Chauvet CH-BOB User manual

Troubleshooting
• If the unit is not functional – check main power supply is ‘on’ and check fuses.
• If the unit is functional but lamp does not light - lamp may require replacing.
• If after trying this solution you still have a problem contact your dealer or CHAUVET.
Contact Chauvet
USA
Tecnical Assistance: 1-800-762-1084 [phone]
E-Mail [email protected]
Europe
Technical Assistance: [phone]
E-Mail [email protected]
Caution
Do not obstruct the air vents.
Do not touch unit or lamps while hot.
Never put any objects through the air grill on the top of the unit.
No user serviceable parts inside, please refer to CHAUVET for service.
Power Connections
The unit is supplied with a power plug appropriate to its voltage and destination. Should any other
connections be required they must be carried out with the following configuration.
Earth = Green/Yellow cable
Neutral = Blue cable
Live = Brown cable
In the USA & Europe, it is required that all plugs are 3-pin type i.e. with Earth/Ground connection.
In the UK, it is required that all mains plugs are fitted with 5A fuses.
Technical Specifications
User Informtion (Please complete for your records)
Date Purchased: / / Serial No: ________________
Dealer Stamp Model: CH-BOB FLAME LIGHT
Power
Fuse
Lamps
Dimensions
Weight
120V~60Hz AC
20mm Glass 1A Fast Blow
4 x 12V 20W
Part No MR11 12v 20W
279mm x 279mm x 160mm / 11in x 11in x 6.3in
5kg / 11lbs
230V~50Hz AC
20mm Glass 0.6A Fast Blow
4 x 12V 20W
Part No MR11 12v 20W
279mm x 279mm x 160mm / 11in x 11in x 6.3in
5kg / 11lbs
Bob Flame Light
CH-BOB
User Guide
Please read these instructions carefully befor use
World-wide Headquarters:
3000 North 29th Ct., Hollywood, Florida, USA, FL 33020
Tel: [phone] Fax: [phone]
European Office:
Unit 18, Hunslet Trading Estate, Leeds, UK
LS10 1BL
Tel: [phone] Fax: [phone]
www.ChauvetLighting.com
Package Contains:
1 x Flame Fixture
6 x Screws
1 x Chain for Hanging
1 x Simulated Flame Cloth
with Magnets
3 x Orange MR11 12v 20w
1 x Blue MR11 12v 20w

Replacing Lamps
1. Disconnect from main power supply before attempting to replace either lamps or fuse.
2. Ensure that the unit is sufficiently cool, before removing blown lamps.
3. Never touch new lamps with your fingers; use a tissue or a cloth.
In order to replace the lamps, disconnect from main power supply first, and unscrew the three screws on
the side of the unit, which are highlighted on the diagram (fig.1). Only use the appropriately rated lamps as
use of any other lamp type may cause the unit to be non-operational.
Due to the nature of halogen lamps it is vitally important that you do not touch the new replacement lamp
with your fingers, as this will reduce lamp life considerably. Once again a tissue or cloth can be used for
fitting the replacement lamp.
Finally before using, check that the lamps are housed correctly in the lamp holder and that the top has
been screwed back into place.
If after replacement of the lamp, the unit is still not working then please contact your dealer or CHAUVET
for servicing.
Replacing Fuses
If the unit does not function at all when connected to the main power supply i.e. the fan does not blow, then
it is highly likely that the fuse has blown.
Disconnect from main power supply before attempting to replace either lamps or fuse.
In order to replace the fuse, disconnect from the main power supply first, and then unscrew the fuseholder
cover to reveal the fuse. The unit has a label attached which indicates the correct fuse rating and you will
also find this listed as part of the specifications for the unit later in this guide. It is most important that
replacement fuses are of the correct rating. Failure to use the correct fuse could damage the lighting effect
beyond economic repair.
The fuse should simply be placed inside the holder and the screw cap replaced, when this is done connect
to the main power supply to check. If the unit is still not working then please contact your dealer or
CHAUVET for servicing.
Cleaning
The body of the unit should be cleaned with a soft damp cloth. We recommend internal cleaning be carried
out by a fully qualified technician.
Maintenance & Servicing
Work on internal parts should be carried out by a qualified technician. Removal of covers other than to
replace the lamps or the fuseholder is considered a breach of warranty and will not be covered under any
such agreement unless authorized first by the company.
Introduction
Congratulations on the purchase of your new CHAUVET lighting effect. We are confident you will enjoy
many trouble free hours with this unit. To assist with the care and use of the product we have prepared this
short guide.
Operation
Before connecting this unit to the mains power supply for the first time you must first install the lamps.
(See ‘Replacing Lamps’ for details) and the simulated flame cloth.
This lighting effect has been designed to function on a mains power supply of either 120V~60Hz or
230V~50Hz and has been fitted with a suitable power plug for use with your local voltage. Check the label
and voltage selector switch (if fitted) on the unit and the power plug for the correct voltage.
When connected to the mains power supply the unit should illuminate. The fan will also start to blow.
Due to the high operating temperature of halogen lamps it is advisable that the effect be used in well
ventilated areas taking care not to obstruct the air vents. After use allow time to ‘cool’ for safety and to
ensure lamp life before moving or touching.
The simulated flame cloth has two magnets attached. The magnets should be affixed to the two metal
plates above the air grill.
Installation / Mounting
This unit is designed to be used either standing on three legs or hanging. The three legs attach easily to
the bottom of the unit by means of two screws each. The screws will be found separately in a plastic bag.
Alternatively, you can hang the unit by means of the included chain. The chain affixes to the unit by means
of tree clips. Be careful to properly secure the chain when hanging the unit.
Use in a well-ventilated area without obstruction to air vents.
On Unit:
• Flame Cloth
• Screws for Lamp Cover
• Fan
• Fuse Holder
• Leg Attach area
Hanging Chain
Fig. 1
