Century Fold 'n Go ElanTM Deluxe Bassinet 10747 User manual

English PM-1717AA 9/00
Do not use this product until
you read and understand
these instructions.
Instruction
Manual

DEDICATED TO QUALITY

If you should have any problems with this product, call
toll-free 1-800-837-4044 from anywhere in the U.S. or
Canada or fax at 1-610-286-4555.
Or write us at: Century Products
P.O. Box 100
Elverson, PA 19520-9974
Attention: Customer Service Department
Please have the following information available. See label
on bottom tubing of Playard/Crib.
Model Number:
Manufacture Date:
Date of Purchase:
Need Help?
✔Read and understand instruction manual before
assembling and using Fold’N Go®élan Deluxe Bassinet.
✔Do not use in any vehicle.
✔Always provide proper supervision for child’s safety.
✔Use with only one (1) child at a time.
✔Do not use bassinet as a car bed.
✔Do not use bassinet if infant can push up on hands and
knees or sit unassisted.
✔Do not carry bassinet with child in it.
✔Do not move or fold Playard/Crib with child in it.
✔Do not add padding or other objects inside Playard/Crib
which may permit child to climb out or cause a
suffocation hazard.
✔Do not use accessories other than those provided
by Century.
Bassinet:
Maximum Weight: 8.2 kg (18 lbs.)
Maximum Height: 63.5 cm (25 inches)
Activity: Discontinue use if child can push up on hands
and knees or sit unassisted.
Playard/Crib:
Maximum Weight: 14 kg (30 lbs.)
Maximum Height: 89 cm (35 inches)
Activity: Discontinue use if child can climb out of
Playard/Crib.
Page:
1 Important Information
2 Warnings
3 Assembly and Use
Playard/Crib
Bassinet
Canopy
7 Folding and Storing
Canopy
Bassinet
Playard/Crib
9 Maintenance
Cleaning
9 Replacement Parts
1
Safety First Checklist
Weight, Height and Activity Limits
Table of Contents
IMPORTANT INFORMATION
Read all instructions BEFORE assembly and USE of this product.
KEEP INSTRUCTIONS FOR FUTURE USE.
Store in pocket on bottom of floorboard.
This product can be used as a Playard,
Bassinet or Sleeping Crib.
This product is NOT intended
for commercial use.

2
WARNING Failure to follow these warnings and the
assembly instructions could result in serious injury or death.
WARNING Failure to follow these warnings and
instructions could result in serious injury or death.
•When child is awake: NEVER leave child unattended. Always keep child in view.
When child is sleeping: Always provide supervision necessary for the continued safety of child.
•Bassinet and Playard/Crib, including side rails, MUST be fully erected prior to use.
•Discontinue use of Playard/Crib when child reaches a height of 89 cm (35 inches), weighs more
than 14 kg (30 lbs.), or is able to climb out.
•Use product with only one child at a time.
•SUFFOCATION HAZARD - To help prevent suffocation from entrapment, use only the floorboard
provided by Century and always use attachment straps to secure floorboard to bottom of
Playard/Crib. NEVER use additional mattress or padding.
•Strings can cause strangulation. DO NOT place items with a string around a child’s neck
(such as hood strings, pacifier cords, etc.). DO NOT suspend strings over product or attach
strings to toys.
•DO NOT place product near a window where cords from blinds or drapes can strangle child.
•Keep product away from stoves, heaters, campfires, fireplaces and other hazards which can
burn or cause injury to child.
•DO NOT add padding or objects inside Playard/Crib which may permit child to climb out.
•DO NOT move or fold Playard/Crib with child in it.
•DO NOT use product in a motor vehicle. Serious injury or death could result from a sudden
stop or accident.
•DO NOT use a water mattress with this product.
•Before each usage, inspect product for damaged hardware, loose joints, missing parts or sharp
edges. DO NOT use product if any parts are missing or broken. Call Century for replacement
parts or instruction manual. DO NOT substitute parts.
•NEVER use plastic shipping bags or other plastic film as mattress covers not sold and intended
for that purpose. They can cause suffocation.
•If refinishing, use a non-toxic finish specified for children’s products.
•DO NOT use accessories other than those provided by Century.

