Changhong Electric LE40D307 User manual

LED(BACKLIGHTING) COLOR
TELEVISION
OPERATION MANUAL
Please read this manual carefully before operation.
LE40D307

Warning
REGULATORY INFORMATION
This equipment generates,uses,and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful
interference to radio communication. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
-Relocate the receiving antenna.
-Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
-Consult the dealer or experienced radio/TV technician for help.
Any changes or modifications not expressly approved by the party responsible for
compliance could void the user's authority to operate the equipment.
CAUTION
DO not attempt to modify this product in any way without written authorization from
supplier. Unauthorized modification could void the user's authority to operate this
product.
It is not recommended to keep a certain still image displayed on the screen for a long
time as well as displaying extremely bright images on screen.
Figures and illustrations in this User Manual are provided for reference only and
may differ from actual product appearance. Product design and specifications
may be changed without notice.
WARNING:
TO REDUCE THE RISK OF ELECTRIC SHOCK DO NOT REMOVE COVER
(OR BACK). NO USER SERVICEABLE PARTS INSIDE. REFER TO
QUALIFIED SERVICE PERSONNEL.
The lightning flash with arrowhead symbol, within an equilateral triangle,
is intended to alert the user to the presence of uninsulated "dangerous
voltage" within the products enclosure that may be of sufficient
magnitude to constitute a risk of electric shock to persons.
The exclamation point within an equilateral triangle is intended to alert the
user to the presence of important operating and maintenance (servicing)
instructions in the literature accompanying the appliance.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
1

Warning
WARNING
To Reduce The Risk Of Fire Or Electric Shock, Do Not Expose This Apparatus To
Rain Or Moisture.
The ventilation should not be impeded by covering the ventilation openings with
items, such as newspapers, table-cloths, curtains, etc.
The Apparatus shall not be exposed to dripping or splashing and that no objects
filled with liquids, such as vases, shall be placed on the apparatus.
Attention should be drawn to the environmental aspects of battery disposal. Don’t
throw used batteries in dustbin. Please contact your retailer in order to protect the
environment.
When you install your TV, maintain a distance of at least 4 inches between the TV
and other objects (walls, cabinet sides, etc.) to ensure proper ventilation. Failing to
maintain proper ventilation may result in a fire or a problem with the product caused
by an increase in its internal temperature.
No naked flame sources, such as lighted candles, should be placed on the
apparatus.
To prevent the spread of fire, keep candles or other open flames away from this
product at all times.
The device may malfunction when under electrostatic discharge. It can be manually
resumed by recycling the power off and on again.
CAUTION connecting the Power Cord
Most appliances recommend they be placed on a dedicated circuit; that is, a single
outlet circuit which powers only that appliance and has no additional outlets or
branch circuits.
Do not overload wall outlets. Overloaded wall outlets, loose or damaged wall outlets,
extension cords, frayed power cords, or damaged or cracked wire insulation are
dangerous. Any of these conditions could result in electric shock or fire. Periodically
examine the cord of your appliance, and if its appearance indicates damage or
deterioration, unplug it, discontinue use of the appliance, and have the cord replaced
with an exact replacement part by an authorized servicer. Protect the power cord
from physical or mechanical abuse, such as being twisted, kinked, pinched, closed
in a door, or walked upon. Pay particular attention to plugs, wall outlets, and the
point where the cord exits the appliance.
The MAINS plug is used as the disconnect device, and the disconnect device shall
remain readily operable.
Operating Temperature: 5°C to 35°C Operating Humidity: ≤80%
Storage Temperature: -15°C to 45°C Storage Humidity: ≤90%
2

Warning
Warning: Changes or modifications to this unit not expressly approved by the party
responsible for compliance could void the user's authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user is encouraged to
try to correct the interference by one or more of the following measures:.
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
- Consult the dealer or an experienced radio/ TV technician for help.
ENERGY STAR is a joint program of the U.S. Environmental Protection Agency and
the U.S. Department of Energy helping us all save money and protect the
environment through energy efficient products and practices.
Home mode is the default as-shipped television configuration and settings. Home
mode is the setting in which the product qualifies for ENERGYSTAR. Any changes to
default as-shipped television configuration and settings would change the energy
consumption. Enabling certain optional features and functionalities may increase
energy consumption beyond the limits required for ENERGY STAR qualification.
The terms HDMI and HDMI High-Definition Multimedia Interface, and the HDMI logo
are trademarks or registered trademarks of HDMI Licensing LLC in the United
States and other countries.
3

