User Manual

Table of Contents
4BAR LT BT User Manual Rev. 1
TABLE OF CONTENTS
1. Before You Begin ......................................................................................... 1
What Is Included ...................................................................................................... 1
Unpacking Instructions............................................................................................. 1
Claims ............................................................................................................................ 1
Text Conventions ..................................................................................................... 1
Symbols ................................................................................................................... 1
Disclaimer ................................................................................................................ 1
Intellectual Property ................................................................................................. 1
Safety Notes............................................................................................................. 2
2. Introduction................................................................................................... 3
Product Overview..................................................................................................... 3
Product Dimensions................................................................................................. 3
3. Setup.............................................................................................................. 4
AC Power ................................................................................................................. 4
Fuse Replacement ......................................................................................................... 4
Mounting .................................................................................................................. 5
Orientation...................................................................................................................... 5
Rigging ........................................................................................................................... 5
4. Operation....................................................................................................... 6
Control Panel Operation........................................................................................... 6
Menu Map ................................................................................................................ 6
Configuration (DMX) ................................................................................................ 6
Starting Address............................................................................................................. 6
D-Fi USB Connectivity ............................................................................................. 7
Configuration (D-Fi USB) ............................................................................................... 7
D-Fi USB DIP Switch Channels ...................................................................................... 7
DMX Channel Assignments and Values .................................................................. 8
15Ch............................................................................................................................... 8
5Ch................................................................................................................................. 8
3Ch................................................................................................................................. 8
Configuration (Bluetooth) ......................................................................................... 9
Configuration (Standalone) ...................................................................................... 9
Automatic Programs....................................................................................................... 9
Auto-Program Speed ...................................................................................................... 9
Sound-Active Mode........................................................................................................ 9
Preset Color Mode ......................................................................................................... 9
Custom Color Mixing...................................................................................................... 9
Dimmer........................................................................................................................... 9
IRC-6 Infrared Remote Control ................................................................................ 10
IRC-6 Operation ............................................................................................................. 10
Footswitch Operation ............................................................................................... 11
Master/Slave Mode (Wired) ..................................................................................... 12
Master/Slave Mode (D-Fi USB)................................................................................ 12
5. Maintenance.................................................................................................. 13
Product Maintenance ............................................................................................... 13
6. Technical Specifications.............................................................................. 14
Returns.............................................................................................................. 15
Contact Us......................................................................................................... 16

Page 1 of 16
4BAR LT BT User Manual Rev. 1
Before You Begin
1. Before You Begin
What Is Included
Unpacking Instructions
Carefully unpack the product immediately and check the container to make sure all the parts are in the
package and are in good condition.
Claims
If the box or the contents (the product and included accessories) appear damaged from shipping, or show
signs of mishandling, notify the carrier immediately, not Chauvet. Failure to report damage to the carrier
immediately may invalidate your claim. In addition, keep the box and contents for inspection.
For other issues, such as missing components or parts, damage not related to shipping, or concealed
damage, file a claim with Chauvet within 7 days of delivery.
Text Conventions
Symbols
Disclaimer
Chauvet believes that the information contained in this manual is accurate in all respects. However,
Chauvet assumes no responsibility and specifically disclaims any and all liability to any party for any loss,
damage or disruption caused by any errors or omissions in this document, whether such errors or
omissions result from negligence, accident or any other cause. Chauvet reserves the right to revise the
content of this document without any obligation to notify any person or company of such revision, however,
Chauvet has no obligation to make, and does not commit to make, any such revisions. Download the latest
version from www.chauvetdj.com.
Intellectual Property
The works of authorship contained in this manual, including, but not limited to, all design, text and images
are owned by Chauvet.
© Copyright 2018 Chauvet & Sons, LLC. All rights reserved.
Electronically published by Chauvet in the United States of America.
CHAUVET, the Chauvet logo, and 4BAR LT BT are registered trademarks or trademarks of Chauvet &
Sons LLC (d/b/a Chauvet and Chauvet Lighting) in the United States and other countries. Other company
and product names and logos referred to herein may be trademarks of their respective companies.
•4BAR LT BT
• Power Cord
•Carrying Bag
•Tripod
• Footswitch
• Hanging Brackets
• Quick Reference Guide
Convention Meaning
1–512 A range of values
50/60 A set of values of which only one can be chosen
Settings A menu option not to be modified
<ENTER> A key to be pressed on the product’s control panel
ON A value to be entered or selected
Symbol Meaning
Critical installation, configuration, or operation information. Not following these
instructions may make the product not work, cause damage to the product, or cause
harm to the operator.
Important installation or configuration information. The product may not function
correctly if this information is not used.
Useful information.

