Celestron MicroDirect Mounting instructions

PC SOFTWARE MANUAL
MODEL #44316

2 | ENGLISH
1. COMPUTER SOFTWARE- INSTALL
Although the MicroDirect® 1080p HD microscope is designed to stream video directly to a monitor or projector,
you have the option to run the microscope on a Windows based computer with the included CD/DVD ROM disk. If
you do not have a CD/DVD ROM drive, the software can be downloaded from our website www.celestron.com.
Note: The software is compatible with Windows systems XP/7/8/10 only. The software is not compatible with MAC
operating systems.
1. CD ROM Install
+ Insert the driver CD into CD-ROM Drive and this will automatically display the following interface:
+ SELECT the Install Software button
+ The installation wizard will guide you through the whole process.
2. COMPUTER SOFTWARE- OPENING
1. Connect your MicroDirect® 1080p HD microscope to your PC using the included USB cable.
2. Open the Portable Capture HD software by clicking the desktop icon.

ENGLISH | 3
NOTE: If your MicroDirect® 1080p HD microscope becomes disconnected from your PC the following message box will appear:
3. COMPUTER SOFTWARE- DETAILS
A. CAPTURE STILL IMAGE
There are 2 ways to capture a photograph with the Portable Capture HD software:
1. Select ‘Photo’ shortcut icon in the main menu bar.
2. Select ‘Capture/Photo’ from the drop down menu.

4 | ENGLISH
B. CAPTURE VIDEO
There are 2 ways to capture video with the Portable Capture HD software:
1. Select ‘Video’ shortcut icon in the main menu bar.
2. Select ‘Video’ from the drop down menu.
C. TIME LAPSE
1. Select ‘Timer’ shortcut icon and then set your time lapse information.
a. Choose between Photo or Video.
b. StartTime:
i. Set the start time- YEAR/MONTH/DAY/SPECIFIC TIME.
c. Interval (sec):
i. Select the interval between each photo or video (in seconds) to be taken.
d. Video time (sec):
i. If you have chosen video time- enter the length of the video clip
(in seconds) you want to be taken at each interval.
e. Total number:
i. Set the total number of images to be taken.
f. Once you are happy with your settings, select the ‘Start’ button and the time
lapse will begin.
g. Select ‘Stop’ to end the time lapse.
NOTE: Intervals can be from 1-999 for interval and total number of images.
This means with still images a maximum time lapse can cover just over
277 hours or 11.5 days. (999 seconds between image for 999 times).

ENGLISH | 5
+
Make sure the X,Y Guide is ON (Options/XY Guide).
+
Place the included Calibration ruler on the stage under the
microscope lens and focus.
+
Take a still image making sure the X,Y Guide and the lines
on the calibration ruler are parallel.
+
Double-click on the image to enter into measurement
interface window.
A. CALIBRATION
4. CALIBRATION AND MEASUREMENT
+
A dimension line will appear and a dimension will be displayed
above the line and a dialogue box will appear.
+
Enter the “known” distance that you measured, based on the
calibration ruler.
+
The software will automatically calibrate the magnification rate.
+
Click ‘OK’ and the adjusted magnification rate will show in the
upper right corner.
NOTE: Save this magnification rate, so that you may use it for
future settings.
+
Now you can take measurements on the saved image.
+
Select the Calibration icon and using your cursor,
click on a start line on the calibration ruler, hold the mouse
button down and drag a dimension line across to the next
black line on the calibration ruler.
NOTE: The idea here is to measure a “known” distance on the
calibration ruler. For example 1mm or .5 mm.

