CENTRAL 58967 Assembly instructions
Visit our website at: http://www.harborfreight.com
Owner’s Manual & Safety Instructions
Save This Manual Keep this manual for the safety warnings and precautions, assembly,
operating, inspection, maintenance and cleaning procedures. Write the product’s serial number in the
back of the manual (or month and year of purchase if product has no number). Keep this manual and the
receipt in a safe and dry place for future reference. 22h
When unpacking, make sure that the product is intact
and undamaged. If any parts are missing or broken,
please call 1-888-866-5797 as soon as possible.
Copyright©2018 by Harbor Freight Tools®. All rights reserved.
No portion of this manual or any artwork contained herein may be reproduced in
any shape or form without the express written consent of Harbor Freight Tools.
Diagrams within this manual may not be drawn proportionally. Due to continuing
improvements, actual product may differ slightly from the product described herein.
Tools required for assembly and service may not be included.
Read this material before using this product.
Failure to do so can result in serious injury.
SAVE THIS MANUAL.
Page 2 For technical questions, please call 1-888-866-5797. Item 58967
SAFETY OPERATION MAINTENANCESETUP
Table of Contents
Safety ......................................................... 2
Specifications ............................................. 6
Setup .......................................................... 6
Operation.................................................... 9
Maintenance.............................................. 11
Parts List and Diagram.............................. 14
Warranty .................................................... 16
WARNING SYMBOLS AND DEFINITIONS
This is the safety alert symbol. It is used to alert you to potential
personal injury hazards. Obey all safety messages that
follow this symbol to avoid possible injury or death.
Indicates a hazardous situation which, if not avoided,
will result in death or serious injury.
Indicates a hazardous situation which, if not avoided,
could result in death or serious injury.
Indicates a hazardous situation which, if not avoided,
could result in minor or moderate injury.
Addresses practices not related to personal injury.
IMPORTANT SAFETY INFORMATION
General Tool Safety Warnings
Read all safety warnings and instructions.
Failure to follow the warnings and instructions may result in electric shock, fire and/or serious injury.
Save all warnings and instructions for future reference.
1. KEEP GUARDS IN PLACE and in working order.
2. REMOVE ADJUSTING KEYS AND
WRENCHES. Form habit of checking to
see that keys and adjusting wrenches are
removed from tool before turning it on.
3. KEEP WORK AREA CLEAN.
Cluttered areas and benches invite accidents.
4. DON’T USE IN DANGEROUS ENVIRONMENT.
Don’t use power tools in damp or wet locations,
or expose them to rain. Keep work area well lighted.
5. KEEP CHILDREN AWAY. All visitors should
be kept safe distance from work area.
6. MAKE WORKSHOP KID PROOF with padlocks,
master switches, or by removing starter keys.
7. DON’T FORCE TOOL. It will do the job better
and safer at the rate for which it was designed.
Page 3For technical questions, please call 1-888-866-5797.Item 58967
SAFETYOPERATIONMAINTENANCE SETUP
8. USE RIGHT TOOL. Don’t force tool or attachment
to do a job for which it was not designed.
Table A: RECOMMENDED MINIMUM WIRE GAUGE
FOR EXTENSION CORDS
(120 VOLT)
NAMEPLATE
AMPERES
(at full load)
EXTENSION CORD
LENGTH
25′ 50′ 100′ 150′
0 – 6 18 16 16 14
6.1 – 10 18 16 14 12
10.1 – 12 16 16 14 12
12.1 – 16 14 12 Do not use.
9. USE PROPER EXTENSION CORD. Make sure your
extension cord is in good condition. When using
an extension cord, be sure to use one heavy
enough to carry the current your product will draw.
An undersized cord will cause a drop in line voltage
resulting in loss of power and overheating.
Table A shows the correct size to use depending
on cord length and nameplate ampere rating.
If in doubt, use the next heavier gauge.
The smaller the gauge number, the heavier the cord.
10. WEAR PROPER APPAREL. Do not wear
loose clothing, gloves, neckties, rings, bracelets,
or other jewelry which may get caught in moving
parts. Nonslip footwear is recommended.
