Chauvet DJ Freedom Par H9 IP User manual

User Manual

Table of Contents
Freedom Par H9 IP and H9 IPX4 User Manual Rev. 1
Table of Contents
1. Before You Begin ....................................................................... 1
What Is Included ........................................................................................... 1
Unpacking Instructions.................................................................................. 1
Claims ............................................................................................................................ 1
Text Conventions .......................................................................................... 1
Symbols ........................................................................................................ 1
Safety Notes.................................................................................................. 2
Battery Charge Notes.................................................................................... 2
FCC Compliance............................................................................................................ 3
RF Exposure Warning for North America and Australia................................................. 3
Disclaimer ..................................................................................................... 3
2. Introduction ................................................................................ 4
Product Overview.......................................................................................... 4
Product Dimensions ...................................................................................... 5
3. Setup ........................................................................................... 6
AC Power...................................................................................................... 6
Battery Power................................................................................................................. 6
Mounting ....................................................................................................... 7
Orientation...................................................................................................................... 7
Rigging ........................................................................................................................... 7
Accessories................................................................................................... 8
4. Operation .................................................................................... 9
Control Panel Operation................................................................................ 9
Menu Map ..................................................................................................... 9
DMX Configuration........................................................................................ 13
DMX Personality and Starting Address.......................................................................... 13
DMX Values .................................................................................................. 14
Standalone Configuration.............................................................................. 18
Preset Color Mode ......................................................................................................... 18
Fixed Color Mode........................................................................................................... 18
Custom Color Mixing...................................................................................................... 18
Automatic Programs....................................................................................................... 19
Sound Sensitivity............................................................................................................ 19
White Balance ................................................................................................................ 19
D-Fi Setting .................................................................................................................... 20
RF Setting ...................................................................................................................... 20
Run Time........................................................................................................................ 20
Dimmer Mode................................................................................................................. 20
Display Back Light.......................................................................................................... 20
Password ....................................................................................................................... 21
Product Information........................................................................................................ 21
Factory Reset................................................................................................................. 21
Master/Slave Mode ....................................................................................... 22
RFC Remote Control..................................................................................... 23
RFC Remote Control Operation..................................................................................... 23
5. Maintenance................................................................................ 24
Product Maintenance .................................................................................... 24
6. Technical Specifications ........................................................... 25
Contact Us ...................................................................................... 26
Warranty & Returns....................................................................................... 26

1
Freedom Par H9 IP and H9 IPX4 User Manual Rev. 1
Before You Begin
1. Before You Begin
What Is Included
Freedom Par H9 IP
Freedom Par H9 IPX4
Unpacking Instructions
Carefully unpack the product immediately and check the container to make sure all the parts are in the
package and are in good condition.
Claims
If the box or the contents (the product and included accessories) appear damaged from shipping, or show
signs of mishandling, notify the carrier immediately, not Chauvet. Failure to report damage to the carrier
immediately may invalidate the claim. Keep the box and contents for inspection.
For other issues, such as missing components or parts, damage not related to shipping, or concealed
damage, file a claim with Chauvet within 7 days of delivery.
Text Conventions
Symbols
• Freedom Par H9 IP
• External power supply
• Magnetic diffuser
• Quick Reference Guide
• 4 Freedom Par H9 IP products
• 4 magnetic diffusers
• Carry bag
•RFC
• Multi-charger
• Power cable
• Quick Reference Guide
Convention Meaning
1–512 A range of values
50/60 A set of values of which only one can be chosen
Settings A menu option not to be modified
<ENTER> A key to be pressed on the product’s control panel
ON A value to be entered or selected
Symbol Meaning
Electrical warning. Not following these instructions may cause electrical damage to
the product, accessories, or the user.
Critical installation, configuration, or operation information. Not following these
instructions may make the product not work, cause damage to the product, or cause
harm to the operator.
Important installation or configuration information. The product may not function
correctly if this information is not used.
Useful information.
!

