Chauvet Led Shadow User manual

User Manual

Page 2 of 16 LED Shadow™ User Manual Rev. 6
TABLE OF CONTENTS
1. Before You Begin .......................................................................................................... 3
What Is Included .............................................................................................................................3
Unpacking Instructions....................................................................................................................3
Claims..................................................................................................................................................... 3
Text Conventions ............................................................................................................................ 3
Symbols ..........................................................................................................................................3
Disclaimer ....................................................................................................................................... 3
Product at a Glance ........................................................................................................................4
Safety Notes....................................................................................................................................4
2. Introduction ................................................................................................................... 5
Product Overview............................................................................................................................ 5
Product Dimensions ........................................................................................................................ 6
3. Setup.............................................................................................................................. 7
AC Power ........................................................................................................................................ 7
Fuse Replacement ..........................................................................................................................7
Power Linking ......................................................................................................................................... 7
Mounting ......................................................................................................................................... 8
Orientation .............................................................................................................................................. 8
Rigging ................................................................................................................................................... 8
4. Operation ....................................................................................................................... 9
Control Panel Operation.................................................................................................................. 9
Menu Map .......................................................................................................................................9
DMX Linking..................................................................................................................................10
Configuration (DMX) ............................................................................................................................. 10
DMX Starting Address .......................................................................................................................... 10
DMX Channel Assignments and Values .......................................................................................10
3-CH ..................................................................................................................................................... 10
Configuration (Standalone) ...........................................................................................................11
Auto Programs...................................................................................................................................... 11
Sound-Active ........................................................................................................................................ 11
Manual Mode........................................................................................................................................ 11
Display Timeout.................................................................................................................................... 11
Test Mode............................................................................................................................................. 11
Reset .................................................................................................................................................... 11
IRC-6 Infrared Remote Control .....................................................................................................12
IRC-6 Operation.................................................................................................................................... 12
Master/Slave Mode .......................................................................................................................12
5. Maintenance .................................................................................................................13
Product Maintenance ....................................................................................................................13
6. Technical Specifications..............................................................................................14
Returns .............................................................................................................................15
Contact Us ........................................................................................................................16

LED Shadow™ User Manual Rev. 6 Page 3 of 16
1. BEFORE YOU BEGIN
What Is
Included
• LED Shadow™
• Power Cord
• Warranty Card
• Quick Reference Guide
Unpacking
Instructions
Carefully unpack the product immediately and check the container to make sure all the
parts are in the package and are in good condition.
Claims
If the box or the contents (the product and included accessories) appear damaged from
shipping, or show signs of mishandling, notify the carrier immediately, not Chauvet. Failure
to report damage to the carrier immediately may invalidate your claim. In addition, keep the
box and contents for inspection.
For other issues, such as missing components or parts, damage not related to shipping, or
concealed damage, file a claim with Chauvet within 7 days of delivery.
Text
Conventions
Convention Meaning
1—512
A range of values
50/60
A set of values of which only one can be chosen
Settings
A menu option not to be modified
Menu > Settings
A sequence of menu options to be followed
<ENTER>
A key to be pressed on the product’s control panel
ON
A value to be entered or selected
Symbols
Symbol Meaning
Electrical warning. Not following these instructions may cause
electrical damage to the product, accessories, or the user.
Critical installation, configuration, or operation information. Not
following these instructions may make the product not work, cause
damage to the product, or cause harm to the operator.
Important installation or configuration information. The product
may not function correctly if this information is not used.
Useful information.
Disclaimer
The information and specifications contained in this document are subject to change
without notice. Chauvet
assumes no responsibility or liability for any errors or omissions
that may appear in this manual. Chauvet
reserves the right to update the existing
document or to create a new document to correct any errors or omissions.
You can download the latest version of this document from www.chauvetlighting.com.
© Copyright 2015 Chauvet. All rights reserved.
Electronically published by Chauvet in the United States of America.
Author Date Editor Updated
R. Isenstadt 07/14/2015 M. Trouard 07/14/2015