Wear protective hair covering to contain long hair.
11. ALWAYS USE SAFETY GLASSES. Also use
face or dust mask if cutting operation is dusty.
Everyday eyeglasses only have impact resistant
lenses, they are NOT safety glasses.
12. SECURE WORK. Use clamps or a vise to
hold work when practical. It’s safer than using your
hand and it frees both hands to operate tool.
13. DON’T OVERREACH.
Keep proper footing and balance at all times.
14. MAINTAIN TOOLS WITH CARE. Keep
tools sharp and clean for best and safest
performance. Follow instructions for
lubricating and changing accessories.
15. DISCONNECT TOOLS before servicing;
when changing accessories, such as
blades, bits, cutters, and the like.
16. REDUCE THE RISK OF UNINTENTIONAL
STARTING. Make sure switch is in
off position before plugging in.
17. USE RECOMMENDED ACCESSORIES.
Consult the owner’s manual for recommended
accessories. The use of improper accessories
may cause risk of injury to persons.
18. NEVER STAND ON TOOL.
Serious injury could occur if the tool is tipped or
if the cutting tool is unintentionally contacted.
19. CHECK DAMAGED PARTS. Before further use
of the tool, a guard or other part that is damaged
should be carefully checked to determine that
it will operate properly and perform its intended
function – check for alignment of moving parts,
binding of moving parts, breakage of parts,
mounting, and any other conditions that may
affect its operation. A guard or other part that is
damaged should be properly repaired or replaced.
20. DIRECTION OF FEED.
Feed work into a blade or cutter against the
direction of rotation of the blade or cutter only.
21. NEVER LEAVE TOOL RUNNING UNATTENDED.
TURN POWER OFF. Don’t leave tool
until it comes to a complete stop.
Page 4 For technical questions, please call 1-888-866-5797. Item 58967
SAFETY OPERATION MAINTENANCESETUP
Grounding Instructions
TO PREVENT ELECTRIC SHOCK AND DEATH FROM INCORRECT
GROUNDING WIRE CONNECTION READ AND FOLLOW THESE INSTRUCTIONS:
110-120 VAC Grounded Tools: Tools with Three Prong Plugs
1. In the event of a malfunction or breakdown,
grounding provides a path of least resistance for
electric current to reduce the risk of electric shock.
This tool is equipped with an electric cord having an
equipment-grounding conductor and a grounding
plug. The plug must be plugged into a matching
outlet that is properly installed and grounded in
accordance with all local codes and ordinances.
2. Do not modify the plug provided – if it will
not fit the outlet, have the proper outlet
installed by a qualified electrician.
3. Improper connection of the equipment-grounding
conductor can result in a risk of electric shock.
The conductor with insulation having an outer
surface that is green with or without yellow
stripes is the equipment-grounding conductor.
If repair or replacement of the electric cord or
plug is necessary, do not connect the equipment-
grounding conductor to a live terminal.
4. Check with a qualified electrician or service
personnel if the grounding instructions are
not completely understood, or if in doubt as
to whether the tool is properly grounded.
5. Use only 3-wire extension cords that
have 3-prong grounding plugs and 3-pole
receptacles that accept the tool’s plug.
6. Repair or replace damaged or
worn cord immediately.
Grounding
Pin
125 VAC 3-Prong Plug and Outlet
(for up to 125 VAC and up to 15 A)
7. This tool is intended for use on a circuit that has
an outlet that looks like the one illustrated above in
125 VAC 3-Prong Plug and Outlet. The tool has
a grounding plug that looks like the plug illustrated
above in 125 VAC 3-Prong Plug and Outlet.
8. The outlet must be properly installed and grounded
in accordance with all codes and ordinances.
9. Do not use an adapter to connect
this tool to a different outlet.
Grinder Tool Safety Warnings
For Your Own Safety Read Instruction
Manual Before Operating Tool Grinder
1. Wear eye protection.
2. Use grinding wheel suitable for speed of grinder.
3. Replace cracked wheel immediately.
4. Always use guards and eye shields.
5. Do not overtighten wheel nut.
6. Use only flanges furnished with the grinder.
7. Adjust distance between wheel and work rest
to maintain 0.125 inch or less separation as the
diameter of the wheel decreases with use.
