1.BEFORE YOU BEGIN
What Is
Included
•SlimSTRIP UV-18 IRC
•2 L-Brackets
•Power Cord
•Warranty Card
•Quick Reference Guide
Unpacking
Instructions
Carefully unpack the product immediately
and check the container to make sure all the
parts are in the package and are in good condition.
Claims
If the box or the contents (the product and
included accessories) appear damaged from
shipping, or show signs of mishandling, notify the carrier immediately, not Chauvet. Failure
to report damage to the carrier immediately may invalidate your claim. In addition, keep the
box and contents for inspection.
For other issues, such as missing components or parts, damage not related to shipping, or
concealed damage, file a claim with Chauvet within 7 days of delivery.
Text
Conventions
Convention
Meaning
1—512
A range of values
50/60
A set of values of which only one can be chosen
Settings
A menu option not to be modified
Menu > Settings
A sequence of menu options to be followed
<ENTER>
A key to be pressed on the product’s control panel
ON
A value to be entered or selected
Symbols
Symbol Meaning
Critical installation, configuration, or operation information. Not
following these instructions may make the product not work, cause
damage to the product, or cause harm to the operator.
Important installation or configuration information. The product
may not function correctly if this information is not used.
Useful information.
Disclaimer
Chauvet believes that the information contained in this manual is accurate in all respects.
However, Chauvet assumes no responsibility and specifically
disclaims any and all liability
to any party for any loss, damage or disruption caused by any errors or omissions in this
document, whether such errors or omissions result from negligence, accident or any other
cause. Chauvet reserves the right to revise t
he content of this document without any
obligation to notify any person or company of such revision, however, Chauvet has no
obligation to make, and does not commit to make, any such revisions. Download the latest
version from www.chauvetlighting.com.
The works of authorship contained in this manual, including, but not limited to, all design,
text and images are owned by Chauvet.
© Copyright 2016 Chauvet & Sons, LLC. All rights reserved.
Electronically published by Chauvet in the United States of America.
CHAUVET, the Chauvet logo and “SlimSTRIP UV-18 IRC
” are registered trademarks or
trademarks of Chauvet & Sons, LLC. (d/b/a Chauvet and Chauvet Lighting) in the United
States and other countries. Other company
and product names and logos referred to
herein may be trademarks of their respective companies.

Page 4 of 15 SlimSTRIP UV-18 IRC User Manual Rev. 2
Product at a
Glance
Use on Dimmer
x
Auto Programs
P
Outdoor Use
x
Auto-ranging Power Supply
P
Sound-Active
P
Replaceable Fuse
P
DMX
P
User-Serviceable
x
Master/Slave
P
Safety Notes
Please read the following Safety Notes carefully before working with the product. The
Notes include important safety information about installation, usage, and maintenance.
•Always connect the product to a grounded circuit to avoid the risk of electrocution.
•Always disconnect the product from the power source before cleaning or replacing
the fuse.
•Avoid direct eye exposure to the light source while the product is on.
•Make sure the power cord is not crimped or damaged.
•Never disconnect the product from power cord by pulling or tugging on the cord.
•If mounting the product overhead, always secure to a fastening device using a
safety cable.
•Make sure there are no flammable materials close to the product when operating.
•
Do not touch the product’s housing when operating because it may be very hot.
•Always make sure that the voltage of the outlet to which you are connecting the
product is within the range stated on the decal or rear panel of the product.
•The product is for indoor use only! (IP20) To prevent risk of fire or shock, do not
expose the product to rain or moisture.
•Always install the product in a location with adequate ventilation, at least 20 in
(50 cm) from adjacent surfaces.
•Be sure that no ventilation slots on the product’s housing are blocked.
•Never connect the product to a dimmer.
•Make sure to replace the fuse with another of the same type and rating.
•Never carry the product from the power cord or any moving part. Always use the
hanging/mounting bracket.
•The maximum ambient temperature (Ta) is 104 °F (40 °C). Do not operate the
product at higher temperatures.
•In the event of a serious operating problem, stop using the product immediately.
•Never try to repair the product. Repairs carried out by unskilled people can lead to
damage or malfunction. Please contact the nearest authorized technical assistance
center.
•To eliminate unnecessary wear and improve its lifespan, during periods of non-use
completely disconnect the product from power via breaker or by unplugging it.
•Keep this User Manual for future use. If you sell the product to someone else, be
sure that they also receive this document.