Safety instructions
IMPORTANT SAFETY INSTRUCTIONS
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
7. Do not block any of the ventilation
openings. Install in accordance with the
manufacturer's instructions.
5. Do not use this apparatus near water.
8. Do not install near any heat source such
as radiators, heat registers, stoves, or
other apparatus (including amplifiers)
that produce heat.
6. Clean only with a dry cloth.
9. Do not defeat the safety purpose of the
polarized or grounding type plug. A
polarized plug has two blades with one
wider than other. A grounding type plug
has two blades and a third grounding
prong. The wide blade or the third
prong is provided for your safety. When
the provided plug does not fit into your
outlet, consult an electrician for
replacement of the obsolete outlet.
4

Safety instructions
10. Protect the power cord from being
walked on or pinched particularly at
plugs, convenience receptacles, and
the point where they exit from the
apparatus.
13. Unplug this apparatus during
lightning storms or when unused for
long periods of time.
11. Only use the attachments/
accessories specified by the
manufacturer.
12. Use only with a cart, stand, tripod,
bracket, or table specified by the
manufacturer, or sold with the
apparatus. When a cart is used, use
caution when moving the cart/
apparatus combination to avoid
injury from tip-over.
14. Refer all servicing to qualified service
personnel. Servicing is required when
the apparatus has been damaged in
any way, such as power supply cord
or plug is damaged, liquid has been
spilled or objects have fallen into the
apparatus, the apparatus has been
exposed to rain or moisture, does not
operate normally, or has been
dropped.
ON DISPOSAL
-The fluorescent lamp used in this product contain a small amount of mercury.
-Do not dispose of this product with general household waste.
-Disposal of this product must be carried out in accordance to the regulations of your
local authority.
NOTE
-If the TV feel cold to the touch, there may be a small "flicker" when it is turned on.
This is normal, there is nothing wrong with TV.
-Some minute dot defects may be visible on the screen, appearing as tiny red,
green, or blue spots. However there have no adverse effect on the monitor's
performance.
-Avoid touching the screen or holding your finger(s) against it for long periods of time.
Doin
g
so may produce some temporary distortion effect on the screen.
5

Getting Started
UsingtheRemoteControl
When using the remote control, aim it at remote sensor on the television. If there is an
object between the remote control and the remote sensor on the unit, the unit may no
operate.
•Point the remote control at the REMOTE SENSOR located on the television.
•When using this television in a very brightly lit area, the infrared REMOTE CONTROL
SENSOR may not work properly.
•The recommended effective distance for using the remote control is about 7 metres.
Installing Batteries in the Remote Control
1. Open the cover at the back of the remote control.
2. Install two AAA size batteries. Make sure to match
the “+” and “-” ends of the batteries with the
diagram inside the compartment.
3. Replace the cover.
Battery Replacement
You will need to install the batteries into the remote control to make it operate following
the instruction below.
When the batteries become weak, the operating distance of the remote control will be
greatly reduced and you will need to replace the batteries.
Notes on Using Batteries:
The use of the wrong type of batteries may cause chemical leakage and/or explosion.
Please note the following:
•Always ensure that the batteries are inserted with the + and - terminals in the correct
direction as shown in the battery compartment.
•Different types of batteries have different characteristics. Do not mix different types.
•Do not mix old and new batteries. Mixing old and new batteries will shorten battery life
and/or cause chemical leakage.
• Replace batteries as soon as they do not work.
•Chemicals which leak from batteries may cause skin irritation. If any chemical matter
seeps out of the batteries, wipe it up immediately with a dry cloth.
• The batteries may have a shorter life expectancy due to storage conditions. Remove the
batteries whenever you anticipate that the remote control will not be used for an
extended period.
•The batteries (battery pack or batteries installed) shall not be exposed to excessive heat
such as sunshine, fire or the like.
CAUTION:
•It may result in an explosion if batteries are replaced incorrectly.
•Only replace batteries with the same or equivalent type.
6

