Chef's EH-IH545 User manual

Electric Induction hobs Chef’s
EH
-
IH
545
1
INSTALLATION AND OPERATION MANUAL
ELECTRIC INDUCTION HOBS
(BUILT-IN)
Model: EH-IH545
Please read the instruction manual carefully before using

Electric Induction hobs Chef’s
EH
-
IH
545
2
TABLE OF CONTENTS
PREFACE
1. SAFETY INSTRUCTION.. ……………………………………………………………………
2. INSTALLATION INSTRUCION ……………………………………………………………...
3. INDUCTION COOKING ………………………………………………………………………
4. PRODUCT SPECIFICTION ………………………………………………………………….
5. BASIC CONTROL FUNCTIONS ....................................................................................
6. SWITCHING ON/OFF THE COOKTOP
.........................................................................
7. SELECTING A POWER LEVEL FOR A
HEATER .........................................................
8. FAST BOIL (BOOSTER)
FUNCTION.............................................................................
9. SWITCHING OFF A HEATER
.......................................................................................
10. KEY
LOCK ................................................................................................................ ..
11. AUTOMATIC SAFETY
OFF.........................................................................................
12. PAUSE FUNCTION …….
............................................................................................
13. OPERATING THE
TIMER ……………..........................................................................
14. DISPLAYING SPECIAL STATUSES
..........................................................................
15.
ERRORS/ALARMS .....................................................................................................

Electric Induction hobs Chef’s
EH
-
IH
545
3
Preface
Thank you for choosing CHEF’S cooking appliances.
Read this instructions carefully. Only after doing this will you be able to operate
your appliance properly.
Keep this Instructions in a safe place. If the appliance is given to another person,
ensure the appliance documentation is also included.
Any defects and losses caused by ignoring the mentioned items and cautions
mentioned in the operation and installation instruction are not covered by our warranty
and any liability. Please keep all document in a safety place for future reference. If you
have any doubt, please contact our local customer service center or dealer.
Check the appliance after removing it from the packaging. If you find the induction
hob (built-in) is visibly damaged, do not use it.
Contact your local Customer Service or dealer immediately.

Electric Induction hobs Chef’s
EH
-
IH
545
4
1. Safety Instructions
The induction hob (built-in) is designed for domestic use only. Only use the
induction hob for food preparation so that it should be installed in the kitchen.
Safe operation:
To use this appliance safely, adults and children who as a result of
* physical, sensory or mental disability
* or lack of experience or knowledge are not capable of using this appliance
should not do.
Children must be supervised to ensure that they do not play with the appliance.
Overheated oil, butter or margarine:
Overheated oil or butter (margarine) can quickly ignite. It may cause a fire!
Ensure that you keep a constant watch when cooking foods with oil or butter.
In the event that the oil or butter catches fire, never use water to put it out. Put the
fire out quickly by covering the pan with a cover or dish. Switch off the hotplate.
Not to add additional timer or remote control to control the hob.
Hot cooking hob
Risk of burns! Do not touch the hot areas of the hob. It is imperative that children
keep away from the appliance. The residual heat Indicator tells you if the hotplates are
hot (See “Residual heat warning light” section ).
It may cause a fire! Never rest flammable objects on the cooking hob.
It may cause a fire! If there is a drawer below the induction hob, this should not be
used to store any flammable objects or sprays.
Wet hotplates and pan bases
Risk of injuries! If there is any liquid between the base of the
pan and the hotplate this could generate steam pressure. As a
result, the pan could jump unexpectedly.
Always ensure that the hotplate and the base of the pan are
kept dry.
Cracks in the hob
Risk of electrocution! Disconnect the appliance from the mains if the induction hob
is broken or cracked. Contact Local Customer Service or Dealer.

Electric Induction hobs Chef’s
EH
-
IH
545
5
The hotplate heats up but the visual indication does not work
Risk of burns! Disconnect the hotplate if the indicator does not work. Contact Local
Customer Service or dealer.
Do not place metal objects on the Induction hob
Risk of burns! Do not leave cutlery, lids or other metal
objects on the hob as they can heat up very quickly.
Taking care of the cooling fan
This induction hob is fitted with a fan in the lower section.
Risk of malfunction! If a drawer is fitted beneath the hob you must not keep small
objects or paper in it as, if they are Picked up, they could damage the cooling fan or
affect the cooling system.
Please, note: there should be a minimum distance of 2 cm between the drawer
contents and the cooling fan.
Incorrect repairs
Risk of electric shock! Incorrect repairs can be dangerous.
Repairs may only be carried out by the Customer Service.
Power cable
Any work on the appliance, including replacing the power Cable must be carried out
by the Customer Service.
The power cable of the appliance must not touch the hot areas of the hob. The
cable insulation and hob can be damaged.
This appliance complies with current safety regulations and electromagnetic
compatibility regulations.
Nevertheless, people with a peacemaker should not use this appliance.
It is impossible to guarantee that all such devices found on the market comply with
current safety regulations and electromagnetic compatibility regulations, and that
dangerous interference will not occur. It is also possible that people with other types of
device, such as hearing aid, could experience some discomfort.
Switching the hob off
Always switch the hob using the main switch of the Control Panel after each use.
Do not wait until the hob switches off automatically when the pan is removed.

