Celestron 4040 User manual

Microscope
Instruction Manual
Models # 4040, 4050 and 4060

2
Table of Contents
Introduction ……………………………………………………………………… 1
Stereo Dissecting Microscope Model #4040 ………………………………. 2
Biological Microscope Model #4050 …………………………………………. 5
Research Microscope Model #4060 ………………………………………….. 8
Care and Maintenance ………………………………………………………….. 12
Introduction
Congratulations on your purchase of a Celestron microscope. Celestron offers a complete line of
quality microscopes ranging from beginner and educational microscopes to research level
instruments. Your Celestron microscope is a precision optical instrument, made of the highest
quality materials to ensure durability and long life. Your microscope is designed to give you a
lifetime of pleasure with a minimal amount of maintenance.
The first sections of this manual will help you become familiar with the various parts of your
microscope and how they work together. Read carefully the sections on viewing specimens and
focusing. Take special notice of all precautions regarding using the illuminator mirror (if
applicable to your model) to focus sunlight and regulating the focuser travel so as not to damage
specimen slides or the objective lens.
The final section provides simple care and maintenance tips for you to follow to ensure that your
microscope provides you with years of quality performance and enjoyment.

2
Stereo Dissecting Microscope – Model #4040
Figure 1
1 Eyepiece 8 Power Cord
2 Diopter Ring 9 Illuminator Switch
3 Binocular Head 10 Top Light Illuminator
4 Binocular Head Tension Screw 11 Focus Adjustment Knob
5 Objective Turret 12 Pillar Stand Locking Bolt
6 Slide Holder Clips 13 Pillar Stand
7 Glass Stage Plate
Standard Accessories:
Your Celestron microscope (#4040) comes complete with the following standard accessories:
•Two 10x Eyepieces •Rubber Eyecups
•One 2x Objective lens (20x) •Black/White Stage Plate
•One 4x Objective lens (40x) •Plastic Dust Cover
Item #4040 Specifications:
Optical Head 45ºinclined Binocular Head; 360º Rotatable
Interpupillary distance Adjustable from 55-75mm
Illuminator Top/Bottom built-in electric illuminator;
Incandescent Bulb
Stage 94.5mm glass stage and black/white stage plate
Power Supply 110v
Nosepiece Turret objective 2x/4x
Objectives Achromatic objectives
3
1
2
4
5
6
7
8
9
11
12
13
10

3
Assembling Your Microscope
Before you can view through your Celestron microscope, the binocular head assembly must be
attached to the pillar stand (13) and the rubber eyecups must be placed over the eyepieces. To
attach the binocular head assembly:
1. Remove the safety screw from the top of the pillar stand (13).
2. Partially unthread the pillar stand locking bolt (12) located behind the focuser assembly.
3. Place the binocular head assembly onto the pillar stand (13) and slide it half way down the
stand. Be careful not to put too much tension on the cord that goes from the microscope base
to the top light illuminator (10).
4. Rotate the binocular head assembly until the objective turret (5) is directly over the center of
the stage (7).
5. Tighten the pillar stand locking bolt (12) to hold the binocular head assembly in place.
6. Thread the safety screw back onto the top of the pillar stand.
To Attach the Rubber Eyecups:
1. Place the rubber eyecups over the eyepieces with the rubber lips facing up.
2. Push the eyecups down over the tops of the eyepieces.
3. Rotate the eyepieces so that the rubber lips are facing out to the sides.
Your microscope is now ready to view specimens.
Microscope Operation
Powering the illuminator:
Your Celestron microscope has a built-in, 3-setting illuminator powered by 110v AC power. To
power the illuminator:
1. Plug the power cord (8) into a wall outlet.
2. Turn the illuminator switch (9) to the "I" setting to turn on the bottom illuminator bulb.
3. Turn the illuminator switch (9) to the "II" setting to turn on the top illuminator bulb.
4. Turn the illuminator switch (9) to the "III" setting to turn on both the top and bottom
illuminator bulbs.
Viewing a Specimen
To view a specimen:
1. Place the round glass stage plate (7) into the opening above the illuminator. When viewing a
specimen using top lighting only, you may wish to replace the glass stage plate with the
black/white stage plate.
Tip: Specimens of different size and thickness will require different levels of illumination.
Experiment with different lighting for each specimen. When using top lighting, the white side
of the stage plate may wash out fine detail where as the black side will increase contrast but
may make the specimen less bright.
2. Place a specimen slide under the specimen holder clips (6) and center the specimen directly
in the center of the stage.

