Chargery S1500 User manual

©2015 Chargery Power Co., Ltd. 1/7/2015 V2.0
Add: Room 2-1603,Dianlihuayuan, Chuangye Road NanShan 518054 ShenZhen, China,
Tel: [phone], Fax: [phone], Email: [email protected]
S1500
PFC programmable Power supply
High efficiency wide input voltage
90V~265VAC Input
10V~30V DC Output
60Amps 1500W max.
Thanks for your purchasing the intelligent and powerful power supply.
Read the ENTIRE instruction manual to become familiar with the features/functions of the device
before operating.
Feel free to send an email to [email protected] or call at 86 755 2643 6165 should you have
any questions and suggestions.
Jason Wang

S1500
High efficiency wide input voltage
PFC programmable Power supply
90V~265VAC input
10V~30VDC output
60Amps 1500W max.
www.chargery.com page 2 total 8
Features
S1500 is a high efficiency wide input voltage PFC power supply, the device can output 1500W at
AC90V~265V in a smaller size. Many creative technology help to realize up to 94% of efficiency, and the
internal temperature is still under 80℃. The following are some new features:
◼Intelligent control output voltage and current by microprocessor, 100% calibration before
delivery
◼±1% voltage and current accuracy
◼Active PFC: smaller AC input current less interference, and Conform to European Commission
Regulation no 278/2009 and Energy Star Version 2.0
◼AC 90-265V worldwide operation: need not any alternative switcher, worldwide safe operation.
◼Low power consumption (less than 1W) at idle mode and standby mode
◼Up to 94%of convert efficiency.
◼Programmable output voltage from 10Vto 30V
◼Programmable output current from 1A to 60A
◼TFT color LCD display output Voltage, current, power and internal temperature on time.
◼Over current, over voltage, over load, over temperature, and short circuit protection
◼Short-circuit protection on output, safer and more reliable.
◼2 Intelligent cooling fans turned on upon the temperature automatically
◼4 outputs can do more chargers simultaneously, 3 pairs 4.0mm gold connector up to 20A each
output, one 4.5mm gold connector (XT-90) up to 60A
◼ZVS/ZCS and Synchronous Rectification assure
the highest efficiency.
◼High power density: 652W/Kg
◼Start at no load or full load
◼Approved by CE
◼24 months warranty
Application
◼Home application

S1500
High efficiency wide input voltage
PFC programmable Power supply
90V~265VAC input
10V~30VDC output
60Amps 1500W max.
www.chargery.com page 3 total 8
◼10-30V DC charger, balance charger for RC mode
◼E-bike, E-scooter battery charger.
Operation
1. Connect S1500 to AC 110 / 220V outlet by the special heavy power cable, if use other brand cable,
please note the wire AWG must be AWG14 at least.
2. 2 seconds later, default output voltage (12V) and maximal output current can be displayed, actual
power and internal temperature is also displayed, but S1500 is at idle mode(power off) to save
power consumption, as the following picture 1. Confirm the voltage and current is suitable for your
charger and other load, then press START/ENTER button turn on S1500, the LCD will display actual
output voltage, current, output power and internal temperature as the following picture 2.
If the voltage is NOT suitable for your charger or other load, press INC or DEC button setup the
voltage. It is easy to adjust as same as a potential meter and need not confirm the change, because
the voltage will be updated with your operation. Finish the voltage setup, the device can remember
the new value till next change.
You can also change the voltage at any time whether power
on or power off status.
If need change the maximal current or other items, please
operate according to the following steps.
3. Press STOP/SET button for 2 seconds enter into Program Setup
menu, The LCD displays the following information in sequence
and you can change the value. When you want to alter a parameter
value, press the Start/Enter button to the value blink then change the value with the DEC or INC
Picture 3 Program setup
Power OFF / Power ON
Actual power
Setup voltage/Actual voltage
Internal temperature
Setup current/Actual current
Picture 1: Idle mode
Picture 2: work mode

S1500
High efficiency wide input voltage
PFC programmable Power supply
90V~265VAC input
10V~30VDC output
60Amps 1500W max.
www.chargery.com page 4 total 8
buttons. The new value will be confirmed and saved by pressing the Start/Enter button again. Press
DEC or INC buttons alternate different items, and press STOP/SET to quit the setup menu.
Note:
◼All parameters will be remembered by the S1500 till next change.
◼After increase setup voltage, if actual voltage doesn’t increase, please enter into program setup
menu, and then increase the maximal current limitation.
◼After increase maximal current limitation, if actual current limitation doesn’t increase, please
increase setup voltage value.
◼You can setup all parameters on Power ON and Power OFF status at any time. Voltage can be setup
press DEC or INC button directly, but other items must be enter into the setup menu and then
change it.
◼At any time you can press the STOP/SET button turn off the power supply, S1500 will work in idle
mode to save power consumption till disconnect the S1500 to the AC outlet. Generally you needn’t
disconnect S1500 from AC outlet, because the S1500 consume under 1W power at idle mode. When
Setup the maximal output current, range from 1A~60A, step
0.1A, default 60A. The maximal current can protect your
charger or loads from damaged.
Max current
---> 60A
Setup the Temperature unit, ℃or ℉, default ℃.
Temp. Unit
---> ℃
Setup the fan starting temperature, range from 30~50℃,
step 1℃, default 40℃.
Fan ON Temp.
---> 40℃
The beeper sounds for each button press to confirm your
action. These sounds can be ON or OFF. Default ON.
Buzzer
---> ON
This menu sets the back-light time of LCD screen backlight.
Options: 1MIN, 5MIN, 10MIN, 20MIN and Always on,
default 5MIN. At default 5min, LCD back-light will be off to
save the power, press any button resume the back-light.
BACK-LIGHT TIME
---> 5MIN
Setup over temperature protection, range from 70~ 90℃,
step 1℃, default 80℃.
Shut Down Temp.
---> 80℃

