Chargery Power S1500 User manual

© 2013 Chargery Power Co., Ltd. 06/18/2013 V1.1
Add: Room 6-303, Langqiny , Ch angye Road NanShan 518054 ShenZhen, China,
Tel: [phone], Fax: [phone], Email: [e-mail]
S1500
PFC programmable Power supply
High efficiency wide input voltage
90V~2 5VAC Input
10V~25V DC Output
0Amps 1500W max.
T hanks for your purchasing the intelligent and powerful power supply.
R ead the ENTIRE instruction manual to become familiar with the features functions of the device
before operating.
F eel free to send an email to [e-mail] or call at 86 755 2643 6165 should you have
any questions and suggestions.
Jason Wang

S1500
High efficiency wide input voltage
PFC programmable Power supply
90V~2 5VAC input
10V~25VDC output
0Amps 1500W max.
www.chargery.com page 2 total 8
Features
S 1500 is a high efficiency wide inp t voltage PFC power s pply, the device can o tp t 1500W at
AC90V~265V in a smaller size. Many creative technology help to realize p to 94% of efficiency, and the
internal temperat re is still nder 80℃. The following are some new feat res:
Intelligent control o tp t voltage and c rrent by microprocessor, 100% calibration before
delivery
±1% voltage and c rrent acc racy
Active PFC: smaller AC inp t c rrent less interference, and Conform to E ropean Commission
Reg lation no 278/2009 and Energy Star Version 2.0
AC 90-265V worldwide operation: need not any alternative switcher, worldwide safe operation.
Low power cons mption (less than 1W) at idle mode and standby mode
Up to 94% of convert efficiency.
Programmable o tp t voltage from 10 to 25V
Programmable o tp t c rrent from 5 to 60A
1.8” TFT color LCD display o tp t Voltage, c rrent, power and internal temperat re on time.
Over c rrent, over voltage, over load, over temperat re, and short circ it protection
Short-circ it protection on o tp t, safer and more reliable.
2 Intelligent cooling fans t rned on pon the temperat re a tomatically
4 o tp ts can do more chargers sim ltaneo sly, 3 pairs 4.0mm gold connector p to 20A each
o tp t, one 4.5mm gold connector (XT-90) p to 60A
ZVS/ZCS and Synchrono s Rectification ass re the highest efficiency.
High power density: 652W/Kg
Start at no load or f ll load
Approved by CE
24 months warranty
Application
Home application
10-25V DC charger, balance charger for RC mode

S1500
High efficiency wide input voltage
PFC programmable Power supply
90V~2 5VAC input
10V~25VDC output
0Amps 1500W max.
www.chargery.com page 3 total 8
E-bike, E-scooter battery charger.
Operation
1. Connect S1500 to AC 110 / 220V o tlet by the special heavy power cable, if se other brand cable,
please note the wire AWG m st be AWG14 at least.
2. 2 seconds later, defa lt o tp t voltage (12V) and maximal o tp t c rrent can be displayed, act al
power and internal temperat re is also displayed, b t S1500 is at idle mode(power off) to save
power cons mption, as the following pict re 1. Confirm the voltage and c rrent is s itable for yo r
charger and other load, then press START ENTER b tton t rn on S1500, the LCD will display act al
o tp t voltage, c rrent, o tp t power and internal temperat re as the following pict re 2.
If the voltage is NOT s itable for yo r charger or other load, press INC or DEC b tton set p the
voltage. It is easy to adj st as same as a potential meter and need not confirm the change, beca se
the voltage will be pdated with yo r operation. Finish the voltage set p, the device can remember
the new val e till next change.
You can also change the voltage at any time whether power on
or power off status.
If need change the maximal current or other items, please
operate according to the following steps.
3. Press STOP SET b tton for 2 seconds can enter into Program
Set p men , The LCD displays the following information in
seq ence and yo can change the val e. When yo want to alter a
parameter val e, press the Start Enter b tton to the val e blink then change the val e with the DEC
or INC b ttons. The new val e will be confirmed and saved by pressing the Start Enter b tton again.
Picture 3 Program setup
Power OFF Power ON
Actual power
Setup voltage Actual voltage
I
nternal temperature
Setup current Actual current
P
icture 1
:
Idle mode
Picture 2: work mode

