Chef cooking CRI714DB User manual

Rangehoods
Installation and User Manual
CRI514DB, CRI714DB cooking

2
WELCOME TO CHEF
Thank you for purchasing this appliance. You’ve chosen
a product that brings with it decades of professional
experience and innovation. Ingenious and stylish, it has
been designed with you in mind. So whenever you use
it, you can be safe in the knowledge that you’ll get great
results every time.
LEGEND
The symbols you will see in this booklet have
these meanings:
WARNING!
This symbol indicates information concerning
your personal safety
CAUTION!
This symbol indicates information on how to avoid
damaging the rangehood
IMPORTANT!
This symbol indicates tips and information about
use of the rangehood
ENVIRONMENT!
This symbol indicates tips and information about
economical and ecological use of the rangehood
CONDITIONS OF USE
This appliance is intended to be used in household and
similar applications such as:
• Staff kitchen areas in shops, offices and other
working environments
• Farm houses
• By clients in hotels, motels and other residential
type environments
• Bed and breakfast type environments.
• Catering and similar non-retail applications
CONTENTS
3Important safety instructions
4Installation
6Operation and maintenance
7Warranty
RECORD MODEL AND SERIAL
NUMBER HERE:
Model:
Serial No:
Adherence to the directions for use in this manual is
extremely important for health and safety. Failure to strictly
adhere to the requirements in this manual may result in
personal injury, property damage and affect your ability
to make a claim under the manufacturer’s warranty provided
with your product. Products must be used, installed and
operated in accordance with this manual. You may not be
able to claim on the manufacturer’s warranty in the event that
your product fault is due to failure to adhere this manual.
IMPORTANT INFORMATION THAT MAY IMPACT
YOURMANUFACTURER’S WARRANTY

3
SAFETY INSTRUCTIONS
Please read this manual carefully prior to installing and
using the rangehood in order to avoid damage or injury.
The manufacturer will not accept liability for damage
caused from not following these instructions. If you
need assistance contact Customer Care. Please keep
the manual for future reference and pass it on to any
new owners of the appliance.
ENVIRONMENT!
Remove and discard any packaging material before
using this accessory. Most of the packaging materials are
recyclable. Please dispose of those materials through your
local recycling depot or by placing them in the appropriate
collection containers.
WARNING!
• This appliance is not intended for use by persons
(including children) with reduced physical, sensory
or mental capabilities, or lack of experience and
knowledge, unless they have been given supervision
or instruction concerning use of the appliance by a
person responsible for their safety.
Children should be supervised to ensure that they do
not play with the appliance.
• Ensure the rangehood is switched off before carrying
out maintenance, to avoid any possibility of electric
shock.
• Grease filters must be removed every four weeks
(maximum) for cleaning to reduce the risk of fire.
• Do not flambe or have an exposed flame under the
rangehood.
• This rangehood is not recommended for barbecues.
• The exhaust air from the rangehood must not be
discharged into any heating flue, which may carry
combustion products from other sources.
• Exhaust air must not be discharged into a wall cavity,
unless the cavity is designed for the purpose.
• There must be adequate ventilation of the room
when the rangehood is used at the same time as
appliances burning gas or other fuels.
• Always cover lit gas burners with pots or pans when
the rangehood is in use.
• Always switch off gas burners before you remove pots
or pans.
CAUTION
• Accessible parts may become hot when used with
cooking appliance.
• Regulations concerning the discharge of air have to
be fulfilled.
• WARNING: Failure to install the screws or fixing
device in accordance with these instructions may
result in electrical hazards.
Cleaning
• Wipe the rangehood body and flue with a sponge or
soft cloth soaked in warm soapy water, and dry with a
soft cloth, for stainless steel models apply a stainless
steel protector. Do not use oven cleaners or other
abrasive materials.
• There is a fire risk if cleaning is not carried out in
accordance with the instructions.
Electrical Connection
• Check that the mains voltage matches with the
voltage on the data plate inside the rangehood.
• Check that the installation complies with standards of
local gas and electricity authorities.
• If the supply cord is damaged, it must be replaced
by the manufacturer or its service agent or a similarly
qualified person in order to avoid a hazard.
Accessories
• Use 120mm round exhaust ducting for best
performance.
• When using flexible duct always install duct with the
wire helix pulled taut to minimise pressure loss.
• Try to keep exhaust duct short and straight.
• Keep bends in the exhaust duct to a minimum.
• Do not restrict exhaust duct.
• Reducing the size of the exhaust duct will reduce the
airflow of the rangehood. Please read instructions
carefully. Service calls resulting from incorrect
installation will be charged for.
Installation must comply in all respects with your gas and
electrical authorities. This rangehood is an indoor domestic
appliance, and has been manufactured and tested to
comply with Australian and New Zealand Standard
AS/NZS 60335.2.31
• In order to avoid a hazard due to inadvertent resetting
of the thermal cut-out, this appliance must not be
supplied through an external switching device, such
as a timer, or connected to a circuit that is regularly
switched on and off by the utility.
•This appliance has a 1.2m power cord and 10A plug,
ensure that the plug is accessible after installation.
• Range hoods and other cooking fume extractors may
adversely affect the safe operation of appliances
burning gas or other fuels (including those in other
rooms) due to back flow ofcombustion gases. These
gases can potentially result in carbon monoxide
poisoning. After installation of a range hood or other
cooking fume extractor, the operation of open flued
gas appliances should be tested by a competent
person to ensure that back flow of combustion
gases does not occur.
Means for disconnection must be incorporated in the
fixed wiring in accordance with the wiring rules.
•