8. Frequently clean grinding dust from beneath grinder.
9. Wear a full face shield over ANSI-approved
safety goggles during use.
10. Do not grind with side of wheel unless wheel is
specifically designed for that type of grinding.
11. DO NOT OPERATE WITH ANY GUARD
DISABLED, DAMAGED, OR REMOVED. Moving
guards must move freely and close instantly.
12. The use of accessories or attachments not
recommended by the manufacturer may
result in a risk of injury to persons.
13. When servicing use only identical replacement parts.
14. Do not depress the spindle lock (if applicable)
when starting or during operation.
Page 5For technical questions, please call 1-888-866-5797.Item 58967
SAFETYOPERATIONMAINTENANCE SETUP
15. Only use safety equipment that has been approved
by an appropriate standards agency. Unapproved
safety equipment may not provide adequate
protection. Eye protection must be ANSI-approved
and breathing protection must be NIOSH-approved
for the specific hazards in the work area.
16. Stay alert, watch what you are doing and use
common sense when operating a power tool.
Do not use a power tool while you are tired or
under the influence of drugs, alcohol or medication.
A moment of inattention while operating power
tools may result in serious personal injury.
17. Industrial applications must follow OSHA guidelines.
18. Maintain labels and nameplates on the tool.
These carry important safety information.
If unreadable or missing, contact
Harbor Freight Tools for a replacement.
19. Avoid unintentional starting.
Prepare to begin work before turning on the tool.
20. People with pacemakers should consult their
physician(s) before use. Electromagnetic fields in
close proximity to heart pacemaker could cause
pacemaker interference or pacemaker failure.
21. The warnings, precautions, and instructions
discussed in this instruction manual cannot cover all
possible conditions and situations that may occur.
It must be understood by the operator that
common sense and caution are factors
which cannot be built into this product,
but must be supplied by the operator.
Vibration Safety
This tool vibrates during use. Repeated or
long-term exposure to vibration may cause
temporary or permanent physical injury,
particularly to the hands, arms and shoulders.
To reduce the risk of vibration-related injury:
1. Anyone using vibrating tools regularly or for an
extended period should first be examined by a
doctor and then have regular medical check-ups
to ensure medical problems are not being caused
or worsened from use. Pregnant women or
people who have impaired blood circulation to
the hand, past hand injuries, nervous system
disorders, diabetes, or Raynaud’s Disease should
not use this tool. If you feel any medical or
physical symptoms related to vibration (such as
tingling, numbness, and white or blue fingers),
seek medical advice as soon as possible.
2. Do not smoke during use. Nicotine reduces
the blood supply to the hands and fingers,
increasing the risk of vibration-related injury.
3. Use tools with the lowest vibration when there
is a choice between different processes.
4. Include vibration-free periods each day of work.
5. Grip workpiece as lightly as possible (while still
keeping safe control of it). Let the tool do the work.
6. To reduce vibration, maintain the tool as
explained in this manual. If any abnormal
vibration occurs, stop use immediately.
SAVE THESE INSTRUCTIONS.
Page 6 For technical questions, please call 1-888-866-5797. Item 58967
SAFETY OPERATION MAINTENANCESETUP
Specifications
Electrical Rating 120VAC / 60Hz / 1.3A
Motor No Load Speed n0: 11000/min-1
Grinding Wheels 1- 3 x 3/4″ Grinding Stone
1- 3 x 3/4″ Fiber Wheel
Arbor Size 10 mm
Flex Shaft 31″
Flex Shaft Collet 1/8″ diameter
Flex Shaft Bit 1/8″ mounted stone
Features Variable Speed Dial
Flex shaft wrench set
Note: Performance of this tool may vary depending on variations in local line
voltage. Extension cord usage may also affect tool performance.
Setup - Before Use:
Read the ENTIRE IMPORTANT SAFETY INFORMATION section at the beginning of this
manual including all text under subheadings therein before set up or use of this product.
TO PREVENT SERIOUS INJURY FROM ACCIDENTAL OPERATION:
Turn the Power Switch of the tool off and unplug the tool from its electrical outlet
before performing any procedure in this section.
