CeoTronics CT-DECT Multi M7 User manual

dok1702-us-07-0221
CT-DECT Multi M7
Configuration 2400105
Operating manual
English –USA

dok1702-us-07-0221 2/ 20
Contents
1General Operating- and Safety Instructions ....................................................................................2
2Purpose..........................................................................................................................................7
2.1 Profiles.....................................................................................................................................7
3Technical description ...................................................................................................................10
3.1 Plug connections ................................................................................................................... 11
4Switch-on...................................................................................................................................... 12
5Switch-off......................................................................................................................................12
6Display..........................................................................................................................................12
7Menu............................................................................................................................................. 12
7.1 Menu control..........................................................................................................................12
7.2 Menu structure.......................................................................................................................13
7.2.1 Profiles „Standard“ and „GC Multi“.................................................................................. 13
7.2.1 Profil „Expert“..................................................................................................................14
8Setting the profile.......................................................................................................................... 15
9Subscription - DECT..................................................................................................................... 15
10 Pairing –Bluetooth (only in profile „Expert“) ..............................................................................16
11 Headset volume ........................................................................................................................16
12 Microphone switch-off................................................................................................................16
13 Power supply –Battery change................................................................................................. 17
13.1 Display remaining capacity .................................................................................................... 18
13.2 Display remaining time (only when use Li-Po accu pack)....................................................... 18
13.3 Status LED ............................................................................................................................18
14 Servicing and maintenance .......................................................................................................19
14.1 Condition check.....................................................................................................................19
14.2 Cleaning ................................................................................................................................19
1 General Operating- and Safety Instructions
For the use of the device and for prevention of personal injury or property damage,
notice the national safety and accident prevention regulations and the following
warning and safety instructions in this document.
⚫Before using CeoTronics products, read completely the appropriate operating instructions. If in
doubt, ask our technical staff.
⚫Keep this document for later use.
⚫Use CeoTronics products only without damage and abrasion.
⚫If repair work of any kind needs to be done to CeoTronics products, arrange for it to be performed
only by the company CeoTronics or by a specialized workshop that is authorized by CeoTronics. In
all other cases, our warranty and liability for the product shall lapse.
⚫Keep CeoTronics products out of the reach of children and any other persons who are not familiar
with the handling and operation thereof.
⚫CeoTronics products may only be used for the specific application envisaged.
⚫Safe operation requires clean devices. Ensure that the devices (microphones, connectors etc.) are
clean and in good condition at all times.
⚫Should equipment, supplied by CeoTronics, be definitely put out of service you may return it to
CeoTronics. We ensure recycling and / or disposal of outdated equipment in compliance with
the applicable environment protection law.
Product damage!
⚫Do not immerse a CeoTronics product into water, unless expressly specified for this purpose.
⚫Connect CeoTronics accessories to a device or disconnect them from a device only after switching
the device off, unless otherwise described in the operating instructions.