4
INSTALLATION
Standard ducting installation
It is recommended that the unit be positioned at a
minimum of 600mm for an electric cooktop and 650mm
for a gas cooktop, and no further from the cooktop than
800mm. The unit becomes less effective as the distance
from the cooking surface to the rangehood increase.
650
GAS
ELECTRIC
600
Fixing point dimensions – CRI514DB
Fixing point dimensions – CRI714DB
Parts supplied with hood
1 x Ø 120mm air outlet
4 x self tapping screws 3.5 x 12mm
4 x self tapping screws 4 x 32mm
2 x air intake grilles
Parts to be purchased
• Aluminium tape or cable ties to secure flue pipe
• Ducting accessories
Cutting the wooden support
Cut the slot in the wooden support as pictured below
Fixing the air outlet
underside of
rangehood
top of cooking
surface
if the cooktop
manufacturer
specifies
a greater
clearance
then that
must be used
Wooden support
304
512
170
12
120
276
453
200
304
712
170
12
120
276
644
200
455 / 648
277
225
478 / 668
Flip the non-return valves and fix them with tape or clamp
temporarily. Use screws to fix the air outlet to the
rangehood then release the non-return valves.

5
INSTALLATION
Fixing the rangehood
Use screw to fasten the rangehood to the wood
support from botton side.
Fixing the flue pipe
Fix a Ø 120mm, non-combustible, rigid flue pipe to the
exhaust transition duct using cable ties or duct tape.
IMPORTANT!
If using a flexible duct, always install duct with the
wire helix pulled taut to minimise pressure and noise.
Accessories can be bought from your local appliance
retailer, or in Australia at our online spare parts and
accessories store: shop.electrolux.com.au
Recirculating installation
If recirculating installation is used, carbon filters are
recommended.
Replace the air intake grills with carbon filters.
Fixing the front panel and filter
Replace the front cover by replacing the 4x screws,
then refit the filters.
Note:The Edision Screw lamps may have come loose
during transportation. Ensure that lamps are tighted
firmly into the socket before fixing the front panel.
AR125WV
Installing carbon filters
air intake grill
carbon filter
ST 4 x 32
Optional carbon filters diminish cooking odours in the
recirculated air. Depending on the frequency of use and
the type of cooking, the expected life of carbon filters is
3 months. Using carbon filters will reduce the airflow of
the rangehood.
Ducting accessories - CRI514DB CRI714DB
For best performance Ø 120mm ducting is recommended
roof cowl
AR125RC
AR125F
AR125FD
AR125FJ
wall vent kit
AR125WV
bend AR125B
E653140