Note: For additional information regarding the parts listed in the following pages,
refer to the Assembly Diagram near the end of this manual.
Assembly/Mounting
The Two mounting holes in the Base can be
used to attach this Grinder to a stable workbench
using appropriate hardware (sold separately).
1. Install the Work Rest Support (38) to the right inner
Wheel Guard (17) with the Knob Tensioner (59).
2. Adjust the Work Rest Support (38) to within
1/16″ of the Grinding Wheel. To adjust
this distance, loosen Knob Tensioner (59)
and move Work Rest Support (38).
Wheel Guard (17)
Work Rest
Support (38)
Knob
Tensioner (59)
Figure A:
Page 7For technical questions, please call 1-888-866-5797.Item 58967
SAFETYOPERATIONMAINTENANCE SETUP
3. Assemble the Safety Shields (54) to the Spark
Guards (18) with the Screws (55) and Nuts (56).
4. Assemble the Spark Guards (18) to the Wheel
Guards (17, 28) with the Screws (58) and Nuts (57).
Leave the Screws (58) and Nuts (57) slightly loose.
5. Adjust each Spark Guard (18) to within 1/16″
of the Grinding and Polishing Wheel (2, 11),
then tighten the Screws (58) and Nuts (57).
Safety Shield (54)
Spark
Guard (18)
Screw (58)
Wheel Guard
(17, 28)
Nut (57)
Screw (55)
Nut (56)
Figure B:
6. Adjust the Safety Shields (54) so the Wheels
(2, 11) are visible through the Safety Shields
(54) to protect the operator′s eyes.
Page 8 For technical questions, please call 1-888-866-5797. Item 58967
SAFETY OPERATION MAINTENANCESETUP
Functions
Mounted
Stone Bit (48)
Flex Shaft (32)
Collet (46)
Collet Nut (47) Wrench (50)
Safety
Shield (54)
Speed Control
Knob (31)
Polishing
Wheel (2)
Grinding
Wheel (11)
Power
Switch (52)
Page 9For technical questions, please call 1-888-866-5797.Item 58967
SAFETYOPERATIONMAINTENANCE SETUP
Operating Instructions
Read the ENTIRE IMPORTANT SAFETY INFORMATION section at the beginning of this
manual including all text under subheadings therein before set up or use of this product.
Tool Set Up
TO PREVENT SERIOUS INJURY FROM ACCIDENTAL OPERATION:
Turn the Power Switch of the tool off and unplug the tool from its electrical outlet
before performing any procedure in this section.
TO PREVENT SERIOUS INJURY:
DO NOT OPERATE WITH ANY GUARD DISABLED, DAMAGED, OR REMOVED.
Moving guards must move freely and close instantly.
Installing a Grinding Wheel
1. The Grinding Wheel MUST be:
• rated to at least 11,000 RPM.
• no larger than 3″ (76.2 mm) in diameter.
• fitted with a 10mm round arbor hole.
• 3/4″ thick or less.
• suitable for edge grinding, not surface grinding.
• dry, clean. and undamaged after inspection.
2. Disconnect power. Remove Wheel Cover (14, 49).
3. Hold the Wheel to prevent the Spindle from turning
while removing the Nut (1, 12) and Shaft Nut (13 - if
applicable).
Note: The Nut (1) on the Polishing Wheel
(2) has reverse threads and must be
turned Clockwise to be removed.
4. Remove the Wheel (2, 11) and Flanges (3).
Inner
Flange (3)
Outer
Flange (3)
Wheel (2, 11)
Nut
(1, 12)
Shaft Nut (13)
(Grinding
Wheel Only)
Bushing (4)
Figure C:
5. Closely inspect the Wheel (2, 11) for any
defects or damage before mounting.
6. Mount the new Wheel (2, 11) with Flanges (3) onto
the Spindle. For Wheels (2, 11) with paper gaskets
(blotters) or metal gaskets: Slip the Wheel (2, 11)
onto the Spindle with the gasket first. The gasket
should be centered on the Wheel (2, 11) and the
Wheel (2, 11) and gasket should rest flat against the
Inner Flange (3).