4
Focusing:
To achieve the best focus with your microscope, not only can you make adjustments with the
focus adjustment knobs, but you can also adjust the left diopter ring as well as the interpupillary
distance between the eyepieces. To achieve sharpest focus:
1. Rotate the objective turret (5) to the 2x position . (Always begin by viewing a specimen at low
power, then switch to high power when needed).
2. Turn the focus adjustment knob (11) until the specimen comes into focus. If there is not
enough travel in the focuser mechanism to reach focus, it may be necessary to loosen the
pillar stand locking bolt (12) and slightly raise or lower the entire binocular head assembly
until the image becomes sharp.
3. Next, while looking through the eyepieces, adjust the interpupillary distance by sliding both
eyepieces side to side until the whole field of view can be observed through both eyes at the
same time.
4. Finally, close your right eye and turn the left eyepiece diopter ring until the image is in sharp
focus through the eyepiece.
If higher power is desired, rotate the objective turret (5) to the 4x position and readjust the focus
knobs (11) until the specimen comes into focus.

5
Biological Microscope - Model #4050
1 Eyepiece 9 Power Switch
2 Monocular Head 10 Fine Focus Adjustment Knob
3 Objective Lens Rotator 11 Power Cord
4 Objective Lens 12 Course Focus Adjustment Knob
5 Condenser 13 Specimen Holder Clips
6 Specimen Stage 14 Focus Travel Safety Screw
7 Diaphragm Dial 15 Stand Column
8 Illuminator
Standard Accessories:
Your Celestron microscope (#4050) comes complete with the following standard accessories:
•10x eyepiece with pointer •4x Objective lens (40x)
•Plastic Dust Cover •10x Objective lens (100x)
•40x Objective lens (400x)
Item #4050 Specifications
Objective Lens Achromatic Objective
Nosepiece Triple nosepiece with click stop
Stage 120mm x 110mm, with paired clips
Illuminator Built-in electric illuminator; 20W tungsten bulb
Diaphragm Disc diaphragm with five aperture sizes
Head Monocular head, 45º incline, 360º rotatable
Focuser Course focus; Fine focus adjustments
1
3
4
6
7
8
9
1
0
11
12
14
13
1
5
2
5

6
Assembling Your Microscope
Before you can view through your Celestron microscope, the objective lenses must first be
attached.
Installing the Objective Lenses:
1. Remove the three objective lenses from their individual containers. Unscrew the container
lids from the threaded portion of the objective lens.
2. Thread the end of the 4x objective lens into one of the holes on the objective lens rotator (3).
It may be necessary to lower the specimen stage (6) by turning the coarse focus knob (12).
3. Now turn the objective rotator to the next opening and thread each of the remaining
objective lenses into the remaining holes.
Your microscope is now ready to view specimens.
Microscope Operation
Powering the illuminator:
Your Celestron microscope has a built-in illuminator powered by 110v AC power. To power the
illuminator:
5. Plug the power cord (11) into a wall outlet.
6. Turn the power switch (9) to the "on" position.
To regulate the amount of light shining on the specimen, rotate the diaphragm dial (7). The
diaphragm dial has five openings of different sizes which allow different amounts of light to pass
from the illuminator.
Viewing a Specimen
To view a specimen:
3. Press downward on the back portion of the spring-loaded specimen holder clips (13) to raise
the front of the clips off of the specimen stage (6).
4. Place a specimen slide under the specimen holder clips (13) and center the specimen directly
over the condenser lens .
You are now ready to focus and view the specimen, but first you must take some precautions so
as not to damage the specimen slide or objective lens. Your microscope is equipped with a focus
travel safety screw (14) which allows you to regulate the range of travel on the focuser. This
assures that the objective lenses will not accidentally come in contact with specimen slide,
breaking the slide or scratching the objective lens. To adjust the travel on the focuser
mechanism:
1. Lower the specimen stage by rotating the course focus adjustment knobs (12).
2. Partially unscrew the focus travel safely screw (14) so that about 1 inch is sticking up.
3. Turn the objective lens rotator (3) until the 40x lens is directly over the light condenser (5).
4. Use the focus knobs (12) to raise the stage (6) until the tip of the lens is slightly above the
specimen slide. (Be careful not to touch the slide to the objective lens).
5. Thread the focus travel safely screw (14) down until it stops against the focuser mechanism.
6. Rotate the knurled locking nut downward to lock the safety screw in place.