dok1702-us-07-0221 3/ 20
⚫Let devices that are designed for outdoor use during use outdoors always closed (e.g. CT-DECT
Case) and close unused ports with appropriate cover –if available.
⚫Do not store CeoTronics products in the open air or in damp ambient conditions. At all times keep
them clean, dry and at normal air humidity. CeoTronics pro- ducts must not be stored in areas with a
temperature of over +80° C (+176° F), e.g. in the summertime on the parcel shelf of a car. If not
stated otherwise, the following temperature ranges are acceptable for CeoTronics products: -10 to
+55°C for operation, -40 to +80° C (-40 to +176° F) for storage.
⚫Pay attention that no humidity could penetrate into the device during cleaning. Do not use solvents
(e.g. benzene, alcohol, etc.) for cleaning! Safe operation requires clean devices. Ensure that the
devices (microphones, connectors etc.) are clean and in good condition at all times.
Risk of injury by connection leads!
⚫When using CeoTronics products that are equipped with connection leads ensure that the leads do
not get caught up in operational machinery or wheels!
Risk of injury by speaker volume!
⚫Please, note that in some audio devices (e.g. radios) very loud signaling beeps could be present as
the radio is switched on. There are various types of devices generating a series of tones in different
loudness levels. It may be necessary to adjust the volumes of the tones separately. These tones
could damage your hearing if they are set too high. Therefore, adjust signaling beeps to a
convenient level as desired before starting to use CeoTronics accessories. Follow the instructions of
the audio device manufacturer’s operating manual to adjust the signaling beeps.
⚫For safety reasons reception volumes in excess of 85 dB (A) are possible with a whole series of
CeoTronics products. However, these can be regulated by the user. After switching on the
communication system, set the reception volume to approx. 1/2 the available loudness volume and
then test the speaker volume, e.g. by opening the squelch on the radio set.
⚫Do not set the volume any higher than is necessary. A very high volume setting can lead to
damaged hearing, particularly if it is continuous. For high volumes or noise levels, wear additional
earplugs. If in doubt, ask your safety officer or company doctor.
Road traffic hazard!
⚫Do not leave CeoTronics products lying around loose in cars, e.g. on the parcel shelf. Stow these
products in a suitable, safe place in the car so that they do not present a danger to you or to other
occupants of the car, if emergency braking is effected.
⚫When driving a car, do not use the radio because it may distract you from the other traffic. Never use
a CeoTronics product (headset, insert earphone, induction receiver etc.) that will impair your hearing.
Impairment of flight operation!
⚫When on board an airplane always keep a transmitter/receiver switched off. Operation of the
transmitter / receiver could affect the safety of the aircraft, and it is therefore prohibited. Never
operate electronic devices on board an aircraft without the express approval of an authorized
member of the cabin crew.
⚫The CT-DECT GateCom Compact must always be removed from the aircraft once the intercom
communication is completed. Never remove the warning flag „Remove before flight“ from the CT-
DECT GateCom Compact.
Impairment of radio transmission!
⚫Transmit only when it is necessary. Unnecessarily occupying a channel can prevent the transmission
of vitally important information.
Risk of explosion!
⚫CeoTronics products that are not intrinsically safe (explosion-proof) and there- fore have no special
explosion-proof designation must basically not be operated in potentially explosive environments.
Potentially explosive atmospheres can arise, for example, in refuelling areas or in storage and
transport facilities for fuels and chemicals! Devices that are not explosion-proof can trigger off
explosions in such areas!

dok1702-us-07-0221 4/ 20
It is important that you strictly observe the guidelines, arrangements and regulations applicable to
your area of activity!
Risk of electric shock!
⚫Before opening line voltage operated products (e.g. for service purposes), always disconnect first the
mains plug from the mains socket!
⚫Use CeoTronics products only in undamaged condition. In case of any kind of damage, refrain from
further using the CeoTronics product and have it repaired.
Adverse effect on cardiac pacemakers!
⚫If you are a cardiac pacemaker carrier, before operating a transmitter / receiver ask the manufacturer
of your cardiac pacemaker for information about any impairment that could be caused due to high
frequencies.
Rechargeable batteries and batteries!
⚫Observe the environmental regulations when handling storage batteries! Do not throw used
(defective) storage batteries into the domestic refuse. Observe the battery ordinance (BattV).
Risk of injury by Rechargeable batteries and batteries!
⚫Insert the rechargeable batteries only after having read and understood all safety instructions.
Rechargeable batteries imply potential risks, which could cause physical injury and material damage.
⚫Never intend to open a rechargeable battery and never throw it into open fire. Ensure that contacts
and charging sockets of the rechargeable battery do not cause short circuit (risk of fire and injury) by
bridging (bent-open paper clip, bunch of keys or similar). In such a case, the guarantee is void.
⚫Transport spare rechargeable batteries in electrically non-conductive packing material in order to
avoid shorting the rechargeable batteries.
⚫Keep the rechargeable batteries away from persons who are not familiar with their handling and use
(e.g. children).
⚫Charging rechargeable batteries in potentially explosive areas is strictly prohibited (risk of
explosion!). Charge and change rechargeable batteries only in areas where no explosive gases,
vapours, or dusts could be present in combination with air.
Damage to charger or rechargeable batteries!
⚫Charge rechargeable batteries only using the corresponding appropriate CeoTronics charger.
Regard voltage and current data, also on the mains side (e.g. 230 V AC or 115 V AC).
⚫Never use the battery charger for charging non-rechargeable batteries.
⚫Chargers are neither waterproof nor dust-tight and need protection against water, rain, and
contamination. Use them only in the appropriate environment, intended for the system. Don´t cover
the ventilation openings.
⚫Don‘t charge rechargeable batteries outdoors.
Radio Software (firmware) –Risk of malfunction!
Please note that the function of radio accessories is depending on the software settings set up in your
radio. Be careful with software updates and / or changes to the software settings. If you update the
radio’s software, or if you change the software settings, check first on a radio that the radio accessory is
still functioning properly after these changes. It is possible that the receiving volume of some radios is
not satisfactory. In these cases, we suggest you check if an increase of the receiving volume is possible
via the parameters in the audio profile of your radio.
Follow the information of the radio manufacturer!
If you have any further questions in regards to this subject, do not hesitate to contact our sales back
office.