WARNING: To prevent serious injury, gaskets
must be used for all Grinding Wheels they are
provided with. Gaskets help prevent grinding
Wheel damage and Wheel slippage,
causes of Wheel failure.
7. Replace the Nut (1, 12) and Shaft Nut (13 - if
applicable). Wrench tighten only enough so that the
Wheel (2, 11) is securely held on the Spindle.
WARNING: To prevent serious injury,
do not overtighten Flange. Overtightening can
damage the Wheel, causing Wheel failure.
8. Reassemble the Wheel Cover (14, 49).
Workpiece and Work Area Set Up
1. Designate a work area that is clean and well-lit.
The work area must not allow access by children
or pets to prevent distraction and injury.
2. Route the power cord along a safe route to reach
the work area without creating a tripping hazard or
exposing the power cord to possible damage. The
power cord must reach the work area with enough
extra length to allow free movement while working.
3. There must not be objects, such as utility lines,
nearby that will present a hazard while working.
Page 10 For technical questions, please call 1-888-866-5797. Item 58967
SAFETY OPERATION MAINTENANCESETUP
General Operating Instructions
1. Make sure that the Power Switch
is in the off-position, then plug in the tool.
Note: If workspace requires use of an extension
cord, use extension cord of appropriate rating.
2. Stand to the side of the Grinder, turn Power Switch
to ON position, adjust tool speed to highest RPM′s,
and allow it to run for 1 minute. The Grinding
Wheel should rotate smoothly; if any problems are
noted, stop the Grinder and replace the Wheel.
3. Adjust Speed Control Knob to desired speed.
4. Allow the tool speed to stabilize
before touching the Wheel.
5. Bring the workpiece into the Wheel gently,
without jarring. If the tool bogs down, use
lighter pressure, or increase Wheel speed.
6. To create a smoother surface,
keep the workpiece moving over the Wheel.
7. When grinding high speed steels such as drill
and tool bits, avoid high temperature buildup
as this can affect the temper of the steel.
8. For small workpieces such as drill bits or chisels,
avoid applying pressure to the Wheel at a high
angle that could cause the workpiece to become
lodged between the tool rest and the Wheel.
WARNING! Adjust distance between Wheel and
work rest to maintain 0.125 inch or less separation
as the diameter of the Wheel decreases with use.
9. To turn OFF, turn Power Switch to OFF position.
10. To prevent accidents, turn off the tool and unplug
the tool from its electrical outlet after use. Do not
leave the Bench Grinder running unattended. Clean,
then store the tool indoors out of children’s reach.
Speed Control
Knob (31)
Power
Switch (52)
Figure E:
WARNING: Do not use worn down grind wheels.
Replace grinding wheel if diameter is less than 2-1/8″.
Grinding with the Flex Shaft
1. Disconnect power to the Grinder.
2. Secure the Flex Shaft (32) to the Wheel Cover (14).
Align and insert the shaft. It can only go in one way.
3. Tighten the Shaft Connector Nut (37) over
the threads on the Wheel Cover.
Wheel Cover (14)
Shaft
Connector
Nut (37)
Flex Shaft (32)
Figure F:
4. Loosen the Collet Nut (47) with the Wrench (50).
5. Insert the Mounted Stone Bit (48) through the
Collet Nut (47), into the Collet (46), then tighten
the Collet Nut (47) with the Wrench (50).
Mounted Stone Bit (48)
Flex Shaft (32)
Collet (46)
Collet Nut (47) Wrench (50)
Figure G:
6. Grasp the Flex Shaft handle with one hand,
and turn the Grinder ON with the other hand.
WARNING! TO PREVENT SERIOUS INJURY: Wear
ANSI-approved safety glasses when grinding.
7. When finished, turn the Grinder OFF and wait for
it to stop before setting down the Flex Shaft.
8. Disconnect the Flex Shaft (32) from the
Wheel Cover (14) when not in use.
Page 11For technical questions, please call 1-888-866-5797.Item 58967
SAFETYOPERATIONMAINTENANCE SETUP
Maintenance and Servicing
Procedures not specifically explained in this manual must
be performed only by a qualified technician.
