Chauvet Professional Well STX 180 User manual

USER MANUAL

WELL STX 180 User Manual Rev. 1
Edition Notes
The WELL STX 180 User Manual includes a description, safety precautions, installation, programming,
operation and maintenance instructions for the WELL STX 180 as of the release date of this edition.
Trademarks
CHAUVET, the Chauvet logo and WELL STX 180 are registered trademarks or trademarks of Chauvet &
Sons, LLC (d/b/a Chauvet and Chauvet Lighting) in the United States and other countries. Other company
and product names and logos referred to herein may be trademarks of their respective companies.
Copyright Notice
The works of authorship contained in this manual, including, but not limited to, all design, text and images
are owned by Chauvet.
© Copyright 2021 Chauvet & Sons, LLC. All rights reserved.
Electronically published by Chauvet in the United States of America.
Manual Use
Chauvet authorizes its customers to download and print this manual for professional information purposes
only. Chauvet expressly prohibits the usage, copy, storage, distribution, modification, or printing of this
manual or its content for any other purpose without written consent from Chauvet.
Document Printing
For best results, print this document in color, on letter size paper (8.5 x 11 in), double-sided. If using A4
paper (210 x 297 mm), configure the printer to scale the content accordingly.
Intended Audience
Any person installing, operating, and/or maintaining this product should completely read through the guide
that shipped with the product, as well as this manual, before installing, operating, or maintaining this
product.
Disclaimer
Chauvet believes that the information contained in this manual is accurate in all respects. However,
Chauvet assumes no responsibility and specifically disclaims any and all liability to any party for any loss,
damage or disruption caused by any errors or omissions in this document, whether such errors or
omissions result from negligence, accident or any other cause. Chauvet reserves the right to revise the
content of this document without any obligation to notify any person or company of such revision, however,
Chauvet has no obligation to make, and does not commit to make, any such revisions. Download the latest
version from www.chauvetprofessional.com.
Document Revision
This WELL STX 180 User Manual is the 1st edition of this document. Go to www.chauvetprofessional.com
for the latest version.

WELL STX 180 User Manual Rev. 1
Table of Contents
i
TABLE OF CONTENTS
1. Before You Begin ....................................................................... 1
What Is Included ........................................................................................... 1
Claims ........................................................................................................... 1
Manual Conventions ..................................................................................... 1
Symbols ........................................................................................................ 1
Expected LED Lifespan................................................................................. 1
Safety Notes.................................................................................................. 2
Personal Safety.............................................................................................................. 2
Mounting and Rigging .................................................................................................... 2
Power and Wiring........................................................................................................... 2
Operation ....................................................................................................................... 2
FCC Compliance........................................................................................... 2
2. Introduction ................................................................................ 3
Features........................................................................................................ 3
Product Overview.......................................................................................... 3
Product Dimensions ...................................................................................... 4
3. Setup.......................................................................................... 5
AC Power...................................................................................................... 5
AC Plug .......................................................................................................................... 5
Power Linking................................................................................................................. 5
Battery Charge Notes..................................................................................................... 5
Storage Notes ................................................................................................................ 5
DMX Linking.................................................................................................. 5
DMX Personalities.......................................................................................................... 5
Wireless Operation......................................................................................................... 6
Master/Slave Connectivity............................................................................. 6
Mounting ....................................................................................................... 7
Orientation...................................................................................................................... 7
Rigging ........................................................................................................................... 7
Procedure....................................................................................................................... 7
Stealth Filter.................................................................................................. 7
4. Operation .................................................................................... 8
Control Panel Operation................................................................................ 8
Control Options ............................................................................................. 8
Programming................................................................................................. 8
Control Panel Lock........................................................................................ 8
Configuration (DMX) ..................................................................................... 8
DMX Personalities.......................................................................................................... 8
Starting Address............................................................................................................. 8
Menu Map ..................................................................................................... 9
DMX Values .................................................................................................. 12
67Ch............................................................................................................................... 12
64Ch............................................................................................................................... 14
15Ch............................................................................................................................... 15
4Ch................................................................................................................................. 17
Color Temperature Chart .............................................................................. 17