Page 2 of 16
Before You Begin
4BAR LT BT User Manual Rev. 1
Safety Notes
• This product is not intended for permanent installation.
• Always connect the product to a grounded circuit to avoid the risk of electrocution.
• Always disconnect the product from the power source before cleaning or replacing the fuse.
• Avoid direct eye exposure to the light source while the product is on.
• Make sure the power cord is not crimped or damaged.
• Never disconnect the product from power by pulling or tugging on the cord.
• If mounting the product overhead, always secure to a fastening device using a safety cable.
• Make sure there are no flammable materials close to the product when operating.
• Do not touch the product’s housing when operating because it may be very hot.
• The voltage of the outlet to which you are connecting this product must be within the range
stated on the decal or rear panel of the product.
• The product is for indoor use only! (IP20) To prevent risk of fire or shock, do not expose the
product to rain or moisture.
• Always install the product in a location with adequate ventilation, at least 20 in (50 cm) from
adjacent surfaces.
• Be sure that no ventilation slots on the product’s housing are blocked.
• Never connect the product to a dimmer or rheostat.
• Make sure to replace the fuse with another of the same type and rating.
• Never carry the product from the power cord or any moving part. Always use the handles.
• The maximum ambient temperature is 104 °F (40 °C). Do not operate this product at higher
temperatures.
• In the event of a serious operating problem, stop using the product immediately.
• Do not open this product. It contains no user-serviceable parts.
• To eliminate unnecessary wear and improve its lifespan, during periods of non-use completely
disconnect the product from power via breaker or by unplugging it.
Keep this User Manual for future use. If the product is sold to someone else, be sure that they
also receive this document.

Page 3 of 16
4BAR LT BT User Manual Rev. 1
Introduction
2. Introduction
Product Overview
Product Dimensions
WARNING! DO NOT plug anything other than a D-Fi USB into the USB port. Doing so may
cause damage to the product.
DMX
In/Out
Fuse
Holder
Power
In
Menu
Buttons
LED
Display
D-Fi
USB
Port
IR Sensor
Sensitivity
Knob Microphone IR Sensor
10.8 in
274.3 mm
3.7 in
95 mm
36.1 in
918.1 mm

Page 4 of 16
Setup
4BAR LT BT User Manual Rev. 1
3. Setup
AC Power
The 4BAR LT BT has an auto-ranging power supply and it can work with an input voltage range of 100 to
240 VAC, 50/60 Hz.
To determine the product’s power requirements (circuit breaker, power outlet, and wiring), use the current
value listed on the label affixed to the product’s back panel, or refer to the product’s specifications chart.
The listed current rating indicates the product’s average current draw under normal conditions.
Fuse Replacement
1. Disconnect the product from power.
2. Wedge the tip of a flat-head screwdriver into the slot of the fuse holder.
3. Pry the fuse holder out of the housing.
4. Remove the blown fuse from the holder and replace with a fuse of the exact same type and rating.
5. Insert the fuse holder back in place and reconnect power.
• Always connect the product to a protected circuit (a circuit breaker or fuse). Make sure
the product has an appropriate electrical ground to avoid the risk of electrocution or
fire.
• To eliminate unnecessary wear and improve its lifespan, during periods of non-use
completely disconnect the product from power via breaker or by unplugging it.
Never connect the product to a rheostat (variable resistor) or dimmer circuit, even if the
rheostat or dimmer channel serves only as a 0 to 100% switch.
Disconnect the product from the power outlet before replacing the fuse.
Safety cap
Spare fuse holder
(inside safety cap)
Installed fuse
(held by plastic clip)