TO PREVENT SERIOUS INJURY FROM ACCIDENTAL OPERATION:
Turn the Power Switch of the tool off and unplug the tool from its electrical outlet
before performing any procedure in this section.
TO PREVENT SERIOUS INJURY FROM TOOL FAILURE:
Do not use damaged equipment. If abnormal noise or vibration
occurs, have the problem corrected before further use.
Cleaning, Maintenance, and Lubrication
1. BEFORE EACH USE, inspect the general
condition of the tool. Check for:
• loose hardware,
• misalignment or binding of moving parts,
• cracked or broken parts,
• damaged electrical wiring, and
• any other condition that may
affect its safe operation.
2. AFTER USE, wipe external surfaces
of the tool with clean cloth.
3. Periodically, wear ANSI-approved
safety goggles and NIOSH-approved
breathing protection and blow dust and grit out
of the motor vents using dry compressed air.
4. WARNING! If the supply cord of this
power tool is damaged, it must be replaced
only by a qualified service technician.
Dressing the Grinding Wheel
Note: New wheels frequently are not true and
during operation will often become grooved, glazed
(build up), out of round, or misshapen. You will
need a grinding wheel dresser for this operation.
Dressers are available from Harbor Freight Tools.
1. Stand to the side of the wheel for this operation.
2. If the wheel is new let it run for a minute with no
load. If the wheel runs straight and true, you will
not need to dress it prior to operation. If it does
not, proceed with the following instructions.
3. If you are using a “pistol grip” dresser, grip the
handle firmly with one hand and the arm of
the dresser with the other. Allow the wheel to
reach full speed. Use the tool rest to support
your hand and the dresser, and evenly apply
the dresser to all surfaces of the wheel. The
wheel can be dressed in a few minutes.
4. If you are using an “inline” dresser, hold the handle
firmly, put the dresser on the tool rest so that its
wheels can move freely (i.e., the exposed part of the
wheel should be facing up). Let the wheel reach full
speed and apply the dresser evenly to all surfaces.
Accessory Storage and Handling
1. Handle accessories carefully to prevent
dropping or bumping. Do not use wheels
that have been dropped or bumped.
2. Store accessories in shelves, racks, boxes, or
drawers. Keep storage area dry and above
freezing. Any grinding wheels exposed to humidity
or freezing temperatures must not be used.
Page 12 For technical questions, please call 1-888-866-5797. Item 58967
SAFETY OPERATION MAINTENANCESETUP
Troubleshooting
Problem Possible Causes Likely Solutions
Tool will not start. 1. Cord not connected.
2. No power at outlet.
3. Tool’s thermal reset breaker
tripped (if equipped).
4. Internal damage or wear. (Carbon
brushes or switch, for example.)
1. Check that cord is plugged in.
2. Check power at outlet. If outlet is unpowered,
turn off tool and check circuit breaker.
If breaker is tripped, make sure circuit is right
capacity for tool and circuit has no other loads.
3. Turn off tool and allow to cool.
Press reset button on tool.
4. Have technician service tool.
Tool operates
slowly.
Extension cord too long or
wire size too small.
Eliminate use of extension cord. If an extension cord
is needed, use one with the proper diameter for its
length and load. See Table A on page 3.
Performance
decreases
over time.
1. Accessory dull or damaged.
2. Carbon brushes worn or damaged.
1. Keep cutting accessories sharp.
Replace as needed.
2. Have qualified technician replace brushes.
Excessive noise
or rattling.
Internal damage or wear. (Carbon
brushes or bearings, for example.)
Have technician service tool.
Overheating. 1. Forcing machine to work too fast.
2. Accessory dull or damaged.
3. Blocked motor housing vents.
4. Motor being strained by long or
small diameter extension cord.
1. Allow machine to work at its own rate.
2. Keep cutting accessories sharp.
Replace as needed.
3. Wear ANSI-approved safety goggles and
NIOSH-approved dust mask/respirator while
blowing dust out of motor using compressed air.
4. Eliminate use of extension cord.
If an extension cord is needed, use one with
the proper diameter for its length and load.