Table of Contents
WELL STX 180 User Manual Rev. 1
ii
Configuration (Standalone) ........................................................................... 18
Static Mode .................................................................................................................... 18
Auto Programs ............................................................................................................... 18
Auto Program Speed...................................................................................................... 18
White Balance ................................................................................................................ 18
Run Time........................................................................................................................ 18
Back Light ...................................................................................................................... 18
Dimmer Profiles.............................................................................................................. 19
System Information ........................................................................................................ 19
Factory Reset................................................................................................................. 19
Master/Slave Mode ........................................................................................................ 19
Infrared Remote Control................................................................................ 20
IR Remote Operation ..................................................................................................... 20
5. Technical Information ................................................................ 21
Product Maintenance .................................................................................... 21
6. Technical Specifications ........................................................... 22
Returns............................................................................................ 23
Contact Us ...................................................................................... 24

Page 1 of 24
WELL STX 180 User Manual Rev. 1
Before You Begin
1. Before You Begin
What Is Included
Claims
Carefully unpack the product immediately and check the container to make sure all the parts are in the
package and are in good condition.
If the box or the contents (the product and included accessories) appear damaged from shipping, or show
signs of mishandling, notify the carrier immediately, not Chauvet. Failure to report damage to the carrier
immediately may invalidate your claim. In addition, keep the box and contents for inspection.
For other issues, such as missing components or parts, damage not related to shipping, or concealed
damage, file a claim with Chauvet within 7 days of delivery.
Manual Conventions
Symbols
Expected LED Lifespan
Over time, use and heat will gradually reduce LED brightness. Clustered LEDs produce more heat than
single LEDs, contributing to shorter lifespans if always used at full intensity. The average LED lifespan is
40,000 to 50,000 hours. To extend LED lifespan, maintain proper ventilation around the product, and limit
the overall intensity.
• (6) WELL STX 180
• TRUE1-style power cord with Edison plug
(EU bare end)
• Charging flight case
• (6) stands
• (12) magnetic clamps
• (6) hanging eye bolts
• (6) stealth black filters
• Quick Reference Guide
Convention Meaning
1–512 A range of values
50/60 A set of values of which only one can be chosen
<SET> A button on the product’s control panel
Settings A product function or a menu option
Symbol Meaning
Electrical warning. Not following these instructions may cause electrical damage to
the product, accessories, or the user.
Critical installation, configuration, or operation information. Not following these
instructions may make the product not work, cause damage to the product, or cause
harm to the operator.
Important installation or configuration information. The product may not function
correctly if this information is not used.
Useful information.
Any reference to data or power connections in this manual assumes the use of
Seetronic IP-rated cables.
The term “DMX” used throughout this manual refers to the USITT DMX512-A digital
data transmission protocol.

Page 2 of 24
Before You Begin
WELL STX 180 User Manual Rev. 1
Safety Notes
Read all the following safety notes before working with this product. These notes contain important
information about the installation, usage, and maintenance of this product.
Personal Safety
• Avoid direct eye exposure to the light source while the product is on.
• Always disconnect the product from the power source before cleaning or replacing the fuse.
• Always connect the product to a grounded circuit to avoid the risk of electrocution.
• Do not touch the product’s housing when operating because it may be very hot.
Mounting and Rigging
• Do not submerge this product (IP65). Temporary outdoor operation is fine.
• CAUTION: When transferring product from extreme temperature environments, (e.g., cold truck to
warm, humid ballroom) condensation may form on the internal electronics of the product. To avoid
causing a failure, allow product to fully acclimate to the surrounding environment before connecting
it to power.
• Not for permanent outdoor installation in locations with extreme environmental conditions. This
includes, but is not limited to:
• Exposure to a marine/saline environment (within 3 miles of a saltwater body of water).
• Locations where the normal high or low temperatures exceed the temperature ranges in this
manual.
• Locations that are prone to flooding or being buried in snow.
• Areas where the product will be subjected to extreme radiation or caustic substances.
• Mount this product in a location with adequate ventilation, at least 20 in (50 cm) from adjacent
surfaces.
• Make sure there are no flammable materials close to the product when operating.
• When hanging this product, always secure to a fastening device using a safety cable.
Power and Wiring
• Always make sure you are connecting the product to the proper voltage in accordance with the
specifications in this manual or on the product’s specification label.
• Never connect the product to a dimmer pack or rheostat.
• Never disconnect this product by pulling or tugging on the power cable.
Operation
• Do not operate this product if there is damage on the housing, lenses, or cables. Have the damaged
parts replaced by an authorized technician at once.
• Do not cover the ventilation slots when operating to avoid internal overheating.
• The maximum ambient temperature is 113 °F (45 °C). Do not operate the product at higher temperatures.
• The minimum startup temperature is -4°F (-20°C). Do not start the product at lower temperatures.
• The minimum ambient temperature is -22°F (-30°C). Do not operate the product at lower temperatures.
• In the event of a serious operation problem, stop using this product immediately!
FCC Compliance
This device complies with Part 15 Part B of the FCC Rules. Operation is subject to the following two
conditions:
1. This device may not cause harmful interference, and
2. This device must accept any interference received, including interference that may cause
undesired operation.
Any changes or modifications not expressly approved by the party responsible for compliance could void
the user’s authority to operate the equipment.
RF Exposure Warning for North America, and Australia
Warning! This equipment complies with FCC radiation exposure limits set forth for an uncontrolled
environment. This equipment should be installed and operated with a minimum distance of 20cm between
the radiator and your body. This transmitter must not be co-located or operating in conjunction with any
other antenna or transmitter.
This product contains no user-serviceable parts. Any reference to servicing in this
User Manual will only apply to properly trained, certified technicians. Do not open the
housing or attempt any repairs.
All applicable local codes and regulations apply to proper installation of this product.
If your Chauvet product requires service, contact Chauvet Technical Support.

