Chariot CABRIOLET User manual

CABRIOLET
USER GUIDE
Cabriolet_Manual_English_100212.indd 1 12-10-31 2:35 PM

1 IntroductIon
1.0 Thank You 03
1.1 Manual Intended Use 04
1.2 Carrier Intended Use 04
1.3 Specications 04
2 Parts descrIPtIon
2.0 Included in the box 05
3 safety
3.0 Safety Introduction 06
3.1 Symbols and Instructions 06
3.2 General Safety Instructions 06
4 GettInG started
4.0 Unpacking Your Carrier 08
4.1 Included Components 08
4.2 Unfolding the Carrier 09
4.3 Folding the Carrier 09
4.4 Installing the Parking Brake 10
4.5 Installing the Wheels 10
4.6 Removing the Wheels 11
4.7 Installing the Handlebar 12
4.8 Installing a CTS™ Conversion Kit 12
5 use & features
5.0 Setting the Parking Brake 13
5.1 Using the Two-in One Cover 14
5.2 Adjusting the Padded Shoulder Harness 15
5.3 Child Placement and Seatbelt 16
5.4 Using the Safety Wrist Strap 17
5.5 Using the Sunscreen 17
5.6 Using the Side Vents 17
5.7 Storage 18
6 addItIonal InformatIon
6.0 Accessories 19
6.1 Service and Care 19
6.2 Storage 20
6.3 Wear and Tear 20
CONTENTS
C www.chariotcarriers.com 51100456
Cabriolet_Manual_English_100212.indd 2 12-10-31 2:35 PM

3
C www.chariotcarriers.com 51100456
1
INTRODUCTION
INTRODUCTION
Thank you for choosing a ChariotTM Cabriolet child carrier. This chassis is the key component of the world‘s premiere
Child Transport System (CTS). Your new CTS carrier offers superior quality, safety features and comfort.
PLEASE NOTE:
AllChariot™carriersaredesignedwiththeendconsumerinmindandtheirdesireformaximumexibility&
performance; in order to achieve this, the purchase of CTS conversion kit(s) is required allowing you to choose the
activity you desire while also eliminating the need to purchase several dedicated child carriers. The four Chariot™ CTS
Conversion Kits available for sale from your local dealer are:
CTS Strolling Kit CTS Jogging Kit CTS Bicycle Trailer Kit CTS Hiking Kit
Thule Child Transport Systems Ltd. retains all rights to this Owner’s Manual. No text, details, or illustrations from this
manual may be reproduced, distributed, or become the subject of unauthorized use for commercial purposes, nor may
they be made available to others.
Additional Manuals for using this carrier may be downloaded from www.chariotcarriers.com.
Great care has been taken in assembling this manual. Nevertheless, should you discover any errors, we would be
grateful if you could bring them to our attention.
North America Contact:
Thule Child Transport Systems Ltd.
105 - 5760 9th Street SE
Calgary, AB T2H 1Z9
Canada
Telephone:
1.800.262.8651
[email protected]
Europe Contact:
[email protected]
Cabriolet_Manual_English_100212.indd 3 12-10-31 2:35 PM