Page 4 of 16 LED Shadow™ User Manual Rev. 6
Product at a
Glance
Use on Dimmer
Auto Programs
Outdoor Use
Auto-ranging Power Supply
Sound-Active
Replaceable Fuse
DMX
User-Serviceable
Master/Slave
Safety Notes
Please read the following Safety Notes carefully before working with the product. The
Notes include important safety information about installation, usage, and maintenance.
• Always connect the product to a grounded circuit to avoid the risk of electrocution.
• Always disconnect the product from the power source before cleaning or replacing
the fuse.
• Avoid direct eye exposure to the light source while the product is on.
• Make sure the power cord is not crimped or damaged.
• Never disconnect the product from power cord by pulling or tugging on the cord.
• If mounting the product overhead, always secure to a fastening device using a
safety cable.
• Make sure there are no flammable materials close to the product when operating.
•
Do not touch the product’s housing when operating because it may be very hot.
• The product is not intended for permanent installation.
• Always make sure that the voltage of the outlet to which you are connecting the
product is within the range stated on the decal or rear panel of the product.
• The product is for indoor use only! (IP20) To prevent risk of fire or shock, do not
expose the product to rain or moisture.
• Always install the product in a location with adequate ventilation, at least 20 in
(50 cm) from adjacent surfaces.
• Be sure that no ventilation slots on the product’s housing are blocked.
• Never connect the product to a dimmer.
• Make sure to replace the fuse with another of the same type and rating.
• Never carry the product from the power cord or any moving part. Always use the
hanging/mounting bracket.
• The maximum ambient temperature (Ta) is 104 °F (40 °C). Do not operate the
product at higher temperatures.
• In the event of a serious operating problem, stop using the product immediately.
• Never try to repair the product. Repairs carried out by unskilled people can lead to
damage or malfunction. Please contact the nearest authorized technical assistance
center.
• To eliminate unnecessary wear and improve its lifespan, during periods of non-use
completely disconnect the product from power via breaker or by unplugging it.
Keep this User Manual for future use. If you sell the product to someone else, be
sure that they also receive this document.

LED Shadow™ User Manual Rev. 6 Page 5 of 16
2. INTRODUCTION
Product Overview
Safety Loop
Display
Menu Buttons
Microphone
Sensitivity Knob
Fuse Holder
Power In
Power Out
DMX In/Out

Page 6 of 16 LED Shadow™ User Manual Rev. 6
Product Dimensions
6.5 in
165 mm
14 in
356 mm
9.8 in
248 mm

LED Shadow™ User Manual Rev. 6 Page 7 of 16
3. SETUP
AC Power
The LED Shadow™ has an auto-ranging power supply and it can work with an input
voltage range of 100 to 240 VAC, 50/60 Hz. To determine the product’s power
requirements (
circuit breaker, power outlet, and wiring), use the current value listed on the
label affixed to the product’s back panel, or refer to the product
’s specifications chart. The
listed current rating indicates the product’s average current draw under normal conditions.
• Always connect the product to a protected circuit (circuit breaker or fuse).
Make sure the product
has an appropriate electrical ground to avoid the risk
of electrocution or fire.
•
To eliminate unnecessary wear and improve its lifespan, during periods of
non-
use completely disconnect the product from power via breaker or by
unplugging it.
Never connect the product
to a rheostat (variable resistor) or dimmer circuit, even if
the rheostat or dimmer channel serves only as a 0 to 100% switch.
Fuse
Replacement
1. Wedge the tip of a flat-head screwdriver into the slot of the fuse holder.
2. Pry the fuse holder out of the housing.
3. Remove the blown fuse from the holder and replace with a fuse of the exact same
type and rating.
4. Insert the fuse holder back in place and reconnect power.
Disconnect the product from the power outlet before replacing the fuse.
Power Linking The product provides power linking via the Edison outlet located in the back of the product.
Please see the diagram below for further explanation.
Power Linking
Diagram
You can power link up to 43 LED Shadow™ product
s on 120 VAC or
up to 74 LED Shadow™ products on 230 VAC.
The power linking diagram corresponds to the North American version of the
product ONLY! If using the product
in other markets, you must consult with the
local Chauvet distributor as power linking connectors and requirements may differ
in your country or region.
1st Product
2nd Product
3rd Product
Additional
Products
Installed fuse
(held by plastic clip)
Spare fuse holder
(inside safety cap)
Safety cap

