Chamberlain Passport User manual

1
To prevent possible SERIOUS INJURY or DEATH from
electrocution:
• Be sure power is not connected BEFORE installing the
receiver.
To prevent possible SERIOUS INJURY or DEATH from a moving
gate or garage door:
• ALWAYS keep remote controls out of reach of children.
NEVER permit children to operate, or play with remote
control transmitters.
• Activate gate or door ONLY when it can be seen clearly,
is properly adjusted, and there are no obstructions to
door travel.
• ALWAYS keep gate or garage door in sight until completely
closed. NEVER permit anyone to cross path of moving gate
or door.
SPECIFICATIONS
Power: 12VDC, 50 mA
Temperature Rating: -40° to +185° F
Model CPWR3 RF Frequency: 390 MHZ
Accessory Transmitters
Visors: CPT1, CPT2, CPT3, CPT4
Key chains: CPTK1, CPTK3, CPTK1PH, CPTK3PH
OVERVIEW
The Wiegand Receiver (CPWR) is a communication device that
transmits an information packet to an access control unit such as
a Sentex Telephone Entry System. All receiver units utilize the
latest in Chamberlain®rolling code technology.
ACCESS CONTROL COMPATIBILITY
The CPWR outputs a 26-bit or 30-bit Wiegand format compatible
with Sentex access control systems.
CARTON INVENTORY
Wiegand Receiver
Antenna
Instructions
PARTS NOT PROVIDED
# 6 Mounting Hardware
5-conductor shielded cable; 22 AWG wire
Extension Kit (Optional)
MODEL CPWR
390 MHz Wiegand Receiver with
Passport Technology

12
3
1535F11
3-Button Remote
Tr a n sm i t t er
Buttons 1-3 are
factory-set to ON.
3
2
1
BUTTON
S1
3
2
1
0
FORMAT
FFC
Figure 5: 3-Button Transmitter Button Switches
2
1535F7
S1
3
2
1
0
FORMAT
3
2
1
FFC
BUTTON
Figure 2: 30-bit DIP Switch Setting
SETTING THE SWITCHES
Before making changes to any of the DIP switches (Figure 1),
power MUST be disconnected from the receiver (unplug the
terminal block from J2 on the circuit board). Otherwise, your
changes will not take effect. Also, when setting the receiver’s DIP
switches, refer only to the numbers silk screened on the circuit
board (not the numbers on the DIP switch itself).
1. Disconnect power to the receiver.
2. Turn screws counterclockwise 1/4 turn and remove front
cover.
3. Before or while touching the circuit board, discharge any
static electricity:
(1) Use a grounding strap OR
(2) Touch a cold, grounded, metallic pipe.
4. The output code format switch settings are factory-set for the
30-bit format (Figure 2). To change the settings to 26-bit,
refer to Figure 3.
30-bit Switch Settings (Default):
S1, 3 = OFF or 0
S1, 2 = OFF or 0
S1, 1 = ON or 1
S1, 0 = ON or 1
26-bit Switch Settings:
S1, 3 = OFF or 0
S1, 2 = OFF or 0
S1, 1 = ON or 1
S1, 0 = OFF or 0
5. Set the transmitter button response(s).
• There are three DIP switches used to set the transmitter
button response(s) (Figures 4 or 5).
• To disallow receiver response to transmitter buttons, move
the DIP switch(es) to the LEFT. All button switches are
factory set to ON.
Switch S1, 1 controls Button #1 and Button #4*
Switch S1, 2 controls Button #2
Switch S1, 3 controls Button #3
* If using a CPT4 transmitter, Button #4 reacts to Button #1
settings, but uses a unique identification number and facility
code.
Left = OFF or 0
Right = ON or 1
RP2 U9
1
C7
RP3 U10
1
C8
RP1
U8
1
C6
F AC I L I T Y COD E
SENTEX SYSTEMS
MADE I N USA
15
14
13
12
11
109
8
7
65
43
21
0
FORMAT
3
21
03
21
BUTTON
FFC
C4
C3
C2
C5
U5 1TP1 TP4
1
U4
14
U3
14
U2
14
1
1
22C
C9
12C
Y3
C9
U1
CLOCK
IN
DATA
IN
C13 R1
L1
J1
E1
L3
Y2
C17
C23
C20
C18
Y4
L2
C14
C10
C11 Y1
C15
C12
C16 R5 C19 R4 U6
62C
33C
43C
C29
0
1R
C27
L4
C25
C2
R2
R3
R7
U7
R25
C28
R12
J3
R8
6
2R
4Q
6R 11R
22R
3
2R
42
R12
R
D11
D12
D13
D9
D1
SIGNAL
DATA
VALID
POWER
GRANTED
C30
C31
TP3
TP2
+5V
GND
Q2
Q1
R19 R20
C32
U12
D7 D6 D5 D4
D2
D8
D3
R17 R16 R14 R15
R13
D3
D16
01R
FACILITY CODE
15 73
2
6
5
4
3
2
1
0
14
13
12
11
10
9
8
1
0
3
2
1
FFC
FORMAT
BUTTON
Figure 1
1535F10
S1
3
2
1
0
FORMAT
3
2
1
FFC
BUTTON
Figure 3: 26-bit DIP Switch Setting
1535F8
CPT4
Transmitter
Buttons 1-3 are
factory-set to ON.
3
2
1
BUTTON
S1
3
2
1
0
FORMAT
FFC
Figure 4: CPT4 Transmitter Button Switches