2
Before You Begin
Freedom Par H9 IP and H9 IPX4 User Manual Rev. 1
Safety Notes
Battery Charge Notes
Rechargeable lithium-ion batteries are potentially hazardous and can present a serious FIRE HAZARD,
SERIOUS INJURY, and/or PROPERTY DAMAGE if damaged, defective, or improperly used.
■ALWAYS:
• Connect to a grounded circuit.
• Connect to operating voltages as specified on the product's spec sticker.
• Disconnect from power before replacing the fuse.
• Disconnect from its power source during periods of inactivity.
• Use a safety cable when suspending overhead.
• Heed all restrictions and warnings on the spec sticker.
• Mount in a location with at least 20 in (50 cm) of ventilation.
• Replace the fuse with the same type and rating..
■In the event of a serious operating problem, stop using immediately.
■DO NOT:
• Open this product or attempt any repairs. It contains no user-serviceable parts.
• Look at the light source when the product is on.
• Use if the power cord is crimped or damaged.
• Disconnect by pulling on the power cord.
• Allow flammable materials close to the product when it is operating.
• Touch the housing when it is on.
• Block any ventilation holes/slots in the housing.
• Connect to a dimmer or rheostat.
• Carry the product by its power cord.
• Operate in temperatures higher than 104°F (40°C).
• Expose to environments that exceed the Ingress Protection (IP) rating.
•Submerge.
• Expose to corrosive environmental conditions such as temperature, humidity, salinity,
pressure, radiation, or shock.
• Set this product on a flammable surface.
■ALWAYS:
♦Charge using a manufacturer-provided charger while the product is powered off.
♦Charge the battery in temperatures between 32°–95°F (0°–35°C).
♦Allow a depleted battery to charge for a few minutes before turning on the product. If the
battery is completely discharged, the device cannot be turned on immediately when the
charger is connected.
♦Keep at least 3 ft (1 m) distance to any heat source and away from flammable materials.
♦Keep the lid of any charging case open while charging.
♦Keep batteries away from children.
♦Store batteries between 40–60% charge.
♦Follow local regulations when disposing of batteries.
♦Replace with an authentic Chauvet battery.
■DO NOT:
♦Continue charging if the battery becomes hot, smokes, swells, or gives off an odor during
charging.
♦Leave the product unattended while charging.
♦Deplete the battery below 10%.
♦Charge the battery in a closed container.
♦Charge for more than 24 hours.

3
Freedom Par H9 IP and H9 IPX4 User Manual Rev. 1
Before You Begin
FCC Compliance
This device complies with Part 15 Part B of the FCC rules. Operation is subject to the following two
conditions:
1. This device may not cause harmful interference, and
2. This device must accept any interference received, including interference that may cause
undesired operation.
Any changes or modifications not expressly approved by the party responsible for compliance could void
the user’s authority to operate the equipment.
RF Exposure Warning for North America and Australia
Warning! This equipment complies with FCC radiation exposure limits set forth for an uncontrolled
environment. This equipment should be installed and operated with a minimum distance of 20 cm between
the radiator and the user. This transmitter must not be co-located or operating in conjunction with any other
antenna or transmitter.
Disclaimer
Chauvet believes that the information contained in this manual is accurate in all respects. However,
Chauvet assumes no responsibility and specifically disclaims any and all liability to any party for any loss,
damage or disruption caused by any errors or omissions in this document, whether such errors or
omissions result from negligence, accident or any other cause. Chauvet reserves the right to revise the
content of this document without any obligation to notify any person or company of such revision, however,
Chauvet has no obligation to make, and does not commit to make, any such revisions. Download the latest
version from www.chauvetdj.com.
The works of authorship contained in this manual, including, but not limited to, all designs, text, and images
are owned by Chauvet.
© Copyright 2023 Chauvet & Sons, LLC. All rights reserved.
Electronically published by Chauvet in the United States of America.
Chauvet, the Chauvet logo, and Freedom Par H9 IP and H9 IPX4 are registered trademarks or trademarks of
Chauvet & Sons LLC. (d/b/a Chauvet and Chauvet Lighting) in the United States and other countries. Other
company and product names and logos referred to herein may be trademarks of their respective companies.
Keep this User Manual for future use.