Page 8 of 16 LED Shadow™ User Manual Rev. 6
Mounting
Before mounting the product
, read and follow the safety recommendations indicated in the
Safety Notes.
Orientation
The LED Shadow™
may be mounted in any position; however, make sure adequate
ventilation is provided around the product.
Rigging
• Before deciding on a location for the product, always make sure there is easy access
to the product for maintenance and programming purposes.
• Make sure that the structure onto which you are mounting the product can support the
product’s weight. See the Technical Specifications for weight information.
• When mounting the product overhead, always use a safety cable. Mount the product
securely to a rigging point, whether an elevated platform or a truss.
• When rigging the product onto a truss, use a mounting clamp
of appropriate weight
capacity.
• When power linking multiple products, mount the products close enough for power
linking cables to reach.
• The bracket adjustment
knobs allow for directional adjustment when aiming the
product to the desired angle. Only loosen or tighten the bracket knobs manually.
Using tools could damage the knobs.
Mounting Diagram
Mounting Clamp
(such as the CLP-
15N
from Chauvet)
Mounting Bracket
Safety Cable
(such as CH-05
from Chauvet)
Bracket Adjustment
Knob x 2
Flush Mounting
Bracket
Flush Mounting
to Wall (Drywall
Screws x 4)

LED Shadow™ User Manual Rev. 6 Page 9 of 16
4. OPERATION
Control Panel
Operation
To access the control panel functions, use the four buttons located underneath the display.
Please refer to the Product Overview to see the button locations on the control panel.
Button Function
<MENU>
Press to find an operation mode or to back out of the current menu
option
<ENTER>
Navigates upwards through the menu list and increases the numeric
value when in a function
<UP>
Navigates downwards through the menu list and decreases the
numeric value when in a function
<DOWN>
Enables the currently displayed menu or sets the currently selected
value into the selected function
Menu Map
Main Level
Programming Steps
Description
Aut
(automatic)
Aut0
S. 01–99 Automated programs and
speed
Aut1
Aut2
Aut3
Aut4
Aut5
Sou
(sound-active)
Soud Sound-Active mode
CoL CoLo
L.000–255 (UV)
Dimmer
S. 0–8
Strobe rate
Addr
d001–510
3-channel DMX mode
SLA
SLAV
Slave mode
SYS
LEdS
On
Display timeout on
oFF
Display timeout off
tESt
Performs a test of all LEDs
rEST
Resets the software

Page 10 of 16 LED Shadow™ User Manual Rev. 6
DMX Linking
The LED Shadow™ works with a DMX controller. Information about DMX is in the
CHAUVET® DMX Primer, which is available from the Chauvet website
http://www.chauvetlighting.com/downloads/DMX_Primer_rev05_WO.pdf.
Configuration
(DMX)
Set the product in DMX mode to control with a DMX controller.
1. Connect the product to a suitable power outlet.
2. Connect a DMX cable from the DMX output of the DMX controller to the DMX input
socket on the product.
DMX
Starting
Address
When selecting a starting DMX address, always consider the number of DMX channels the
product
uses. If you choose a starting address that is too high, you could restrict the
access to some of the product’s channels.
The LED Shadow™ uses 3
DMX channels, which defines the highest configurable
address to 510. If you are not familiar with the DMX prot
ocol, download the DMX Primer
from www.chauvetlighting.com.
To select the starting address, do the following:
1. Press <MENU>repeatedly until Addr shows on the display.
2. Press <ENTER> and d001–510 will show on the display.
3. Use <UP> or <DOWN> to select the starting address.
4. Press <ENTER>.
DMX Channel Assignments and Values
3-CH
Channel
Function
Value
Percent/Setting
1 Mode
000
No function
001 039 Dimmer mode
040
079
Automatic mode 1
080
119
Automatic mode 2
120
159
Automatic mode 3
160
199
Automatic mode 4
200
239
Automatic mode 5
240
255
Sound-active
2
Strobe Mode Speed
(When Ch. 1 is 001 039)
000
009
No strobe
010
255
Strobe speed (0–100%)
Auto Mode Speed
(When Ch. 1 is 040
239)
000 255 Automatic mode speed (slow to fast)
No Function
(When Ch. 1 is 240
255)
000 255 No function
3
Intensity
000 255
100–0%