1Pull travel bag up and remove
Playard/Crib.
2Stand Playard/Crib on legs and
wheels and unfasten Floorboard
Attachment Straps.
3Separate Playard/Crib legs to
approximately 60 cm (2 feet)
apart.
5Push down on center of
Playard/Crib floor until it is
flat and locks into position.
NOTE: Locking action is
automatic.
HINT: It may be necessary to
lift end of Playard/Crib to push
center down.
4Pull up on Top Rails until all
“click” and lock.
IMPORTANT: Floor loop
MUST remain raised at least
45.7 cm (18 inches) in order
for rails to lock.
NOTE: Test by pushing
down on each top rail
to be sure they are locked.
ASSEMBLY and USE
3
Playard/Crib
2 Feet
WARNING
All top rails MUST be straight and locked in
position or child may become entrapped and
suffocate.
Top Rail
Floorboard
Attachment
Straps

6Place floorboard in Playard/Crib
with padded side facing up.
NOTE: DO NOT install floorboard if using
bassinet. Go to bassinet assembly section.
7Secure ends of floorboard to
Playard/Crib:
• Pass Attachment Straps
through holes in
Playard/Crib floor.
• Secure straps to underside
of Playard/Crib floor.
1Lay bassinet on flat surface
and spread open.
2Rotate and extend four (4)
Hooks until they “click” in
place.
3If floorboard is installed in
Playard, remove floorboard.
4Fold Floorboard into “W”
shape and place in center
of bassinet.
Playard/Crib assembly is now complete
and ready to use.
4
ASSEMBLY and USE continued
WARNING
To prevent child from
suffocating, attachment
straps MUST be secured
to underside of
Playard/Crib.
Hook
Bassinet
Attachment
Strap
WARNING
Avoid serious injury or death:
• Use bassinet with infant who weighs less
than 8.2 kg (18 lbs.) and is less than
63.5 cm (25 inches) tall.
• DO NOT use without floorboard being
properly placed in bassinet.
• Discontinue use of bassinet if infant can
push up on hands and knees or sit
unassisted.
• DO NOT carry bassinet with infant in it.
• DO NOT use as a car bed.
•SUFFOCATION HAZARD: To help prevent
suffocation from entrapment, use only
floorboard provided by Century. NEVER
use additional mattress or padding.
Floorboard

To use bassinet with Playard/Crib:
Place bassinet in center of
Playard/Crib so that hooks
go over long rails.
Bassinet is now ready for use with
Playard/Crib.
5Insert one side of floorboard
under Pocket on side of
bassinet.
6Pull Pocket down over
floorboard to hold
floorboard in place.
Repeat steps 5 and 6 for
other side of floorboard.
7Push down on center of
floorboard to flatten.
Bassinet assembly is now complete.
•Bassinet can be used with or without Playard/Crib.
ASSEMBLY and USE continued
5
1Set bassinet on flat and stable surface that will keep
floorboard level so child will not roll into corner or side of
bassinet resulting in breathing difficulties.
2Keep at least 30.5 cm (12 inches) away from surface edges
and stay within reach of child. Child’s wiggling and rocking
may cause bassinet to move and possibly fall off surfaces.
WARNING
Prevent falls and suffocation:
• Use only on a surface that is flat, level and
stable.
• Keep bassinet away from surface edges.
Pocket
Pockets
To use bassinet without Playard/Crib:

4Pull end of Sleeve over rod and
release rod.
Repeat for other rod.
5Set canopy over Playard/Crib
and insert canopy tabs into
curved slots of Playard/Crib
corners.
6Secure canopy bottom around
Playard/Crib corners using
Attachment Strips.
ASSEMBLY and USE continued
6
1Lay canopy on flat surface.
2Unfold rods and insert fiber
glass ends into aluminum ends.
NOTE: There are three
(3) sections of each rod
that must be extended.
3Slide rod completely into
canopy fabric.
Repeat for other rod.
Canopy
WARNING
Avoid serious injury or death:
Temperature inside Playard/Crib with canopy
can be higher than outside:
• DO NOT cover mesh. Keep well ventilated.
• Keep out of direct sun.
• Remove child from Playard/Crib before
child becomes overheated.
Attachment
Strips
Canopy can only be used with Playard/Crib.
DO NOT use canopy when using bassinet. Sleeve

1Remove bassinet from
Playard/Crib.
FOLDING and STORING
7
2Remove floorboard from
bassinet.
3Press release buttons on each
hook and push hook into
larger tube.
4Rotate hooks to center of
bassinet.
5Fold bassinet.
6Place bassinet in pocket of
travel bag.
IMPORTANT: If continuing to use Playard/Crib,
be sure to properly secure floorboard in Playard/Crib.
Bassinet
1Unfasten attachment strips, pull canopy tabs out of
corners and lift canopy up and away from Playard/Crib.
2Remove rods from canopy.
3Pull rods apart and fold.
NOTE: Rods are NOT a play
toy! Keep out of reach of
children. Store in pocket of
travel bag.
4Fold canopy.
5Place canopy and rods
in pocket of travel bag.
Canopy