dok1702-us-07-0221 5/ 20
Important safety information concerning the use of CT-DECT digital radio systems!
⚫Legal note for operation in the European Union
The transmitter of the CT-DECT device should be used in the European
Union only when it is marked as following:
⚫Legal note for operation in the USA
The transmitter of the CT-DECT device should be used in the USA only when
it is marked as following:
Improper use!
The use of CeoTronics products for special applications, such as explosive and hazardous areas,
aviation, bomb disposal (EOD) or other similar applications, is in the sole responsibility of the end user.
The end user has to check and decide that the products can be used without risk.
CeoTronics does not take over responsibility for any damage or material losses nor injuries to persons,
caused by the use described above or by any other abnormal use of the products.

dok1702-us-07-0221 6/ 20
Important Notes for operation of the CT-DECT System in the USA
Please note that any changes or modifications not expressly approved by the party
responsible for compliance will void the user’s authority to operate the equipment.
This device complies with part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful interference, and (2) this device must
accept any interference received, including interference that may cause undesired operation.
NOTE: This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This equipment
generates, uses, and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
. Reorient or relocate the receiving antenna.
. Increase the separation between the equipment and receiver.
. Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
. Consult the dealer or an experienced radio/TV technician for help.

dok1702-us-07-0221 7/ 20
Definition
FP = Fixed Part (Base / Basis) –e.g. CT-DECT Case
PP = Portable Part (Standard / Mobilteil)
DNR = Digital Noise Reduction (Digitale Unterdrückung störender Geräusche)
Sidetone = S/T audible feedback of your voice
GC Multi = Profile for GateCom Multi (aircraft ground handling)
2 Purpose
The CT-DECT Multi M7 is a mobile communication device based on DECT radio technology.
It enables the user to connect wirelessly to a CT-DECT network and thus use a voice communication
(full duplex). The CT-DECT Multi M7 can use only as an “PP” device.
2.1 Profiles
The device can be set to different profiles.
Profil
PP/FP
Application
Standard
PP
General DECT application as standard device
Expert
PP
Expert mode –for use by trained personnel only
GC Multi
PP
DECT application as standard device - aircraft ground handling
How to change the profiles is described in section 8.
A DECT system always consists of a base station (FP / Base e.g. CT-DECT Case) and at least one
mobile device (PP / Standard).

dok1702-us-07-0221 8/ 20
1
Standard
Standard
Standard
Standard
Base
All users can communicate with each other in full duplex.

dok1702-us-07-0221 9/ 20
2
Suitable adapter cables are available for various intercom systems. Please contact us to select the appropriate
adapter cable for your application.
GC Multi
GC Multi
GC Multi
GC Multi
Intercom
All users with profil „GC Multi“ and the Intercom can communicate in full duplex.
Base

dok1702-us-07-0221 10 / 20
3 Technical description
Microphone
On/Off
Catch-cord fastener
Accessory connector
(for connection of headset)
CT-ComLink® SF
Battery status
LED
Volume +
PTT
Display
Softkey 1
Battery compartment
On-/Off button
Fixing clamp
Softkey 2
Volume -
3 - Operating elements

dok1702-us-07-0221 11 / 20
3.1 Plug connections
Place the plug
on the socket. Make sure
that the red dot on the plug
and socket match.
Turn the plug carefully
on the socket until it
something slides into
the socket.
Press the plug into
the socket until you
feel it lock into place.
To disconnect the
plug, grasp only the
front part of the plug
and carefully pull
the plug out of the
socket.
CAUTION
The locked connector must neither be twisted (Figure 5) nor kinked (Figure 6). Improper
handling can damage the connector.
Never pull on the cable of the plug connection. Pulling on the cable can damage the connector
(Figure 7).
NO
NO
4 - Connect and disconnect the plug connection
5
6

dok1702-us-07-0221 12 / 20
4 Switch-on
Press on/off button until display starts.
The display first shows the current profile
5 Switch-off
Keep the On/Off button pressed until “Shutdown” appears on the display – press the button again to
confirm.
6 Display
8
7 Menu
7.1 Menu control
For menu control / menu
selection use On/Off button and softkeys 1 and 2
Select submenu:
Change submenu:
confirm selection:
Status line
Speaker volume / On/Off
Microphone On/Off
Profile Name
DECT display –signal strength
Battery status
STANDARD
7
NO