LED Shadow™ User Manual Rev. 6 Page 11 of 16
Configuration
(Standalone)
Set the product in one of the standalone modes to control without a DMX controller.
Connect the product to a suitable power outlet.
Never connect a product that is operating in any standalone mode
to a DMX string
connected to a DMX controller. Products in standalone mode may
transmit DMX
signals that could interfere with the DMX signals from the controller.
Auto Programs
To run an auto program, do the following:
1. Press <MENU> repeatedly until Aut shows on the display.
2. Press <ENTER> and Aut0–5 will show on the display.
3. Use <UP> or <DOWN> to select the desired program.
4. Press <ENTER> and S. 01–99 will show on the display.
5. Use <UP> or <DOWN> to increase or decrease the program speed.
6. Press <ENTER>.
Sound-Active
To run the LED Shadow™ in sound-active mode, follow the instructions below:
1. Press <MENU> repeatedly until Sou shows on the display.
2. Press <ENTER>. Soud will show on the display.
3. Turn the sensitivity knob until the product responds to the beat of the music.
In Sound-Active mode, the product will only respond to low frequencies of music
(bass and drums).
Manual Mode
To run the LED Shadow™ in manual mode, follow the instructions below:
1. Press <MENU>repeatedly until CoL shows on the display.
2. Press <ENTER> and CoLo will show on the display.
3. Press <ENTER> again and L.000–255 will show on the display.
4. Use <UP> or <DOWN> to increase or decrease the dimmer value.
5. Press <ENTER> and S. 0–8 will show on the display.
6. Use <UP> or <DOWN> to increase or decrease the strobe rate.
7. Press <ENTER>.
Display Timeout
To turn the display timeout on or off, do the following:
1. Press <MENU> until SYS shows on the display.
2. Press <ENTER> and LEdS, tESt, or rESt will show on the display.
3. Use <UP> or <DOWN> to select LEdS.
4. Press <ENTER> and on or oFF will show on the display.
5. Use <UP>or <DOWN> to select whether the display timeout should be on or oFF.
6. Press <ENTER>.
Test Mode
To run a test of the LEDs, follow the instructions below:
1. Press <MENU> until SYS shows on the display.
2. Press <ENTER> and LEdS, tESt, or rESt will show on the display.
3. Use <UP> or <DOWN> to select tESt.
4. Press
<ENTER>
.
Reset
To reset the software of the LED Shadow™, do the following:
1. Press <MENU> until SYS shows on the display.
2. Press <ENTER> and LEdS, tESt, or rESt will show on the display.
3. Use <UP> or <DOWN> to select rESt.
4. Press <ENTER>.

