CheckVideo CV154 Manual

Step One Connect Camera to Router
CheckVideo High Denion Indoor Micro Dome Camera
Installaon Quick Reference
Fig. 1 - Add Device: Enter device serial number
1. For later reference, enter the device’s serial number in the box below. Also known as MAC, this number is found on the underside of the
camera:
2. Before installing the camera in its final location, power the camera and connect it to the network. If your router supports PoE, connect the
camera to a PoE port via a Cat-5 network cable. Otherwise, connect the camera to an open port on the router and use a DC 12V/PoE 48V
power supply to power the camera. Note: Ethernet cable runs can be no longer than 100 meters.
3. If using the PoE injector, connect the router or switch to “Data In” on the injector and connect the injector’s “Data & Power Out” port to the
camera using Cat-5 network cables. Connect the injector to a power outlet.
Included in the box:
• CheckVideo® HD Dome Camera
•Bag of mounting parts: screws (5), drywall
mounts (5), hex wrench, 2 Phoenix con-
nectors
•256GB MicroSD card, pre-inserted
•Power Over Ethernet (PoE) injector
(recom-mended for testing only)
• Camera cabling giude
You’ll also need:
•PC or Mac® with Broadband Internet
Service
• Router, connected to the Internet
•Phillips screwdriver
•Cat-5 network cables
•DC 12V/PoE 48V power supply
1. If camera will be monitored by a central staon, contact
them to add the device to their account.
2. If self-monitored, go to the CheckVideo Dashboard via
login page: portal.checkvideo.net
3. On the CheckVideo Dashboard, click on Devices > Add
Device
4. In the Register Device secon, enter the MAC ID found on
the underside of the camera and create a Device Name.
5. Click the Test Device buon to make sure the Check-
Video Soware Service (CVSS) can communicate with the
device.
6. When prompted, update the device rmware.
Step Two Add CheckVideo HD Camera
Things You Need for Installaon
If this CheckVideo device will be monitored by a central staon, please contact the central staon for a username and password on their exisng
CheckVideo account. The central station will add the device to their account.
If this device will be self-monitored, you will be adding it to your CheckVideo account. If you do not have an account, contact CheckVideo support.

For more detailed informaon, refer to the CheckVideo HD Indoor Micro
Dome Camera Installaon Guide available at www.checkvideo.com.
Step Three Install Camera
Step Four Conguraon
Fig. 7a - A zone, dened by eight end points
(rst point is green; other points are blue)
Fig. 7b - A completed zone
1. On the CheckVideo Dashboard, click on Devices >
Congure Device.
2. Select Device: Select the device and video resoluons
for event clips and DVR. CheckVideo will default both
resoluons to 720p. You may wish to start with these
sengs. Your chosen resoluon sengs will depend
upon the upload capacity of your Internet provider.
3. Congure Events: Click the Edit buon to create a
zone for a parcular object type. Then use your mouse
to draw the zone by clicking the le mouse buon
wherever you want to dene a point of the zone. The
zone should cover the enre area where you want to
detect an event. Enter a me span, event type, zone,
and duraon and click Add Event buon.
4. Select Nocaon Method - Central Staons: Select a
Central Staon type that should receive alert metadata.
5. Select Nocaon Method - Users: Click the checkbox
next to any user(s) who should receive nocaons for
this camera and their method of nocaon.
6. Click Save.
© 2020 CheckVideo, LLC
CheckVideo is a registered trademark of CheckVideo, LLC. All rights reserved.
7CVCHQC000E-02.00
Fig. 2 - MORE EFFECTIVE: Cameras
are at a 15 to 45 degree downward
lt and are mounted 8 to 20 feet high
Fig. 3 - LESS EFFECTIVE: Cameras are
directly overhead (90 degrees) or parallel
to (0 degrees) the target
To opmize event detecon, place your CheckVideo HD Camera
as follows:
•HEIGHT: Each camera must be installed 8 to 20 feet o the
ground.
•DISTANCE: If you are mainly detecng people, the distance
between the camera and the people you wish to detect
should be 10 to 100 feet. If you are primarily concerned with
detecng vehicles, the range is 30 to 160 feet.
The CheckVideo Camera Placement Guide includes a summary
checklist on improving your camera placement.
Once you’ve determined where to place the Camera, run Cat-5
network cable from the router to the desired locaon. The
Camera can be placed on a ceiling or wall.
To adjust the camera to the proper angle, remove the cover using
the included hex wrench. This will expose the ball and lens. The
ball rotates in 3 direcons. Gripping the ball, adjust the angle for
your locaon, seeking to maintain a 15 to 45 degree downward
lt. Be careful not to touch the lens as rotang it will change the
focus and may result in ngerprints on your video images.
Using the mounng screws, aach the camera to the wall or
ceiling and reaach the cover using the previously removed hex
screws.
Remember to pay aenon to the microSD card, being
careful to avoid pressing on it with the camera's cover.
Power up the camera (refer to Step 1 for addional informaon).
Fig. 6- Rotate Image buon
Fig. 4 - Remove the cover using the
supplied hex wrench
Fig. 5 - Rotate the Ball to achieve the
proper viewing angle.
Make sure your browser is set to 100% when drawing
your zone.
,
Ball Lens
MicroSD
Card