1To remove floorboard:
• Unfasten attachment straps.
• Remove floorboard and set
aside.
2To unlock and raise floor:
• Push down on center of
Playard/Crib floor.
• Lift Floor Handle and rotate
in direction of arrow
(counterclockwise).
• Pull up on Floor Handle to
raise floor.
Raise approximately
45.7 cm
(18 inches).
3To fold top rails:
• Pull up on top rail slightly.
• Squeeze Release Button
on bottom of top rail and
push rail down. (Release
buttons are identified by
printed arrows.)
Repeat for other sides.
NOTE:
• If rails are difficult to
unlock, raise center of
floor higher and
squeeze Release
Button again.
• If only one side of rail
folds, squeeze Release
Button again to fully
fold.
FOLDING and STORING continued
8
Playard/Crib 4Gather Playard/Crib frame together
while pulling up on Floor Loop.
5Wrap floorboard around
Playard/Crib frame with
padding facing in.
NOTE: Floorboard Handle MUST
be aligned with wheels as shown.
6Secure Attachment Straps:
• Bottom - Thread Attachment
Strap through Leg Loop then
through Floorboard Loop
and fold back onto itself.
• Middle and Top - Thread
Attachment Straps
through remaining
floorboard loops
and fold back onto
themselves.
7Position travel bag over
Playard/Crib so Handle comes
through Opening in side of bag.
Pull travel bag over Playard/Crib.
Pull Floor Loop through
opening on top of travel bag.
NOTE: To prevent rubbing,
make sure travel bag is
positioned above wheels.
Release
Button
Floor
Handle
Handle
Attachment
Straps
Floor Loop
Handle
Opening
Floor Loop
Leg Loop
Floorboard Loop

A. Travel Bag US $ 12.00 x _____ = $ ______
(CAN $ 19.00)
B. Padded Floorboard US $ 18.00 x _____ = $ ______
(CAN $ 28.00)
C. Instruction Manual FREE x _____ = FREE
REPLACEMENT PARTS
Parts List (Model 10-747) Price Quantity Total
NOTE: Prices subject to change. Total Parts $ ______
Playard/Crib, Bassinet, Canopy, Floorboard and
Travel Bag
Surface wash with mild detergent and water, air dry.
9
MAINTENANCE
Cleaning

Cardholder’s Name:
Card Number:
Card Exp. Date:
Check enclosed for $
SHIP TO:
Name:
Address:
City:
State: Zip:
Telephone No.:( )
Please make checks payable in US currency to CENTURY
PRODUCTS or charge to VISA, MASTERCARD or DISCOVER.
Orders outside USA Must use credit card.
Total Parts $
Sales Tax $
Shipping & Handling $
Outside Continental USA $
Total $
MAIL BOTH PAGES OF ORDER TO:
CENTURY PRODUCTS
P.O. BOX 100
ELVERSON, PA 19520-9974
ATTENTION: CUSTOMER SERVICE DEPARTMENT
or
FAX BOTH PAGES OF ORDER TO:
[phone]
REPLACEMENT PARTS ORDER FORM
We must have this information to process your order: see
label on bottom tubing of Playard/Crib.
Model No.:
Manufacture Date:
NOTE: If requested color is not available, a similar color
will be substituted.
PM-1717AA 9/00
Shipping & Handling
US $ 0.01 to $ 9.99 = US $ 3.00
(CAN $ 0.01 to $ 15.49 = CAN $ 4.75)
US $ 10.00 and over = US $ 5.00
(CAN $ 15.50 and over = CAN $ 7.75)
Outside Continental USA
Add: US $ 10.00
(CAN $ 15.50)
Sales Tax
• California, Illinois, Indiana,
Maryland and New York Residents
Add Sales & Applicable Local Taxes
• Ohio Residents Add 5.75% Sales Tax
• Pennsylvania Residents Add 6% Sales
Tax except for Philadelphia and
Allegheny Counties add 7% Sales Tax
• South Carolina Residents Add 5% Sales
Tax

Remember
We are here to help you!
For immediate help, call our Customer
Service Department at 1-800-837-4044
from anywhere in the U.S. or Canada
or fax at 1-610-286-4555.
Visit us at our web site:
www.centuryproducts.com

Century Products
Graco Children’s Products Inc.
A Division of Newell Rubbermaid
Macedonia, Ohio 44056-2096
