN 6110 4
-In order to prevent the glass tray from breaking, do not place
hot foods, hot utensils, frozen foods or frozen utensils on it.
-After operating, the container is likely to be very hot. Use
gloves in order to avoid burns and injuries.
-In Grill or Combination (1, 2, 3) mode, all oven parts
will be very hot during and after operation, including
door and top part of the microwave. Remember to use
handle, gloves or any other type of protection.
-The appliance is not intended to be used by children under
the age of 8. It can be used by children over the age of 8, as
long as they are given continuous supervision.
-This appliance can be used by children aged 8 and above,
and persons with reduced physical, sensory or mental
capabilities or lack of experience and knowledge, as long as
they have been given supervision or instruction concerning
the use of the appliance in a safe way and understand the
hazards involved.
-Children shallnot playwith the appliance. Close supervision
is necessary when the appliance is being used by or near
children.
-This product is a Group 2 Class B ISM equipment. The
denition of Group 2 which contains all ISM (Industrial,
Scientic and Medical) equipment in which radio-frequency
energy is intentionally generated and/or used in the form of
electromagnetic radiation for the treatment of material, and
spark erosion equipment. Class B equipment is suitable for
domestic use and in establishments directly connected to a
low voltage power supply network, which supplies buildings
used for domestic purpose.
-Technical service and reparations that involve cover
removals or exposure to cables must always be carried out
by a competent, professional and qualied person.

PROCLEAN 6110
5
-It is important to use materials and containers which are
suitable and safe for microwave cooking. The table below
shows which materials are suitable and which are not:
Material of
container
Grill Combi Microwaves Warnings
Heatproof
ceramics.
Yes Yes Yes Never use
ceramics which
are decorated
with
metal rim or
glazed.
Heatproof
plastic
No No Yes Cannot be used
for long time
microwave
cooking.
Heatproof
glass.
Yes Yes Yes
Plastic lm. No No Yes It should not
be used when
cooking meat,
high temperature
might damage
the lm.
Grill. Yes Yes No
Metal
container.
No No No Microwave
cannot cook
through metal.

PROCLEAN 6110 6
Lacquer. No No No Poor heat-
resistance.
Cannot
be used
for high-
temperature
cooking.
No No No Poor heat-
resistance.

PROCLEAN 6110 7
1. PARTS AND COMPONENTS
Fig. 1
1. Door safety lock system
2. Microwave window
3. Rotating axis
4. Roller ring
5. Rotary plate
6. Control panel
7. Mica panel
Fig. 2
1. Start/Stop
2. Weight cooking
3. Weight defrost
4. Fast defrost
5. ON button
6. Timer button
7. Grill/Combi
8. Numbers
9. Preset programmes
10. Reset
11. Clock
12. Reheat
2. BEFORE USE
- Never remove the mica plate.
-Take the product out of the box. If the microwave has a protective lm, tear it o before
starting operation. Check carefully if there is any damage, and if there is, immediately
notify the Technical Support Service of Cecotec.
-The product must be placed on a at, stable and dry place and kept away from corrosive
materials, heat and humidity, such as gas burners or water.
-To ensure enough ventilation, minimum distances have to be kept:
-From the back part to the wall: 10 cm.
-From the side to the wall: 5 cm.
-Free distance from the top surface: 20 cm.
-From the microwave to the ground: 85 cm.

PROCLEAN 6110
8
-The product must be placed, at least, at 5 m from the TV, Radio or antenna.
-The product must be placed in such way that the plug is accessible and must ensure an
eective grounding in case of leakage in order to avoid electric shocks.
-The microwave door must be closed in order to operate.
- In case there is any manufacturing rests in the microwave cavity or on the heating
elements, leave the microwave open to ensure good ventilation. In such case, it is
recommended to heat a glass of water at high power for several times.
3. OPERATION
Beeps during setting
- 1 beep: Microwave accepts the entry.
- 2 beeps: Microwave does not accept the entry.
Number pads
Number pads are used for selecting food kind, cooking time and power level.
Key Power % Microwave instruction
On 100 % P100 and P90: High power, 100% and 90% microwave power. Perfect for
quick and thorough cooking.
9 90 %
8 80 % P80 and P70: Medium-High power, 80 % and 70 %. Perfect for medium
express cooking.
7 70 %
6 60 % P60 and P50: Medium power, 60 % and 50 %. Perfect for steaming food.
5 50 %
4 40 % P40 and P30: Medium-Low power, 40 % and 30 %, perfect for defrosting
food.
3 30 %
2 20 % P20 and P10: Low power, 20 and 10 %. Perfect for keeping food warm.
1 10 %
Reset
Press the Reset button to clear all previous settings.
Start/Stop
Press the Start/Stop to start or stop cooking.