Page 5 of 16
4BAR LT BT User Manual Rev. 1
Setup
Mounting
Before mounting the product, read and follow the safety recommendations indicated in the Safety Notes.
Orientation
The 4BAR LT BT may be mounted in any position; however, make sure adequate ventilation is provided
around the product.
Rigging
• Before deciding on a location, always make sure there is easy access to the product for
maintenance and programming.
• Make sure adequate ventilation is provided around the product.
• Make sure that the structure or surface onto which you are mounting the product can support the
product’s weight. (see the Technical Specifications)
• When mounting the product overhead, always use a safety cable. Mount the product securely to a
rigging point, whether an elevated platform or a truss.
• When rigging the product onto a truss, use a mounting clamp of appropriate weight capacity.
• When mounting the product on the floor, make sure that the product and cables are away from
people and vehicles.
Mounting Diagram
Tripod Adjustment Knobs
Safety Cable
(such as CH-05 from
Chauvet)
Mounting Clamp (x2)
(such as CLP-15 from
Chauvet)
Pod Pan Adjustment
Knob (x4)
Hanging Bracket (x2)
Tripod Insertion Point
Pod Tilt Adjustment
Knob (x2 per pod)
Bracket Adjustment
Knob (x2)
Clamp Hanging
Bolt (x2)

Page 6 of 16
Operation
4BAR LT BT User Manual Rev. 1
4. Operation
Control Panel Operation
To access the control panel functions, use the four buttons located underneath the display. Please refer to
the Product Overview to see the button locations on the control panel.
Menu Map
*The Bluetooth® word mark and logos are registered trademarks owned by the Bluetooth SIG, Inc. and
any use of such marks by Chauvet & Sons, LLC is under license. Other trademarks and trade names are
those of their respective owners.
Configuration (DMX)
The 4BAR LT BT works with a DMX controller. Information about DMX is in the CHAUVET DMX Primer,
which is available from the Chauvet website http://www.chauvetlighting.com/downloads/
DMX_Primer_rev05_WO.pdf.
Starting Address
When selecting a starting DMX address, always consider the number of DMX channels the selected DMX
mode uses. If you choose a starting address that is too high, you could restrict the access to some of the
product’s channels.
The 4BAR LT BT uses up to 15 DMX channels, which defines the highest configurable address as 498.
If you are not familiar with the DMX protocol, download the DMX Primer from www.chauvetdj.com.
To select the starting address, do the following:
1. Press <MENU> repeatedly until 3Ch, 5Ch, or 15Ch shows on the display.
2. Press <ENTER>.
3. Use <UP> or <DOWN> to select the starting address, from d 1–510.
4. Press <ENTER>.
Button Function
<MENU> Exits from the current menu or function
<UP> Navigates upwards through the menu list or increases a selected numeric value
<DOWN> Navigates downwards through the menu list or decreases a selected numeric value
<ENTER> Enables the currently displayed menu or sets a selected value into the selected function
Main Level Programming Levels Description
DMX Mode
3Ch
d 1–510
3-channel DMX mode
5Ch 5-channel DMX mode
15Ch 15-channel DMX mode
Static Colors C-- C 1–19 Static colors
Automatic
Programs P-- P 1–8 Automatic programs
Auto Speed S-- S. 1–100 Program speed for P 1–8
Dimmer d-- L. 1–255 Dimmer
Sound-
Active Mode Snd Snd1–8 Sound-active programs
Custom
Color Mixing u--
r. 0–255 Custom static colors
Combine red, green, and blue
G. 0–255
b. 0–255
S. 0–100 Strobe rate
Bluetooth
Mode* bLE _ _ _ _ _ Bluetooth control mode, displays Bluetooth ID
Control
Mode SEt
ir on Turns infrared on or off
oFF
out SLAV Enable Master/Slave with other BT products
dMX Enable Master/Slave with non-BT products

Page 7 of 16
4BAR LT BT User Manual Rev. 1
Operation
D-Fi USB Connectivity
The 4BAR LT BT is able to become a D-Fi wireless receiver/transmitter with the use of the D-Fi USB from
Chauvet DJ. Simply set the product's DMX Personality and DMX Address, set the DIP switch D-Fi
receiving/transmitting channel, then plug it into the D-Fi USB port.
Configuration (D-Fi USB)
1. Set the DMX Personality and DMX address on the 4BAR LT BT.
2. Use the Chart provided to set BOTH:
• the Channel, and then
• The Receiving or Transmitting option
NOTE: DIP Switch 5 is for Transmitting OR Receiving, please choose carefully.
D-Fi USB DIP Switch Channels
WARNING! DO NOT plug anything other than a D-Fi USB into the USB port. Doing so may
cause damage to the product.
Once plugged in, the D-Fi USB will take over the product. Wired DMX and manual display
control / menu buttons will be unavailable until you unplug the D-Fi USB. The priority
levels are:
1. D-Fi USB
2. Wired DMX
3. Manual Digital Display/Menu Buttons
1234T/R
1234T/R