S1500
High efficiency wide input voltage
PFC programmable Power supply
90V~265VAC input
10V~30VDC output
60Amps 1500W max.
www.chargery.com page 5 total 8
you need power your load such as charger and so on, what you do is press the START/ENTER button
again.
Environment Requirements
◼Ambient Temperature : -10--45℃
◼Ambient Humidity ：5%--95%
◼Storage Temp. ：-20℃--70℃
◼Storage Humidity ：30%--90%
Input
◼Rated Voltage ：AC110 / 220V
◼Voltage allowed：AC90 ~ 265V
◼Rated Freq. ：50/60Hz
◼Freq. Allowed ：47~63Hz
◼Max Current : 18A @90V, 7.5A @220V
◼Efficiency: 94% at 65% load and 220Vac input.
◼Active PFC: PF>0.99 at 90VAC and 100% of load;
PF>0.97 at 220VAC and 100% of load
Output
◼Voltage ：10 ~ 30V programmed
◼Voltage accuracy: ±1%
◼Current accuracy: ±1%
◼Ripple voltage: 150mV.
◼Current：1 ~ 60A programmed
◼Power: 1500W max.
Protection
◼Over voltage protection, over 2V setup value.
◼Over current protection, over 2A setup value.
◼Over load protection, 1500W max.
◼Over temperature protection, 90℃max.
◼Short- circuit protection on output.
Mechanical Characteristics
◼Size：252*145*68 (L*W*H, mm) or 9.9 * 5.7 * 2.7 (L*W*H,
inch)
◼Weight: 2.3Kg without input cable
◼Input power cable: AWG14 wire, 1.5m length

S1500
High efficiency wide input voltage
PFC programmable Power supply
90V~265VAC input
10V~30VDC output
60Amps 1500W max.
www.chargery.com page 6 total 8
◼Output DC connector:
⚫3 pairs 4mm gold banana female connector, each connector for up to 20A maximal current
⚫One 4.5mm gold male connector (XT90) for up to 60A.
Packaging Information
◼S1500 base unit: 1pcs
◼Power cable: 1pcs
◼Manual:1pcs
◼XT-90 female connector with AWG10 silicon glue
wire: 1pcs
The XT-90 Female connector used to connection of S1500 and your charger or other loads at 60A
Optional Accessory
The following adapter wire (XT90 female to EC5 female, length 100mm, AWG10) is for Cellpro PowerLab
8 (1344W charge power) and iCharger 4010DUO (2000W charge power). Then S1500 can power the
chargers perfectly and get the maximal charge power safety and reliably.

S1500
High efficiency wide input voltage
PFC programmable Power supply
90V~265VAC input
10V~30VDC output
60Amps 1500W max.
www.chargery.com page 7 total 8
Error Information
When the following error events trigged, the beeper will sound for 10 seconds and error information will
flash, you can press STOP/SET to turn off the beeper and flash.
Error information
DESCRIPTION
DISPLAY
Over voltage
Output voltage over 2V of setup value for 2
seconds, S1500 turn off automatically and turn on
manually
On power off page, OVER voltage is
displayed
Over current
Output current over 2A of setup for 2 seconds,
S1500 turn off automatically and turn on manually
On power off page, OVER CURRENT is
displayed.
Over temperature
The heat sink temperature over 90℃for 2
seconds, S1500 turn off automatically, and turn on
automatically
On power off page, OVER TEMPERATURE
is displayed.
Short circuit
Output voltage is under 9.5V for 2 seconds and 3
times repeatedly, S1500 turn off automatically, and
turn on manually
On power off page, SHORT CIRCUIT is
displayed
Related parts
The following parts are similar to the S1500 and maybe of interest:
MODEL
DESCRIPTION
COMMENTS
S400
High efficiency wide input voltage PFC power supply
6~15V 25A 400W output
S600
High efficiency wide input voltage PFC power supply
10~18V 33A 600W output
S1200
High efficiency wide input voltage PFC power supply
12~24V 50A 1200W output
Warnings
◼Never leave the power supply unattended when it turn on. If any malfunction is observed,
please turn off the power supply as fast as possible.
◼Keep away the power supply from dust, damp, rain, heat direct sunshine and vibration. Do not
drop it.
◼The power supply should be set up on non-inflammable and non-conductive surface. Never

S1500
High efficiency wide input voltage
PFC programmable Power supply
90V~265VAC input
10V~30VDC output
60Amps 1500W max.
www.chargery.com page 8 total 8
place on a car seat, carpet or similar.
◼Keep all the inflammable volatile materials well away from operating area.
◼Do not attempt to charge any types of battery including below:
⚫Lead acid battery or VRLA
⚫NIMH/NICd battery pack
⚫Li-ion and lithium polymer battery
Version history
version
Output Voltage
Output Current
Beeper time on START
V1.2
10~25V
5~60A
5 Seconds
V2.0
10~30V
1~60A
1 second
Warranty and Service
Chargery Power Co., Ltd. as manufacture of R/C model power warrants S1500 power supply to be free
of defects in material and workmanship. This warranty is effective for 24 months from date of purchase.
If within the warranty period the customer is not satisfied with the products performance resulting from
a manufacturing defect, the accessory will be replaced or repaired. This warranty does not cover the
damage due to wear, misuse, incompetent handling or using of incorrect accessories.
Chargery Power Co., LTD.
Tel: [phone], fax: [phone]
Email: [e-mail]
Homepage: www.chargery.com