PROCLEAN 6110 9
Automatic cooking
Use this mode for multi-stage cooking. It allows cooking at dierent power levels at dierent
pre-set times, changing from one stage to another automatically.
Clock setting
-On standby state, press Clock key.
-Use number keys to enter the correct time. You must press at least three numbers to set
the clock (one for hour and two for minutes).
-Press the Clock key again to conrm time.
Warning:
The clock is 24 hours. When the microwave is rst plugged in or when power resumes after
a power interruption, the display panel will show ENTER, CLOCK, TIME. If you prefer not to
have the clock displayed, press the Reset key. You can check the clock time while cooking is in
progress by pressing the Clock key.
Example: Setting clock at 12:30
Steps Display
1After powering up, the display panel shows the colon sign.
Press the Reset button once or wait for 30 seconds.
:
2Press keys “1”, “2”, “3”, “0”. 12:30
3 Press the Clock key to conrm.
Setting timer
-You can use the timer function independently, even while the microwave is operating.
-Press the Timer button.
-Enter cooking time by pressing the number keys. The timer is set in minutes and seconds,
from left to right. The maximum cooking time is 99 minutes, 99 seconds.
-For example, to program:
1. 5 seconds: Press 5.
2. 24 minutes, 5 seconds: Press 2405.
3. Press the Start/Stop key to conrm.
Warning
The timer countdown can be seen in display for 3 seconds before it goes back to the stand by
mode.
Press Timer and then press Reset to cancel timer during countdown.

PROCLEAN 6110
10
Setting cooking time and power level
One-stage cooking
1. From the home display, use the number keys to enter the desired cooking time. The
cooking time can be from 1 second to 99 minutes and 99 seconds. If the desired
cooking time is more than 1 minute, enter numbers for both minutes and seconds.
For example: to set 20 minutes, enter 2, 0, 0, 0.
2. Press the power button and set the desired power level using the number keys.
3. Press the Start/Stop key to start operation.
Example: Cooking at P80 for 10 minutes.
Steps Display
1After powering up, the display panel shows the colon sign.
Press the Reset button once or wait for 30 seconds.
:
2Press the On button repeatedly to select he desired power level . 80P
3 Set the cooking time by pressing number keys “1”, “0”,“0”, “0”. 10:00
4Press the Start/Stop button to start operation. The LED will display the
countdown.
Warning:
-The maximum programmable cooking time is 99 minutes, 99 seconds.
- It is recommended to turn or stir food at least once during the process.
- Press Reset button once to resume operation.
-If food is removed before the pre-set time, make sure you press Reset once in order to stop
operation and avoid the microwave from operating automatically and empty when closed.
-When operating at maximum power, the microwave will automatically lower power after
a certain time in order to lengthen the appliance’s shelf life.
Two-stage cooking
In order to obtain the best result, some recipes require of dierent steps. This function allows
you to personalise and to combine your cooking processes.
Example: Cooking food on microwave mode at 100 P, for 3 minutes,then 20P for 9 minutes.
Steps Display
1Select 100 P microwave for 3 minutes.
1.1 The display shows colon, press, press the Reset key once or wait for 30
seconds.
:
1.2 Press ”3” “0”, “0” to set cooking time. 3:00

PROCLEAN 6110 11
1.3 Press the Power button once and then select the desired power level by
pressing “1” “0”.
100P
1.4 Press the Cooking button once to conrm.
220P for 9 minutes.
2.1 Press “9”, “0”, “0” to set cooking time. 9:00
2.2 Press the Power button once and select microwave power by pressing “2”. 20P
3Press the Start/Stop button to start operation.
Fast defrost
1. From the home or clock display, press Speed Defrost key.
2. Enter desired defrosting time by pressing the correct number keys.
Press the Start/Stop key.
Example: Speed defrost 0.2 kg of poultry for 2 minutes, 50 seconds
Steps Display
1After powering up, the display panel shows the colon sign.
Press the Reset button once or wait for 30 seconds.
:
2 Press Speed Defrost key. :
3 Press “2”,”5”,”0” to set defrost time. 2:50
4 Press the Start/Stop button to start operation.
Warning:
-Once preset time is over, 4 alarm beeps will sound and display will show END. Press the
Reset button or open door to return to stand by state.
-After setting Speed Defrost, the microwave can be programmed to switch automatically
to:
-Stage 1 cooking: Before pressing Start, press the On button
-to set the power level and enter the cooking time. Then press the Start/Stop key.
-2-stage cooking: Before pressing the Start/Stop key, enter two-stage cooking programme.
Weight cooking
-The microwave has default cooking programmes for simple operations.
-Set food weight and type and the microwave will automatically set the cooking time and
power level.