Figure 7
Mounting
Holes
J2
To Access Control
Circuit Board (Reader Port)
Figure 8
RP2 U9
1
C7
RP3 U10
1
C8
RP1
U8
1
C6
F A C I L I T Y CO D E
SENTEX SYSTEMS
MADE I N USA
15
14
13
12
11
109
8
7
65
43
21
0
FORMAT
3
21
03
21
BUTTON
FFC
C4
C3
C2
C5
U5 1TP1 TP4
1
U4
14
U3
14
U2
14
1
1
22
C
C9
1
2
C
Y3
C9
U1
CLOCK
IN
DATA
IN
C13 R1
L1
J1
E1
L3
Y2
C17
C23
C20
C18
Y4
L2
C14
C10
C11 Y1
C15
C12
C16 R5 C19 R4 U6
62C
3
3C
43C
C29
0
1R
C27
L4
C25
C2
R2
R3
R7
U7
R25
C28
R12
J3
R8
62R
4Q
6R 11R
22R32
R4
2
R
12R
D11
D12
D13
D9
D1
SIGNAL
DATA
VALID
POWER
GRANTED
C30
C31
TP3
TP2
+5V
GND
Q2
Q1
R19 R20
C32
U12
D7 D6 D5 D4
D2
D8
D3
R17 R16 R14 R15
R13
D3
D16
01R
Mounting
Holes
3
SETTING THE SWITCHES CONTINUED
6. Set a Fixed Facility Code (FFC).
• The FFC switch must be in the ON position (switch set to
right).
• Set the receiver’s facility code switches (labeled 0-5) to match
the facility code of the access control system.
Refer to the switch settings chart in the Appendix on page 5 for
assistance.
NOTE: For installations that require the facility code of the
transmitters to be passed to the access control system, set the
FFC switch to the OFF position (set switch to left). Facility codes
are set in the transmitter at the factory to avoid code duplication.
FACILITY CODE
5
4
3
2
1
0FFC
15
14
13
12
11
10
9
8
73
2
6
1
0
3
2
1
FORMAT
BUTTON
The outside of the antenna connector is not ground. If using
an extension kit, do not allow it to contact a metal object.
INSTALLATION AND WIRING
1. Mount the Receiver.
Mount receiver to surface using #6 hardware (not provided).
(Figure 8)
NOTE: Mount receiver with 18" of space above the receiver for the
antenna. The receivers should be installed at least 5' apart to
avoid “cross-talk”.
2. Connect the antenna.
Screw on antenna clockwise and slide rubber boot down to
meet o-ring (Figure 7).
3. Connect signal/power wires.
Remove the terminal block from J2 on the circuit board.
Connect wires from the CPWR 6-pin connector to the access
control system (Figure 8). Then re-insert the terminal block
onto J2.
Wire the CPWR to the access control systems’ card reader
port. Refer to the access control system’s instructions for
appropriate wiring detail. A typical wire connection might
resemble the following:
NOTE: At power up, the CPWR will perform a system check and
produce a series of LED flash sequences (this is normal).
Facility code switches 6-15 are not used (must remain in the
OFF or left position).
FFC Factory Setting = ON (switch set to right).
Facility Code Factory Setting = All OFF (switches set to left).
CABLE SIGNALS WIRE COLOR
LED BROWN
DATA 1 WHITE
DATA 0 GREEN
+12VDC RED
COMMON (GND) BLACK
SHIELD SHIELD