6 | ENGLISH
B. MEASURING TOOLS
+Select the Measurement icon
NOTE: This is a good time to verify your calibration. Using the ANY
ANGLE TOOL, take a measurement of the same “known”
dimension you used in the Calibration step. If the measurement
is the same or very close, the calibration was successful.
C. MEASUREMENT CHOICES
1. Any Angle Line Measurement
+Click from one point and drag to the next point, and then release the click.
2. Continuous Line Measurement
+The Continuous Line measurement allows you to measure any continuous desired length, not just a straight line.
Simply click and drag from one point to other desired point, and then release mouse button.
3. Radius Circle Measurement
+Click and drag a line out to the desired radius and release the mouse button.
+The radius, circumference and area of the circle will show up accordingly.
4. Diameter Circle Measurement
+Click and drag a line out to the desired diameter and release the mouse button.
+The diameter, circumference and area of the circle will show up accordingly.
5. Three Point Angle Measurement
+Cllick any three points in an angle and the value of the angle will be displayed.
D. SET THE CALIBRATION MAGNIFICATION
+So far the calibration and measurement features we have discussed involve the measurements on ONE image (your saved image)
and the magnification rate was determined by the computer when calibrating.
+The MicroDirect®Portable Capture HD software allows you to “lock in” a magnification rate, which allows you to take multiple pictures
and then make measurements on them based on this “locked in” rate.
NOTE: Once the calibration is completed, you cannot change the physical position or focus range of your microscope, or you will
change the actual magnification and your measurements will not be correct.
+Click > Set magnification > Set capture magnification.
Now any pictures you take from this point forward will use the
same magnification rate for your measuring. Remember, you cannot
change the position of the microscope or focus point or the
magnification will be wrong and you will have to reset it.

ENGLISH | 7
HD Portable Capture includes functionality to mark, draw on, or and add notes to saved images. This can be handy for
quick note taking and pointing out features on your specimen image.
+
To use this feature, click the Draw icon in the Image Preview window.
+
The complete choices in the Draw dropdown menu are:
MAIN
1. Line: Draws a straight line on the image.
2. Arrow: Draws a line with an arrow on the image.
3. Freehand: Allows user to draw freehand. Good for quick, handwritten notes.
4. Rectangle: Draws a box. Good for calling out features on the image or framing text.
SETTINGS
1. Line Properties: Allows for setting
the line type, size and color.
+
To type notes on the image, select the Type icon.
+
In the dropdown menu, you can choose the font type, size and color.
A. MARKING
5. NOTE TAKING AND MARKING THE IMAGE
B. ADD TEXT

8 | ENGLISH
A. MAIN WINDOW ICONS
Photo: Take a still image
Video: Start / Stop record video
Timer: Time Lapse feature
Full Screen: Streaming image- full size
(Press ESC or double-click to exit)
B. MAIN MENU
1. File
Photos Directory: Set the directory to store photos taken
Videos Directory: Set the directory to store video taken
2. Options
Resolution: Change preview size
Date/Time: Set to display system date/time on preview window
Language: Choose different OSD language
Crossing: Display cross on preview window
Full-screen mode: Enter into full screen. Click ESC or double click to exit
3. Capture
Photo: Take a photo
Video: Record a video clip
6. SOFTWARE INTERFACE INSTRUCTIONS

ENGLISH | 9
7. CARE AND MAINTENANCE
Your Celestron MicroDirect® 1080p HD microscope is a precision optical instrument and should be treated with care
at all times. Follow these suggestions and your microscope will need very little maintenance throughout its lifetime.
+Store your microscope in a clean, dry place.
+Never use your microscope where operation of such
devices is restricted. Improper use creates the risk of
serious accident.
+Only use your microscope within the 23° to 120°F (-5°
to 50° C) temperature range. Try to limit sudden
temperature changes as this may create moisture in
the microscope housing.
+Do not try to access the internal components of your
microscope or attempt to modify it in any way. Only
authorized technicians should perform maintenance
or repairs.
+Keep your microscope away from water and other
liquids. Never use it in rain or snow. Moisture creates
the danger of fire and electric shock.
+If the exterior of your microscope needs cleaning, wipe
it with a moist cloth.
8. WARRANTY
Your Celestron MicroDirect® 1080p HD microscope has a two year limited warranty. Please visit the Celestron website for
detailed information on all Celestron microscopes: www.celestron.com.
C. MEASUREMENT INTERFACE INSTRUCTIONS
Save as
Copy to
clipboard
Copy file
Previous
Next
Undo
Redo
Draw
Text note
Measurement
Calibration

©2016 Celestron • All rights reserved. • www.celestron.com
2835 Columbia Street • Torrance, CA 90503 U.S.A.
Telephone: [phone] • Printed in China 2016