Basic Operation
TurningonandofftheTV
■Turn on the TV
Connect the power cable, and press the button to turn on the TV.
■Turn off the TV
Press the button on the remote control to enter standby mode.
Do not leave your set in standby mode for long periods of time. It is best to unplug the
set from the mains and aerial.
When there is an accident power off, it is recommended to unplug the power cable
from the power socket.
■No signal
There is No Signal menu on screen when there is no input signal. In TV mode, if there
automatically turn off in 30 seconds if no input signal. When VGA cable is connected,
the TV turns on automatically.
ProgrammeSelection
■Using the CH on the panel of TV or on the remote control.
■Using 0- 9 digital buttons and – button.
You can select the channel number by pressing 0 to 9. (In ATV mode)
In DTV mode, press number buttons and – button to select channel.
To tune the TV to a channel not programmed in the channel memory, you must use
the number buttons on the remote control.
■Example
To select - channel (e.g. Channel 1): Press 1.
To select -- channel (e.g. Channel 20): Press 2 and 0 in a short time.
To select --.- channel (e.g. Channel 20.1): Press 2, 0, – and 1 in a short time.
VolumeAdjustment
■You can release mute by pressing the
ChangingtheInputSource
control.
to confirm your choice.
■If you want to switch the sound OFF, press the MUTE.
■Press the +VOL- button to adjust the volume.
MUTE or increase the volume.
2. Press the▲/▼button to cycle through the input source, and press the SELECT button
▲▼
Press to increase channel number.
Press to decrease channel number.
▲
▼
1. You can select the input source by pressing the INPUT button on the remote
is no signal in 15 minutes, the TV will turn off automatically. In PC mode, the TV set will
7

Connection and Setup
CableInstallation
Before the installation and use, please read carefully the relevant content in “Warning and
Safety instructions”.
NOTE:
• When you plug or unplug the TV, computer or other equipments, you must make sure
that the AC power has been already shut down;
• When unplugging the power cable or signal cable, please hold the plug (the insulated
part), do not draw the body of the cable.
2. The RF output terminal can be connected with the RF input port of the TV.
3. The output AV terminal of DVD can be connected with the AV input port of the TV
through AV cable.
1. Take out the TV from the wrapping package and put it in a drafty and flat place.
NOTE:
• Component and AV can not be used at same time for they share of one audio channel.
Component Y signal and AV video signal share one channel.
• Both Audio signals of AV and COMPONENT are input from "R - Audio - L".
4. The output COMPONENT (YPbPr) terminal of a DVD can be connected with the
COMPONENT (YPbPr) input port of the TV through an AV cable.
5. Connect one end of the VGA cable with the VGA port on the computer, connect the
other end of the VGA cable with the VGA port on the TV, and tighten the bolts
clockwise on each end of VGA cable.
NOTE:
• While connecting the 15-pin VGA, please do not insert the plug with enormous force,
otherwise the connector or a pin might be broken.
6. Connect one end of the HDMI cable with HDMI output port, connect the other end of
the HDMI cable with the HDMI port on the TV.
NOTE:
• While connecting the HDMI, please aim it carefully, and do not insert with enormous
force, otherwise the connector or a pin might be broken.
• HDMI1 and MHL share one port.
7. Sending the TV's digital audio signal to external audio equipment via the Digital Audio
Output port.
8. Check and make sure that all AV cables are connected with the corresponding ports
correctly.
9. Connect the AC power cable with 100-240V~ power supply.
NOTE：
• The range of input power for the TV is 100-240V~, 50/60Hz. Do not connect the TV
power input port with the AC power out of the above range.
• Please hold the insulated part of the plug when you are unplugging the power cable. Do
not touch directly the metallic part of the cable.
8