Page 3 of 24
WELL STX 180 User Manual Rev. 1
Introduction
2. Introduction
Features
• (6) pixel-mapping, battery-operated, 1 meter, IP65-rated LED strips with 180° viewing angle,
including (6) mounting stands, (12) magnetic brackets, (6) hanging eye bolts, (6) stealth black
filters, (1) IR remote, and (1) charging case
• 16 individual zones of control for pixel mapping effects
• High-CRI (Color Rendering Index) LEDs for fantastic skin tone rendering
• Simple and complex operational modes
• Built-in editable pre-programmed effects that are controllable from the menu and over DMX
• 3-, 5-, 8-, and 12-hour settings for optimizing performance time
• Included accessories for several mounting options
• Included charging flat case for easy transportation and charging of fixtures
• Update software over USBc connection in flight case (upload all 6 fixtures at once)
• Works in both standalone modes and under DMX over W-DMX
• Works perfectly with the WELL COM controller and app
Product Overview
Menu buttons
Hanging eye
bolt
Magnetic
clamp (2x)
Display
Floor
stand
Charging
flight case
Accessories

Page 4 of 24
Introduction
WELL STX 180 User Manual Rev. 1
Product Dimensions
42.4 in
1078 mm
39.3 in
1000 mm
2.5 in
64 mm
1.6 in
42 mm
2.2 in
55 mm
12.6 in
320 mm
54.6 in
1388 mm
18.1 in
459 mm
20.9 in
530 mm
21.5 in
546 mm
5 in
127 mm