Electric Induction hobs Chef’s
EH
-
IH
545
6
Causes of damage:
The base of the pans
The rough bases of pans may scratch the hob.
Avoid leaving empty pans on the hotplates. These may
cause damage.
Hot pans
Never rest hot pans on the control panel, the indicator area or the hob surround.
Salt, sugar and sand
salt, sugar and sand may scratch the ceran glass.
Do not lean on the hob or use it as work surface.
Hard and pointed objects
Hard or pointed objects may cause damage if they fall onto the hob.
Spilt food
Sugar and other similar products may damage the hob.
These products should be removed immediately using a
glass scraper.
Inappropriate cleaning products
Discolorations in the metal are caused by using unsuitable cleaning products and
wear as a result of contact with pans.
Plastic and foil
Aluminum foil and plastic containers will melt if placed on the hot areas of the hob
Advice on saving energy
Use a pan with thick flat base. Curved bases increase
energy consumption.
Place a ruler on the base of the pan, if there are no
gaps, the base of the pan is completely flat.
The diameter of the base of the pan should fit the
size of the hotplate.
Check if the manufacturer has indicated the upper diameter of the pan. In general,
this is greater than the diameter of the base of the pan.
If the diameter of the pan does not fit the diameter of the hotplate, you are
recommended to use a pan which is larger than the size of the hotplate, or else about
half the energy will be lost.

Electric Induction hobs Chef’s
EH
-
IH
545
7
Choose pans which are the right size for the amount of food to be prepared. A large
pan which is half full will consume a lot of energy.
Always centre the pan on the hotplate and always cover the pan with the matching
lid. Cooking without using the lid quadruples energy consumption.
Cook using small amounts of water. This will save energy and will also help green
vegetables retain their vitamins and minerals.
During their cooking, food such as stews, soups may heat up too quickly without
any indication, spilling out of the cookware.
It is therefore advisable to heat this type of food gently, selecting a suitable power
level and stirring the contents before and during cooking.
We recommend not to use for Induction hob pots that have been used in a gas hob
fire can deform the flatness of bottom). In case of use, check that bottom is flat.
2. Installation instructions
EH-IH545 Cut-out Dimension

Electric Induction hobs Chef’s
EH
-
IH
545
8
Important notes
Safety in use is only guaranteed if the technical installation of the hob has been
carried out correctly and in accordance with the installation instructions. The installation
technician shall be liable for any damage cause as a result of incorrect installation.
Only an authorized technician is able to connect the appliance. The guidelines set
out by the electricity provider must be observed.
This appliance should be used only with an earthed connection.
Using this appliance without an earthed connection or after it has been incorrectly
installated may, in very rare cases, cause serious harm.
The manufacturer accepts no responsibility for any malfunction or damage which is
caused by incorrect electrical installation.
If the appliance is not fitted with an accessible plug, disconnecting means must be
incorporated in the fixed installation, in accordance with the installation regulations.
The power cable must be positioned so that it does not touch any of the hot parts of
the hob.
Refrigerators, dishwashers, ovens, or washing machines must not be installed
under the induction hob.