4
C www.chariotcarriers.com 51100456
1.1 manual Intended use
Who is this Manual intended for?
This Manual is intended for the purchaser and user
of the carrier, who is also responsible for keeping
it in proper condition, carrying out maintenance as
prescribed and performing repairs.
When using this carrier with the Bicycle Trailer Kit,
please also follow the owner’s manual of the bicycle
usedfortowingandthespecicationsthereregarding
the maximum allowable full load for the bicycle.
1.2 carrIer Intended use
Use as intended
The carrier is intended for use within the
performancerangesspeciedforthecarryingof
childrenindaylighthours,onsidewalks,lighttrafc
public roads, and smooth paths.
Luggage may also be carried in the storage bags
intended for that purpose, provided the children in
the carrier are not put at risk.
1.3 sPecIfIcatIons
If the child carrier is used in conditions of poor
visibility, at dusk or in the hours of darkness, it
ishighlyrecommendedtobettedwithasafety
approved working light set.
As part of the recommended use, you should also
follow this Owner’s Manual and comply with the
prescribed maintenance requirements.
Use not recommended
Any use that goes beyond the above is not
recommended.
Use not recommended is primarily the conveying of
people together with animals, use of this carrier on
rough off-road terrain, use for commercial purposes,
overloading, excessive speed and improper repair
of defects.
The manufacturer is not liable for damages arising
from use that is not recommended – this is at the
risk of the user.
Cabriolet
Maximum Load Carrying Capacity including passenger(s) 45 kg/100 lb
and cargo combined
Number of child(ren) 1 or 2
Dimensions without handlebars (Length x Width x Height) 107 x 81 x 110 cm
42 x 32 x 43.5 in
Dimensions folded (Length x Width x Height) 97 x 78 x 28 cm
38 x 31 x 11 in
Weight of child carrier without CTS™ conversion kits 10.7 kg/ 24 lb
Maximum body height of passenger(s) 111 cm / 44 in
Head / helmet must not stick out of the carrier frame
.......................................................................................................................................................................................................
.......................................................................................................................................................................................................
.......................................................................................................................................................................................................
.......................................................................................................................................................................................................
.......................................................................................................................................................................................................
INTRODUCTION
Cabriolet_Manual_English_100212.indd 4 12-10-31 2:35 PM

5
C www.chariotcarriers.com 51100456
a d
B
c
2
PARTS DESCRIPTION
Included
A. Cabriolet chassis
B. 2 - 20" Aluminum wheels
C. Parking Brake
D. Handlebar
E. 2 in 1 weather cover
(Not shown in photo)
e
PARTS DESCRIPTION
Cabriolet_Manual_English_100212.indd 5 12-10-31 2:35 PM

6
C www.chariotcarriers.com 51100456
3
SAFETY
The safe use of this child carrier is vital to the
enjoyment of it. For that reason it is extremely
important that you familiarize yourself with the
safety instructions in this manual and follow
them whenever you use this child carrier.
3.1 symBols and InstructIons
This owner’s manual uses warnings and notices
throughout to emphasize safety and optimal use
information.
3.2 General safety InstructIons
Read these instructions carefully before use and keep
them for future reference. Your child’s safety may be
affected if you do not follow these instructions.
• Neverleaveachildunattendedinthischildcarrier.
• Putontheparkbrakewheneveryouparkthis
child carrier.
• Donotcarryextrachildrenorbagsonthis
child carrier.
• Thischildcarrierwillbecomeunstableifthe
manufacturer’s recommended load is exceeded.
• Donotusewithchildrenwhoexceedtheweight
limitations.
• Whenusingthischildcarrierwithonlyonechild,the
child should be seated in the center seating position.
NOTICE
Notices provide additional instructions to make
using the product easier.
WARNING
Warnings provide instructions critical to the
safe use and operation of this child carrier.
Failure to follow these instructions could
result in an accident, potentially causing
serious injury or death to you and/or your
passenger(s).
SAFETY
Cabriolet_Manual_English_100212.indd 6 12-10-31 2:35 PM

7
C www.chariotcarriers.com 51100456
• Theuserofthischildcarriermustbeawareof
exposure hazards such as wind chill and heat
exhaustion, either by less active children in prolonged
exposure in colder temperatures, or by extended
periods in warmer temperatures without adequate
ventilation or hydration.
• Donotallowanyofthechildren’sbody,clothing,shoe
laces, or toys to come into contact with moving parts.
• Caremustbetakenwhenfoldingandunfoldingthis
childcarriertopreventngerentrapment.Ensure
children are clear of any moving parts, otherwise they
may be injured.
• Donotinstallacarseatoranyotherseatingdevicenot
approved by Thule Child Transport Systems Ltd. on this
child carrier.
• OnlyuseThuleChildTransportSystemsLtd.approved
rack products otherwise this child carrier will become
unstable if any other parcel bag or rack is used.
• Donotuseanyaccessoryproductswhicharenot
approved by Thule Child Transport Systems Ltd.
• Donotuseanycleaningsolventsonthischildcarrier,
clean only with mild soap and water.
• Makenomodicationstothischildcarrier.
• Donotusethischildcarrieraroundornearanopen
reorexposedame.
• AreectorthatcomplieswithCPSCregulationsshall
be visible on the rear of this child carrier when it is
used for cycling.
• Beforeeachride,ensuretheattachedchildcarrier
does not interfere with braking, pedaling, or steering of
the bicycle.
• Neverrideabicycleatnightwithoutadequatelighting.
Obey all local legal requirements for lighting.
SAFETY
WARNING
This product is not suitable for skating.
WARNING
This product is not suitable for running unless
a CTSTM Jogging Kit is attached.
Cabriolet_Manual_English_100212.indd 7 12-10-31 2:35 PM

