Celabs UHX70M User manual

CE Labs, LLC.
MANUAL
UHX70M

www.celabs.com/contact
Thank you for your purchase. CE Labs manufactures a full line
of commercial-grade products. For more information about our
products and services please visit www.celabs.com.
We strive to provide superior support through out the product
lifecycle. For technical assistance please call 1-800-767-6189 or
scan the QR code.
CE Labs
Thank You!
After-Sales Service Care
We provide limited warranty for the product for three years.

UHX70M
CE Labs, LLC.
Packing List:
Features:
Product Introduction:
• 1x 4K Extender Receiver
• 1x 4K Extender Transmitter
• 2x DC 5V 2A Adapter
• 1x IR Receiver Cable
• 1x IR Emitter Cable
• 1x Hardware Mounting Pack
• 1x Product Manual
The UHX70M is a commercial-grade Ultra-High Definition HDMI Extender
kit. The UHX70M supports 4K/60 @70M. With a ultra-compact and rugged
chassis the UHX70M is ideal for professional environments that require 24/7
performance. Extends HDMI 4K UHD @60Hz, HDR and IR signal over one CAT6
cable.
Performance: Extends HDMI 4K UHD @60Hz, HDR and IR signal
Range: 70M by CAT 6/6a/7
Video Output: 4K@60Hz at 70M, 1080p@60Hz at 100M
Audio Output: LPCM 7.1 @ 192KHz, Dolby TrueHD, Dolby Digital 5.1
I/O Parts: HDMI 2.0, RJ45, 2.5mm power, S/PDIF/ Optical
LED Indicators: Pwr On, Blue
Control: Bi-directional IR, supports 30-60kHz
Rating: 24/7 Operation
Audio Select: Audio extraction SPDIF optical or ARC

Transmitter I/O Panels
Panel Descriptions:
Receiver I/O Panels
HDMI Input
IR In
IR Out
Reset Button
1
RJ45 Signal Output
2
Power/Signal Indicator
3
DC5V Input
4
HDMI 2.0 Output
5
6
7
8
S/PDIF Out
HDMI 2.0 Output
IR In
IR Out
Reset Button1
Audio Switch
2
RJ45 Signal Input
3
Power/Signal Indicator
4
DC5V Input
5
6
7
8
9

UHX70M
CE Labs, LLC.
Installation Diagram:
Cable:
CE labs recommendation: TIA/EIA-568-B. high quality CAT6, CAT6a, CAT7
UTP (Un-shielded Twisted Pair)/STP (Shielded Twisted Pair) or FTP (Foiled
Twisted Pair) cables.
RJ45 Define:
Video Link (TIA/EIA-568-B)
1. Orange-white DATA0+
2. Orange DATA0-
3. Green-white DATA1+
4. Blue DATA2+
5. Blue-white DATA2-
6. Green DATA1-
7. Brown-white DATA3+
8. Brown DATA3-
It connected through a wall plate the cable length must be less than 5 meters
between HDMI extender and wall jack.
Distance Chart by Cable:
Cable Type Range Supported Video
Cat6 100m Up to 1080p 60Hz 12bit
Cat6a/ Cat7 100m
Cat6 70m Up to 4096x2160@
60Hz 4:4:4
Cat6a/ Cat7 70m
MAX 70M
WALL
JACK
WALL
JACK
5M MAX 5M MAX

Troubleshooting Tips:
1. Keep the wiring away from any equipment with electromagnetic wave,
i.e.: microwave, radio equipment, fluorescent lamp, high voltage power.
2. Use Premium certified HDMI cables. Make certain they are inserted
fully.
3. Verify RJ45 are crimped firmly and securely. Insert until they click in
socket.
4. Verify Power / Signal LED is solid blue. If flashing, there is no HDMI
input.
5. This device’s RJ45 port is not compatible with standard computer
Ethernet signal; do not connect with Network devices to avoid damage.
6. Avoid interference with the IR extender. Do not place the IR transmitter
and IR receiver close to one another.
See our full product line at www.celabs.com.
CE Labs can support many areas of your video playback
and distribution needs. We manufacture UHD media players,
Digital Signage Solutions, HDTV compatible Video Scalers, UHD
distribution amplifiers, and cables of all types.
Q: There is no output on screen when all connections are correct?
A: 1) Please make sure the HDMI cables supports 4Kx2K if the output signal
from the source device is 4Kx2K resolution.
2) Please check and make sure the network cable insert to the RJ45 port
well.
3) Restart the transmitter or receiver by pressing the reset button.
Q: Black screen happened on the display /monitor?
A: 1) Check if the length of the cable is within the specified range.
2) Reset the transmitter to re-built the connection.
Q: The display shows unusual color or no sound?
A: 1) Reset the transmitter or receiver to re-built the connection.
2) Check if the HDMI cables are connected well.
3) Reconnect the network cable.
FAQs:

UHX70M
CE Labs, LLC.
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with dry cloth.
7. Do not block any ventilation openings. Install in accordance with the
manufacturer’s instructions.
8. Do not install near any heat sources such as radiators, heat registers,
stoves, or other apparatus (including amplifiers) that product heat.
9. Protect the power cord from being walked on or pinched particularly at
plugs, convenience receptacles, and the point where the exit from the
apparatus.
10. Only use the attachments/accessories specified by the manufacturer.
11. Use only with the cart, stand, tripod, bracket, or table specified by the
manufacturer, or sold with the apparatus. When a cart is used, use
caution when moving the cart/apparatus combination to avoid injury
from tip-over.
12. Unplug this apparatus during lightning storms or when unused for long
periods of time.
13. Refer all servicing to qualified service personnel. Servicing is required
when the apparatus has been damaged in any way such as power
supply cord or plug is damaged, liquid has been spilled or objects have
fallen into the apparatus, the apparatus has been exposed to rain or
moisture, does not operate normally, or has been dropped.
IMPORTANT SAFETY INSTRUCTIONS:
CE Labs LLC warrants this product to be free from defects in material and
workmanship, under normal use and service, for a period of three years
from the purchase by the original purchaser. If this product is defective or
malfunctions, CE Labs will replace or repair this unit (at our option) within a
reasonable time. No expressed or implied warranty is made for any defects
or damage caused by immersion or exposure to liquids, abuse, neglect,
improper operation of unit, acts of nature (including but not limited to flood,
wind, and lightning), excess wear and tear and or defects resulting from
unauthorized disassembly and or modification.

email: [email protected]
Phone: [phone]
CE Labs, LLC.
3209 Wood Drive Garland, Texas 75041-9205