Connection and Setup
When the TV is initially powered on, a sequence of on-screen prompts will assist in
to go to the next step. Press the ◄button to return to the previous menu.
language.
■Time Zone: Press the ▲/▼button to select your time zone.
■Time Format: Press the ▲/▼button to select 12-hour or 24-hour.
NOTE:
•If the TV doesn't receive any channels, please check your aerial connection or the
country you selected, then try an auto tuning again.
•If the TV just receives some of the channels, it means the aerial's reception isn't good
enough and an antenna service is recommended.
into the Hotel Mode to adjust the relative settings.
Hotel■Enable: Set the Hotel Enable On/Off by pressing the ◄/►buttons.
• When Hotel Mode is On, the Channel function is locked.
■On Source: Set the default signal source by pressing the ◄/►buttons. (The default
signal source will be displayed when the TV is turned on.)
■On Channel: Set the default channel by pressing the ◄/►buttons. (The default
channel will be displayed when the TV is turned on.)
■On Volume: Set the default volume by pressing the ◄/►buttons. (The default volume
is the volume when the TV is turned on. Remember the default volume should be less
than the maximum volume).
■Volume Max.: Set max volume by pressing the◄/►buttons. When the max volume is
lower than the default volume, the max volume is the priority.
■Logo Select: Both "Hotel Enable" and "Logo Select" are ON the Logo is displaying
when power on.
■BACKUP: "BACKUP" means to write the TV data to USB device.
The function is supposed to be used when all the settings have been completed and
the "Hotel Enable" is ON.
■RESTORE: "RESTORE" means to read data from USB device and write to local flash,
then the machine needs restart to initiate the parameters.
HotelMenu
Setup Wizard
■Menu Language: Press the ▲/▼button to select the desired OSD (On Screen Display)
■Source: Press the ▲/▼button to select Air or Cable.
■TV Mode: Press the ▲/▼button to select Retail or Home.
configuring basic settings. Press the SELECT button to start the guide. Press the ►button
■Auto Channel Scan: Scans and saves available programmes automatically.
Press the INPUT button to display the Source Menu, then press(2(0(1(2 to enter
9

Remote Control
The buttons of the original remote control are as following:
Definition of the buttons on remote control:
1.
INFO/ : Press to display the current program
information on the screen.
13. NUMBER BUTTONS: Choose channels or
password importation.
MENU: Press to display/disappear the on screen
menus or to quit some operations.
16.
EXIT: Quit the current interface.
▲/▼/◄/►: Select direction.
:Fast reverse (in USB mode)
:Fast forward (in USB mode)
: Previous (in USB mode)
: Next (in USB mode)
26.
: Stop (in USB mode)
27.
23.
Mute or restore sound.
Select signal source.
-: In DTV mode, press number buttons and - key to
select channel.
MUTE:
C.C.: Press to select the closed caption.
LAST :
ASPECT: Choose the aspect ratio.
HDMI1/2/3: Press to directly access the
HDMI Inputs.
►
: Play (in USB mode)
:Pause (in USB mode)
22. : Scroll to next/previous channel.
▼
▲
CH /CH
VOL+/VOL-: Increase/Decrease audio volume.
USB: Link into USB mode.
Return to last viewed program.
POWER: Select or quit the standby mode.
28.
Press to display the Favourite channel.
SELECT: Select or confirm menu item.
AUDIO:
: Press this button to switch to HDMI1 as the
source input, or turn to the HOME menu of the
MHL device.
456
789
0
2 3
HDMI1 HDMI2 INPUT
ENTER
SELECT
MENU EXIT
FAV C.C. AUDIO LAST
ASPECT P.MODE
MUTE
HDMI3
POWER
INFO
USB
2
2
5
6
2
9
12
15
16
19
22
23
2
1
3
4
8
7
13
17
18
21
24
2
14
2
12 . INPUT:
14.
25.
18.
19.
17.
21.
2.
3.
5.
4.
24. FAV :
7.
8.
9.
10.
6.
11.
11
20
5
6
78
920.
Press to change the audio language.
15. Select or confirm functions for the
On-Screen menu.
ENTER:
10
Press to change the picture mode.
information on the screen.
29.P.MODE :

Menu Operation
HowtoNavigateMenus
Before using the TV follow the steps below to learn how to navigate the menu in order to
select and adjust different functions. The access step may differ depending on the
selected menu.
1. Press the MENU button to display the main menu.
access the submenu.
4. Press the ▲/▼/◄/►button to select the desired value. Settings will be saved after exit.
The adjustment in the OSD may differ depending on the selected menu.
5. Press the MENU button to return to the previous menu.
6. Press the EXIT button exit from the menu.
NOTE:
•When an item in MENU is displayed gray, it means that the item is not available or
cannot be adjusted.
•Some items in the menus may be hidden depending on modes or signal sources used.
•Buttons on the TV have the same function as corresponding buttons on the remote
control. If your remote control is lost or couldn’t work, you may use the buttons on the
TV to select menus. This manual focuses on operation of the remote control.
Before your TV can begin memorizing the available channels,
you must specify the type of signal source that is connected
to the TV (i.e. an Air or a Cable system).
You can select the antenna source in the Cmenu.hannels
Tuning which automatically scan and store all available
programmes.
2. Press the◄/►button to cycle through the main menu. Press the SELECT button to
3. Press the▲/▼button to select the desired sub item, then press the SELECT button.
■Source: Select the signal type for channels.
■
ConfiguringtheChannelsMenu
■Auto Channel Scan: Press the SELECT button to start Auto
■
■Favorite CH List:
Press SELECT button to set the favorite
channel.
Channel Skip: Press SELECT button to skip the channel.
Channel List: Press SELECT button to call up the
channel list.
11