6
OPERATION & MAINTENANCE
Maintenance
WARNING!
Do not change the light bulb or carry out maintance
immediately after use as the bulb and the cooker
hood maybe hot. Allow it to cool first.
Use both hands for removing and re-fitting the filter
and the front panel to avoid accidentally dropping
the filter or the front panel on to your cooktop or
kitchen bench.
0 1 0 1 2
IMPORTANT!
The Edison Screw lamps may have come loose during
transportation.
Ensure that lamps are tightened firmly into the socket
before power is applied.
Best result are obtained by using a low speed for normal
conditons and a high speed when odours are more
concentrated. Turn the hood on a few minutes before you
start cooking. It should be left on after cooking for about
15 minutes or untill all odours have disappeared.
Light switch: This switch is used to turn the light
fitted in the hood on and off.
Extractor fan switch:
Slide position 0:
Slide position 1:
Slide position 2:
Used to select fan speeds.
Fan off
Fan speed Low.
Fan speed High.
• Before maintenance or cleaning is carried out,
the rangehood should be disconnected from
the main power supply. Ensure that the rangehood
is switched off at the wall socket and the plug
removed.
• External surfaces are susceptible to scratches
and abrasions, so please follow the cleaning
instructions to ensure the best possible result is
achieved without damage.
• There is a fire risk if cleaning is not carried out
in accordance with the instructions.
•
•
1. Remove the filter, then unfasten the front panel fixing
screws then remove the front panel.
2. Replace with 5.5W maximum E14 LED candle lamp.
The lamp assembly includes a sillicone seal, this must be
replaced when a new lamp is used. The silicone seal is
placed over the lamp thread and then the lamp is screwed
into the holder. Ensure replacement lamp is tightened
firmly. Replacement lamps from Electrolux Parts Centres
are supplied with sillicone seals.
Cleaning the surface
Clean the surfaces using non-abrasive cleaning products.
To ensure best results also use an even pressure.
Use of a soft cloth reduces the risk of scratching. If the
cloth is wet ensure that a dry soft cloth is used to wipe
down the surface again.
Cleaning grease filters
The mesh filters can be cleaned by hand in warm soapy
water. Soak in warm water and some washing up liquid.
For stubborn grease stains use a soft nylon brush to help
remove these stains.
The filters can be washed in the dishwasher,
recommended the filters be placed on the top shelf of
the dishwasher.
After cleaning ensure that the filters are completely dry
before refitting.
Replacing the lamp
Take care of sharp edges during installation,
maintenance and cleaning. When the filters,
light cover or fascia panel are removed,
wear gloves for protection.
•
E14 5.5W LED -> DBL-5.5-H-E14-35/102
Suitable lamp for replacement