Page 5 of 24
WELL STX 180 User Manual Rev. 1
Setup
3. Setup
AC Power
Each WELL STX 180 has an auto-ranging battery charger inside the fixture that works with an input
voltage range of 100 to 240 VAC, 50/60 Hz. To determine the power requirements for each
WELL STX 180, refer to the label affixed to the product or the Technical Specifications chart in this manual.
The listed current rating indicates the maximum current draw during normal operation. For more
information, download Sizing Circuit Breakers from the Chauvet website: www.chauvetprofessional.com.
AC Plug
The WELL STX 180 charging case comes with a power input cord terminated with a Seetronic Powerkon
connector on one end and an Edison plug on the other end (U.S. market). If the power input cord that came
with your product has no plug, or if you need the change the plug, use the table below to wire the new plug
.
Power Linking
The product supports power linking of up to 8 products at 120 V, and 11 products at 208 V and 230 V. This
product comes with a power input cord. Power-linking cables are available from Chauvet for purchase.
Battery Charge Notes
This product is equipped with a built-in rechargeable lithium-ion battery.
• Avoid depleting the battery below 10%.
• For best results, charge the battery in a temperature between 32 °F (0 °C) and 95 °F (35 °C).
• When charging the battery, keep the product at least 1 m from any open flame or hot plate.
• If the battery is completely discharged, the device cannot be turned on immediately when the charger
is connected. Allow a depleted battery to charge a few minutes before turning on the device.
• While charging, the device may heat up. This is normal and should not affect the device’s lifespan or
performance. If the battery gets hotter than usual, the charger may stop charging.
• When charging the battery, keep the road case’s cover open.
• Always charge the battery with the product in an upright position.
• Do not charge the battery for more than 24 hours.
Storage Notes
• Store charged product(s) in a dry environment, away from direct sunlight.
• Charge or discharge the battery to approximately 50% of capacity before storage.
• Lithium-ion batteries continue to slowly discharge (self-discharge) when not in use or while in
storage. Routinely check the battery’s charge status.
• Store the battery at temperatures between 41 °F and 68 °F (5 °C and 20 °C).
DMX Linking
The WELL STX 180 can be linked to a DMX controller using a wireless DMX connection. If using other
DMX-compatible products with this product, you can control each individually with a single DMX controller.
DMX Personalities
The WELL STX 180 uses a wireless DMX data connection for the 4Ch , 15Ch , 64Ch , and 67Ch DMX personalities.
• Refer to the Operation chapter to learn how to configure the WELL STX 180 to work in these personalities.
•TheDMX Values section provides detailed information regarding the control personalities.
• Always connect the product to a protected circuit (a circuit breaker or fuse). Make sure
the product has an appropriate electrical ground to avoid the risk of electrocution or fire.
• To eliminate unnecessary wear and improve its lifespan, during periods of non-use
completely disconnect the product from power via breaker or by unplugging it.
Never connect the product to a rheostat (variable resistor) or dimmer circuit, even if the
rheostat or dimmer channel serves only as a 0 to 100% switch.
Connection Wire (U.S.) Wire (Europe) Screw Color
AC Live Black Brown Yellow or Brass
AC Neutral White Blue Silver
AC Ground Green/Yellow Green/Yellow Green
If you are not familiar with or need more information about DMX standards, Master/Slave
connectivity, or the DMX cables needed to link this product to a DMX controller, download
the DMX Primer from the Chauvet website: www.chauvetprofessional.com.

Page 6 of 24
Setup
WELL STX 180 User Manual Rev. 1
Wireless Operation
In optimal conditions, the WELL STX 180 can operate up to 300 m (900 ft) away from the W-DMX TRX
transmitter. The W-DMX receiver in the WELL STX 180 must be paired with the W-DMX TRX transmitter
for wireless operation.
Initial Setup
1. Turn the W-DMX TRX transmitter on.
2. Connect the W-DMX TRX transmitter to a DMX controller.
3. Place the WELL STX 180 within 300 m from the W-DMX TRX transmitter.
4. Turn the WELL STX 180 on.
Configuration
1. From the WELL STX 180 control panel, go to DMX Address.
2. Select the start address, as with any other DMX compatible product.
3. Go to Wireless Setting > Operating Mode.
4. Select Receive.
5. Go to Wireless Setting > W-DMX On/Off.
6. Select On. (The Signal Strength Indicator will show a ?in front of the bars).
7. Press the reset button on the W-DMX transmitter. (The Signal Strength Indicator on the
WELL STX 180 will show a ϟin front of the bars for 3 seconds while a connection is established.).
Product Pairing
If the WELL STX 180 has already been paired with the W-DMX TRX transmitter, the Signal Strength
Indicator in the middle of the LCD screen will show the strength of the signal. In this case, the
WELL STX 180 is ready to work in wireless mode.
To pair the WELL STX 180 and a new W-DMX transmitter, follow the instructions below:
1. From the WELL STX 180 control panel, go to Wireless Setting > Receive Reset.
2. Select Yes. The Signal Strength Indicator on the WELL STX 180 will show a ?in front of the bars.
3. From the W-DMX transmitter, press <RESET> (the Signal Indicator on the transmitter will flash).
4. Once the transmitter has found the WELL STX 180, the Signal indicator on the W-DMX transmitter
will illuminate solid.
5. The Signal Strength Indicator in the middle of the LCD screen on the WELL STX 180 will show the
strength of the signal.
Master/Slave Connectivity
The Master/Slave mode allows an WELL STX 180 (the master) to control one or more WELL STX 180
products (the slaves) without a DMX controller. One WELL STX 180 becomes the master when running an
auto program, or by being in Static mode.
You must configure each slave’s control panel to operate in Slave mode. During Master/Slave operation,
the slaves will operate in unison with the master.
Once a WDMX receiver has been linked to a specific W-DMX TRX transmitter, it will remain
linked to that specific transmitter until it is linked to a different one.
W-DMX operation can be interrupted or inhibited by liquid masses between the transmitter
and receiver. For best results, keep the area between the transmitter and receiver clear of
any liquid mass.
DO NOT connect a DMX controller to products operating in Master/Slave mode. The DMX
controller signals may interfere with the signals from the master.
•TheMaster/Slave Mode section of this manual provides detailed instructions on how to
configure the master and slaves.
• If you are not familiar with or need more information about DMX standards, or the DMX
cables needed to link this product to a DMX controller, download the DMX Primer from
the Chauvet website: www.chauvetprofessional.com.

