Cerwin-Vega CLS Series CLS-15S Manual

9340 De Soto Ave. • Chatsworth, California 91311
Phone:[phone] • Fax: [phone] • www.cerwin-vega.com
TECHNICAL SPECIFICATIONS:
High Power Cast-Frame Woofers
Custom designed woofers made with cast aluminum frames,
exotic fiber impregnated cellulose cones and huge high temp
voice coils submerged in a massive motor structure result in
legendary CV bass output and dynamics!
Proprietary Integrated Midrange and Tweeter Waveguide
Computer optimized waveguide provides high sensitivity and
dynamics with extremely low distortion. The geometry of the
waveguides results in near perfect integration of the midrange
and tweeter for seamless midrange and highs.
CLS-6 CLS-6C CLS-10 CLS-12 CLS-15 CLS-215 CLS-12S
CLS-15S
Frequency
Response
50Hz - 20kHz 50Hz - 20kHz 38Hz - 20kHz 32Hz - 20kHz 28Hz - 20kHz 24Hz - 20kHz 28Hz - 150Hz
25Hz - 150Hz
Power handling 125W Peak 125W Peak 200W Peak 300W Peak 400W Peak 500W Peak 250W
200W RMS
Dimensions
(h x w x d)
15.4x8x10.45 8x22.7x9.5 33x12.2x11 37x14x11.7 40x16.5x16.6 48x16.5x19 19x17x17
23.5”x18.8”x18.8”
Weight 20lbs 27lbs 48lbs 57lbs 80lbs 110lbs 46lbs
64lbs
HOME AUDIO SERIES
CLS SERIES
System Features:
• Revised waveguide with taller midrange protective grille
• Improved high frequency tweeter response with copper
shorting ring.
• Improved midrange power handling
• Dual pairs of gold plated all metal binding posts with jumper
straps for bi-wire or bi-amp applications
CLScutsheet1229 1/20/06 11:42 AM Page 1
