CEGA MV510-2 Assembly instructions

REF MV510-2 Cart
CEGA510-2_20210630_V3.9
Sioux Falls, SD 57108
1-800-440-5605
cegaco.com
TOOLS REQUIRED:
Adjustable Wrench
Phillips Screwdriver (#2 & #3 Phillips Bits Required)
Electric Drill/Phillips Bit (#2 & #3 Bits Required)
PARTS LIST:
Base Assembly (1 pc)
Casters (2 pcs)
Locking Casters (2 pcs)
Fenders (2 pcs)
Pillar (1 pc)
Handle (1 pc)
Side Hose Hangers (2 pcs)
Front Hose Hanger (1 pc)
HARDWARE LIST:
Caster Washers (4 pcs)
Caster Lock Nuts (4 pcs)
M4 x 19mm Screws (12 pcs)
M6 x 10mm Screws (10 pcs)
M5.5 x 19mm Screws (6 pcs)
CEGA® Air Supply Moun�ng
Bracket (1 pc)
Universal Moun�ng Bracket (1 pc)
HANDLE
(1 pc)
SIDE HOSE HANGER
(2 pcs)
FRONT HOSE HANGER
(1 pc)
PILLAR
(1 pc)
SIDE HOSE HANGER
(2 pcs)
M6 X 10MM Screws
(6 pcs)
CEGA® AIR SUPPLY
MOUNTING BRACKET
(1 pc)
LOCK NUTS
(4 pcs)
CASTER
M4 X 19MM SCREWS
(12 pcs)
BASE ASSEMBLY
(1 pc)
FENDERS
(2 pcs)
WASHERS
(4 pcs)
M6 X 10MM
SCREWS
(4 pcs)
M5.5 x 19MM SCREWS
(6 pcs)
LOCKING CASTER
CASTER
(2 pcs)
(2 pcs)
ASSEMBLY STEPS:
1. Attach Casters (A), to Base Assembly using
Washers (4 pcs) & Lock Nuts (4 pcs). Place
locking casters (B) at the diagonal.
2. Attach Fenders (C) to Base
Assembly using M4 x 19mm Screws
(12 pcs) and #2 Phillips Bit.
6. Attach either the CEGA®Air Supply Mounting Bracket (F) or the Universal
Mounting Strap (G) using M5.5 x 19mm Screws (2 pcs) and a #3 Phillips Bit.
D
C
FG
3. Attach Pillar to Base Assembly
using M6 x 10mm Screws
(4 pcs) & #3 Phillips Bit.
4. Apply outward force (D) to
seat handle on pillar (E).
Attach Handle to Pillar
using M5.5 x 19mm Screws
(4 pcs) & #3 Phillips Bit.
5. Attach Hose Hangers to
Handle using M6 x 10mm
Screws (6 pcs) #3 Phillips Bit.
Instructions for Assembly
D
E
A
A
B

Warranty Terms & Conditions
CEGA Innovations®, Inc., hereafter “CEGA®”, warrants to the original purchaser that the Accessory Cart (MV510-2) (and parts thereof)
will be free of defects in workmanship or material for a period of one year from the date of delivery. Should any failure to conform
to this warranty appear, CEGA® shall upon notication within such time period, correct such non-conformity, at its option, either
by repairing any defective part or parts, or by replacing a part or parts with an equivalent or current version of the owner’s model,
provided that the equipment is returned to CEGA®. In all cases freight both ways will be at the expense of the customer. Equipment
shall not be returned without advance notice to and consent of CEGA®.
Correction of non-conformities or defects in the manner and for the period of time provided above shall constitute fulllment of all
liabilities of CEGA® to the customer, whether based on contract, negligence or otherwise with respect to, or arising out of, such equipment.
The remedies set forth herein are exclusive, and the total liability of CEGA® with respect to this sale or anything done in connection therewith,
whether in contract, in tort, under any warranty, or otherwise, and shall not, except as expressly provided herein, exceed the price of the
equipment or part on which such liability is based.
This warranty is subject to the following exceptions and limitations:
This warranty does not cover repairs due to normal wear and tear, accident, neglect, misuse or abuse, incorrect installation or use other than
used as the Accessory Cart. This warranty is rendered void if repairs are made or attempted by persons not authorized by CEGA®.
Even if any covered products are beyond the warranty period, we suggest you contact CEGA® or your supplier for repair and
replacement information.
CEGA® assumes no liability for malfunction or damage to any unit or components thereof, caused by the use of consumables other than those
manufactured, provided, or recommended by CEGA®.
For most current patent information, visit cegaco.com/patents
For most current instructions for use, visit cegaco.com/ifu