S1500
High efficiency wide input voltage
PFC programmable Power supply
90V~2 5VAC input
10V~25VDC output
0Amps 1500W max.
www.chargery.com page 4 total 8
Press DEC or INC b ttons alternate different items, and press STOP SET to q it the set p men .
Note:
All parameters will be remembered by the S1500 till next change.
After increase set p voltage, if act al voltage doesn’t increase, please enter into program set p
men , and then increase the maximal c rrent limitation.
After increase maximal c rrent imitation, if act al c rrent limitation doesn’t increase, please
increase set p voltage val e.
Yo can set p all parameters on power on and power off stat s at any time. Voltage can be set p
press DEC or INC b tton directly, b t other items m st be enter into the set p men and then
change it.
At any time yo can press the STOP SET b tton t rn off the power s pply, S1500 will work in idle
mode to save power cons mption till disconnect the S1500 to the AC o tlet. Generally yo needn’t
disconnect S1500F from AC o tlet, beca se the S1500 cons me nder 1W power at idle mode.
When yo need power yo r load s ch as charger etc. what yo do is press the START ENTER b tton
Set p the maximal o tp t c rrent, range from 5A~60A, step
1A, defa lt 60A. The maximal c rrent can protect yo r
charger or loads from damaging.
Max c rrent
---> 60A
Set p the Temperat re nit, ℃or ℉, defa lt ℃ .
Temp. Unit
---> ℃
Set p the working mode of fan, Options: Long life, Normal
and Low noise. Long Life means the fan will start at lower
temp. to extend the nit life. Low Noise means the fan start
at higher temp. it will ca se a low noise at light load. Normal
is defa lt set p, the fan start at middle temp. level.
Fan Mode
---> Normal
The beeper so nds for each b tton press to confirm yo r
action. A beeper so nds at vario s times d ring operation to
alert the ser to mode changes. These so nds can be ON or
OFF.
Key Beeper
---> ON
This men sets the back-light time of LCD screen backlight.
Options: 1MIN, 5MIN, 10MIN, 20MIN and Always on,
default 5MIN. At defa lt 5min, LCD back-light will be off to
save the power, press any button can turn on the back-light.
BACK-LIGHT TIME
---> 5MIN

S1500
High efficiency wide input voltage
PFC programmable Power supply
90V~2 5VAC input
10V~25VDC output
0Amps 1500W max.
www.chargery.com page 5 total 8
again.
Environment Requirements
Ambient Temperat re : -10--45℃
Ambient H midity ：5%--95%
Storage Temp. ：-20℃--70℃
Storage H midity ：30%--90%
Input
Rated Voltage ： AC110 / 220V
Voltage allowed：AC90 ~ 265V
Rated Freq. ：50/60Hz
Freq. Allowed ：47~63Hz
Max C rrent : 18A @90V, 7.5A @220V
Efficiency: 94% at 65% load and 220Vac inp t.
Active PFC: PF>0.99 at 90VAC and 100% of load;
PF>0.97 at 220VAC and 100% of load
Output
Voltage ：10 ~ 25V programmed
Voltage acc racy: ±1%
Ripple voltage: 150mV.
 C rrent：0 ~ 60A (62A MAX.)
Protection
Over voltage protection, 25.5V max.
Over c rrent protection, 62A max.
Over load protection, 1550W max.
Over temperat re protection, 90℃ max.
Short- circ it protection on o tp t.
Mechanical Characteristics
Size：252*145*68 (L*W*H, mm) or 9.9 * 5.7 * 2.7
(L*W*H, inch)
Weight: 2.3Kg witho t inp t cable
Inp t power cable: AWG14 wire, 1.5m length
O tp t DC connector:
3 pairs 4mm gold banana female connector, each
connector for p to 20A maximal c rrent