SlimSTRIP UV-18 IRC User Manual Rev. 2 Page 5 of 15
2.INTRODUCTION
Product Overview
DMX In/Out
Power Out
Fuse Holder
Safety Loop
LED Display
IR Sensor
Microphone
Control
Buttons
Power In

Page 6 of 15 SlimSTRIP UV-18 IRC User Manual Rev. 2
Product Dimensions
41.9 in
1,064 mm
2.3 in
60 mm
5 in
126 mm
5 in
126 mm

SlimSTRIP UV-18 IRC User Manual Rev. 2 Page 7 of 15
3.SETUP
AC Power
The SlimSTRIP UV-18 IRC has an auto-
ranging power supply and it can work with an
input voltage range of 100 to 240 VAC, 50/60 Hz. To determine the product’s power
requirements (
circuit breaker, power outlet, and wiring), use the current value listed on the
label affixed to the product’s back panel, or refer to the product
’s specifications chart. The
listed current rating indicates the product’s average current draw under normal conditions.
Always connect the product to a protected circuit
(circuit breaker or fuse). Make
sure the product has
an appropriate electrical ground to avoid the risk of
electrocution or fire.
Never connect the product to
a rheostat (variable resistor) or dimmer circuit, even if
the rheostat or dimmer channel serves only as a 0 to 100% switch.
Disconnect the product from the power outlet before replacing the fuse.
Fuse
Replacement
1. Wedge the tip of a flat-head screwdriver into the slot of the fuse holder.
2. Pry the fuse holder out of the housing.
3. Remove the blown fuse from the holder and replace with a fuse of the exact same
type and rating.
4. Insert the fuse holder back in place and reconnect power.
Power Linking The product provides power linking via the Edison outlet located in the back
of the unit.
Please see the diagram below for further explanation.
Power Linking
Diagram
You can power link up to 17 SlimSTRIP UV-18 IRC units on 120 VAC or up to 34
SlimSTRIP UV-18 IRC units on 230 VAC.
The power linking diagram corresponds to the North American version of the
product ONLY! If using the product in other markets, consult with the local Chauvet
distributor as power linking connectors and requirements may differ in your country
or region.
1st Product
2nd Product
3rd Product
Other products
Installed fuse
(held by plastic clip)
Spare fuse holder
(inside safety cap)
Safety cap

Page 8 of 15 SlimSTRIP UV-18 IRC User Manual Rev. 2
Mounting
Before mounting the product
, read and follow the safety recommendations indicated in the
Safety Notes.
Orientation
The SlimSTRIP UV-18 IRC
may be mounted in any position; however, make sure
adequate ventilation is provided around the product.
Rigging
•Before deciding on a location for the product, always make sure there is easy access
to the product for maintenance and programming purposes.
•Make sure that the structure onto which you are mounting the product can support the
product’s weight. See the Technical Specifications for weight information.
•When mounting the product overhead, always use a safety cable. Mount the product
securely to a rigging point, whether an elevated platform or a truss.
•When rigging the product onto a truss, use a mounting clamp
of appropriate weight
capacity.
•When power linking multiple products, mount the products close enough for power
linking cables to reach.
•The bracket adjustment
knobs allow for directional adjustment when aiming the
product to the desired angle. Only loosen or tighten the bracket knobs manually.
Using tools could damage the knobs.
Mounting Diagram
Bracket
Adjustment Knobs
(x2)
Mounting Clamps
L-Brackets
(x2)
(also used as floor supports)
Safety Cable
(such as CH-05 from Chauvet)

