8 • 07101392
CAUTION
If ignition does NOT occur in 5 seconds, turn the
control knob OFF, wait 5 minutes and repeat the
lighting procedure. If the burner does not ignite with
the valve open, gas will continue to flow out of the
burner and could accidently ignite with risk of injury.
Turn control knob and LP cylinder OFF when not in
use.
WARNING
Ignitor Lighting
• Do not lean over appliance while lighting.
1. Turn ON LP gas cylinder.
2. Open the top covers.
3. Press and turn the control knob to HIGH.
4. Turn ROTARYIGNITOR knob rapidly.
5. If ignition does not occur in 5 seconds, turn the burner control
knob OFF, wait 5 minutes, and repeat lighting procedure.
If ignition still does not occur, follow match-lighting
instructions.
Turning Appliance Off
• Turn control knobs to position. Turn LP cylinder off by
turning hand-wheel clockwise to a full stop.
Ignitor Check
• Turn gas off at LP cylinder. Turn ignitor knob. "Click" should
be heard each time at electrode. See "Troubleshooting" if no
click or spark.
Valve Check
• Important: Make sure gas is off at LP cylinder before
checking valve. Each knob locks in position. To check
valve, first push in knob and release, knob should spring back.
If knob does not spring back, replace valve assembly before
using appliance. Turn knob to HIGH position then turn back to
position. Valve should turn smoothly.
Hose Check
•Before each use, check to see if hose is cut, worn or kinked.
Replace damaged hose before using appliances. Use only
valve/hose/regulator specified by manufacturer.
General Appliance Cleaning
• Do not mistake brown or black accumulation of grease and
smoke for paint. Interiors are not painted at the factory (and
should never be painted).Apply a strong solution of detergent
and water or use a grill cleaner with scrub brush on insides of
appliance lid and bottom. Rinse and allow to completely air dry.
Do not apply a caustic grill/oven cleaner to painted
surfaces.
• Plastic parts: Wash with warm soapy water and wipe dry.
Do not use citrisol, abrasive cleaners, degreasers or a
concentrated grill cleaner on plastic parts. Damage to and
failure of parts can result.
• Painted surfaces: Wash with mild detergent or non-abrasive
cleaner and warm soapy water. Wipe dry with a soft non-
abrasive cloth.
• Stainless steel surfaces: To maintain the high quality
appearance, wash with mild detergent and warm soapy water
and wipe dry with a soft cloth after each use. Baked-on grease
deposits may require the use of an abrasive plastic cleaning
pad. Use only in direction of brushed finish to avoid damage.
Do not use abrasive pad on areas with graphics.
OFF
OFF
OFF
Burner Flame Check
• Light burner, rotate knob from HIGH to LOW. Looking through
the damper holes on the side of the smoker oven, you should
see the flame height decrease when turning knob from HIGH
to LOW. Always check flame prior to each use. If only low
flame is seen refer to "Sudden drop or low flame" in the
Troubleshooting Section.
Normal
Hose Kinked
Hose
Smoker Oven Match-Lighting
Do not lean over appliance while lighting.
1. Turn ON LP cylinder.
2. Remove oven drawer and water pan.
3. Place lit match into match holder (located at the side of the
appliance). Light match and place next to burner. Shown Figure A.
4. Push in and turn control knob to HIGH. Be sure burner lights and
stays lit.
5. If ignition does not occur in 5 seconds, turn the burner control knob
OFF, wait 5 minutes, and repeat lighting procedure.
Top Burner Match-Lighting
Do not lean over appliance while lighting.
1. Turn ON LP cylinder.
2. Place lit match into match holder (located at the side of the
appliance). Light match and place next to burner.
3. Push in and turn control
knob to HIGH. Be sure
burner lights and stays lit.
4. If ignition does not occur in
5 seconds, turn the burner
control knob OFF, wait 5
minutes, and repeat lighting
procedure.
6. If burner stays lit, replace
water pan and oven drawer.
Figure A Figure B
View flame
height
through
Damper.