dok1702-us-07-0221 13 / 20
7.2 Menu structure
7.2.1 Profiles „Standard“ and „GC Multi“
9
Menu
DECT
Subscription
Einstellungen
Display
Always on
5s
30s
60s
120s
Language
English
German
French
Reset Battery
NiMh
Alkaline
Info
Software
Version
Remaining
capacity in %
Serialnumber
Remaining Time
(only Li-Po Pack)
Shut down
Confirm
all Configurations
only when using AAA adapter
only when using AAA adapter Li-Po accu pack

dok1702-us-07-0221 14 / 20
7.2.1 Profil „Expert“
10
Menu
DECT
Subscription
ON / OFF
Bluetooth
ON / OFF
Pair
Friendly Name
Audio
Tone
+12
+6
0
-6
-12
-18
-24
-30
DNR
OFF
0
-10
-15
-20
S/T
+12
+6
0
-6
-12
-18
OFF
Settings
Display
Always on
5s
30s
60s
120s
Language
English
German
French
Reset Battery
NiMh
Alkaline
Info
Software
Version
Remaining
capacity in %
Serialnumber
Remaining
(only Li-Po Pack)
Shut down
Confirm
all Configurations
only when using AAA adapter
only if Bluetooth ON
only if DECT ON
Data in the menu „Audio“ in dB
Tones: Volume of the signal tones transmitted to the radio default
value (0)
DNR: default value (-15)
S/T: Sidetone
default value (0)
only when using Li-Po accu pack

dok1702-us-07-0221 15 / 20
8 Setting the profile
You can change the profile as follows:
Switch the device off
- Keep the On/Off button pressed until “Shutdown” appears on the display –
press the button again to confirm.
Switch-on - Press on/off button and Softkey 2 until display starts.
- The display first shows “Profile”
- The Display show now the menu for profil selection
- Select the desired profile with both buttons
- Confirm your selection by renewed pressing the On/Off button
9 Subscription - DECT
Subscribe simultaneously always only one CT-DECT Multi M7 to a CT-DECT “FP” (CT-DECT Case).
Set the CT-DECT “FP” in subscription mode. Start the subscription process on the CT-DECT Multi M7
as follows: Carry out steps 1 and 2 quickly one after another to avoid a “Time Out”.
Step 1
Press up to
Press up to
Press
Subscription in
progress
Press
and…
Step 2
Follow the subscribtion description of the operation manual of the CT-DECT “FP”.
X
SUBSC
X
MENU
--)
STANDARD
X
OK
--)
DECT
X
OK
--)
SUBSCRIPT
OK
SUCESSFUL

dok1702-us-07-0221 16 / 20
10 Pairing – Bluetooth (only in profile „Expert“)
In the "Expert" profile, a Bluetooth device can also be additionally paired with the CT-DECT Multi M7.
Step 1 –Switch On the Bluetooth function in CT-DECT Multi M7
Press up to
Press up to
Press
Press
Press
Press
Step 2
Set the desired Bluetooth device to pairing mode. Note the operating instructions of your Bluetooth
device.
Step 3 –Pairing
Press up to
Press up to
Press
Press
Press
Pairing in
progress
Press
After confirming the pairing code, the name of the other Bluetooth device is displayed.
The devices are now connected via Bluetooth.
If the pairing process takes longer than 1 minute, the CT-DECT Multi M7 interrupts the process with the
message "Time Out".
11 Headset volume
The CT-DECT Multi M7 is equipped with 6 headset volumes. It can be adjusted with the
Volume buttons "+" and "-". The display shows the volume levels in steps of two.
12 Microphone switch-off
The CT-DECT Multi M7 is equipped with a microphone switch-off function.
Volume „+“
Volume „-“
Speaker „OFF“
Step:
1-2
3-4
5-6
Microphone
ON/OFF
Microphone
OFF
Microphone
ON
ON OFF
ON OFF
X
PAIRING
X
MENU
--)
EXPERT
X
MENU
--)
DECT
X
MENU
--)
BLUETOOTH
X
EDIT
--)
ON OFF
X
OK
--)
ON OFF
X
OK
--)
ON OFF
X
MENU
--)
EXPERT
X
MENU
--)
DECT
X
MENU
--)
BLUETOOTH
X
EDIT
--)
ON OFF
X
OK
--)
PAIR
X
OK
--)
XXXXXX