See Table A on page 3.
Follow all safety precautions whenever diagnosing or servicing the tool.
Disconnect power supply before service.
Page 13For technical questions, please call 1-888-866-5797.Item 58967
SAFETYOPERATIONMAINTENANCE SETUP
PLEASE READ THE FOLLOWING CAREFULLY
THE MANUFACTURER AND/OR DISTRIBUTOR HAS PROVIDED THE PARTS LIST AND ASSEMBLY DIAGRAM
IN THIS MANUAL AS A REFERENCE TOOL ONLY. NEITHER THE MANUFACTURER OR DISTRIBUTOR
MAKES ANY REPRESENTATION OR WARRANTY OF ANY KIND TO THE BUYER THAT HE OR SHE IS
QUALIFIED TO MAKE ANY REPAIRS TO THE PRODUCT, OR THAT HE OR SHE IS QUALIFIED TO REPLACE
ANY PARTS OF THE PRODUCT. IN FACT, THE MANUFACTURER AND/OR DISTRIBUTOR EXPRESSLY
STATES THAT ALL REPAIRS AND PARTS REPLACEMENTS SHOULD BE UNDERTAKEN BY CERTIFIED AND
LICENSED TECHNICIANS, AND NOT BY THE BUYER. THE BUYER ASSUMES ALL RISK AND LIABILITY
ARISING OUT OF HIS OR HER REPAIRS TO THE ORIGINAL PRODUCT OR REPLACEMENT PARTS
THERETO, OR ARISING OUT OF HIS OR HER INSTALLATION OF REPLACEMENT PARTS THERETO.
Page 14 For technical questions, please call 1-888-866-5797. Item 58967
SAFETY OPERATION MAINTENANCESETUP
Part Description Qty
1Reverse Threaded Nut 1
2 Polishing Wheel 1
3 Flange 4
4 Bushing 2
5 Bearing 1
6 Snap Ring 2
7 Rotor 1
8 Armature 1
9 Fan 1
10 Bearing 1
11 Grinding Wheel 1
12 Nut 1
13 Shaft Mounting Nut 1
14 Right Wheel Cover 1
15 Nut 6
16 Bolt 2
17 Right Wheel Guard 1
18 Spark Guard 2
19 Stator 1
20 Clamp 2
21 Wire Cover 2
22 Brush Holder 1
23 Wire Cover 2
24 Brush Screw 2
25 Brush Spring 2
26 Brush 2
27 Motor Housing 1
28 Left Wheel Guard 1
29 Circuit Board 1
30 Base Holder 1
Part Description Qty
31 Speed Control Knob 1
32 Flex Shaft 1
33 Adaptor 1
34 Cord 1
35 Spring 1
36 Plug 1
37 Shaft Connector Nut 1
38 Work Rest Support 1
39 Flex Shaft Hose 1
40 Spring 1
41 Chuck Cover 1
42 Bearing 1
43 Washer 1
44 Bearing 1
45 Spindle 1
46 Collet 1
47 Collet Nut 1
48 Mounted Stone Bit 1
49 Left Wheel Cover 1
50 Wrench 1
51 Base 1
52 Power Switch 1
53 Mounting Plate 1
54 Safety Shield 2
55 Screw 2
56 Nut 2
57 Nut 4
58 Screw 4
59 Knob Tensioner 1
60 Screw 2
Parts List and Diagram
Parts List
Record Product’s Serial Number Here:
Note: If product has no serial number, record month and year of purchase instead.
Note: Some parts are listed and shown for illustration purposes only, and are not available
individually as replacement parts. Specify UPC 193175452061 when ordering parts.
Page 15For technical questions, please call 1-888-866-5797.Item 58967
SAFETYOPERATIONMAINTENANCE SETUP
Assembly Diagram
50
51
49
34
52
29
S
P
E
E
D
O
F
F
O
N
54
1 2 7
3465 8 9 10
28
30
23
27
26
252420
21
2219
31
11 12 13
18
171614
15
38
53
44 41
47
48 45
46 43 42
40
36
37
35
33
32
39
55 56
59
58
57
60