PROCLEAN 6110
12
Display codes Food type Weight
1 Beef 0,1, 0,15, 0,2...2,9, 2,95, 3 kg
2 Lamb 0,1, 0,15, 0,2...2,9, 2,95, 3 kg
3Pork 0,1, 0,15, 0,2...1,9, 1,95, 2 kg
Example: Cooking 1.2 kg of beef
Steps Display
1After powering up, the display panel shows the colon sign.
Press the Reset button once or wait for 30 seconds.
:
2 Press Cook By Weight button.
3 Select the food kind by entering code “1”. 1
4Set food weight by pressing number ”1” “2” “0”. 1.20
5The microwave starts cooking and time will appear automatically on the
display.
34:24
During the cooking process, two beeps will sound in order to remind you to turn over the
food. After turning over the food, press Start/Stop to resume cooking.
Warning:
-Weight must be specied in kg.
-Once preset time is over, 4 alarm beeps will sound and display will show END. Press the
Reset button or open door to return to stand by state.
-Please, wait a few minutes before removing food from inside.
Weight defrost
Set food weight and type and the microwave will automatically set the
defrosting time.
Example: Defrosting 1.15 kg of beef
Steps Display
1After powering up, the display panel shows the colon sign.
Press the Reset button once or wait for 30 seconds.
:
2 Press Defrost By weight button. 0.

PROCLEAN 6110 13
3 Set defrosting weight by pressing numbers“1”, “1”, “5”. 1.15
4Press the Start/Stop key to start operation. The LED will display the
countdown.
23:00
During the cooking process, two beeps will sound in order to remind you to turn over the
food. After turning over the food, press Start/Stop to resume cooking.
- It is highly recommended to turn over food during operation on order to obtain uniform
eect.
-Usually defrosting will need longer time than cooking food.
-If the food can be cut by knife, the defrosting process can be considered completed.
- Microwave radiation penetrates around 4 cm into most foods.
-Defrosted food should be used as soon as possible. It is not recommended to freeze or put
back in the fridge again.
-Weight must be set in kg, from 0.1 to 3.0 kg.
Grill and Combination
G (Grill) Only heating elements will be energised during operation. Perfect for cooking
sausages, chicken wings, etc.
C.1 Combines 30 % microwave operation and 70 % grill operation.
C.2 Combines 55 % microwave operation and 45 % grill operation.
Example: Grilling food on C.2 mode for 10 minutes.
Steps Display
1After powering up, the display panel shows the colon sign. :
2 Press the Grill/Combi button to select the mode. C.2
3 Set the cooking time by pressing number keys “1”, “0”,“0”, “0” 10:00
4 Press the Start/Stop key to start operation.
Warning: All the microwave’s parts may reach high temperatures during operation in Grill/
Combi mode. Be careful when removing tools or containers from inside the microwave.
About “Quick Cook” programmes
These programmes allow cooking or heating up food automatically without setting time or
power level. On the control panel, choose between 6 programmes:

PROCLEAN 6110
14
Popcorn
1. In standby or clock state, press Popcorn key which automatically sets the cooking
time of microwave popcorn.
2. Press the Start/Stop key.
Warning:
To reset Popcorn time, tap Popcorn key twice. ENTER TIME appears on display. Press the
number keys to enter minutes and seconds. Press the Start/Stop key. This new cooking time
will remain set by default whenever you press the Popcorn key until you reset it.
Baked potato
1. In standby or clock state, press the Baked Potato key once.
2. Enter the number of potatoes by pressing number keys from 1 to 4.
3. Press the Start/Stop key.
Pizza
1. In standby or clock state, press the Pizza key once.
2. Press the Start/Stop key.
Drinks
1. In standby or clock state, press the Beverage key once.
2. Enter the number of cups by pressing number keys from 1 to 4.
3. Press the Start/Stop key.
Frozen dinner
1. In standby or clock state, press the Frozen dinner key once.
2. Press 1 or 2 to select 1 or 2 dishes.
3. Press the Start/Stop key.
Reheat
1. In standby or clock state, press the Reheat key once.
2. Press the Start/Stop key.
Child safety lock setting
-Security systemthat blocks controlpanel to ensure small children do not use the appliance
without supervision.
-To activate lock: Hold the Reset button for 3 seconds.
-To deactivate lock: Hold the Reset button for 3 seconds.