Page 7 of 24
WELL STX 180 User Manual Rev. 1
Setup
Mounting
Before mounting the product, read and follow the safety recommendations indicated in the Safety Notes.
For our CHAUVET Professional line of mounting clamps, go to http://trusst.com/products/.
Orientation
Always mount this product in a safe position, making sure there is adequate room for ventilation,
configuration, and maintenance.
Rigging
Chauvet recommends using the following general guidelines when mounting this product.
• Before deciding on a location for the product, make sure there is easy access to the product for
maintenance and programming purposes.
• Make sure that the structure onto which you are mounting the product can support the product’s
weight. See the Technical Specifications for weight information.
• When mounting the product overhead, always use a safety cable. Mount the product securely to a
rigging point, whether an elevated platform or a truss.
• When rigging the product onto a truss, use a mounting clamp of appropriate weight capacity.
• When power linking multiple products, mount the products close enough for power linking cables to reach.
• The bracket adjustment knobs allow for directional adjustment when aiming the product to the desired
angle. Only loosen or tighten the bracket knobs manually. Using tools could damage the knobs.
Procedure
The WELL STX 180 comes with a bracket to which you can attach a mounting clamp directly. Mounting
clamps are sold separately. Make sure the clamps are capable of supporting the weight of this product.
Use at least one mounting point per product. For the CHAUVET Professional line of mounting clamps, go
to http://www.trusst.com/products.
Mounting Diagram
Stealth Filter
The WELL STX 180 comes with black stealth filters that allow the product to become invisible when it is
turned off and is in front of a dark background. The stealth filter easily snaps to the WELL STX 180 for
quick installation and removal.
MENU
DOWN
ENTER
UP
Hanging eye bolt
Magnetic clamp
Safety cable
Floor stand
Stealth filter

Page 8 of 24
Operation
WELL STX 180 User Manual Rev. 1
4. Operation
Control Panel Operation
Control Options
Set the WELL STX 180 starting address in the 001-512 DMX range. This enables control of up to 11
products in the 67-channel personality.
Programming
Refer to the Menu Map to understand the menu options. The menu map shows the main level and a
variable number of programming levels for each option.
• To go to the desired main level, press <MENU> repeatedly until the option shows on the display.
Press <ENTER> to select. This will show the first programming level for that option.
• To select an option or value within the current programming level, press <UP> or <DOWN> until
the option shows on the display. Press <ENTER> to select. This will show either the first option if
there is another programming level, or the selected value.
• Press <MENU> repeatedly to exit to the previous main level.
Control Panel Lock
The setting locks or unlocks the control panel.
1. Go to the Key Lock main level.
2. Select On (locks control panel) or Off (control panel stays unlocked).
Configuration (DMX)
Use DMX configurations to operate the product with a DMX controller.
DMX Personalities
This setting allows the user to choose a particular DMX personality.
1. Go to the DMX Personality main level.
2. Select the desired personality (4Ch, 15Ch, 64Ch, or 67Ch).
Starting Address
In this mode, each product will respond to a unique starting address from the DMX controller. All products
with the same starting address will respond in unison.
1. Go to the DMX Address main level.
2. Set the starting address (001–512).
The highest recommended starting address for each DMX mode is as follows:
Button Function
<MENU> Exits from the current menu or function
<ENTER>
Enables the currently displayed menu or sets the currently selected value in to the current function
<UP> Navigates upward through the menu list or increases the numeric value when in a function
<DOWN> Navigates downward through the menu list or decreases the numeric value when in a function
When the control panel lock is activated, the product will prompt for the passcode to
access the menu. To enter the passcode, press:
<UP>, <DOWN>, <UP>, <DOWN>, <ENTER>.
• See the Starting Address section for the highest starting address suggested for each
personality.
• Make sure that the starting addresses on the various products do not overlap due to
the new personality setting.
DMX Personality DMX Address
4Ch 509
15Ch 498
64Ch 449
67Ch 446