Page 8 of 16
Operation
4BAR LT BT User Manual Rev. 1
DMX Channel Assignments and Values
15Ch
5Ch
3Ch
Channel Function Value Percent/Setting
1 Auto Programs
000  009 No function
010  029 Auto program 1
030  049 Auto program 2
050  069 Auto program 3
070  089 Auto program 4
090  109 Auto program 5
110  129 Auto program 6
130  149 Auto program 7
150  169 Auto program 8
170  189 Auto program 9
190  209 Auto program 10
210  229 Auto program 11
230  249 Auto program 12
250  255 Sound-active program
2 Dimmer 000  255 0–100%
3
Strobe
(when Ch. 1 is 000  009)
000  009 No function
010  255 Strobe, slow to fast
Auto Speed
(when Ch. 1 is 010  249) 000  255 Program speed, slow to fast
Sound Sensitivity
(when Ch. 1 is 250  255)
000  010 Sound sensitivity off
011  255 Sound sensitivity on
4 Red 1 000  255 0–100%
5 Green 1 000  255 0–100%
6 Blue 1 000  255 0–100%
7 Red 2 000  255 0–100%
8 Green 2 000  255 0–100%
9 Blue 2 000  255 0–100%
10 Red 3 000  255 0–100%
11 Green 3 000  255 0–100%
12 Blue 3 000  255 0–100%
13 Red 4 000  255 0–100%
14 Green 4 000  255 0–100%
15 Blue 4 000  255 0–100%
Channel Function Value Percent/Setting
1 Red 000  255 0–100%
2 Green 000  255 0–100%
3Blue 000  255 0–100%
4 Dimmer 000  255 0–100%
5 Strobe 000  015 No function
016  255 Strobe, slow to fast
Channel Function Value Percent/Setting
1 Red 000  255 0–100%
2 Green 000  255 0–100%
3Blue 000  255 0–100%

Page 9 of 16
4BAR LT BT User Manual Rev. 1
Operation
Configuration (Bluetooth)
The 4BAR LT BT can be operated with the BTAir application over a Bluetooth connection.
1. Download and install the BTAir app from your preferred app store.
2. Press <MENU> repeatedly until bLE shows on the display.
3. Press <ENTER>.
4. The app will find and pair automatically to all the BT series products within range.
Configuration (Standalone)
Set the product in one of the standalone modes to control without a DMX controller.
Automatic Programs
To run the 4BAR LT BT in automatic mode, follow the instructions below.
1. Press <MENU> repeatedly until P-- shows on the display.
2. Press <ENTER>.
3. Use <UP> or <DOWN> to select and automatic program, from P 1–8.
4. Press <ENTER>.
Auto-Program Speed
To change the auto-program speed on the 4BAR LT BT, do the following:
1. Press <MENU> repeatedly until S-- shows on the display.
2. Use <UP> or <DOWN> to increase or decrease the program speed, from S. 1–100.
3. Press <ENTER>. The product will return to Auto mode.
Sound-Active Mode
To run the 4BAR LT BT in sound-active mode, follow the instructions below.
1. Press <MENU> repeatedly until Snd shows on the display.
2. Press <ENTER>.
3. Use <UP> or <DOWN> to select a sound-active program, from Snd1–8.
4. Press <ENTER>.
Preset Color Mode
To run the 4BAR LT BT on a static color, do the following:
1. Press <MENU> repeatedly until C-- shows on the display.
2. Press <ENTER>.
3. Use <UP> or <DOWN> to select a static color, from C 1–19.
4. Press <ENTER>.
Custom Color Mixing
To custom mix a static color, follow the instructions below.
1. Press <MENU> repeatedly until u-- shows on the display.
2. Press <ENTER> and one of the following will show on the display:
•r. _ _ _ (red)
•G. _ _ _ (green)
•b. _ _ _ (blue)
•S. _ _ _(strobe rate)
3. Press <ENTER> to cycle through the options.
4. Use <UP> or <DOWN> to increase or decrease the selected value, from 0–255 (for red, green, or
blue) or from 0–100 (for strobe rate).
• Strobe rate - 0: no function, 1–99: slow to fast, 100: sound-active.
5. Repeat steps 3 and 4 until the color is set as desired.
Dimmer
To adjust the output level of the 4BAR LT BT, do the following:
1. Press <MENU> repeatedly until d-- shows on the display.
2. Press <ENTER>.
3. Use <UP> or <DOWN> to increase or decrease the dimmer value, from L. 1–255.
4. Press <ENTER>.
Never connect a product that is operating in any standalone mode to a DMX string
connected to a DMX controller. Products in standalone mode may transmit DMX signals
that could interfere with the DMX signals from the controller.
The product will only respond to low frequencies of music (bass and drums).

