Charder HM 101M User manual

12
Manufacturer’s Declaration of Conformity
This product has been manufactured in accordance with the
harmonized European standards, following the provisions of the
below stated directives:
93/42/EEC as amended by
2007/47/EC
Medical Device Directive
Please see separate document showing on sticker of device for
above CE marking.
Authorized EU Representative:
Manufactured by:
Charder Electronic Co., Ltd.
No.103, Guozhong Rd., Dali Dist.,
Taichung City 412 ,Taiwan (R.O.C.)
CD-IN-1371[15245E] 04/2019
1
HM 101M
Height Measurement
USER MANUAL
Please keep the instruction manual at hand all the time for future reference.

2
TABLE OF CONTENTS
PREFACE................................................................................................. 3
CLEANING.............................................................................................. 3
MAINTENANCE ..................................................................................... 3
INTENDED USE...................................................................................... 3
SAFETY INSTRUCTIONS...................................................................... 4
WARRANTY............................................................................................ 5
EXPLANATION OF THE GRAPHIC SYMBOLS.................................... 6
SETTING UP HM101M ........................................................................... 7
HOW TO MEASURE YOUR BABY........................................................ 9
SPECIFICATION ................................................................................... 10
HM101M WALL MOUNTED INSTRUCTION...................................... 10
11
2. Press wall anchors into the holes.
3. Fasten the rod on the wall.
4.

10
3. Keep the baby on the surface with the left hand gently.
4. Gently press baby’s knees down and push right head stop to the sole
of the baby’s feet.
5. Read off the length of the baby from HM101M height marking.
SPECIFICATION
Measuring Range: 100mm ~ 1000mm
Graduation: 1mm
Accuracy:±10mm
Dimension: 1020(W) x 50(H) x 275(D)mm
Weight: approx. 520g
Operation temperature: 5℃ / 35℃
HM101M WALL MOUNTED INSTRUCTION
1. Mark and drill two holes on the wall according to the hole-positions on the
rod. Make sure two holes are on the same level.
3
PREFACE
Thank you for choosing CHARDER MEDICAL product. All features of
this product were designed to state of the art and are optimized for
simple and straightforward use. If you have any queries or
experience any problems not addressed in the operating instructions,
please contact your CHARDER MEDICAL service partner, or visit us
on the Internet at www.chardermedical.com
CLEANING
To clean the measuring rod as required using cleaning agent or
disinfectant agent.
MAINTENANCE
The device does not require any routine maintenance. Daily wipe
with water or cleaning agent to keep cleaning and disinfected is
recommended.
INTENDED USE
This scale is used to determine weight of patients who are supported
by professional personnel in rooms intended for carrying out health
care. The weighing value can be read off after a stable weighing
value has been obtained. Before any use, the scale must be checked
for correct condition by the authorized person.

4
SAFETY INSTRUCTIONS
Proper use
This height measuring rod is used to determine the height of
persons while standing upright, or of lying babies, according to its
model, in medical treatment localities. This height measuring rod
is suitable to detect, prevent and survey diseases.
Ensure that the height measuring rod may only come into contact
only with uninjured skin.
Improper Use
The structure of the height measuring rod may not be modified.
This may result in incorrect measuring results, safety-related
defects as well as destruction.
The height measuring rod may only be used according to the
described conditions.
Safety Instructions
Observe operating instructions.
Please use no other than the supplied fixtures for mounting.
During assembling, ensure that screws are tightened properly
and that the height measuring rod has been assembled
correctly.
To prevent risk of injury, ensure that the head stop is returned to
9
HOW TO MEASURE YOUR BABY
1. Push the buckle to release right head stop with your left hand.
2. Using your right hand to push head stop in the direction of baby’s feet.

8
Measurement range is from 100mm to 1000mm
Push head stop to measure the length of baby.
5
folded-in position after each use.
The body height measuring emits only reliable values, when the
back and the head are straightly aligned, nevertheless the body
height of a person may change about some cm during a day.
Never leave a baby on the surface unsupervised
When sliding the rod, ensure that baby is safely on the measuring
area.
WARRANTY
An eighteen(18) month warranty from date of delivery applies to
defects attributable to poor materials or workmanship. Defects,
which come under warranty, will be made good for the customer
at no charge on production of the receipt. No further claims can
be entertained. The costs of transport in both directions will be
borne by the customer should the equipment be located
anywhere other than the customer’s premises. In the event of
transport damage, claims under warranty can be honored only if
the complete original packaging was used for any transport and
the device secured and attached in that packaging just as it was
when originally packed. All the packaging should therefore be
retained.

6
A claim under warranty will not be honored it the equipment is
opened by persons not expressly authorized by Charder to do so.
We would ask our customers abroad to contact their local sales
agent in the event of a warranty matter.
PLEASE VISIT WWW.CHARDERMEDICAL.COM FOR MORE
INFORMATION.
EXPLANATION OF THE GRAPHIC SYMBOLS
SN-T13000001
Designation of the serial number of
every device, applied at the device.
(Number as an example)
“Please note the accompanying
documents“
or “Observe operating instructions”
Charder Electronic Co., Ltd.
No.103, Guozhong Rd., Dali Dist.,
Taichung City 412, Taiwan (R.O.C.)
Identification of manufacturer of medical
product including address
7
“Electro-medical appliance“
with attachment for type B
Dispose of old appliances separately
from your household waste !l!
Instead, take them to communal
collection points.
Carefully read this operation manual
before setup and commissioning, even
if you are already familiar with Charder
scales.
SETTING UP HM101M
Place HM 101M on stable surface.