SlimSTRIP UV-18 IRC User Manual Rev. 2 Page 9 of 15
4.OPERATION
Control Panel
Operation
To access the control panel functions, use the four buttons located underneath the display.
Please refer to the Product Overview to see the button locations on the control panel.
Button Function
<MENU> Press to find an operation mode or to back out of the current menu
option
<UP> Press to scroll up the list of options or to find a higher value
<DOWN> Press to scroll down the list of options or to find a lower value
<ENTER>
Press to activate a menu option or a selected value
Menu Map
Mode
Programming Steps
Description
DMX Personality and
Starting Address
3-CH d 0–d512
Selects the DMX personality and starting
address
Custom U--
d 0–d255
Selects the custom UV output (0–100%)
S 0–S255 Selects the strobe speed (0–33 Hz)
Sound-Active
Snd
Sets the Sound-Active mode
Sound Sensitivity
SenS
u 0–u100
Selects the sound sensitivity
Infrared SET
On
Turns infrared on or off
OFF
DMX Linking
The SlimSTRIP UV-18 IRC works with a DMX controller
. Information about DMX is in the
CHAUVET® DMX Primer, which is available from the Chauvet website:
http://www.chauvetlighting.com/downloads/DMX_Primer_rev05_WO.pdf
Configuration
(DMX)
Set the product in DMX mode to control with a DMX controller.
1. Connect the product to a suitable power outlet.
2. Connect a DMX cable from the DMX output of the DMX controller to the DMX input
socket on the product.
Starting Address
When selecting a starting DMX address, always consider the number of DMX channels the
selected DMX mode uses. If you choose a starting a
ddress that is too high, you could
restrict the access to some of the product’s channels.
The SlimSTRIP UV-18 IRC uses up to 3 DMX channels,
which defines the highest
configurable address to 510.
If you are not familiar with the DMX protocol, download the DMX Primer from
www.chauvetlighting.com.
To select the starting address, do the following:
1. Press <MENU>repeatedly until 3-CH shows on the display.
2. Press <ENTER> and d 0-d512 will show on the display.
3. Use <UP> or <DOWN> to select the starting address.
4. Press <ENTER>.
DMX Channel Assignments and Values
3-CH
Channel Function Value Setting
1 Strobe
000
ó
001
Open
002
ó
255
Strobe, slow to fast
2 Dimmer 000ó255 0–100%
3 Sound-Active 000ó010 No function
011
ó
255
Sound-Active

Page 10 of 15 SlimSTRIP UV-18 IRC User Manual Rev. 2
Configuration
(Standalone)
Set the product in one of the standalone modes to control without a DMX controller.
•Connect the product to a suitable power outlet.
Never connect a product that is operating in any standalone mode
to a DMX string
connected to a DMX controller. Product
s in standalone mode may transmit DMX
signals that could interfere with the DMX signals from the controller.
Custom Mode
To create your own effect in the custom mode, follow the instructions below:
1. Press <MENU> repeatedly until U-- shows on the display.
2. Press <ENTER>.
3. Use <UP> or <DOWN> to select either
•d 0-d255 for custom UV output (0–100%), or
•S 0-S255 for custom strobe speed (0–33 Hz)
4. Press <ENTER>.
5. Use <UP> or <DOWN> to increase or decrease.
6. Press <ENTER>.
Sound-
Active
Mode
To enable the Sound-Active mode, do the following:
1. Press <MENU repeatedly until Sndshows on the display.
2. Press <ENTER>.
Adjusting Sound
Sensitivity
To adjust the sensitivity of the Sound-Active mode, do the following:
1. Press <MENU repeatedly until SenS shows on the display.
2. Press <ENTER> and u 0-u100 will show on the display.
3. Turn the music on and adjust the sound sensitivity using the <UP> and <DOWN>
buttons until the product starts responding to the beat of the music.
4. Press <ENTER>.
Turning Infrared
On/Off
To enable the Infrared option, do the following:
1. Press <MENU repeatedly until SET shows on the display.
2. Press <ENTER>.
3. Use the <UP> and <DOWN> to choose On or OFF.
4. Press <ENTER>.
IRC-6 Operation
Be sure the IRC-6 remote is pointing directly at the product and there is nothing in
between the remote and the product.
The following buttons function with this product:
•<UV>- adjusts the UV color of the LEDs
•<SOUND>- activated Sound-Active mode
•<SENSITIVITY> - adjusts sound sensitivity
•<STROBE>- controls strobing
•<+> - increases values for controls as described above
•<-> - decreases values for controls as described above
•<BLACKOUT>- turns LEDs on/off
•All other buttons on the remote have no function with this product.
The IRC-6 will not respond to any inputs when Black Out is activated. If the remote
does not respond when a button is pressed, try pressing <BLACK OUT>. You may
have inadvertently activated Black Out.