Page 10 of 16
Operation
4BAR LT BT User Manual Rev. 1
IRC-6 Infrared Remote Control
The 4BAR LT BT is compatible with the IRC-6 infrared remote control from Chauvet. To set the 4BAR LT
BT to IR mode, follow the instructions below:
1. Press <MENU> repeatedly until SEt shows on the display.
2. Press <ENTER>.
3. Use <UP> or <DOWN> to select ir.
4. Press <ENTER>.
5. Press <UP> or <DOWN> to select on or oFF.
6. Press <ENTER>.
IRC-6 Operation
Automatic Mode
Automatic mode will enable you to run the automatic programs on the product.
To turn on Automatic mode:
1. Press <AUTO> on the IRC-6.
2. Press <+> or <–> to choose between the different auto programs, or press
<AUTO> to cycle through them.
To select a fading program:
1. Press <FADE> on the IRC-6.
2. Press <FADE> to cycle programs 5–8.
To adjust the speed of the automatic program:
1. Press <SPEED> on the IRC-6.
2. Press <+> or <–> to increase or decrease the speed of the program.
Sound-Active Mode
Sound-Active mode will enable the product to respond to the music.
To turn on Sound-Active mode:
1. Press <SOUND> on the IRC-6.
2. Press <+> or <–> to choose between the different sound-active programs,
or press <SOUND> to cycle through them.
Manual Color Control
To choose a specific color with the IRC-6:
1. Press any number between <0>~<9> to choose a preset color.
To manually control the RGB percentage:
1. Press <R> (red), <G> (green), or <B> (blue) to choose your color.
2. Press <+> or <–> to increase or decrease the value of each color.
•Pressing <R>, <G>, or <B> more than once will toggle that color between
255 and 0.
•Pressing <UV/P> more than once will toggle red and blue between 255 and
0. Green will stay at 0.
•Pressing <W> more than once will toggle red, green, and blue between 255
and 0.
To activate or deactivate strobing:
1. Press <STROBE> on the IRC-6.
2. Press <+> or <–> to increase or decrease the strobe rate.
Blackout
To black out the lights:
1. Press <BLACK OUT> on the IRC-6.
This will turn off all the lights until the button is pressed again.
NOTE: The IRC-6 will not respond to any inputs when Black Out is activated. If the
remote does not respond when a button is pressed, try pressing <BLACK OUT>.
You may have inadvertently activated Black Out.
BLACK
OUT AUTO SOUND
SENSI-
TIVITY
SPEEDSTROBE
%MANUAL FADE
RGB
WUVA
+ 0
-
123
654
789

Page 11 of 16
4BAR LT BT User Manual Rev. 1
Operation
Footswitch Operation
The included footswitch provides quick access to preset colors and programs.
To use the footswitch:
1. Connect the product to power.
2. Connect the footswitch to the 4BAR LT BT with the attached 4-pin cable.
3. Press the left pedal (Programs) to activate control. When working, the product will output white.
4. Use the chart below to activate the desired function.
To disconnect the footswitch:
1. Unplug the footswitch from the 4BAR LT BT.
2. Disconnect the product from power.
3. Reconnect the product to power to operate without the footswitch.
Pedal Action Function
Left
(Programs)
Tap pedal to activate, then
tap to cycle through
functions
White
Red
Green
Blue
Yellow
Magenta
Cyan
Automatic program (snap)
Automatic program (fade)
Right
(Blackout)
Tap Blackout
Press and Hold Fade to/from blackout
Both Tap Sound-active program
Press and Hold Strobe on
The 4BAR LT BT footswitch will work properly in any mode. No settings need to be
modified before using the footswitch.