Electric Induction hobs Chef’s
EH
-
IH
545
9
Any change to the appliance’s interior, including changing the power cable, must be
performed by the Customer Service.
Preparing the Kitchen
The worktop should be flat and horizontal. The aperture should be cut before the
appliance is installed. Remove any shavings, as these can affect the operation of the
electrical components. When the cutting has been completed, the unit’s stability should
be checked again.
Surfaces which have been cut should be sealed so that they are heat resistant and
so that they do not swell when moist.
The kitchen units to be fitted must resist temperatures of up to 90oC.
The gap between the aperture and the side wall must be at least: 40 mm
It is not recommended that the hob be placed between two side walls but, if this is
the case, a gap of at least 200 mm should also be left on one side.
If the induction hob is installed above a sterilizer there must be a gap of 70 mm from
the top of worktop to the top of the sterilizer.
If the induction hob is installed without sterilizer or above a drawer, the worktop
thick around the hob must be 20 mm as minimum.
If the interior width of the kitchen unit is less than 700 mm, a 80 mm – long cut must
be made in the side walls from the top section of the hob.
Taking into account the hob ventilation:
An aperture must be cut in the top section of the back of the kitchen unit, 680 mm
wide and 45 mm high.
There must be a gap of 20 mm between the back of the kitchen unit and the kitchen
wall.
if the hob is installed above a drawer, allow a gap of 65 mm between the drawer
and the top section of the worktop.
Installing and connecting the hob
The earth wire ( green and yellow) should be connected first and disconnected last.
It should also be longer than the others, so that even if the hob is moving the other
wires can be disconnected before the earth wire.

Electric Induction hobs Chef’s
EH
-
IH
545
10
Connection diagram ( see figure)
1. Brown
2. Blue
3. Green and Yellow
Is required 16A electrical installation at
customer’s house (electrical circuit, socket and fuse ).
Do not trap the lead during installation and do not guide it over sharp edges.
The hob and the worktop should not be sealed with silicone as the hob itself has a
seal which serves this function.
Removing the hob
Disconnect the cooker from the power supply.
Push out the hob from below
3. Induction cooking
Advantages of induction cooking
ØGreater speed in cooking and frying; as the pan is heated directly.
ØReduced energy consumption
ØCleaner and easier to use; spilt food does not burn as much on the hob.
ØCooking control and safety; the hob supplies or cuts off the heat as soon
as the controls are operated. The Induction hotplate stops supplying heat if
the pan is removed before the power has been switched off.
Suitable pans
Ferromagnetic pans are the only pans which are suitable for induction cooking.
They can be made of:
·enameled steel
·cast iron
·specially designed cookware for induction cooking made from stainless steel
Special pans for induction cooking.
Other types of special pans are available for induction cooking, where the base of
the pan is not entirely ferromagnetic. Check the diameter as this could affect the pan
detection as well as the cooking results.

Electric Induction hobs Chef’s
EH
-
IH
545
11
Checking pans using a magnet
To find out whether the pans are suitable, check
that they are attracted to a magnet.
The manufacturer will usually indicate if their pans
are suitable for induction cooking.
Unsuitable pans. Never use pans made from:
·standard, high quality steel
·glass / earthenware
·copper / aluminum
Characteristics of the base of the pan
The characteristics of the base of the pan can
affect the evenness of the cooking.
Pans which are made from heat-diffusing materials
( such as “sandwich” pans made from stainless
steel) distribute the heat evenly, saving time and
energy.
No pan or incorrect size pan
If no pan is place on the hotplate, or the pan is not made of a suitable material or it
is not a suitable size, the heat setting on the hotplate indicator will flash.
Place a suitable pan on the hotplate to stop the indicator flashing. If there is a delay
of more than 90 seconds, the hotplate switches off automatically.
Empty pans or pans with a thin base
Do not heat empty pans and do not use pans with thin bases. Although your hob is
equipped with an internal safety system, empty cookware can heat up so quickly that
the “automatic OFF” function does not have time to react and a very high temperature
may be reached. The base of the pan could melt and damage the hob’s glass surface.
If this happens, do not touch the pan and switch off the hotplate. If it does not work
after cooling, contact our Local Service Center or dealer.
Pan detection
Each hotplate has a minimum limit for pan detection which varies according to the
material from which the pan being used is made. It is for this reason you are
recommended to use a hotplate which matches the diameter of the pan.

Electric Induction hobs Chef’s
EH
-
IH
545
12
Pan size detection
Cooking zone Pan size minimum
220mm 130mm
160mm 90mm
4. Product’s specification
Specification EH-IH545
Voltage 220VAC
Frequency 50Hz
Individual Induction power (kW)
Left hotplate / Cooking zone (cm) 2000W (booster) / 22cm
Individual Induction power (kW)
Front-right hotplate / Cooking zone (cm) 1500W ( booster) / 14cm
Individual Electric power (kW)
Back-right / Cooking zone (cm) 2000W (booster) / 22cm
Induction total rated power (KW) 5500W
Dimension (W×D×H) mm 600 x 520 x 60
Height above installation table mm 5.5
Cut-out size (W×D) mm 560 x 490
Minimum thickness of
installation table mm 20
Installation method Built-in
Net weight (kg) 6.0
Gross weight kg 7.5
Faceplate Shott caran Glass, black color