This document sets out the terms and conditions of the product
warranties forChef Appliances. Itis an important document.Please
keep it with your proof of purchase documents in a safe place for
future reference should there be a manufacturing defect inyour
Appliance. This warranty isin addition to other rights you may have
under the Australian Consumer Law.
1. In this warranty:
(a) ‘ACL’ or‘AustralianConsumer Law’ means Schedule 2 to the
Competitionand Consumer Act 2010;
(b) ‘Appliance’means any Electrolux product purchased by you and
accompanied by this document;
(c) ‘ASC’ means Electrolux’s authorised servicedcentres;
(d) ‘Chef’ is thebrand controlled by Electrolux Home Products PtyLtd
of 163 O’Riordan Street, Mascot NSW 2020, ABN 51 004 762 341
in respect of Appliances purchased in Australia and Electrolux (NZ)
Limited (collectively “Electrolux”) of 3-5 Niall Burgess Road, Mount
Wellington, in respect of Appliances purchased in New Zealand;
(e) ‘WarrantyPeriod’ means the period in clause 3 of this
warranty;
(f) ‘you’ means the purchaser of the Appliance not having purchased
theAppliance for re-sale, and ‘your’ has a corresponding meaning.
2. Application: This warranty only applies to new Appliances, purchased
and used in Australia orNew Zealand and isinaddition to (and does not
exclude, restrict, ormodify inany way) other rights and remedies under
alaw to which the Appliancesor services relate, including any non-
excludable statutory guaranteesin Australia and New Zealand.
3. Warranty Period:Subject to these terms and conditions, this warranty
continues for in Australia for a periodof24 months and inNew Zealand
for a periodof24 months, following the date oforiginal purchase of the
Appliance.
4. Repair or replace warranty: During the Warranty Period, Electrolux
or its ASC will, at no extra charge ifyour Appliance is readily accessible
for service, without special equipment and subject to these terms and
conditions, repairor replace any parts whichitconsiders to be defective.
Electrolux may, inits absolute discretion, choose whether the remedy
for a valid warranty claim is repair or replacement. Electrolux or its
ASC may use refurbished parts to repairyour Appliance. You agree that
any replaced Appliancesor parts become the property of Electrolux.
5. Traveland transportation costs:Subject to clause 7, Electrolux will
bear the reasonable cost of transportation, travel and delivery of the
Appliance to and from Electrolux orits ASC. Travel and transportation will
be arranged by Electrolux as part ofany validwarranty claim.
6. Proof ofpurchaseis required before youcanmake a claim under this
warranty.
7. Exclusions:You may not make a claim under this warrantyunless the
defect claimedis due to faulty or defective parts orworkmanship. This
warranty does not cover:
(a) light globes, batteries, or similar perishable parts;
(b) parts and Appliances not supplied by Electrolux;
(c) cosmetic damage which does not the operation of the
Appliance;
(d) damage to the Appliance caused by:
(i) negligence or accident;
(ii) misuse or abuse, including failure to properly maintain or service;
(iii) improper, negligent or faulty servicing or repair works done by
anyone other than an Electrolux authorised repairer or ASC;
(iv) normal wear and tear;
(v) power surges, electrical storm damage or incorrect power supply;
(vi) incomplete or improper installation;
(vii) incorrect, improper or inappropriate operation;
(viii) insect or vermin infestation;
(ix) failure to comply with any additional instructions suppliedwith
the Appliance;
In addition, Electrolux is not liable under this warranty if:
(a) the Appliancehas been, or Electrolux reasonably believes that the
Appliance has been, used for purposes other than those for which
the Appliance was intended, including where the Appliance has
been used for any non-domestic purpose;
(b) theAppliance is without authority from Electrolux in writing;
(c) the Appliance’s serial number or warranty seal has been removed
or defaced
8. How to claim under this warranty: To enquire about claimingunder
this warranty, please follow these steps:
(a) carefully check theoperating instructions,user manual and theterms
of this warranty;
(b) have the model and serial number of the Appliance available;
(c) have the proof of purchase (e.g. an invoice) available;
(d) telephone the numbers shown below.
9. Australia: For Appliances and services provided by Electrolux in
Australia: Electrolux goods come with guarantees that cannot be
excluded under the Australian Consumer Law. You are entitled to a
replacement or refund for a major failure and for compensation for any
other reasonably foreseeable loss or damage. You are also entitled to
have theAppliance repaired or replaced if the Appliance fails to be of
acceptable quality and the failure does not amount toa major failure.
‘Acceptable quality’ and ‘major failure’ have thesame meaning as
referred to in theACL.
10. New Zealand: For Appliances and services provided by Electrolux
in New Zealand, the Appliances come with a guarantee by Electrolux
pursuant totheprovisions of the Consumer Guarantees Act, the Sale
of Goods Act and theFair Trading Act. Where the Appliance was
purchased in New Zealand for commercial purposes the Consumer
Guarantee Act does not apply.
11. You accept that if you makea warrantyclaim, Electrolux
and its agents including ASCmay exchange information in relation to you
to enable Electrolux to meet its obligations under this warranty.
Warranty
FOR SALES IN AUSTRALIA AND NEW ZEALAND
APPLIANCE: CHEF RANGEHOODS
CRange_War_Jul19
Important Notice
Before calling for service, pleaseensure that the steps listed in clause8 above havebeen followed.
AUSTRALIA
FOR SERVICE
or to the address of your nearest
authorised service centre in Australia
PLEASE CALL 13 13 49
For the cost of a local call
FOR SPARE PARTS
or to the address of your nearest
spare parts centre in Australia
PLEASE CALL 13 13 50
For the cost of a local call
NEW ZEALAND
FOR SERVICE
or to the address of your nearest
authorised service centre in New Zealand
PLEASE CALL 0800 10 66 10
FOR SPARE PARTS
or to the address of your nearest
spare parts centre in New Zealand
PLEASE CALL 0800 10 66 20

Chef. We are part of the Electrolux family.
Share more of our thinking at electrolux.com.au
© 2019 Electrolux Home Products Pty Ltd
ABN 51 004 762 341
CMAN_Rangehoods_April21
For further information on all Chef appliances, or to obtain
detailed dimension and installation information, call into
your Retailer, phone or email our Customer Care team or
visit our website:
Australia
phone: ..........................................................13 13 49
fax:.......................................................1800 350 067
email: ............................. [email protected]
web:............................................chefappliances.com.au
like to know more?