Menu Operation
■Picture Mode: You can select the type of picture which
best corresponds to your viewing requirements.
Contrast: Adjusts the signal level between black and white
in the picture. You may use Contrast when the bright part
of the picture is saturated.
Brightness: Adjusts the base level of the signal in the
picture.
Sharpness: Adjusts the level of crispness in the edges
between the light and dark areas of the picture.
Tint: Adjusts the balance between red and green levels.
(Only in the NTSC mode)
The adjusted values are stored according to the User mode.
■Backlight: To control the brightness of the screen, adjust the brightness of panel.
Configuringthe Menu
■Sound Mode: You can select a sound mode to suit your
personal preferences.
Mode: Changes the Sound mode.
120Hz/500Hz/1.5KHz/5KHz/10KHz: Adjust the curve
of 5 bands equalizer.
Based on your favorites about which frequency band
need to be adjusted, make small adjustment with certain
frequency band at a time. Suggest not making too la
changes.
rge
The adjusted values are stored according to the User
mode.
Video
Configuringthe Menu
■Noise Reduction: Reduces screen noise without compromising video quality.
Audio
■Aspect Ratio: You can select the picture size which best corresponds to your viewing
requirements.
Color: Adjusts intensity of all colours.
■DBC:Switch the Energy mode on or off.
■Color Temperature: Select the color temperature of the
picture.
Picture Mode: Changes the image mode.
Clock: Eliminates the vertical(CLOCK) interfering lines.
Phase: Adjust when characters have low contrast or when the image flickers.
■PC Settings (In PC mode)
H.Position: Centre the image by moving it left or right.
V.Position: Centre the image by moving it up or down.
Auto adjust: Adjust the image automatically.
12

Menu Operation
■Balance: You can adjust the sound balance of the speakers to preferred levels.
programmes. Because each broadcasting station has its own signal conditions,
volume adjustment may be needed every time when the channel is changed. This
feature allows users to enjoy stable volume levels by making automatic adjustments for
each program.
external receiver, you may hear a sound echo caused by the difference
in decoding
this occurs, set the TV to External Speaker.
When you set Speaker to TV both the TV’s speakers and the external
speakers are on. You will hear sound through both. The volume of the
external device can’t be adjusted.
When you set Speaker to External, the TV’s speakers are turned off.
You will hear sound through the external speakers only. Adjusts the
volume with the knob attached to the external device.
Press your password (it is 0 0 0 0 at first), Then you will go the sub-menu as following.
■Change Password: You can set your private password.
Press the number buttons on the remote control to set the
new password. When the new password has been input
twice, the setting is finished successfully.
Age Define
TV-Y General audience
TV-Y7 Parental guidance suggested
TV-G Parents strongly cautioned
TV-PG Retricted
TV-14 No one 17 and under admitted
TV-MA Adult audience only
TV-None None
■Perfect Volume: AVC automatically remains on the same level of volume if you change
through an
speed between the TV’s speakers and the speakers attached to your
audio receiver. If
■Internal Speakers: If you are listening to the sound track of a broadcast or movie
ConfiguringtheLocks Menu
■Parental Control: Set the system lock On or Off.
■Lip Sync: Correct audio-video sync problems, when watching DTV and when listening
■U.S.: To select the TV/Movie Rating you want to lock or not.
TV Rating
■Digital Output: Press SELECT button to select PCM or RAW.
■Surround: To switch the surround sound.
On
Off
to digital audio output using an external device such as an audio receiver (0ms~25ms).
If you forget, the super password of 7777 still valid.
13