Electric Induction hobs Chef’s
EH
-
IH
545
13
5. Basic control functions
• Full induction cooktop with 3 heater:
2000W ( 22cm) / 1500W (16cm) / 2000W (22cm).
• Key Lock function.
• Fast boil function for induction heaters ( Booster function).
• Pause function
• Independent timer for each heater.
• 99-minute timer for each selected heating element.
• Indication of residual heat for each heater.
• Thermal control protection.
• Protection from accidental activation of keys:
- One or more keys activated for more than 10 sec. -> Switching off the touch
control. A warning beep sounds every 10 sec., while the key/s is/are activated.
- With all heaters at zero power during 30 sec. -> The Cooktop is switched
off. If the switching off is due to an accidental activation of keys, the touch
control actuates as above.
• Acoustic warning to attract the user’s attention.
• Pan detection for induction heaters; After 60 sec. with no pan, the heater
switches off.
GENERAL KEYS
- 1 key for switching On/Off the Cooktop [ON/OFF_KEY].
- 1 key for locking/unlocking the keyboard [KEYLOCK_KEY].
- 1 key for Pause function [PAUSE KEY].
- 2 key for timer time set [-TIMER] [+TIMER], independent setting for each heater.
- 1 slider key ( SLIDER KEY) for adjust the level.
DISPLAYS AND LEDS
- 3 7_segment displays to show the heaters setting.
- 2 7_segment displays and 5 LED-s to show the timer setting.
- 1 LED to show if the cooktop is locked/unlocked.
- 1 LED to show if the Pause function
- 1 Bargraph LED to show the selected power for the selected heater.
BUZZER SOUNDS
- 3 beeps for switching Off the Cooktop [OFF_SOUND].

Electric Induction hobs Chef’s
EH
-
IH
545
14
Fig. 1: User Interface complete configuration for Induction heater
6. Switching On/Off the Cooktop
The Cooktop is switched ON by touching the [ON/OFF] key for 1 sec. A beep sounds
and all the heater displays show a number “0”
Fig. 2: Switching ON the cooktop
If the selection of a heater is not done in 10 seconds, the cooktop will be turned off
automatically.
The cooktop is switched Off by touching the [ON/OFF] key for 1 sec. An
[OFF_SOUND] sounds and all the heaters are switched Off. The purpose of these
[OFF_SOUND] is to distinguish the OFF action over all others.
Fig. 3: Switching OFF the cooktop
When the cooktop is OFF, after 5 sec without any Error/Alarm to display and

Electric Induction hobs Chef’s
EH
-
IH
545
15
without any message to indicate ( residual heat) , the control switch off the
(KEYLOCK_LED) in order to reduce the as much as possible the power
consumption.
As soon as we touch a key, the (KEYLOCK_LED) goes ON and we can continue
to operate as normal unlocking the keyboard if necessary and touching the
(ON_OFF_KEY) key to switch ON the cooktop.
The (ON/OFF) key will be locked to switch On the cooktop:
* if the key lock is activated,
* or if there is any appliance error.
7. Selecting a power level for a heater
To switch on a heater it is necessary to actuate every cooking zone by means
of two operations:
·Select a heater
·Select the desired cookset.
7.1 Selecting a heater
A heater is selected by touching the heater key for 160ms, a beep sound and
the heater display show the power level.
The heaters that are not selected are shown with a dot point.
Fig. 4: Heater selection
The (HEATER_KEY) key will be locked to select a heater:
·If the cooktop is off (all the heater display off), or

Electric Induction hobs Chef’s
EH
-
IH
545
16
·if the key lock is activated, or
·if there is any heater or appliance error.
The heater selection will be finish:
·10 sec after the last touch over the SLIDER key
·If another heater is selected
·Or if the (HEATER_KEY) key is touched for 160ms.
When the heater selection is finished after 10 sec, a beep sound and all the heater
displays show the power level again.
7.2 Selecting a power level for a heater
Once the heater is selected, the power level can be selected by touching
SLIDER. Each position over the slider surface corresponds to a cooking level. The
power level selection is done by sliding the finger or by placing the finger on a
specific position of the slider surface. When the power level is changed sliding the
finger a slider sound sounds.
There are 11 selectable power levels, from 0 to 9 and P ( booster) level. If
booster power level is selected the heater display will show a P.
The power set will be shown by displays [HEATERn_DISPLAY] and the
[BARGRAPH_LED].
The [SLIDER] keys will be locked:
·If no heater is selected, or
·if the key lock is activated , or
·if there is any heater or appliance error.