4
Introduction
Freedom Par H9 IP and H9 IPX4 User Manual Rev. 1
2. Introduction
Product Overview
Menu buttons
Kickstand
Power button
Kickstand
release
Display screen
DC
power in
Carry handle
Magnetic
diffuser
Freedom Par H9 IP
Freedom Par H9 IPX4
Freedom Par H9 (x4)
Custom foam case
RFC remote
RFC-XL remote (optional)
Gore valve

5
Freedom Par H9 IP and H9 IPX4 User Manual Rev. 1
Introduction
Product Dimensions
4.7 in
120 mm
4.9 in
126 mm
4.7 in
120 mm
4.9 in
125 mm
Freedom Par H9 IP
Freedom Par H9 IPX4
15.8 in
402 mm
19.8 in
503 mm
13.7 in
349 mm

6
Setup
Freedom Par H9 IP and H9 IPX4 User Manual Rev. 1
3. Setup
AC Power
The Freedom Par H9 IP has an external power supply and can work with an input voltage of 24 VDC, 50/60 Hz.
To determine the product’s power requirements (circuit breaker, power outlet, and wiring), use the current value
listed on the label affixed to the product’s back panel or refer to the product’s specifications chart. The listed
current rating indicates the product’s average current draw under normal conditions.
Battery Power
The Freedom Par H9 IP comes with a rechargeable lithium battery for cable-free operation.
Charging the Battery
The battery charges whenever the Freedom Par H9 IP is plugged into a power source using the included
power cord. If the product is plugged in and not in operation, make sure the product is turned off.
Battery Life Indicator
The indicators on the LED Menu Display show how much battery life remains available. The drawing below
provides a key to reading the battery life indicators.
Battery Run Time
• Always connect the product to a protected circuit (a circuit breaker or fuse).
Make sure the product has an appropriate electrical ground to avoid the risk of
electrocution or fire.
• To eliminate unnecessary wear and improve its lifespan, completely
disconnect the product from power via breaker or by unplugging it during
periods of non-use.
Never connect the product to a rheostat (variable resistor) or dimmer circuit, even if
the rheostat or dimmer channel serves only as a 0 to 100% switch.
• The LED indicator light will flash if units are overcharged.
• DO NOT use the Freedom Par H9 IP on full power mode (all LEDs at 100%) while
being charged/plugged into a power source, as the unit will get extremely hot.
Maximum Run Time Recharge Time
Up to 12 hours 3 hours
!
100% 75% 50% 25%

7
Freedom Par H9 IP and H9 IPX4 User Manual Rev. 1
Setup
Mounting
Before mounting the product, read and follow the safety recommendations indicated in the Safety Notes.
Orientation
The Freedom Par H9 IP may be mounted in any position; however, make sure adequate ventilation is
provided around the product.
Rigging
• Before deciding on a location for the product, always make sure there is easy access to the product
for maintenance and programming purposes.
• Make sure adequate ventilation is provided around the product.
• Mount the product on a structure or surface that can support the product's weight (see the Technical
Specifications for weight information).
• Always use a safety cable when mounting the product overhead. Mount the product securely to a
rigging point (e.g., an elevated platform or a truss).
• Use a mounting clamp of appropriate weight capacity when rigging the product onto a truss.
Mounting Diagram
Safety cable
(such as CH-05 from Chauvet)
Mounting clamp
(such as CLP-15 or CLP-15N
from Chauvet)

8
Setup
Freedom Par H9 IP and H9 IPX4 User Manual Rev. 1
Accessories
The Freedom Par Q9 comes with a removable magnetic diffuser and can be used with a sleeve (sold
separately). To attach or remove the magnetic diffuser and/or the sleeve from the fixture, see the diagram below:
The Freedom Par H9 IPX4 comes in an easily transportable gear bag with custom foam:
Magnetic diffuser
Sleeve
Custom foam
Gear bag