PROCLEAN 6110 15
4. TIPS
-Food arrangement: Place the thickest food parts towards the edge of the glass tray. If
possible, do not overlap food.
-Watch cooking time: Cook for the shortest amount of time at rst, and add more minutes in
case it is necessary. Over-cooking may result in smoke and burns.
-Cover food while cooking: Covering the food you are going to cook avoids spattering and
allows for a more even cooking.
-Flip or stir food once during the cooking process.
-Respect pre-heating time. Pre-heating time specied on the food’s label must not be
exceeded.
5. CLEANING AND MAINTENANCE
-The device, as well as food rests, must be cleaned and removed regularly.
-Disconnect the power cord from the wall socket before cleaning. Do not immerse the
product in water or any other uid during cleaning.
-Failure to maintain the product in clean conditions could lead to surface deterioration and
could adversely aect the product’s shelf life, resulting in possible hazard.
-Never use strong detergents, abrasive powder or metal brush to clean any part of the
product.
- Do not remove the wave guide.
-When the microwave has been used for a long time, some strong odours may arise from
inside. To eliminate these odours, follow one of the below methods:
-Place several lemon slices in a cup and heat them at high power for 2 or 3 minutes.
-Place a cup of red tea inside the microwaves and heat it at high power for 2 or 3 minutes.
- Place orange peels inside the microwaves and heat it at high power for 1 minute.
-Use a dampened soft cloth to clean enclosures, door, interior walls and the door frame.
6. TECHNICAL SPECIFICATIONS
Model: ProClean 6110
Product reference: 01537
Inlet power: 1280 W
Microwave power: 800 W
Voltage and frequency: 230 V, 50 Hz
Capacity: 23L
Made in China | Designed in Spain

PROCLEAN 6110
16
7. DISPOSAL OF OLD ELECTRICALAPPLIANCES
The European directive 2012/19/EU on Waste Electrical and Electronic
Equipment (WEEE), species that old household electrical appliances must
not be disposed of with the normal unsorted municipal waste. Old
appliances must be collected separately, in order to optimise the recovery
and recycling of the materials they contain and reduce the impact on
human health and the environment.
The crossed out “wheeled bin” symbol on the product reminds you of your obligation to
dispose of the appliance correctly.
Consumers must contact their local authorities or retailer for information concerning the
correct disposal of old appliances and/or their batteries.
8. TECHNICAL SUPPORT AND WARRANTY
This product is under warranty for 2 years from the date of purchase, as long as the proof
of purchase is submitted, the product is in perfect physical condition, and it has been given
proper use, as explained in this instruction manual.
The warranty will not cover the following situations:
-The product has been used for purposes other than those intended for it, misused,
beaten, exposed to moisture, immersed in liquid or corrosive substances, as well as any
other fault attributable to the customer.
-The product has been disassembled, modied, or repaired by persons, not authorised by
the ocial Technical Support Service of Cecotec.
-Faults deriving from the normal wear and tear of its parts, due to use.
The warranty service covers every manufacturing defects of your appliance for 2 years,
based on current legislation, except consumable parts. In the event of misuse, the warranty
will not apply.
If at any moment you detect any problem with your product or have any doubt, do not
hesitate to contact Cecotec Technical Support Service at [phone].

PROCLEAN 6110
17
Fig./Img./Abb./Afb./ Rys./Obr. 1
1
2
58 7
3 4 6
7

PROCLEAN 6110 18
Fig./Img./Abb./Afb./ Rys./Obr. 2
9
1
8
11
5
2
10
12
76
43

www.cecotec.es
Grupo Cecotec Innovaciones S.L.
C/ de la Pinadeta s/n, 46930
Quart de Poblet, Valencia (Spain)
IC02210202