Electric Induction hobs Chef’s
EH
-
IH
545
17
Fig. 5: Select power level by slider
8. Fast Boil (Booster) Function
The heater will work at maximum power level ( booster level) for 10 minutes. After
these 10 minutes a beep sounds and the heater will return to level “9”.
Fig. 6: Select the booster level by sliding up to +b position
9. Switching Off a Heater
When a heater is on, the heater can be switched off by select power level to 0.
Fig. 7: Switch off the heater by sliding down to 0 position
10. Key lock
Touching the [KEYLOCK] key for 1 second, the key lock function is activated and
deactivated. If the LED associated to the key lock key is on, the keyboard is locked.
The locking function can be activated when the heaters are on or when the cook top is
off. If the cook top is on, the key lock function locks all the keys except the general
[ON_OFF_KEY] key and the [KEYLOCK_KEY]

Electric Induction hobs Chef’s
EH
-
IH
545
18
When the cook top is off, the key lock function locks all the keys, including the general
[ON/OFF] key.
The key-lock is always activated at the start up of the control.
Fig. 8: Key Lock
11. Automatic safety off
11.1 Protection from accidental activation of keys
If any key/s is maintained pressed for a more than 10 seconds, the cooktop is
switched off automatically. A warning beep sounds every 10 sec., while the key/s is/are
activated.
11.2 Heater auto switch off in a specific time
After maximum time of operation at the same power level (see the table below) the
heater is switched off automatically.
The heater auto switch off time is automatically reset when the power level is
changed.
If the power level is not changed during a preset time, the corresponding heater
turns off automatically.
The maximum time a heater can stay on, depends on the selected cooking level.
Power level Max. time on (hours)
1 10
2 5
3 5
4 4
5 3
6 2
7 2
8 2
9 1
Table 1: Heater Auto switch off

Electric Induction hobs Chef’s
EH
-
IH
545
19
12. Pause function
Pause function allows temporary pausing of the cooking process, allowing the
users to answer the door or the telephone without worrying that the water is boiling
over. This function is also useful to clean the user interface surface without changing
the cooking set up.
The pause function is activated if the [PAUSE_KEY] is touched for more than
120 milliseconds:
· [PAUSE_LED] blinks, a [PAUSE_SOUND] sounds and the cooktop is stopped,
Fig. 9: Active Pause function
·the heaters actual power setting is stored and all the active heaters power is set to
power level 0,
·the heaters auto swich off time is stopped,
·all the timers running count downs are stopped,
·all keys are locked except [PAUSE_KEY] and [ON_OFF_KEY],
·the Pause LED is blinking and all the heater displays show the stop sequence.
Stop sequence: All the heater displays show a line growing sequentially until a round is
filled, when the round is filled the round segments are switched off sequentially. When the
last segment is going to be switched off the cycle begins again. The round segments are
switched on/off anticlockwise. A new segment is switched on/off every T_320ms.
To deactivate the stop function:

Electric Induction hobs Chef’s
EH
-
IH
545
20
·if the [PAUSE_KEY] is touched for more than 120 milliseconds a beep sounds and
the heaters actual power setting is reastored, or
·if the cooktop is stopped for more than 10 minutes the cooktop is switched off
automatically.
13. Operating the timer
It is possible for the user to set a switch off time for all heaters at any power level.
The timer value can be selected between 1 and 99 minutes. The timer last minute will
be displayed in seconds.
The [+TIMER] [-TIMER] keys will be locked:
o If the Cooktop is off, or
o if the key lock is activated (KEYLOCK LED on).
13.1. Selecting a timer for a heater
Once a heater is selected, a switch-off time can be selected by touching the
[+TIMER_KEY] or [-TIMER_KEY]. When the timer is off, it is activated by pressing the
timer keys [+TIMER_KEY] or [-TIMER_KEY] . A beep sounds, the timer display shows
a “00” blinking and the timed heater LED blinks.
Fig. 10: Timer activation
The [+TIMER_KEY] or [-TIMER_KEY] keys will be locked:
·If no heater is selected, or
·if the key lock is activated , or
·if there is any error.
13.2. Selecting the time
When the timer is waiting a time selection the timer display blinks. The timer value can
be selected between 1 and 99 minutes touching the [+TIMER_KEY] or [-TIMER_KEY]
keys,