8
C www.chariotcarriers.com 51100456
4
GETTING STARTED
4.0 unPackInG your carrIer
A. Opentheboxapsandremovethestaples.
B. Remove the handlebar from inside the box.
C. Lay the box on its side on a clean, sturdy surface.
D. Slide the carrier and wheels out of the box.
(See image 1)
E. Remove and discard all packaging materials
including the shipping box, the plastic bag, packing
foam, silica desiccant packs, product tags and
wheel packing discs.
4.1 Included comPonents
Verify that your carrier was packaged with the
following items:
• CabrioletChassis
• Two-in-OneCover(onChassis)
• Handlebar
• Two20inchWheels
• ParkingBrake
• Owner'sManual
NOTICE
This child carrier is not packaged with any
CTS™ conversion kits. These kits are sold and
packaged separately.
NOTICE
Store your carrier and its components in a safe
dry place so that when they are needed, they
are in the best possible condition.
GETTING STARTED
1
Cabriolet_Manual_English_100212.indd 8 12-10-31 2:35 PM

9
C www.chariotcarriers.com 51100456
4.2 unfoldInG the carrIer
A. Undo the fold locking strap.
B. With one hand on the upper frame and the other
hand on the lower frame, pull the two halves apart.
(See image 1)
C. With one hand on the upper frame and the other
hand on the back frame, pull the back frame
rearward until the auto-lock discs engage.
(See image 2)
D. Verifythatthecarrier'sframeislockedbygivingthe
back frame a push inwards.
4.3 foldInG the carrIer
A. With two hands, pull or release the auto-lock discs
on both sides of the back frame. With the locks
released, give the back frame a sharp push inwards.
(See image 3)
B. With one hand on the upper frame and the other
hand on the carrier axle, push the two halves together.
C. Redo the fold locking strap.
2
1 3
WARNING
Care must be taken when folding and
unfolding this child carrier to prevent nger
entrapment. Ensure children are clear of any
moving parts, otherwise they may be injured.
WARNING
Ensure that all the locking devices are engaged
before use.
GETTING STARTED
Cabriolet_Manual_English_100212.indd 9 12-10-31 2:35 PM

10
C www.chariotcarriers.com 51100456
A. Disengage the parking brake.
B. Insert a wheel axle into an axle socket.
(See image 3)
C. Press the wheel axle fully into the axle socket.
D. Verify that the wheel is securely attached to the
carrier by giving it a sharp pull.
E. Repeat for the other wheel.
F. Using a tire pressure gauge check the air pressure in
each tire. The minimum recommended tire pressure is
30 psi (2.1 bar) and the maximum is 35 psi (2.5 bar).
G. Ifairpressureistoolowineitheroneofthetiresll
them up using a bicycle tire pump.
4.5 InstallInG the Wheels
3
WARNING
Before each journey make sure that both of the
wheels are securely locked in the carrier axle.
GETTING STARTED
4.4 InstallInG the ParkInG Brake
A. Remove the wheels from the chassis.
B. Fold the chassis.
C. Lay the chassis on its roof on a clean sturdy surface.
D. With the screwdriver and 7/16" wrench remove the
locking nut and white nylon washer from the bolt on the
brake lever.
E. Insert the bolt along with the black bushing and brake
lever through the hole at the back of the chassis.
(See image 1)
F. Place the white nylon washer and the nut back onto
the bolt from inside the carrier and tighten it until one
screw thread is exposed.
G. With the wrench remove the locking nuts on both of the
bolts on the back corners of the chassis.
H. Insert the bolts on the back corners of the chassis
through the holes on the brake arms. (See image 2)
I. Place the locking nuts back onto the bolts on the back
corners of the chassis and tighten them until one thread
is exposed. (See image 2)
1
2
Cabriolet_Manual_English_100212.indd 10 12-10-31 2:35 PM