Page 9 of 24
WELL STX 180 User Manual Rev. 1
Operation
Menu Map
Refer to the WELL STX 180 product page on www.chauvetprofessional.com for the latest menu map.
Main Level Programming Levels Description
DMX
Address 001–512 Selects DMX address (highest channel restricted to personality chosen)
DMX
Channel
4Ch 4-channel: RGBW
15Ch
15-channel: RGBW, color temperature, strobe,
auto programs,
auto speed, foreground color
dimmer, foreground color, background
color dimmer,
background color, dimmer speed, auto delay
64Ch 64-channel: RGBW 1–16
67Ch 67-channel: RGBW 1–16, strobe, dimmer,
dimmer speed
Static
Manual Color
R
000–255 Manually adjusts RGBW color settings
G
B
W
Color
Temperature
2800K
Selects preset color temperature
2900K
3000K
3100K
3200K
3300K
3400K
3500K
3600K
3700K
3800K
3900K
4000K
4100K
4200K
4300K
4400K
4500K
4600K
4700K
4800K
4900K
5000K
5100K
5200K
5300K
5400K
5500K
5600K
5700K
6000K
6500K
7000K
7500K
8000K

Page 10 of 24
Operation
WELL STX 180 User Manual Rev. 1
Static
(cont.) Fixed color
RRed
GGreen
BBlue
WWhite
GB Green + blue
RB Red + blue
RG Red + green
RGB Red + green + blue
RW Red + white
GW Green + white
BW Blue + white
RGW Red + green + white
RBW Red + blue + white
GBW Green + blue + white
RGBW Red + green + blue + white
Auto Show Auto 1–28 Foreground
RRed
GGreen
BBlue
WWhite
GB Green + blue
RB Red + blue
RG Red + green
RGB Red + green + blue
RW Red + white
GW Green + white
BW Blue + white
RGW Red + green + white
RBW Red + blue + white
GBW Green + blue + white
RGBW Red + green + blue + white
2800K 2800K white
7000K 7000K white
Auto Auto colors
Off No foreground color
Main Level Programming Levels Description

Page 11 of 24
WELL STX 180 User Manual Rev. 1
Operation
Auto Show Auto 1–28 Background
RRed
GGreen
BBlue
WWhite
GB Green + blue
RB Red + blue
RG Red + green
RGB Red + green + blue
RW Red + white
GW Green + white
BW Blue + white
RGW Red + green + white
RBW Red + blue + white
GBW Green + blue + white
RGBW Red + green + blue + white
2800K 2800K white
7000K 7000K white
Auto Auto colors
Off No background color
Speed 1–100 Adjusts speed of auto programs
Wireless
Setting
W-DMX On/Off On Turns wireless DMX mode on/off
Off
Receive Reset
(Only in Receive mode)
No Resets the internal receiver
Yes
Link
(Only in Transmit mode)
Link Links or unlinks to a W-DMX receiver
Unlink
Operating Mode Receive Receives W-DMX
Transmit Transmits W-DMX
White
Balance
Off Turns off white balance
Manual
R
125–255 Adjusts the red, green, blue, and white LED
maximum values manually
G
B
W
IR Setting On Turns on infrared mode for IRC-6 remote use
Off
Run Time
3 hours
Shows product run time
5 hours
8 hours
12 hours
Dimmer
Mode
Off Dimmer off
Dimmer 1–3 Dimming curves Dimmer 1 (fast) to Dimmer 3
(slow)
Back Light
10S Turns off display backlight after 10 seconds of
inactivity
30S Turns off display backlight after 30 seconds of
inactivity
2min Turns off display backlight after 2 minutes of
inactivity
Always On Display backlight always on
Key lock
On Locks/unlocks the display
(Password is: < UP >, < DOWN >, < UP >,
<
DOWN >, < ENTER >)
Off
Main Level Programming Levels Description