4
TESTING AND TROUBLESHOOTING
1. Check the power.
Ensure that the red POWER LED is lit (Figure 9). If not, check
your power connections and/or source. Voltage reading
should be within the range of 9VDC – 18VDC.
2. Check for Receiver operation.
The SIGNAL LED (Figure 9) should be flickering continuously,
indicating that the RF receiver circuitry is operating.
3. Test the Transmitter/Receiver.
Press the transmitter button previously set in step 4, page 3,
within view of the receiver. If the DATA-yellow and
VALID-green LEDs do not light, review the Setting the
Switches and Connect Signal/Power Wires sections.
NOTE: If the DATA-yellow and VALID-green LEDs flash repeatedly
and simultaneously, the format settings may be incorrect (refer to
Output Code Format).
If reception of the transmitter’s signal is significantly reduced,
there may be strong RF interference from other sources.
Common sources of interference include fluorescent lights,
neon signs, mercury vapor lamps, arc welders, and arcing
power lines. Interference due to lighting can be limited by
having an electrician wire a noise suppressor into the lamp,
light, or sign circuit.
NOTE: It may be required to press the transmitter button twice at
first use.
RECEIVER LED REFERENCE
(Figure 9)
SIGNAL – Red
This LED, when lit, indicates that the receiver has detected the
presence of RF energy. It is normal for this LED to flicker
continuously while the receiver is powered up.
DATA – Yellow
This LED indicates that the receiver recognizes the transmission
data as coming from a Chamberlain®transmitter with Passport
technology.
VALID – Green
This LED indicates that the receiver is sending a Wiegand format
output to the access control system.
POWER – Red
This LED indicates that the receiver has power.
GRANTED – Green
This LED indicates that the access control system has validated
the transmitted code and has granted access.
4. Attach the front cover.
Attach front cover of receiver by turning screws clockwise
1/4 turn. Do not over tighten.
Call your local power company if interference is due to arcing
power lines.
SIGNAL
D11
DATA
D12
VA L I D
D13
POWER
D9
GRANTED
D1
Figure 9
RP2 U9
1
C7
RP3 U10
1
C8
RP1
U8
1
C6
F A C I L I T Y CO D E
SENTEX SYSTEMS
MADE I N USA
15
14
13
12
11
109
8
7
65
43
21
0
FORMAT
3
21
03
21
BUTTON
FFC
C4
C3
C2
C5
U5 1TP1 TP4
1
U4
14
U3
14
U2
14
1
1
22C
C9
12C
Y3
C9
U1
CLOCK
IN
DATA
IN
C13 R1
L1
J1
E1
L3
Y2
C17
C23
C20
C18
Y4
L2
C14
C10
C11 Y1
C15
C12
C16 R5 C19 R4 U6
62
C
33C
4
3
C
C29
01R
C27
L4
C25
C2
R2
R3
R7
U7
R25
C28
R12
J3
R8
62
R
4Q
6R 11R
22R32R42R12
R
D11
D12
D13
D9
D1
SIGNAL
DATA
VALID
POWER
GRANTED
C30
C31
TP3
TP2
+5V
GND
Q2
Q1
R19 R20
C32
U12
D7 D6 D5 D4
D2
D8
D3
R17 R16 R14 R15
R13
D3
D16
01R

5
APPENDIX: FACILITY CODE SWITCH SETTINGS
Refer to Figure 1 on page 1 for the facility code DIP switch location. Also, when setting the receiver’s DIP switches, refer only to the
numbers silk screened on the PC board (not the numbers on the DIP switch itself).
FC 000 001 002 003 004 005 006 007 008 009 010 011 012 013 014 015
500 0 0 0 0 0 0 0 0 0 0 0 000
400 0 0 0 0 0 0 0 0 0 0 0 000
300 0 0 0 0 0 0 11111111
200 0 0 11 1100001111
100 1100 1100110011
00101010101010101
FC 016 017 018 019 020 021 022 023 024 025 026 027 028 029 030 031
500 0 0 0 0 0 0 0 0 0 0 0 000
41 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1
300 0 0 0 0 0 0 11111111
200 0 0 11 1100001111
100 1100 1100110011
00101010101010101
FC 032 033 034 035 036 037 038 039 040 041 042 043 044 045 046 047
51 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1
400 0 0 0 0 0 0 0 0 0 0 0 000
300 0 0 0 0 0 0 11111111
200 0 0 11 1100001111
100 1100 1100110011
00101010101010101
FC 048 049 050 051 052 053 054 055 056 057 058 059 060 061 062 063
51 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1
41 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1
300 0 0 0 0 0 0 11111111
200 0 0 11 1100001111
100 1100 1100110011
00101010101010101

©2008, The Chamberlain Group, Inc.
SN6001535H All Rights Reserved
LIMITED WARRANTY
LiftMaster warranties the receiver against original manufacturing defects for a period of three (3) years, measured from the day of
initial shipment by LiftMaster. This warranty is conditioned upon LiftMaster being paid in full for all equipment; this warranty is not
effective until such payment in full has been received. The warranty period shown above applies only to the LiftMaster receiver with
Passport technology). Since this is a manufacturer's warranty, not a dealer's warranty, installation, removal, and freight charges are not
part of this warranty, nor shall the installer be held liable in any way for removal, repair or installation of the Passport system unless
otherwise stated in a separate dealer's warranty. This warranty does not extend to systems or compartments that show evidence of
damage caused by vandalism, acts of God (e.g., lightning, flood), abuse, or unauthorized or improper service.
This document is protected by copyright and may not be copied or adapted without the prior written consent of LiftMaster. This
documentation contains information proprietary to LiftMaster and such information may not be distributed without the prior written
consent of LiftMaster. The software and firmware included in the LiftMaster product as they relate to this documentation are also
protected by copyright and contain information proprietary to LiftMaster.
HOW TO ORDER REPAIR PARTS
OUR LARGE SERVICE ORGANIZATION SPANS AMERICA
Installation and service information are available.
Call our TOLL FREE number:
1-800-528-2806
www.liftmaster.com