11
C www.chariotcarriers.com 51100456
4.6 removInG the Wheels
1
A. Disengage the parking brake.
B. Pull and hold the wheel release lever on one end of
the carrier axle. (See image 1)
C. Pull the wheel out of the carrier axle.
D. Repeat for the other wheel.
GETTING STARTED
Cabriolet_Manual_English_100212.indd 11 12-10-31 2:35 PM

12
C www.chariotcarriers.com 51100456
4.8 Install a cts™ conversIon kIt
A. Select a CTS™ conversion kit from the following:
• CTSStrollingKit
• CTSJoggingKit
• CTSBicycleTrailerKit
• CTSHikingKit
B. Install and use the selected kit according to the
instructions included with the CTS™ Conversion Kits.
GETTING STARTED
4.7 InstallInG the handleBar
A. Position the handlebar behind the carrier with the
handles pointing rearwards.
B. With both hands press and hold the spring pins in on
both ends of the handlebar. (See image 1)
C. Slide both ends of the handlebar into the upper frame of
the carrier. Allow the spring pins to pass inside the
upper frame. (See image 2)
D. Slide the handlebar into the upper frame until the spring
pins engage.
E. Verify that the handlebar is securely attached to the
carrier by giving it a sharp pull - it should not pull out.
F. To remove the handlebar; press both of the spring pins
through the upper frame and pull the handlebar out.
Repeat this process to remove the brake handle from the
handlebar.
2
1
WARNING
Any load attached to the handle affects the
stability of the child carrier.
NOTICE
The HeightRight™ adjustable handlebar has
two positions; high and low. Remove the
handlebar and turn it over to change between
these two positions.
Cabriolet_Manual_English_100212.indd 12 12-10-31 2:35 PM

13
C www.chariotcarriers.com 51100456
5
USE & FEATURES
5.0 settInG the ParkInG Brake
A. Grasp the red handle on the brake lever and swing it to
the left. (See image 1)
B. After engaging the brake always verify that the
parking brake is working - the carrier should not roll
forwards or backwards.
C. Grasp the red handle on the brake lever and swing
it to the right to release the parking brake.
(See image 2)
1 2
WARNING
Never leave your child unattended in this
child carrier.
The parking brake should always be engaged
during the loading and unloading of children.
USE & FEATURES
Cabriolet_Manual_English_100212.indd 13 12-10-31 2:35 PM

14
C www.chariotcarriers.com 51100456
5.1 usInG the tWo-In one cover
A. Toimprovetheairowinsidethecarrier;rollupthe
plastic window. Use the elastic rings at the top of
the cover to keep the window up.
B. To keep the elements out of the carrier; unroll the
plastic window. Use the velcro at the bottom of the
cover to keep the window closed.
C. To open the cover, release both straps on the front
corners of the carrier.
D. To close the cover, attach both straps on the front
corners of the carrier. (See image 1)
E. To remove the cover from the carrier; remove the
handlebar, open the cover, and slide the top of the
cover up, off of the upper frame.
F. To put the cover back on the carrier; remove the
handlebar and slide the holes at the top of the cover
back over the upper frame.
WARNING
The user of this child carrier must be aware of
exposure hazards such as wind chill and heat
exhaustion, either by less active children in
prolonged exposure in colder temperatures, or
by extended periods in warmer temperatures
without adequate ventilation or hydration.
1
USE & FEATURES
WARNING
When this child carrier is used as a cycle
trailer, the weather cover should be closed to
prevent debris from entering the carrier.
Cabriolet_Manual_English_100212.indd 14 12-10-31 2:35 PM