Menu Operation
Rating Define
G General audience. All ages admitted.
PG Parental guidance suggested. Some material may not be suitable for children.
PG-13 Parents strongly cautioned. Some material may be inappropriate for
children under 13.
R Restricted. Children under 17 require accompanying parent or adult guardian.
NC-17 No one 17 and under admitted.
X Adult audience only.
■Canada: To select the Canada English/Canada French Rating you want to lock or not.
Rating Defined as
C Children
C8+ Children 8 years and older
G General programming
PG Parental guidance
14+ Viewers 14 and older
18+ Adult programming
Rating Defined as
G General
8 ans+ Not recommended for younger children
13 ans+ Not recommended for childrenunder age 13
16 ans+ Not recommended for ages under 16
18 ans+ This program is restricted to adults
Movie Rating
English Rating: These ratings are for programs which are using English rating system.
Canadiaa French: The ratings are for programs which are using French rating system.
14

Menu Operation
If you try to tune the TV to a program that exceeds the rating limits you set, the TV will
enter program lock mode and a warning message will appear on-screen. Follow the
instructions to temporarily unlock the program.
NOTE:
•RRT setting and Reset RRT can be selected when the TV signal have RRT rating
information.
Configuringthe Menu
language.
available, to be displayed on screen.
On.
analog programs.
CC1,2,3,4 Displays corresponding caption channel of a
analog program. (Usually be set to CC1 for most programs.)
Service1,2,3,4,5,6 These are different service data channels.
Shadow
Setup
■Menu Language: Select your preferred On Screen Display
Text1,2,3,4 Displays corresponding text service channel
of a analog program.
caption.
Caption Display: Select CC Mode: CC Off, CC on Mute,
CC
modes for
Analog Closed Captions: Select from below closed-caption
Digital Closed Captions: Applies only to digital channels
with closed
Digital Caption Options: You can customize the closed caption display characteristics.
Caption Style: Automatic/Custom. If set to Custom, Digital CC Style is available.
Font: Default/Font 0~7
Size: Medium/ Large/ Small
Edge Effect: Default/ None/ Raised/ Depressed/ Uniform/ Left Shadow/ Right
Edge Color: Default/ Black/ White/ Red/ Green/ Blue/ Yellow/ Magenta/ Cyan
Text Color: Default/ White/ Red/ Green/ Blue/ Yellow/ Magenta/ Cyan
Background Color: Default/ Black/ Red/ Green/ Blue/ Yellow/ Magenta/ Cyan
Text Opacity: Default/ Solid/ Flashing/ Translucent/ Transparency
are broadcasted.)
■Region5: Press SELECT button to set RRT rating.
■Reset Region5: Press SELECT button to reset RRT information.
■Closed Captions: You can select Closed Captions, if
(Available for digital channels if multiple audio
languages
language.
■Preferred Audio Language: Select your preferred audio
15

Menu Operation
■Reset: Restore the system settings to the factory default. When the restore is
environments.
■Health Remind: Switch the Health Remind on or off. While Health Remind is set to On,
a prompt picture will remind you to have a break at intervals of two hours.
■Clock: You can display either the DTV Signal Stream
Time or set the System Time.
according to the DTV broadcasting time automatically.
Otherwise you can set the time manually.
automatically.
will enter into standby mode automatically when there is
no operation in set time.
■Time Zone: Select your time zone.
■Time Format: You can choose to use 12-hour format or
24-hour format.
■Setup Wizard: This is a guide to help you to setup the TV.
Configuringthe
Menu
Time
■Sleep Timer: Select the time to turn the TV to standby
mode
■Auto TV Off: Select the Auto Sleep time you want. The TV
■Demo Mode: Switch the Demo Mode on or off. Demo Mode is the optimal setting for
store
■Update the software.
Auto Clock: If set it to On, the TV will sync the local clock
mode.
complete, the Setup Wizard is displayed on the screen.
Daylight Savings: Selects the Daylight Savings
Background Opacity: Default/ Solid/ Flashing/ Translucent/ Transparency
-
■HDMI CEC: Switch the HDMI-CEC on or off.
Software update(USB):
2015/04/01
16