Page 12 of 16
Operation
4BAR LT BT User Manual Rev. 1
Master/Slave Mode (Wired)
The Master/Slave mode allows a single 4BAR LT BT product (the “master”) to control the actions of one or
more 4BAR LT BT products (the “slaves”) without the need of a DMX controller. The master product will be
set to operate in Stand-Alone or with the IRC-6, while the slave products will be set to operate in Slave
mode. Once set and connected, the slave products will operate in unison with the master product.
Configure the products as indicated below.
Slave products:
1. Press <MENU> repeatedly until
3Ch shows on the display.
2. Press <ENTER>.
3. Set the DMX address to d 1.
4. Connect the DMX input of the first slave product to the DMX output of the master product.
5. Connect the DMX input of the subsequent slave products to the DMX output of the previous slave
product.
6. Finish setting and connecting all the slave products.
Master product:
1. Press <MENU> repeatedly until SEt shows on the display.
2. Press <ENTER>.
3. Use <UP> or <DOWN> to select out.
4. Press <ENTER>.
5. Press <UP> or <DOWN> to select dMX (to Master/Slave with non-BT products) or SLAV (to
Master/Slave with other BT products).
6. Press <ENTER>.
7. Set the master product to operate in Stand-Alone or IR mode.
8. Make the master product the first product in the DMX daisy chain.
Master/Slave Mode (D-Fi USB)
The D-Fi USB allows a single 4BAR LT BT product (the “master”) to control the actions of one or more
4BAR LT BT products (the “slaves”) without the need of a DMX controller or DMX cables. The master
(transmitter) product will be set to operate in Stand-Alone mode, while the slave (receiver) products will be
set to operate in Slave mode. Once set and connected, the slave products will operate in unison with the
master product.
Configure the products as indicated below.
Slave products:
1. Press <MENU> repeatedly until
3Ch shows on the display.
2. Press <ENTER> to accept.
3. Set the DMX address to d 1.
4. Set the D-Fi USB to receive on a specific channel, 1–16.
5. Plug in the D-Fi USB.
6. Finish setting and connecting all the slave products.
Master product:
1. Press <MENU> repeatedly until SEt shows on the display.
2. Press <ENTER>.
3. Use <UP> or <DOWN> to select out.
4. Press <ENTER>.
5. Press <UP> or <DOWN> to select dMX (to Master/Slave with non-BT products) or SLAV (to
Master/Slave with other BT products).
1. Press <ENTER>.
2. Set the master product to operate in Stand-Alone mode.
3. Set the D-Fi USB to transmit on the D-Fi channel the slaves are receiving on.
4. Plug in the D-Fi USB.
• Configure all the slave products before connecting the master to the daisy chain.
• Never connect a DMX controller to a DMX string configured for Master/Slave operation
because the controller may interfere with the signals from the master.
• Do not connect more than 31 slaves to the master.
• All products must be set to the same DMX personality, DMX address, and D-Fi channel.
• Configure all the slave products before configuring the master to transmit.
• Never connect a DMX controller to a D-Fi channel configured for Master/Slave operation
because the controller may interfere with the signals from the master.

Page 13 of 16
4BAR LT BT User Manual Rev. 1
Maintenance
5. Maintenance
Product Maintenance
Dust build-up reduces light output performance and can cause overheating. This can lead to reduction of
the light source’s life and/or mechanical wear. To maintain optimum performance and minimize wear, clean
your lighting products at least twice a month. However, be aware that usage and environmental conditions
could be contributing factors to increase the cleaning frequency.
To clean the product, follow the instructions below:
1. Unplug the product from power.
2. Wait until the product is at room temperature.
3. Use a vacuum (or dry compressed air) and a soft brush to remove dust collected on the external
surface/vents.
4. Clean all transparent surfaces with a mild soap solution, ammonia-free glass cleaner, or isopropyl
alcohol.
5. Apply the solution directly to a soft, lint free cotton cloth or a lens cleaning tissue.
6. Softly drag any dirt or grime to the outside of the transparent surface.
7. Gently polish the transparent surfaces until they are free of haze and lint.
Always dry the transparent surfaces carefully after cleaning them.