15
C www.chariotcarriers.com 51100456
5.2 adJustInG the Padded shoulder
harness
A. Undo the two buckles located at the top of the
padded shoulder harness. (See image 1)
B. Unbuckle the padded shoulder harness from the
crotch strap and remove it from the carrier.
C. Placethepaddedshoulderharnessonyourchild's
chest so that the Chariot logo is positioned over
their lower chest and the two upper straps are
pointed up. (See image 2)
D. Determine which loop is in line with the top of
yourchild'sshoulders.Iftheloopsontheupper
strapsarealreadyinlinewiththetopofyourchild's
shoulders skip to Step H.
E. Remove both of the buckles from the upper straps.
F. Increase or decrease the number of loops the
upper straps are fed through until the straps are
bothintheloopsinlinewiththetopofyourchild's
shoulders. (See image 3)
G. Put both of the buckles back onto the upper straps.
H. Buckle the padded shoulder harness back onto the
crotch strap.
2
1
3
WARNING
Always make sure you thread the belt
through correctly (see illustration above). If
this is not the case, the belt could slip out of
the buckle resulting in the seat belt failing in
which your passenger(s) could suffer serious
injury or death.
Whenever you thread the belt through again,
always give it a good pull to check that it
cannot be pulled out of the buckle.
USE & FEATURES
Cabriolet_Manual_English_100212.indd 15 12-10-31 2:35 PM

16
C www.chariotcarriers.com 51100456
5.3 chIld Placement and seatBelt
A. Engage the parking brake. (See image 1)
B. Open the two-in-one cover.
C. Adjust the shoulder harness. (See section 5.2)
D. Loosen all of the belt adjustments.
E. Undo the buckle on the waist belt.
F. Undo the two buckles located at the top of the
padded shoulder harness, leaving it attached to the
crotch belt.
G. Seat your child(ren). (See image 2)
H. Slide the shoulder belt height adjustment located
on the vertical web straps, in the seat back, to the
sameheightasyourchild(ren)'sshoulders.
(See image 3)
I. Lift up the shoulder harness and connect the
buckles over each shoulder. Be careful not to pinch
yourchild'sneck.
J. Adjust the system using the crotch strap and
shoulder length adjustments until the Chariot logo
located on the shoulder harness is positioned over
their lower chest.
K. Buckle the waist belt(s) around their hips. The waist
belt goes in front of the crotch belt and the buckle
should be centered. (See image 3)
L. Snugly tighten all belts.
NOTICE
When seating a single child in a Cabriolet always
seat the child in the center position, use the center
waist belt, remove one of the shoulder harnesses
and fasten the remaining shoulder harness to the
middle buckles.
WARNING
Always use the crotch strap in combination
with the waist belt.
This seat unit is not suitable for children under
6 months. Use a harness as soon as your
child can sit unaided.
Do not add a pad thicker than 10 mm.
Check that the seat unit attachment devices
are correctly engaged before use.
2
3
1
USE & FEATURES
Cabriolet_Manual_English_100212.indd 16 12-10-31 2:35 PM

17
C www.chariotcarriers.com 51100456
5.4 usInG the safety WrIst straP
A. Loop the free end of the safety wrist strap around
your wrist to prevent the child carrier from becoming
separated from you. (See image 1)
B. When not in use stow the free end of the safety wrist
strap inside the large cavity in the back of
the carrier.
5.5 usInG the sunscreen
A. To enclose the back of child carrier, roll the back
apdownthebackofthecarrier.Usethevelcroat
thebottomofthebackaptokeepitclosed.
B. To shade inside the child compartment; roll the back
apdownthefrontofthecarrier.Usethevelcroatthe
bottom of the sunscreen to keep it closed.
(See image 2)
C. To completely open up the front and back of the child
carrier,rollthebackapup.Usetheelasticringsat
thetopofthebackaptokeepitup.
5.6 usInG the sIde vents
A. Tofurtherimprovetheairowinsidethecarrier;pull
one or both of the side vents open. (See image 3)
B. To keep the elements out of the carrier; press the side
vents closed. Use the velcro along the edges to keep
the vents closed.
WARNING
Failure to use the safety wrist strap could
cause the carrier to become separated
from you resulting in an accident in which
your passenger(s) could suffer serious
injury or death.
1
3
2
USE & FEATURES
Cabriolet_Manual_English_100212.indd 17 12-10-31 2:35 PM