Menu Operation
UsingUSBmode
■To Access/Quit USB mode
also use the signal source selection menu to exit from the USB mode.
NOTE:
•Special USB device may be not or well supported.
•USB max. Load: DC5V 500mA.
■The formats supported
NOTE:
•Special algorithm documents may not be or well be supported by the USB.
•The USB supports the format mentioned above, if the file format is not supported,
change it to the given format.
• There may be abnormal in playing too large files.
■Main Operating Interface
button to
play the selected files. If no file is marked, all the files in the folder will be played in
sequence after you press button.
5. Press the INFO button to display the menu screen in playing.
6. Press the button to stop the playing files.
7. Press the EXIT button to return to the previous menu screen.
Connect an USB device. Press INPUT button to display the main menu. Use the
Photo Show: JPEG.
▲/▼to highlight USB, and the SELECT button to access the USB mode. You may
4. Press CH /CH button to page up or page down the files. Use the arrow buttons to
▲
▲
highlight the file. Use the SELECT button to mark or unmark a file. Press
button to enter.
2. Use the arrow buttons and SELECT button to enter the desired disk.
3. Press arrow buttons and SELECT to open the folder.
1. Press ◄/ ►button to select PHOTO in the main menu, then press SELECT
17

Troubleshooting Guide
Troubleshooting
Before contact the service technician, perform the following simple checks. If any program
still persists, unplug the TV and calling for serving.
Symptoms Possible Reason Solutions
No picture, no sound,
and no indicator light on
1.The power cord is not plugged in
2.The power is off
1.Plug the power cord in
2.Turn the power on
Picture and sound with
abnormity
1.Contrast, sharpness, and color are
set improperly
2.Color system is set improperly
3.Sound system is set improperly
1.Adjust the value of
Contrast, sharpness, and
color
2.Set the Color system to the
country broadcasting
standard
3.Set the Sound system to
the country broadcasting
standard
Picture is spotted or with
snow
Signal source is low-grade or the
signal cord is in a lower quality Use the qualified signal cord
Volume is in the minimum value or
TV is in mute mode. Adjust the value of volume
No picture, no sound and
indicator light is
green/blue The signal cable is not correctly
connected.
Connect the signal cable
correctly
Blue screen, AV or
S-VIDEO is displayed
There is no signal input or the video
cable is not connected or incorrectly
connected
Connect the video cable
correctly
Picture is unclear or
shaking or with black
horizontal strips (in PC
mode)
PC picture is not
centered
PC picture is not correctly adjusted.
Enter into Screen menu,
select Auto Adjust item to
perform automatic calibration
and adjust Phase to solve
the problem
No sound
There is no audio signal input or
audio cable is not connected
correctly
Connect the audio cable
correctly
PC picture display with
improper color
The color temp is adjusted
incorrectly by user
Readjust the color temp, or
select the original color setting
HDMI source, with snow
pixel of full screen The source generate is not standard Plug the HDMI cable again
18

Troubleshooting Guide
The remote control does
not work
Batteries are improperly installed or
exhausted
1. Make sure the positive and
the negative polarities are
correct.
2.Check if there is a loose
contact between the
batteries and the springs
3.Replace the batteries
Maintenance
Early malfunctions can be prevented. Careful and regular cleaning can extend the amount
of time you will have your new TV. Be sure to turn the power off and unplug the power
cord before you begin any cleaning.
Cleaning the screen
1. Here’s a great way to keep the dust off your screen for a while. Wet a soft cloth in a
mixture of lukewarm water and a little fabric softener or dish washing detergent. Wring the
cloth until it’s almost dry, and then used it to wipe the screen.
2. Make sure the excess water is off the screen, and then let it air-dry before you turn on
your TV.
Cleaning the cabinet
To remove dirt or dust, wipe the cabinet with a soft, dry, lint-free cloth. Please be sure not
to use a wet cloth.
Extended Absence
If you expect to leave your TV dormant for a long time (such as a vacation), it’s a
good idea to unplug the power cord to protect against possible damage from
lightning or power surges.
Disposal of old electrical appliances
Equipment (WEEE), requires that old household electrical appliances must not
be disposed of in the normal unsorted municipal waste stream. Old appliances
must be collected separately in order to optimize the recovery and recycling of
the materials they contain, and reduce the impact on human health and the
environment.
The crossed out “wheeled bin” symbol on the product reminds you of your
obligation, that when you dispose of the appliance, it must be separately
collected.
Consumers should contact their local authority or retailer for information
concerning the correct disposal of their old appliance.
The European directive 2012/19/EU on Waste Electrical and Electronic
This equipment is a Class Ⅱor double insulated electrical appliance.
It has been designed in such a way that it does not require a safety connection
to electrical earth.
19