Page 12 of 24
Operation
WELL STX 180 User Manual Rev. 1
DMX Values
67Ch
Information
Fixture Hours _ _ _ _H Shows total hours the product has been
powered on
LED Hours _ _ _ _H Shows total LED hours
Version V_._ Shows current firmware version
UID _ _ _ _ _ _ _ _ _ _ _ _ Shows product UID
Factory
Reset
No Resets the product to factory default settings
Yes
Channel Function Value Percent/Setting
1Red1 000 255 0–100%
2 Green 1 000 255 0–100%
3Blue1 000 255 0–100%
4White1 000 255 0–100%
5Red2 000 255 0–100%
6 Green 2 000 255 0–100%
7Blue2 000 255 0–100%
8White2 000 255 0–100%
9Red3 000 255 0–100%
10 Green 3 000 255 0–100%
11 Blue 3 000 255 0–100%
12 White 3 000 255 0–100%
13 Red 4 000 255 0–100%
14 Green 4 000 255 0–100%
15 Blue 4 000 255 0–100%
16 White 4 000 255 0–100%
17 Red 5 000 255 0–100%
18 Green 5 000 255 0–100%
19 Blue 5 000 255 0–100%
20 White 5 000 255 0–100%
21 Red 6 000 255 0–100%
22 Green 6 000 255 0–100%
23 Blue 6 000 255 0–100%
24 White 6 000 255 0–100%
25 Red 7 000 255 0–100%
26 Green 7 000 255 0–100%
27 Blue 7 000 255 0–100%
28 White 7 000 255 0–100%
29 Red 8 000 255 0–100%
30 Green 8 000 255 0–100%
31 Blue 8 000 255 0–100%
32 White 8 000 255 0–100%
33 Red 9 000 255 0–100%
34 Green 9 000 255 0–100%
35 Blue 9 000 255 0–100%
36 White 9 000 255 0–100%
37 Red 10 000 255 0–100%
Main Level Programming Levels Description

Page 13 of 24
WELL STX 180 User Manual Rev. 1
Operation
38 Green 10 000 255 0–100%
39 Blue 10 000 255 0–100%
40 White 10 000 255 0–100%
41 Red 11 000 255 0–100%
42 Green 11 000 255 0–100%
43 Blue 11 000 255 0–100%
44 White 11 000 255 0–100%
45 Red 12 000 255 0–100%
46 Green 12 000 255 0–100%
47 Blue 12 000 255 0–100%
48 White 12 000 255 0–100%
49 Red 13 000 255 0–100%
50 Green 13 000 255 0–100%
51 Blue 13 000 255 0–100%
52 White 13 000 255 0–100%
53 Red 14 000 255 0–100%
54 Green 14 000 255 0–100%
55 Blue 14 000 255 0–100%
56 White 14 000 255 0–100%
57 Red 15 000 255 0–100%
58 Green 15 000 255 0–100%
59 Blue 15 000 255 0–100%
60 White 15 000 255 0–100%
61 Red 16 000 255 0–100%
62 Green 16 000 255 0–100%
63 Blue 16 000 255 0–100%
64 White 16 000 255 0–100%
65 Strobe 000 010 Off
011 255 Strobe, slow to fast
66 Dimmer 000 255 0–100%
67 Dimmer speed
000 051 Preset dimmer speed from display menu
052 101 Dimmer speed mode off
102 152 Dimmer speed mode 1 (fastest)
153 203 Dimmer speed mode 2
204 255 Dimmer speed mode 3 (slowest)
Channel Function Value Percent/Setting