18
C www.chariotcarriers.com 51100456
WARNING
Do not carry extra children or bags on this
child carrier.
NOTICE
The maximum load capacity of the cargo bag is 4
kg (8.8 pounds).
The handlebar console accessory allows the
carrier to carry an additional 1 kg (2.2 pounds) on
the handlebar.
5.7 storaGe
Your carrier is equipped with the following storage
compartments:
A. One large cavity in the back. (See image 1)
B. Two small mesh pockets inside the carrier at
the front. (See image 2)
21
USE & FEATURES
Cabriolet_Manual_English_100212.indd 18 12-10-31 2:35 PM

19
C www.chariotcarriers.com 51100456
6
ADDITIONAL
INFORMATION
6.0 accessorIes
There are numerous accessories that are compatible
with your Chariot:
• HydrationCage
• ChariotCupHolder
• FenderKit
• JoggingBrake
• Axle-MountezHitchPartial
• ShimanoInternalHubHitchAdapter
• SRAMInternalHubHitchAdapter
• CargoRack
• InfantSling
• All-SeasonBuntingBag
• BabySupporter
• BabyBivy
• Multi-FunctionalHandlebarConsole
• StorageCover
• RainCover
Contact your local dealer or visit our website: www.
chariotcarriers.com for more information.
6.1 servIce and care
Regularly inspect your child carrier, CTS™ Conversion
Kit(s) and accessories for damage and signs of wear.
Metal Components
Check for any dents or cracks. Do not use the child
carrier if any metal components are cracked or damaged.
Fasteners
Regularly examine the child carrier to see if any of the
fasteners are bent, broken, missing or loose. Tighten any
loose fasteners and replace any damaged or missing
fasteners.
Fabric
Examine the fabric regularly for tears, worn spots or any
other signs of damage. Any holes in the fabric could allow
achild'shandtocomeintocontactwiththewheelsor
road surface.
Wheels
Clean the wheel axles and apply grease or oil to all
exposed moving parts. Have the wheels inspected and
serviced at least once a year.
It is highly recommended that you take your child carrier
into an authorized service provider once a year to keep it
in the best possible condition.
Regularly clean the child carrier with warm water and a
mild soapy solution. Never use harsh cleansers or solvents.
WARNING
The proper service and care of this child carrier
affects the performance and safety of it.
ADDITIONAL INFORMATION
Cabriolet_Manual_English_100212.indd 19 12-10-31 2:35 PM

20
6.2 storaGe
Store your child carrier, CTS conversion kit(s) and
accessories in a dry area out of direct sunlight. If
possible, hang the child carrier up off of the ground.
Before storing your child carrier, it should be dry to
prevent the growth of mold or bacteria. Do not store the
wheels in contact with the windows. Do not store the child
carrier coupled to a bicycle for long periods of time.
6.3 Wear and tear
This child carrier is very durable and allows you to
transport your child(ren) for long periods of time. It
is subject to wear and tear over time depending on
several factors.
Use and Milage
The more often this child carrier is used and the farther it
goes the more it will wear.
Service and Care
Keeping this child carrier clean and well maintained is an
important factor in keeping it in good condition.
Storage
Storing this child carrier properly will reduce the amount
of wear, especially to the fabric.
Type of Use
Hard cornering, fast acceleration and braking all
contribute to premature wear of various components
especially brakes and tires.
Weather
Various weather conditions affect individual components
differently. Direct sunlight prematurely wears the fabric,
windows and rubber wheels. Salt in the air or on the road
affectsthewheelrimsandfabricoor.Dirtandmudcan
get into moving parts and contribute to wear as well.
Extreme use of this carrier may lead to premature wear.
The way this child carrier is used and cared for will greatly
affect how quickly it wears.
ADDITIONAL INFORMATION
North America Contact:
Thule Child Transport Systems Ltd.
105 - 5760 9th Street SE
Calgary, AB T2H 1Z9
Canada
Telephone:
1.800.262.8651
[email protected]
Europe Contact:
[email protected]
Cabriolet_Manual_English_100212.indd 20 12-10-31 2:35 PM