Page 14 of 16
Technical Specifications
4BAR LT BT User Manual Rev. 1
6. Technical Specifications
Dimensions and Weight
Note: Dimensions in inches are rounded.
Power
Light Source
Photometrics
Thermal
DMX
Ordering
Length Width Height Weight
36.1 in (918.1 mm) 3.7 in (95 mm) 10.8 in (274.3 mm) 7.8 lb (3.5 kg)
Power Supply Type Range Voltage Selection
Switching (internal) 100 to 240 VAC, 50/60 Hz Auto-ranging
Parameter 120 V, 60 Hz 230 V, 50 Hz
Consumption 47 W 45 W
Operating Current 0.7 A 0.4 A
Fuse T 1.6 A, 250 V T 1.6 A, 250 V
Power I/O U.S./Worldwide UK/Europe
Power input connector IEC IEC
Power Cord plug Edison (U.S.) Local Plug
Type Color Quantity Power Current Lifespan
LED Tri-color RGB 12 3 W 1 A 50,000 hours
Strobe Rate Beam Angle Field Angle Illuminance @ 2 m
0 to 22 Hz 12° 21° 2,382 lux (per pod)
Maximum External Temperature Cooling System
104 °F (40 °C) Convection
I/O Connector Channel Range
3-pin XLR 3, 5 or 15
Product Name Item Code UPC Number
4BAR LT BT 10031522 781462218706

Page 15 of 16
4BAR LT BT User Manual Rev. 1
Returns
Returns
In case you need to get support or return a product:
• If you are located in the U.S., contact Chauvet World Headquarters.
• If you are located in the UK or Ireland, contact Chauvet Europe Ltd.
• If you are located in Benelux, contact Chauvet Europe BVBA.
• If you are located in France, contact Chauvet France.
• If you are located in Germany, contact Chauvet Germany.
• If you are located in Mexico, contact Chauvet Mexico.
• If you are located in any other country, DO NOT contact Chauvet. Instead, contact your local
distributor. See www.chauvetdj.com for distributors outside the U.S., UK, Ireland, Benelux, France,
Germany, or Mexico.
Call the corresponding Chauvet Technical Support office and request a Return Merchandise Authorization
(RMA) number before shipping the product. Be prepared to provide the model number, serial number, and
a brief description of the cause for the return.
To submit a service request online, go to www.chauvetdj.com/service-request.
Send the merchandise prepaid, in its original box, and with its original packing and accessories. Chauvet
will not issue call tags.
Clearly label the package with the RMA number. Chauvet will refuse any product returned without an RMA
number.
Before sending the product, clearly write the following information on a piece of paper and place it inside
the box:
• Your name
• Your address
• Your phone number
•RMA number
• A brief description of the problem
Be sure to pack the product properly. Any shipping damage resulting from inadequate packaging will be
your responsibility. FedEx packing or double-boxing are recommended.
If you are located outside the U.S., UK, Ireland, Benelux, France, Germany, or Mexico,
contact your distributor of record and follow their instructions on how to return Chauvet
products to them. Visit our website www.chauvetdj.com for contact details.
Write the RMA number on a properly affixed label. DO NOT write the RMA number directly
on the box.
Chauvet reserves the right to use its own discretion to repair or replace returned
product(s).

Page 16 of 16
Contact Us
4BAR LT BT User Manual Rev. 1
Contact Us
Outside the U.S., U.K., Ireland, Benelux, France, Germany, or Mexico, contact the dealer of record.
Follow the instructions to request support or to return a product. Visit our website for contact details.
General Information Technical Support
Chauvet World Headquarters
Address: 5200 NW 108th Ave. Voice: [phone]
Sunrise, FL 33351 Fax: [phone]
Voice: [phone] Email: [email protected]
Fax: [phone]
Toll Free: [phone] Website: www.chauvetdj.com
Chauvet Europe Ltd
Address: Unit 1C Email: [email protected]
Brookhill Road Industrial Estate
Pinxton, Nottingham, UK Website: www.chauvetdj.eu
NG16 6NT
Voice: [phone]
Fax: [phone]
Chauvet Europe BVBA
Address: Stokstraat 18 Email: BNLte[email protected]
9770 Kruishoutem
Belgium Website: www.chauvetdj.eu
Voice: [phone]
Chauvet France
Address: 3, Rue Ampère
91380 Chilly-Mazarin
Email: [email protected]
France Website: www.chauvetdj.eu
Voice: [phone]
Chauvet Germany
Address: Bruno-Bürgel-Str. 11
28759 Bremen
Email: [email protected]
Germany Website: www.chauvetdj.eu
Voice: [phone]
Chauvet Mexico
Address: Av. de las Partidas 34 - 3B
(Entrance by Calle 2)
Email: [email protected]
Zona Industrial Lerma Website: www.chauvetdj.mx
Lerma, Edo. de México, CP 52000
Voice: [phone]