Page 14 of 24
Operation
WELL STX 180 User Manual Rev. 1
64Ch
Channel Function Value Percent/Setting
1Red1 000 255 0–100%
2Green1 000 255 0–100%
3Blue1 000 255 0–100%
4White1 000 255 0–100%
5Red2 000 255 0–100%
6Green2 000 255 0–100%
7Blue2 000 255 0–100%
8White2 000 255 0–100%
9Red3 000 255 0–100%
10 Green 3 000 255 0–100%
11 Blue 3 000 255 0–100%
12 White 3 000 255 0–100%
13 Red 4 000 255 0–100%
14 Green 4 000 255 0–100%
15 Blue 4 000 255 0–100%
16 White 4 000 255 0–100%
17 Red 5 000 255 0–100%
18 Green 5 000 255 0–100%
19 Blue 5 000 255 0–100%
20 White 5 000 255 0–100%
21 Red 6 000 255 0–100%
22 Green 6 000 255 0–100%
23 Blue 6 000 255 0–100%
24 White 6 000 255 0–100%
25 Red 7 000 255 0–100%
26 Green 7 000 255 0–100%
27 Blue 7 000 255 0–100%
28 White 7 000 255 0–100%
29 Red 8 000 255 0–100%
30 Green 8 000 255 0–100%
31 Blue 8 000 255 0–100%
32 White 8 000 255 0–100%
33 Red 9 000 255 0–100%
34 Green 9 000 255 0–100%
35 Blue 9 000 255 0–100%
36 White 9 000 255 0–100%
37 Red 10 000 255 0–100%
38 Green 10 000 255 0–100%
39 Blue 10 000 255 0–100%
40 White 10 000 255 0–100%
41 Red 11 000 255 0–100%
42 Green 11 000 255 0–100%
43 Blue 11 000 255 0–100%
44 White 11 000 255 0–100%
45 Red 12 000 255 0–100%
46 Green 12 000 255 0–100%
47 Blue 12 000 255 0–100%
48 White 12 000 255 0–100%
49 Red 13 000 255 0–100%

Page 15 of 24
WELL STX 180 User Manual Rev. 1
Operation
15Ch
50 Green 13 000 255 0–100%
51 Blue 13 000 255 0–100%
52 White 13 000 255 0–100%
53 Red 14 000 255 0–100%
54 Green 14 000 255 0–100%
54 Green 14 000 255 0–100%
55 Blue 14 000 255 0–100%
56 White 14 000 255 0–100%
57 Red 15 000 255 0–100%
58 Green 15 000 255 0–100%
59 Blue 15 000 255 0–100%
60 White 15 000 255 0–100%
61 Red 16 000 255 0–100%
62 Green 16 000 255 0–100%
63 Blue 16 000 255 0–100%
64 White 16 000 255 0–100%
Channel Function Value Percent/Setting
1 Dimmer 000 255 0–100%
2Red 000 255 0–100%
3 Green 000 255 0–100%
4Blue 000 255 0–100%
5White 000 255 0–100%
6 Color temperature 000 255 See Color Temperature Chart
7 Strobe 000 010 No function
011 255 Strobe, slow to fast
8 Auto programs
000 010 No function
011 018 Program 1
019 026 Program 2
027 034 Program 3
035 042 Program 4
043 050 Program 5
051 058 Program 6
059 066 Program 7
067 074 Program 8
075 082 Program 9
083 090 Program 10
091 098 Program 11
099 106 Program 12
107 114 Program 13
115 122 Program 14
123 130 Program 15
131 138 Program 16
139 146 Program 17
147 154 Program 18
155 162 Program 19
163 170 Program 20
171 178 Program 21
Channel Function Value Percent/Setting

Page 16 of 24
Operation
WELL STX 180 User Manual Rev. 1
8 Auto programs (cont.)
179 186 Program 22
187 194 Program 23
195 202 Program 24
203 210 Program 25
211 218 Program 26
219 226 Program 27
227 255 Program 28 (cycles through programs 1–27)
9Autospeed 000 255 Auto programs speed, slow to fast
10 Foreground color dimmer 000 255 0–100%
11 Foreground color
000 013 Red
014 027 Green
028 041 Blue
042 055 White
056 069 Green + blue
070 083 Red + blue
084 097 Red + green
098 111 Red + green + blue
112 125 Red + white
126 139 Green + white
140 153 Blue + white
154 167 Red + green + white
168 181 Red + blue + white
182 195 Green + blue + white
196 209 Red + green + blue + white
210 223 2800K
224 237 7000K
238 255 Auto
12 Background color dimmer 000 255 0–100%
13 Background color
000 013 Red
014 027 Green
028 041 Blue
042 055 White
056 069 Green + blue
070 083 Red + blue
084 097 Red + green
098 111 Red + green + blue
112 125 Red + white
126 139 Green + white
140 153 Blue + white
154 167 Red + green + white
168 181 Red + blue + white
182 195 Green + blue + white
196 209 Red + green + blue + white
210 223 2800K
224 237 7000K
238 255 Auto
Channel Function Value Percent/Setting
