Cheetah RadarDetector Interface User manual

1 x In-line fuse unit (3 Amp)
1 x POWERSENSEnode engine running sensor
1 x Power cable
1 x RADARnode wireless transmitter
1 x RDI software card for the V1 (inserted in RADARnode)
1 x Radarnode connector cable
1 x Cheetah V1 remote adapter
1 x Cheetah connector cable for the V1
1 x User manual
Cheetah parts are pre-connected for your convenience. Our
2-pin mini connectors push-fit together and lock securely. To
unclip, press the lever down and gently pull them apart.
The RADARnode is a wireless transmitter (433 Mhz) that
connects up to your radar detector’s power supply socket.
When your radar detector gives an alert, the RADARnode
digitally analyzes the alert data and transmits a radio code to
your helmet display.
The small flying lead with half a bullet connector at the end
(plastic sheathed) is an over-ride cable for connecting to a
Cheetah Laser Jammer Interface in motorcycle installations.
The POWERSENSEnode is a clever “engine running” sen-
sor that turns on power when you start up your motorcycle
and turns it off when you stop the engine. It’s an instant,
“ignition-switched” supply that makes it quick and easy for
anyone to create a safe power supply directly from the battery
terminals. It eliminates the need for direct wiring into your
bike’s electrical system.
THIS INTERFACE IS COMPATIBLE WITH:
Warranty Registration
Register online at www.SpeedCheetah.com
Limited Warranty
Cheetah Advanced Technologies Ltd. warrant our products
against all defects in materials and workmanship for a period
of one year from the date of the original purchase. Full
warranty terms and conditions available online at:
www.SpeedCheetah.com
Service & Support
If for any reason your Cheetah product develops a fault,
please check our Customer Service page on:
USA & Canada - visit www.GPSdetector.com
Europe & Rest of World - visit www.SpeedCheetah.com
If any problems persist, or to arrange a product return, please
email [email protected]
Cheetah Advanced Technologies Ltd. declares that this product
is in compliance with the essential requirements and other
relevant provisions of Directive 1999/5/EC.
This device complies with Part 15 of the FCC Rules. Operation
is subject to the following two conditions: (1) this device may not
cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause
undesired operation.
© 2009 Cheetah Advanced Technologies Ltd, Scotland. All rights reserved.
RDI Software card
Detector socket
Power socket
Test button
Over-ride cable for
Cheetah LASERnode
The RADARnode Transmitter

Instal the RADARnode according to the diagram above.
Please note that the RADARnode transmitter is not water-
proof so should always be positioned in the seat cavity.
2.1 The Cheetah connector cable for the V1 must be
installed the correct way round. Each end of the cable is
labeled. If the cable is inserted the wrong way round it
will not work. Plug the end labelled “V1” into your Valentine
detector.
2.2 Safely route the Cheetah connector cable from your V1
to the cavity underneath the motorcycle seat. Secure the
cable to the bike wherever possible, avoiding contact with
any high temperature engine components or exhaust system.
2.3 Plug the RDI connector cable into the Cheetah V1
Remote Adapter, and then connect this to the DETECTOR
socket of the RADARnode transmitter.
2.4 Double check that the RDI software card and connector
cable are specific to your radar detector. The RDI software
card is pre-installed in the side of the RADARnode transmit-
ter. Always ensure that the power is OFF before remov-
ing or inserting your RDI software card.
2.5 Connect the Cheetah V1 Remote Adapter to the Valen-
tine direct wire power adapter. Then use the Accessory
socket of the direct wire adapter to connect up the Valentine
Concealed Display or the Valentine Remote Audio Adapter
(or both of them together.)
2.6 To power the system, connect the Valentine direct-wire
adapter to the POWERSENSEnode. The fuse pack can then
be connected directly to the battery terminals. RED is posi-
tive, BLACK is negative. There is no need to remove the
leads from the battery. Just loosen the nut on the clamp,
slide in the spade terminal, and re-tighten the nut.
2.7 OPTIONAL - laser jammer installations only. Connect
the small flying lead with the bullet connector to the similar
over-ride cable on the Cheetah LASERnode.
V1 menu items can be set according to personal preference.
4.1 Starting up your system
The radar detector and VizAlert display work independently.
The POWERnode attached to the battery will automatically
turn on the power to the RADARnode transmitter and radar
detector when you start your motorcycle’s engine. It will
remain on for as long as the engine is running.
The VizAlert’s battery pack has a sliding ON/OFF switch. All
6 LEDs will flash once, at the same time, to confirm it is
switched on. When you power up your detector, the transmit-
ter will begin to transmit to the VizAlert helmet receiver. The
VizAlert LED's will flash in a circular sequence when the
wireless link has been established.
4.2 Testing your system
Press and release the test button on the side of the RADAR-
node. The VizAlert will flash each LED in sequence. Remem-
ber, your engine must be running for the transmitter and
detector to be powered up.
4.3 Alerts
Please refer to the VizAlert manual for interpreting alerts.
Ku band users in Europe - If Ku band is enabled, please
note the V1 uses the same audio tone for K and Ku bands.
The RADARnode will copy this and transmit a K band warn-
ing for both K and Ku alerts so the VizAlert will flash white for
both K and Ku bands.
4.4 Switching off your system.
When you switch off your engine, power to the RADARnode
transmitter and radar detector is automatically switched off.
The VizAlert is motion sensitive and switches off after 10
minutes of no movement.
The VizAlert V2’s battery pack has a sliding ON/OFF switch
and an automatic shut off, if you leave it on by accident.
Constant KU Band radar alert
RDI software card is not correctly installed. It must be fully
inserted into the slot on the side of the RADARnode. Switch
off power, then remove the card and re-insert flush. Always
ensure that the power is OFF before removing or insert-
ing your RDI software card.
Detector
RADARnode
In-line fuse with
battery connectors
Cheetah connector cable must be
inserted the correct way round.
Power in To any Valentine displays
POWERSENSEnode
Jammer
over-ride
Valentine
Concealed Display
Valentine Remote
Audio Adapter
Cheetah connector cable
Valentine
Direct-wire
Power adapter