Page 12 of 16 LED Shadow™ User Manual Rev. 6
IRC-6 Infrared
Remote
Control
The LED Shadow™ is compatible with the IRC-6 infrared remote control from Chauvet.
Make sure to point the IRC-6 directly at the receiver on the front of the product.
IRC-6 Operation
Auto Mode
To run Auto mode:
1. Press <AUTO> to activate Auto program 0.
2. Press <1> – <5> to activate one of the other programs.
3. Use <+> or <–> to increase or decrease the program speed.
Sound-Active Mode
To turn on Sound-Active mode:
Press <SOUND> on the IRC-6.
Manual Control
To manually control the intensity level:
1. Press <MANUAL> or <UV> on the IRC-6.
2. Press <+> or <–> to increase or decrease the output level.
Strobe Mode
To activate Strobe mode:
1. Press <STROBE> on the IRC-6.
2. Press <+> or <–> to increase or decrease the strobe rate.
To deactivate the strobe, switch to another mode.
Black Out
To black out the LEDs:
Press <BLACK OUT> on the IRC-6.
This will turn off all the lights until the button is pressed again.
NOTE: The IRC will not respond to any inputs when Black Out is activated. If the remote
does not respond when a button is pressed, try pressing <BLACK OUT>. You
may have inadvertently activated Black Out.
All other buttons on the IRC-6 infrared remote control have no function with this
product.
Master/Slave
Mode
The Master/Slave mode allows a single LED Shadow™ product
(the “master”) to control
the actions of one or more LED Shadow™ product
s (the “slaves”) without the need of a
DMX controller. The master product will be set to operate in either Automatic mode,
Sound-Active mode, or with the IRC-6, while the slave product
s will be set to operate in
Slave mode. Once set and connected, the slave product
s will operate in unison with the
master product.
Configure the products as indicated below.
Slave products:
1. Press <MODE>until SLA shows on the display.
2. Press <ENTER> to accept. SLAV will show in the display.
3. Connect the DMX input of the first slave product to the DMX output of the master
product.
4. Connect the DMX input of the subsequent slave products to the DMX output of the
previous slave product.
5. Finish setting and connecting all the slave products.
Master product:
1. Set the master product to run in Auto mode, Sound-Active mode, or with the IRC-6.
2. Make the master product the first product in the DMX daisy chain.
• Configure all the slave product
s before connecting the master to the daisy
chain.
•
Never connect a DMX controller to a DMX string configured for Master/Slave
operation because the controller may interfere with the signals from the master.
• Do not connect more than 31 slaves to the master.

LED Shadow™ User Manual Rev. 6 Page 13 of 16
5. MAINTENANCE
Product
Maintenance
Dust build-
up reduces light output performance and can cause overheating. This can lead
to reduction of the light source’s life and/or
mechanical wear. To maintain optimum
performance and minimize wear, clean your lighting product
s at least twice a month.
However, be aware that usage and environmental conditions could be contributing factors
to increase the cleaning frequency.
To clean the product, follow the instructions below:
1. Unplug the product from power.
2. Wait until the product is at room temperature.
3. Use a vacuum (or dry compressed air) and a soft brush to remove dust
collected on the external surface/vents.
4. Clean all transparent surfaces with a mild soap solution, ammonia-free glass
cleaner, or isopropyl alcohol.
5. Apply the solution directly to a soft, lint free cotton cloth or a lens cleaning
tissue.
6. Softly drag any dirt or grime to the outside of the transparent surface.
7. Gently polish the transparent surfaces until they are free of haze and lint.
Always dry the transparent surfaces carefully after cleaning them.