S1500
High efficiency wide input voltage
PFC programmable Power supply
90V~2 5VAC input
10V~25VDC output
0Amps 1500W max.
www.chargery.com page 6 total 8
One 4.5mm gold male connector (XT90) for p to 60A.
Pac aging Information
S1500 base nit: 1pcs
Power cable: 1pcs
Man al:1pcs
XT-90 female connector with AWG10 silicon gl e
wire: 1pcs
The XT-90 Female connector used to connection of S1500 and your charger or other loads at 60A
Optional Accessory
The following adapter wire (XT90 female to EC5 female, length 100mm, AWG10) is for Cellpro PowerLab
8 (1344W charge power) and iCharger 4010DUO (2000W charge power). Then S1500 can power the
chargers perfectly and get the maximal charge power safety and reliably.
Error Information
When the following error events trigged, the beeper will so nd for 10 seconds and error information will
flash, yo can press STOP SET to t rn off the beeper and flash.

S1500
High efficiency wide input voltage
PFC programmable Power supply
90V~2 5VAC input
10V~25VDC output
0Amps 1500W max.
www.chargery.com page 7 total 8
Error information DESCRIPTION DISPLAY
Over voltage O tp t voltage over 10% of set p val e for 2
seconds, S1500 t rn off a tomatically and t rn on
man ally
On power off page, the set p voltage and
over voltage displayed in t rn.
Over c rrent O tp t c rrent over 10% of set p for 2 seconds,
S1500 t rn off a tomatically and t rn on man ally
On power off page, the set p c rrent and
over c rrent displayed in t rn.
Over temperat re
The heat sink temperat re over 90℃ for 2
seconds, S1500 t rn off a tomatically, and t rn on
a tomatically
On power off page, the internal
temperat re and over temperat re
displayed in t rn.
Short circ it O tp t voltage is nder 10V for 2 seconds and 3
times repeatedly, S1500 t rn off a tomatically, and
t rn on man ally
On power off page, the set p voltage and
short circ it displayed in t rn.
Related parts
MODEL
DESCRIPTION COMMENTS
S400 High efficiency wide inp t voltage PFC power s pply 6~15V 25A 400W o tp t
S600 High efficiency wide inp t voltage PFC power s pply 6~15V 40A 600W o tp t
S1200 High efficiency wide inp t voltage PFC power s pply 12~24V 50A 1200W o tp t
Warnings
Never leave the power s pply nattended when it t rn on. If any malf nction is observed,
please t rn off the power s pply as fast as possible.
Keep away the power s pply from d st, damp, rain, heat direct s nshine and vibration. Do not
drop it.
The power s pply sho ld be set p on non-inflammable and non-cond ctive s rface. Never
place on a car seat, carpet or similar.
Keep all the inflammable volatile materials well away from operating area.
Do not attempt to charge any types of battery incl ding below:
Lead acid battery or VRLA
NIMH/NICd battery pack
Li-ion and lithi m polymer battery
Warranty and Service

S1500
High efficiency wide input voltage
PFC programmable Power supply
90V~2 5VAC input
10V~25VDC output
0Amps 1500W max.
www.chargery.com page 8 total 8
Chargery Power Co., Ltd. as man fact re of R/C model power warrants S1500 power s pply to be free
of defects in material and workmanship. This warranty is effective for 24 months from date of p rchase.
If within the warranty period the c stomer is not satisfied with the prod cts performance res lting from
a man fact ring defect, the accessory will be replaced or repaired. This warranty does not cover the
damage d e to wear, mis se, incompetent handling or sing of incorrect accessories.
Chargery Power Co., LTD.
Tel: [phone], fax: [phone]
Email: jasonwang3a@1 3.com