7
Focusing:
Now that the specimen slide is placed directly under the objective lens, use the course focus
knob (12) to focus on the specimen.
•Always start with the lowest power (4x objective lens) and switch to higher power by rotating
the objective lens rotator (3). Be cautious not to let the objective lens touch the specimen
slide when changing to higher power.
•Use the fine focus knob (10) to change the depth of field on the specimen you are observing.
•If you run out of upward travel before reaching sharp focus, you can unscrew the focus travel
safety screw (14) to allow for more upward travel. Once again be careful not to let the
objective lens touch the specimen slide.
Replacing the illuminator lamp:
1. Raise the specimen stage (6) to its highest position by rotating the course focus adjustment
knob (12).
2. Unscrew the black metal illuminator housing (8) and lift it straight up over the lightbulb.
3. Turn the lightbulb counterclockwise while gently pushing down.
4. Replace with a new 20W tungsten bulb.
5. Slide the illuminator housing back over the lightbulb and thread into place.

8
Research Microscope – Model #4060
Figure 3
1Eyepiece 12 Longitudal Specimen Mover Handwheel
2 Eyepiece Diopter 13 Power Switch
3Eyepiece Housing 14 Illuminator
4 Locking Screw 15 Condenser Adjustment Handwheel
5 Stand Column 16 Iris Diaphragm
6 Specimen Holder 17 Condenser
7 Focuser Lock 18 Specimen Stage
8 Coarse Focus Handwheel 19 Specimen Holder Clamp Lever
9 Fine Focus Handwheel 20 Objective
10 Transverse Specimen Mover Handwheel 21 Objective Changer
11 Brightness Control Wheel
Standard Accessories
Your Celestron microscope (#4060) comes complete with the following standard accessories:
•Two 10x Eyepieces •One 100x Objective lens
•Two 15x Eyepieces •Three Color Filters (Red, Blue ,Green)
•One 4x Objective lens •Plastic Dust Cover
•One 10x Objective lens •Cedar Wood Oil
•One 40x Objective lens
115
1
2
3
4
5
6
8
9
10
11
121
3
14
1
5
1
6
17
18
2
0
21
7
19

9
Item #4060 Specifications:
Optical Head
Interpupillary distance 45ºinclined Binocular Head; 360º Rotatable
Adjustable from 55-75mm
Illuminator Built-in, electric illuminator; Halogen bulb
6v/20w
Stage
Size
Working Range
Built-in, Mechanical
123mm x 153mm
70mm x 40mm
Condenser Abbe N.A. 1.25 condenser, and iris diaphragm
Power Supply 110v
Nosepiece Quadruple nosepiece
Objectives Achromatic objectives
Magnification Table
Use the following table to determine the magnification of the different eyepiece/objective lens
combination of your microscope.
Objective Lens
4x 10x 40x 100x
10x 40x 100x 400x 1000x
Eyepiece
15x 60x 150x 600x 1500x
Assembling Your Microscope
Before you can view through your Celestron microscope, the eyepiece housing, eyepieces and
objective lenses must first be attached. To attach the eyepiece housing:
1. Remove the microscope body from its packaging by lifting it by the stand column (5).
2. Unthread the locking screw (4) located on the side of the microscope body just above the
objective lens changer (21).
3. Place the round angled end of the eyepiece housing (3) inside the circular opening at the top
of the microscope body. The round eyepiece housing adapter is slightly angled and should
slide under the two metal tabs on the inside of the microscope body opening.
4. Secure the eyepiece housing by tightening the locking screw (4).
Installing the Binocular Eyepieces
1. Remove the two 10x eyepieces from their individual containers.
2. Slide the narrow end of the eyepiece barrel into each of the eyepiece holders on top of the
eyepiece housing.
Installing the Objective Lenses:
4. Remove the four objective lenses from their individual containers. Unscrew the container lids
from the threaded portion of the objective lenses.
5. Thread the end of the 4x objective lens into one of the holes on the objective changer (21). It
may be necessary to lower the specimen stage (18) by turning the coarse focus knob (8).
6. Now rotate the objective changer to the next opening and thread each of the remaining
objective lenses in order of power (10x, 40x, 100x) into the remaining holes.