Page 14 of 16 LED Shadow™ User Manual Rev. 6
6. TECHNICAL SPECIFICATIONS
Dimensions and
Weight
Length
Width
Height
Weight
14 in (356 mm)
9.8 in (248 mm)
6.5 in (165 mm)
4.9 lb (2.2 kg)
Note: Dimensions in inches rounded to the nearest decimal digit.
Power
Power Supply Type
Range
Voltage Selection
Switching (internal)
100 to 240 VAC, 50/60 Hz
Auto-ranging
Parameter
120 V, 60 Hz
230 V, 50 Hz
Consumption
12 W
11 W
Operating Current
0.1 A
0.1 A
Power linking current
(products)
8 A (43 products) 8 A (74 products)
Fuse
F 1 A, 250 V
F 1 A, 250 V
Power I/O
U.S./Worldwide
UK/Europe
Power input connector
IEC
IEC
Power output connector
Edison
IEC
Power Cord plug
Edison (U.S.)
Local plug
Light Source
Type
Power
Lifespan
LED
0.25 W
100,000 hours
Color
Quantity
Current
UV
192
20 mA
Photometrics
Parameter
Coverage Angle
28°
Wavelength
405 nm
Thermal
Maximum External Temp.
Cooling System
104 °F (40 °C)
Convection
DMX
I/O Connectors
Channel Range
3-pin XLR
3
Ordering
Product Name
Item Code
UPC Number
LED Shadow™
10031085
781462214333

LED Shadow™ User Manual Rev. 6 Page 15 of 16
R
ETURNS
In case you need to get support or return a product:
• If you are located in the U.S., contact Chauvet World Headquarters.
• If you are located in the UK or Ireland, contact Chauvet Europe Ltd.
• If you are located in Mexico, contact Chauvet Mexico.
• If you are located in Benelux, contact Chauvet Europe BVBA.
• If you are located in any other country, DO NOT contact Chauvet. Instead, contact
your local distributor. See www.chauvetlighting.com for distributors outside the U.S.,
UK, Ireland, Mexico, or Benelux.
If you are located outside the U.S., UK, Ireland, Mexico, or Benelux, contact your
distributor of record and follow their instructions on how to return Chauvet
products to them. Visit our website www.chauvetlighting.com for contact details.
Call the corresponding Chauvet Technical Support office and request a Return
Merchandise Authorization (RMA) number before shipping the product. Be prepared to
provide the model number, serial number, and a brief description of the cause for the
return.
Send the merchandise prepaid, in its original box, and with its original packing and
accessories. Chauvet will not issue call tags.
Clearly label the package with the RMA number. Chauvet will refuse any product
returned without an RMA number.
Write the RMA number on a properly affixed label. DO NOT write the RMA number
directly on the box.
Before sending the product, clearly write the following information on a piece of paper
and place it inside the box:
• Your name
• Your address
• Your phone number
• RMA number
• A brief description of the problem
Be sure to pack the product properly. Any shipping damage resulting from inadequate
packaging will be your responsibility. FedEx packing or double-boxing are
recommended.
Chauvet reserves the right to use its own discretion to repair or replace returned
product(s).

Page 16 of 16 LED Shadow™ User Manual Rev. 6
C
ONTACT
U
S
WORLD HEADQUARTERS - Chauvet
General Information
Address: 5200 NW 108th Avenue
Sunrise, FL 33351
Voice: [phone]
Fax: [phone]
Toll free: [phone]
Technical Support
Voice: [phone] (Press 4)
Fax: [phone]
Email: [e-mail]
World Wide Web www.chauvetlighting.com
UNITED KINGDOM AND IRELAND - Chauvet Europe Ltd.
General Information
Address: Unit 1C
Brookhill Road Industrial Estate
Pinxton, Nottingham, UK
NG16 6NT
Voice: [phone]
Fax: [phone]
Technical Support
Email: [e-mail]
World Wide Web www.chauvetlighting.co.uk
MEXICO - Chauvet Mexico
General Information
Address: Av. Santa Ana 30
Parque Industrial Lerma
Lerma, Mexico C.P. 52000
Voice: [phone]
Technical Support
Email: [e-mail]
World Wide Web www.chauvet.com.mx
CHAUVET EUROPE - Chauvet Europe BVBA
General Information
Address: Stokstraat 18
9770 Kruishoutem
Belgium
Voice: [phone]
Technical Support
Email: [e-mail]
World Wide Web www.chauvetlighting.eu
Outside the U.S., United Kingdom, Ireland, Mexico, or Benelux
contact your dealer. Follow their
instructions to request support or to return a product. Visit our website for contact details.