dok1702-us-07-0221 17 / 20
13 Power supply – Battery change
Power is supplied by a Li-Po battery pack or by 3 AAA cells, which are inserted into the device in a
special adapter. Alkaline or NiMH batteries can be used in the adapter.
Batteries and accumulators must not be mixed in the adapter.
A runtime display is only possible when using the Li-Po battery pack.
Depending on the ambient temperature, the headset is used and the intensity of use (transmission /
reception / standby), operating times of up to approx. 16 hours can be achieved with a Li-Po battery
pack and operating times of up to approx. 8 hours can be achieved with NiMH AAA battery cells.
Article Number
Adapter for 3 AAA cells:
4024001
Li-Po accu pack:
4024002
Changing the battery/rechargeable batteries - Li-Po battery pack or adapter with 3xAAA cells
Open the battery
compartment by turning
the latches in the
direction of the arrow
Remove the accu pack or adapter from the device. When reinserting,
make sure that the contacts are at the top and inside of the device.
When using the AAA adapter, set the type of battery used in the
Settings menu - NiMH or alkaline.
Example
accu pack

dok1702-us-07-0221 18 / 20
13.1 Display remaining capacity
Press up to
Press up to
Press
Press for
select
The remaining capacity can be requery via the menu (see diagram). The displayed value is an estimate
designed for the following types of batteries and accus:
- LiPo accu pack (Article Number: 4024002)
- Ansmann Alkaline AAA Battery (Article Number: 4006504 –2 piece)
- Panasonic eneloop AAA NiMh Accu (Article Number: 4008010 –2 piece)
Using other types may lead to different results. A converted to the estimated remaining time is possible
when using the LiPo battery pack. A general approximate indication of the state of charge is given by
the status LED.
13.2 Display remaining time (only when use Li-Po accu pack)
Press up to
Press up to
Press
Press for
select
The values only indicate the remaining estimated runtime based on the percentage of remaining
capacity. This estimated runtime depends to a significant extent on the usage scenario and is
permanently adjusted to this scenario.
13.3 Status LED
approximately
34%
-
100%
capacity green
approximately
10%
-
33%
capacity yellow
approximately
5%
-
9%
capacity red flashing - 2s-cycle
approximately
0%
-
4%
capacity red flashing - 200ms- cycle
DECT
X
MENU
--)
STANDARD
X
MENU
--)
DECT
X
OK
--)
INFO
X
ZUSTAND
--)
31%
status LED
MENU
X
MENU
--)
STANDARD
X
MENU
--)
DECT
X
OK
--)
INFO
X
RESTZEIT
--)
21h35min

dok1702-us-07-0221 19 / 20
The following charger is available for charging the Li-Po battery packs:
Article Number
4-Slot battery charger
4024003
14 Servicing and maintenance
14.1 Condition check
Regularly inspect the system –and especially cables and connectors –for signs of breakage, cracking,
and wear.
14.2 Cleaning
Remove any loose dust with a soft brush. Clean the outside with a suitable clean cloth that has been
slightly moistened with clear water, and rub the parts dry afterwards. If heavily soiled, some
dishwashing liquid can be used in addition.
Clean the contacts of connectors with a commonly available contact cleaning agent.

dok1702-us-07-0221 Copyright ©
Deutschland und
Internationaler Vertrieb
CeoTronics AG
Adam-Opel-Str. 6
63322 Rödermark
Tel. [phone]
Fax [phone]
E-Mail [e-mail]
Spanien
CeoTronics S.L.
C/Ciudad de Frias 7 y 9
Nave 19
28021 Madrid
Tel. [phone]
Fax [phone]
E-Mail [e-mail]
USA/Kanada/Mexico
CeoTronics, Inc.
2133 Upton Drive, Suite 126, PMB 513
Virginia Beach, VA 23452
Tel. [phone]
Fax [phone]
E-Mail [e-mail]
Deutschland und
Internationaler Vertrieb
CT-Video GmbH
Gewerbegebiet Rothenschirmbach 9
06295 Lutherstadt Eisleben
Tel. [phone]
Fax [phone]
E-Mail [e-mail]
Änderungen vorbehalten CeoTronics AG, 63322 Rödermark, Deutschland, Internet www.ceotronics.com
Certificate No.: 01100004023 (ISO9001)
Certificate No.: 01220004023 (ATEX, Directive 2014/34/EU)
Certificate No.: 461801 (PPE, Regulation (EU) 2016/425)
